OWNER’S MANUAL

LED TV*

Please read this manual carefully before operating your TV and

retain it for future reference.

*LG LED TV applies LCD screen with LED backlights.

MT44*

MT45*

www.lg.com

LICENSES

ENGLISH

LICENSES

Supported licenses may differ by model. For more information about licenses, visit www.lg.com.

Manufactured under license from Dolby Laboratories. “Dolby” and the

double-D symbol are trademarks of Dolby Laboratories.

The terms HDMI and HDMI High-Denition Multimedia Interface, and the

HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC

in the United States and other countries.

ABOUT DIVX VIDEO: DivX®is a digital video format created by DivX, LLC,

a subsidiary of Rovi Corporation. This is an ofcial DivX Certied®device

that has passed rigorous testing to verify that it plays DivX video. Visit divx.

com for more information and software tools to convert your les into DivX

videos.

ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certied®device must

be registered in order to play purchased DivX Video-on-Demand (VOD)

movies. To obtain your registration code, locate the DivX VOD section in

your device setup menu. Go to vod.divx.com for more information on how

to complete your registration.

DivX Certied®to play DivX®video up to HD 1080p, including premium

content.

DivX®, DivX Certied®and associated logos are trademarks of Rovi

Corporation or its subsidiaries and are used under license.

Covered by one or more of the following U.S. patents: 7,295,673;

7,460,668; 7,515,710; 7,519,274

4ASSEMBLING AND PREPARING

ENGLISH

yImage shown may differ from your TV.

yYour TV’s OSD (On Screen Display) may differ slightly from that shown in this manual.

yThe available menus and options may differ from the input source or product model that you are

using.

yNew features may be added to this TV in the future.

yThe TV can be placed in standby mode in order to reduce the power consumption. And the

TV should be turned off if it will not be watched for some time, as this will reduce energy

consumption.

yThe energy consumed during use can be significantly reduced if the level of brightness of the

picture is reduced, and this will reduce the overall running cost.

NOTE

ASSEMBLING AND PREPARING

Unpacking

Check your product box for the following items. If there are any missing accessories, contact the local

dealer where you purchased your product. The illustrations in this manual may differ from the actual

product and accessories.

yDo not use any pirated items to ensure the safety and product life span.

yAny damages or injuries by using pirated items are not covered by the manufacturer’s warranty.

ySome models have a thin film attached on to the screen and this must not be removed.

CAUTION

yThe items supplied with your product may vary depending on the model.

yProduct specifications or contents of this manual may be changed without prior notice due to

upgrade of product functions.

yFor an optimal connection, HDMI cables and USB devices should have bezels less than 10 mm

thick and 18 mm width. Use an extension cable that supports USB 2.0 if the USB cable or USB

memory stick does not fit into your TV’s USB port.

*A 10 mm

*B 18 mm

NOTE

ASSEMBLING AND PREPARING

ENGLISH

Remote control, batteries

(AAA)

(See p. 22)

CD (Owner’s Manual) /

Cards

D-SUB Cable

(Depending on model)

(See p. 20, 21)

Power Cord

(See p. 15)

AC-DC Adapter

(See p. 15)

AC-DC Adapter

(Depending on model)

(See p. 15)

Stand Base

(Only MT44*)

(See p. 12)

Stand Base

(Only 22/24/28MT45*)

(See p. 11)

Stand Base

(Only 29MT45*)

(See p. 11)

Stand Body

(Only 29MT45*)

(See p. 11, 13)

Stand Screws

2 EA, M4 x L16

(Only 29MT45*)

(See p. 12, 14)

(Depending on model)

6ASSEMBLING AND PREPARING

ENGLISH

Parts and buttons

(Only MT44*)

Power indicator

yRed : When the power is turned off

yOff : When the power is turned on

Remote Control Sensor

(Power Button)

Button Description

MODE Selects the mode.(Programme → Volume → INPUT)

Programme Scrolls through the saved programmes.

Volume Adjusts the volume level.

INPUT Changes the input source.

Adjusts the mode button level.

yLocal keys work on Power,Programme,Volume and INPUT only.

NOTE

Screen

Speakers

ASSEMBLING AND PREPARING

ENGLISH

(Only 22/24/28MT45*)

Screen

Speakers

Joystick button

(* This button is located below the TV

screen.)

Remote control sensor

Power Indicator

yRed : When the power is turned off

yOff : When the power is turned on

Using the joystick button

You can operate the TV by pressing the button or moving the joystick left, right, up, or down.

Basic Functions

Power On When the TV is turned off, place your nger on the

joystick button and press it once and release it.

Power Off

When the TV is turned on, place your nger on the

joystick button and press it once for a few seconds

and release it.

(Howerver, if the Menu button is on the screen,

pressing and holding the joystick button will let you

exit the Menu.)

Volume Control

If you place your nger over the joystick button and

move it left or right, you can adjust the volume level

you want.

Programmes

Control

If you place your nger over the joystick button and

move it up or down, you can scrolls through the saved

programmes you want.

8ASSEMBLING AND PREPARING

ENGLISH

yWhen your finger over the joystick button and push it to the up, down, left or right, be careful

not to press the joystick button. If you press the joystick button first, you can not adjust the

volume level and saved programmes.

NOTE

Adjusting the Menu

When the TV is turned on, press the joystick button one time.

You can adjust the Menu items (, , , )moving the joystick button up, down, left or right.

TV Off Turns the power off.

Settings Accesses the main menu.

Close Clears on-screen displays and returns to TV

viewing.

Input

List Changes the input source.

ASSEMBLING AND PREPARING

ENGLISH

(Only 29MT45*)

Remote Control Sensor

Power Indicator

yRed : When the power is turned off

yOff : When the power is turned on

Touch Buttons

Speakers

yAll of the buttons are touch sensitive and can be operated through simple touch with your

finger.

NOTE

Touch buttons Description

Scrolls through the saved programmes.

Adjusts the volume level.

OK Selects the highlighted menu option or confirms an input.

SETTINGS Accesses the main menus, or saves your input and exits the menus.

INPUT Changes the input source.

Turns the power on or off.

Screen

10 ASSEMBLING AND PREPARING

ENGLISH

Lifting and moving the TV

Please note the following advice to prevent the

TV from being scratched or damaged and for

safe transportation regardless of its type and

size.

yAvoid touching the screen at all times, as

this may result in damage to the screen.

CAUTION

yIt is recommended to move the TV in the

box or packing material that the TV originally

came in.

yBefore moving or lifting the TV, disconnect

the power cord and all cables.

yWhen holding the TV, the screen should face

away from you to prevent the screen from

scratches.

yHold the top and bottom of the TV frame

firmly. Make sure not to hold the transparent

part, speaker, or speaker grill are

yWhen transporting the TV, do not expose the

TV to jolts or excessive vibration.

yWhen transporting the TV, keep the TV

upright, never turn the TV on its side or tilt

towards the left or right.

yDo not apply excessive pressure to cause

flexing /bending of frame chassis as it may

damage screen.

yWhen handling the TV, be careful not to

damage the protruding joystick button.

(Depending on model)
