LG KG270 Bedienungsanleitung

ENGLISH

࡬฿ᇖ໚

MALAY

INDONESIA

TIẾNG VIỆT

KG270

This manual may differ from the

phone depending on the phone

software version and service

provider used.

P/N : MMBB0240810 (1.0)

KG270

USER GUIDE

This manual may differ from the phone depending

on the phone software version and service provider used.

KG270_ESA_Eng_0416 2007.4.16 3:37 PM Page 1

Installing the SIM Card and

Charging the Battery 3

Installing the SIM Card 3

Illustrations 3

Phone Components 4

Turning Your Phone On and Off 5

Making a Call 5

Answering a Call 5

Making an international call 5

Menu and Options 6

Entering Text 7

T9 Mode 7

ABC Mode 7

123 Mode (Numbers Mode) 7

Symbol Mode 7

Lost Mobile Track (LMT) 8

FM Radio 9

How to set the tone 10

Ringtone 10

Ringtone/Keypad/Message/

Call alert tones and volumes 10

Menu tree 11

Quick feature reference 12

Messaging 12

Contacts 13

Call history 13

Settings 14

Alarm 16

Organizer 16

Radio 16

Tools 16

Guidelines for safe and efficient use

Technical Data 22

Contents

KG270_ESA_Eng_0416 2007.4.16 3:37 PM Page 2

Installing the SIM Card

When you subscribe to a cellular network,

you are provided with a plug-in SIM card

loaded with your subscription details, such

as your PIN, any optional services available

and many others.

Important!

›

The plug-in SIM card and its contacts can

be easily damaged by scratches or bend-

ing, so be careful when handling, inserting

or removing the card. Keep all SIM cards

out of the reach of small children.

›

USIM is not supported in a phone.

Illustrations

Open battery cover

Insert your SIM

Close the battery cover

Charge your battery

Installing the SIM Card and Charging the Battery

1 32

4 5

SIM

Fully charge the

battery before using it for the first time.

KG270_ESA_Eng_0416 2007.4.16 3:37 PM Page 3

Phone Components

Earpiece

Display screen

Alphanumeric keys

These keys are used to dial a

number in standby mode and

to enter numbers or characters

in edit mode.

: Send key

You can dial a phone number

and answer incoming calls.

: End /Power key

Allows you to power the phone

on or off, end calls, or return

to Standby Mode.

: Navigation key

Use for quick access to phone

functions.

Soft keys

Each of these keys performs

the functions indicated by the

text on the display immediately

above them.

KG270_ESA_Eng_0416 2007.4.16 3:37 PM Page 4

Turning Your Phone On and Off

1. Hold down the [END] key until the phone switches on.

2. To switch the phone off, hold down the [END] key until the power-off image displays.

Making a Call

1. Enter a phone number including the area code.

2. Press the [SEND] key to call the number.

3. When finished, press the [END] key.

Answering a Call

1. When the phone rings and the phone icon flashes on the screen, press the [SEND]

key or the left soft key to answer.

2. End the call by pressing the [END] key.

Note

›After the call ends, the phone will go back to standby mode.

Making an international call

1. Press and hold the key for the international prefix. The ‘+’ character automatically

selects the international access code.

2. Enter the country code, area code, and the phone number.

3. Press [send] key to call the number.

KG270_ESA_Eng_0416 2007.4.16 3:37 PM Page 5

Menu and Options

Your phone offers a set of functions that allow you to customize it. These functions are

arranged in menus and sub-menus, accessed via the left and right soft keys.

The label on the bottom of the display screen immediately above the soft keys indicates

their current function.

Press the left soft key to

access the available Menu.

Press the right soft key to

access the available

Favorites.

Menu Favorites

KG270_ESA_Eng_0416 2007.4.16 3:37 PM Page 6

Entering Text

You can enter alphanumeric characters by using the phone’s keypad. To change modes,

press the key.

T9 Mode

This mode allows you to enter words with only one keystroke per letter. Each key on the

keypad has more than one letter. The T9 mode automatically compares your keystrokes

with an internal linguistic dictionary to determine the correct word, thus requiring far

fewer keystrokes than the traditional ABC mode.

ABC Mode

This mode allows you to enter letters by pressing the key labeled with the required letter

once, twice, three or four times until the letter is displayed.

123 Mode (Numbers Mode)

Type numbers using one keystroke per number.

Symbol Mode

This mode allows you to enter special characters by pressing key.

KG270_ESA_Eng_0416 2007.4.16 3:37 PM Page 7

Lost Mobile Track (LMT)

1. The LMT feature of this phone provides you with the ability to have a tracking system

in place for your mobile in case you loose or misplace it.

2. The moment an un-authorized user uses your phone, a SMS is triggered from your

phone and the message is send to your pre-defined number.

3. Setting the LMT ON [Menu 8.5.x]

›A List of tools are displayed.

›Select Lost Mobile track

›Select Set LMT

›Select ON, press OK

Note

›In case you want to use your phone with some other SIM card, make sure to set the

LMT feature OFF.

›It is recommended to enter the pre-defined number with the country code ( e.g. for

INDIA +91 followed by mobile number)

KG270_ESA_Eng_0416 2007.4.16 3:37 PM Page 8

FM Radio (This function may be different in different regions.)

1. Press the corresponding number key of a channel to store the selected radio station.

2. After presetting radio channels, you can listen to another channel by pressing the cor-

responding number key.

3. You can access the following option menus by pressing the left soft key [Options].

›Edit channel: You can adjust frequency and channel 0.1 MHz at a time using the

Left/Right navigation keys and number keys.

›Auto scan: If you turn "Auto Scan Now?" on, this automatically sets the radio chan-

nel. When "Save this Station?" message pops up and you select Yes, the selected

frequency will be stored.

›Reset channels: You can delete all channels you saved.

›Listen via wired headset: Select this to listen to the radio through the built-in

speaker. To turn off the speaker, select "Listen via headset" in the [Options].

KG270_ESA_Eng_0416 2007.4.16 3:37 PM Page 9
