LG 42LA660S Bedienungsanleitung

SMART TV

Quick Setup Guide

Please read this manual carefully before operating

your set and retain it for future reference.

www.lg.com

P/NO: MBM63817852(1306-REV01)

Printed in Korea

ENG

ENGLISH

Wireless Network Connection

Wired Network Connection

* Image shown may differ from your TV.

* Image shown on a PC or mobile phone may vary depending on the OS(Operating System).

Internet connection

Wired router

wireless router

ENGENGLISH

Network Setting

Premium Apps are pre-installed on the TV. These may vary by country.

1 Press the SMART

REC

button to access the Smart

Home menu. Select Settings and press Wheel(OK).



Settings

2 Select the NETWORK → Network Connection

menu.

Network Connection

Network Status

Wi-Fi Direct

MiracastTM/Intel's WiDi

NETWORK

My TV Name : 42LA660S-ZA

3 Select the Start Connection.

Connect to your wired or wireless network.

Network Connection

To connect to a wired network:

Connect a LAN cable to the back of TV.

To connect to a wireless network:

Requires a wireless router or access point.

Start Connection

Enjoy various Smart TV features through network.

4 The device automatically tries to connect to the

network available(wired network first).

Cancel

Connecting to the network.

Network Connection

If you select Cancel or it fails to connect to the

network, the network list available is displayed.

Choose the network you want.

Wired Network

Wireless : AAA

Wireless : BBB

Wireless : CCC

Wireless : 11111

Wireless : 22222

Manual Setup

Refresh List

Network Connection

For wireless routers that have the

ꔒ

symbol, you

need to enter the security key.

Network Connection

Wireless : AAA

Forgot your password? Contact your AP manufacturer.

Enter security key of network.

5 The connected network is displayed.

Select Complete to confirm the network connection.

If you select the Other Network List, the network

list available is displayed.

Network is connected.

Wireless:AAA

Select [Other Network List] to connect to another network.

Complete

Other Network List

Network Connection

ENG

ENGLISH

1 Press the SMART

REC

button to access the Smart

Home menu.



Settings

2 Select the NETWORK →Network Status menu.

Network Connection

Network Status

Wi-Fi Direct

MiracastTM/Intel's WiDi

NETWORK

My TV Name : 42LA660S-ZA

Follow the instructions below that correlate to your

network status.

Check the TV or the router.

Network Status

TV Gateway DNS Internet

When an ✔appears TV.

1Check the connection status of TV, AP and cable

modem.

2Power off and power on TV, AP and cable modem.

3If you are using a static IP, enter IP directly.

4Contact internet companies or AP companies.

yAdditional points to check when using a

wireless connection

1Check the password for the wireless

connection in the router settings window.

2Change the router SSID (network name) or

the wireless channel.

Check the router or consult your Internet

service provider.

Network Status

TV Gateway DNS Internet

When an ✔appears TV and Gateway.

1Unplug the power cord of the AP, cable modem

and try to connect after 5 seconds.

2Initialize(Reset) the AP or cable modem.

3Contact internet companies or AP companies.

Network Status

TV Gateway DNS Internet

When an ✔appears TV, Gateway and DNS.

1Unplug the power cord of the AP, cable modem

and try to connect after 5 seconds.

2Initialize(Reset) the AP or cable modem.

3Check that the MAC address of the TV/router is

registered with your Internet service provider. (The

MAC address displayed on the right pane of the

network status window should be registered with

your Internet service provider.)

4Check the router manufacturer’s website to make

sure your router has the latest firmware version

installed.

Troubleshooting Network Problems

ENGENGLISH

Install the programme on your PC.

1 Go to . Then, select your region.

2 Select SUPPORT. Then, Search for your model.

3 Select Drivers & Software or SOFTWARE UPDATE. Then, select .

4 You can run the programme when installation is complete.

NOTE

yDLNA service is only available if TV and other devices are connected via a single router.

SmartShare PC SW Installing & Setting

DLNA Connection to Smartphone

1 Check that Wi-Fi is enabled on your smartphone.

2 Install/run the app for sharing content on your smartphone (It's called SmartShare on LG phones).

3 Enable your smartphone to share content files with other devices.

4 Select the file type you want to play (movie, audio or photo).

5 Select a movie, music or photo file to play on the TV.

6 Add the selected file to the playlist.

7 Select a TV model name on which to play the files. (The TV model name is labelled on the rear side of the

panel.)

8 Play the media file to view and enjoy it on your TV.

ENG

ENGLISH

SMART

REC

→ Settings → SUPPORT →Software Update

Uses Software Update to check and obtain the latest version. If not updated, certain functions may not work

properly. It is also possible to check manually for available updates.

Software Update Set it to On.

If an update is available, a prompt will appear to perform the update.

Automatic update mode If an update is available, the update automatically starts without prompting.

Check Update Version Checks the latest update version installed. When a new update is available, the

download process can be performed manually.

NOTE

When the update starts, a pop-up window is displayed to show the update status and then disappears within

five seconds.

The latest version can be obtained via the digital broadcast signal or an internet connection.

Changing the programme while downloading the software via a digital broadcast signal interrupts the

download process. Returning to the initial programme allows downloading to resume.

If software is not updated, certain functions may not work properly.

Tag On

Touch the smartphone to the Tag On sticker.

• Using an LG smartphone with the NFC and Miracast

functions, you can:

- TV to Phone: run the LG TV Remote app on the smartphone.

- Phone to TV: view the screen of the smartphone on the TV.

To end the connection, touch the smartphone to the Tag On sticker again.

(You can also disable the Miracast

function on the smartphone.)

SMART

REC

→Settings →NETWORK →

Wi-Fi Direct

The Wi-Fi Direct function supports wireless connection technology. With

SmartShareTM

, you can share files or

screens of devices connected to Wi-Fi Direct.



[TAAAA]

Do you want to request a connection?

Automatically connect without asking

Yes No

Connection

Wi-Fi Direct

Device Name Connection

TAAAA

BBBB

Wi-Fi Direct

If Wi-Fi Direct

is set to On, a list of available devices

appears.

»To use

Wi-Fi Direct, go to

Settings →NETWORK and

set

Wi-Fi Direct

(a) to

When you are prompted to request connection, select Yes.

Wi-Fi Direct is now connected to your TV.

If you are not using Wi-Fi Direct to minimize the interference between Wi-Fi devices, it is recommended to set Wi-

Fi Direct

(a)

to Off. You can only use devices that support Wi-Fi Direct.

Updating the TV Firmware

Tag On

Wi-Fi Direct Setting

ENGENGLISH

MiracastTM Setting

Miracast

allows a portable device to securely send video and sound to TV wirelessly.

Connection

Miracast

/ Intel's WiDi

Device Name Connection

TAAAA

The device which is applied MiracastTM and intel's WiDi

technology can be shown on the TV.

MiracastTM / Intel's WiDi

Miracast

is set to On on your TV and portable device.

Go to the Network settings to set the Miracast

2 When your portable device is detected, select the device.

3 For more information about how to connect the portable device, refer to

the portable device manual.

WiDi (Wireless Display) Setting

WiDi represents Wireless Display. Intel’s WiDi (Wireless Display) technology enables easy and fast connection

without wires or internet network for mirrored and dual monitor display on your TV. You can sit back and experience

your favorite movies, videos, photos, online shows and more in full HD on your TV with great image clarity and

sound.

Intel's WiDi

is set to On. Connect your laptop to AP. (Without AP, it is possible to this function; it is

recommended to connect to AP.) Your laptap runs the Intel WiDi(

ithout AP, it is possible to this function; it is

) programme.

2 It detects LG Smart TVs available, which supports WiDi. In the list, select the TV you want and click Connect.

Enter the PIN number( a) shown on the screen into the input field( b) on your laptop and then click Continue.

NOTE

When you connect the TV and laptop, you should set up TV mode for “Live TV” and “external input”. If not,

your computer cannot detect LG Smart TV.

a

[Intel's WiDi] Request connection

Enter the following Security keys.

* When WiDi is connected, devices connected

with Wi-Fi Direct are disconnected.

MY PIN : ****

Cancel

Remain: 92 second(s)

TV Screen Notebook Screen

3 The wireless environment may affect the screen display. If the connection is poor, the Intel WiDi connection

may be lost.

* LG TV is not need to register.

* For more information on Intel WiDi, visit http://intel.com/go/widi

* A list of Intel's WiDi devices does not appear on the TV screen. Please check the list on your laptop.

ENG

ENGLISH

Time Machine II Ready

Take Control of Time with Time Machine II Ready

With your removable USB storage devices, Timeshift allows you to stop and rewind live TV, and record or set the

timer for your favourite TV programmes.

* Time Machine II Ready can record any programme in analogue and digital format, and can also record AV input.

(Depending on model)

* You can still use other services while recording a TV programme.

* Requires external data storage device (not included).

If you are watching an HbbTV broadcast, use the 123 button to use the (Smart Remote) Time Machine II Ready function.

Time Machine II

TV/

RAD

RATIO INPUT

FAV

MUTE

EXIT

GUIDE

MY APPS

BACK

INFO

.,;@

abc

def

ghi

jkl

mno

pqrs

tuv

wxyz

LIST

Q.VIEW

SMART

Press the

Time Machine II

on the Magic Remote Control

while watching TV. Press

on the Remote Control while watching TV.



Time Machine II

REC.

Press

The progress bar appears and you can use Time

Machine’s various functions. You can return to a live TV programme when using the

Timeshift function.

Live Recorded TV Schedule

You can select the point

you want to play.

REC Live Recorded TV Option

Schedule List Schedule

REC

REC Live Recorded TV

Schedule List

Option

High Quality

Initialize

Recording Quality

Timeshift

Auto deleting

USB device initialization

* You may obtain space by deleting old videos for more space.

The REC icon appears at

the top right of the screen

when recording starts.

You can use these

buttons to go to the time/

location position you

want to playback.

You can view a

list of recorded TV

programmes.

You can change the Time

Machine settings.

(Depending on model)

ENGENGLISH

»a: Change Device tab

»b: Device control buttons

»c: Expand the ScreenRemote

»d: Exits the Screen Remote

»e: Moves the position of the

ScreenRemote to left or right

Time Machine II

External Device Menu External Device Menu

Time Machine II

Universal Control

To use the Universal Control function (for Magic Remote Control only)

With the Magic Remote Control, you can easily control your set-top box, Blu-ray player, home theater system, and

Sound Bar.

1 Check if the device is connected to the TV.

2 After pressing the '

Time Machine II

' button on the Magic Remote Control, select the device you want to control in the

Change Device tab. The Screen Remote that can control the device appears.

Time Machine II

You can control external devices using the Screen Remote on the screen.

(This may not work with the '

Time Machine II

' button for some models.)

Control external devices using the navigation keys, wheel (OK), or BACK button on the Magic Remote Control.

Please call LG Customer Service if you experience any problems.

Inhaltsverzeichnis

Sprachen:

Andere LG Smart-TV Handbücher

LG 65UM7400PDA Bedienungsanleitung

LG 28TK420S Bedienungsanleitung

LG 39LN5700 Bedienungsanleitung

LG UQ80 Series Bedienungsanleitung

LG 55UF850V.AMC Bedienungsanleitung

LG 42LS5700-TA Bedienungsanleitung

LG 28TK420S Bedienungsanleitung

LG OLED65E8 Series Bedienungsanleitung

LG 47G2 Bedienungsanleitung

LG 32LQ570BPSA Bedienungsanleitung

LG 32LQ630B6LB Bedienungsanleitung

LG 39LN5700 Bedienungsanleitung

LG 55LF595T Bedienungsanleitung

LG OLED 55B9 Series Bedienungsanleitung

LG 84LM9600 Bedienungsanleitung

LG 105UC9 Series Bedienungsanleitung

LG OLED55E9PLA Bedienungsanleitung

LG 42LA667V Bedienungsanleitung

LG 50LA620V.AMH Bedienungsanleitung

LG 43UM70 Series Bedienungsanleitung

LG 47LM9600 Bedienungsanleitung

LG 24MT35S-PZ.AEK Bedienungsanleitung

LG 24TL520S-PZ Bedienungsanleitung

LG 55LA860V Bedienungsanleitung

Beliebte Smart-TV Handbücher anderer Marken

Samsung

Samsung The Sero LS05T Bedienungsanleitung

Philips

Philips 55PFL6900 Bedienungsanleitung

FFALCON

FFALCON SF3 Series Bedienungsanleitung

Toshiba

Toshiba 43LL3C63DB Bedienungsanleitung

Hisense

Hisense N3000 Bedienungsanleitung

EKO

EKO K32FSG11 Bedienungsanleitung

Tesla

Tesla TSL-TV-T2KYD55 Bedienungs- und Wartungshandbuch

Philips

Philips 32PFS6401/12 Bedienungsanleitung

Vizio

Vizio Quantum Pro VQP75C-84 Bedienungsanleitung

ALDI

ALDI Bauhn ATV40FHDG-0322 Bedienungsanleitung

TCL

TCL fire TV 65Q650F Bedienungsanleitung

RCA

RCA Roku TV RTRU6027-US Bedienungsanleitung

EKO

EKO K700UGT Bedienungsanleitung

Hisense

Hisense PX2-PRO Bedienungsanleitung

Gazer

Gazer TV22-HS2 Bedienungsanleitung

Samsung

Samsung UN48J5200AF Bedienungsanleitung

Samsung

Samsung Q95T Series Bedienungsanleitung

Regal

Regal 55R6080U Bedienungsanleitung
