LG Flatron M237WD Bedienungsanleitung

Make sure to read the Safety Precautions before

using the product.

Keep the User's Guide(CD) in an accessib e p ace

for furture reference.

See the abe attached on the product and give the

information to your dea er when you ask for service.

OWNER’S MANUAL

MM223377WWDD

Downloaded from ManualMonitor.com Manuals

PREPARATION

FRONT PANEL CONTROLS

■

This is a simp ified representation of the front pane . The image shown may be somewhat different from your

set.

INPUT MENU VOL CHENTER

CHANNEL

Buttons

VOLUME

Buttons

Button

ENTER

Button

INPUT

Button

Power

Button

Headphone

Output

Downloaded from ManualMonitor.com Manuals

PREPARATION

BACK PANEL INFORMATION

■

This is a simp ified representation of the back pane . The image shown may be somewhat different from your

set.

AC IN

AUDIO IN

(RGB/DVI) OPTICAL

DIGITAL

AUDIO OUT

VIDEO

COMPONENT

AV-IN

VIDEO

S-VIDEO

AUDIO

RS-232C IN

(CONTROL & SERVICE)

SERVICE

ONLY

RGB IN (PC)

DVI-D IN (PC)

HDMI IN

AC IN

ANTENNA/

CABLE IN

AUDIO

(MONO)

910 11

87 1

3 4

Power Cord Socket

This set operates on AC power. The voltage is indicat-

ed on the Specifications page. Never attempt to

operate the set on DC power.

HDMI Input

High definition inputs. These two inputs accept TV

Video, not PC Video. They also accept TV Video from

a DVI connection when using an adapter. The HDMI

inputs support video and audio. When using an

adapter for DVI, they only accept video.

RGB/DVI Audio Input

This is the audio input for the RGB and DVI-D video

inputs.

Optical Digital Audio Out

Use this to export audio to an external amplifer.

RGB INPUT (PC)

Analog PC input. Also known as VGA.

S-Video Input

Standard definition (480i), but better quality than

standard A/V input.

SERVICE ONLY PORT

DVI-D Input

Digital PC input.

RS- 3 C IN (CONTROL & SERVICE) PORT

Serial port used for external control or service.

Component Input

High definition analog input.

Audio/Video Input

Standard definition input.

Antenna Input

Connect over-the-air or cable signals to this jack.

Downloaded from ManualMonitor.com Manuals

PREPARATION

STAND INSTALLATION

■

The image shown may be somewhat different from your set.

Carefu y p ace the product screen side down on a

cushioned surface that wi protect product and

screen from damage.

Insert the ssttaanndd bbaasseeinto the product

Attach the monitor to the Stand Base by turning

the screw to the right.

* Turn the screw by using the screw hand e

Screw

Downloaded from ManualMonitor.com Manuals

PREPARATION

DETACHING STAND

P ace the set screen side down on a cushion or

soft c oth.

Detach the monitor from the Stand Base by

turning the screw to the eft.

Turn the screw by using the screw hand e 4

Pu the stand base.

■

The image shown may be somewhat different from your monitor.

Downloaded from ManualMonitor.com Manuals

PREPARATION

DESKTOP PEDESTAL INSTALLATION

For proper ventilation, allow a clearance of 4 inches on each side and from the wall.

4 inches

WALL MOUNT: HORIZONTAL INSTALLATION

For proper ventilation, allow a clearance of 4 inches on each side and from the wall. Follow the instructions

included with the wall mount.

4 inches

4 inches 4 inches

4 inches

Downloaded from ManualMonitor.com Manuals

PREPARATION

POSITIONING YOUR DISPLAY

■

The image shown may be somewhat different from your set.

Adjust the position of the panel in various ways for maximum comfort.

•• TTiilltt rraannggee

LOCATION

Position your set so that no bright light or sunlight falls directly onto the screen. Care should be taken not to

expose the set to any unnecessary vibration, moisture, dust or heat. Also, ensure that the set is placed in a posi-

tion to allow a free flow of air. Do not cover the ventilation openings on the back cover.

If you intend to mount the set to a wall, attach the wall mounting interface (optional parts) to the back of the set.

When you install the set using the wall mounting interface (optional parts), attach it carefully so it will not drop.

- Be sure to use screws and a wall mount that meet VESA standards.

- Using screws longer than those recommended might damage the product.

- Using screws that do not meet VESA standards might either damage the product or result in it coming away from

the wall. We will not be held responsible for any damage resulting from failure to follow these instructions.

< Screw Mounting Interface Dimension >

* 75mm x 75mm hole spacing

* Wall mount interface(LG) : RW1 0

-6

~ -2

~ 18

WWaarrnniinngg::

When adjusting the angle of the

screen, do not put your finger(s)in

between the head of the monitor

and the stand body. You can hurt

your finger(s).

RW1 0

Downloaded from ManualMonitor.com Manuals

PREPARATION

SECURING THE SET TO THE WALL TO PREVENT FALLING

WHEN THE SET IS USED ON A STAND

We recommend that you set up the set c ose to a wa so it cannot fa over if pushed backwards.

Additiona y, we recommend that the set be attached to a wa so it cannot be pu ed in a forward direction,

potentia y causing injury or damaging the product.

Caution: P ease make sure that chi dren don’t c imb on or hang from the set.

■Insert the eye-bo ts (or set brackets and bo ts) to tighten the product to the wa as shown in the picture.

*If your product has the bo ts in the eye-bo ts position before inserting the eye-bo ts, oosen the bo ts.

* Insert the eye-bo ts or set brackets/bo ts and tighten them secure y in the upper ho es.

Secure the wa brackets with the bo ts (so d separate y) to the wa . Match the height of the bracket that is

mounted on the wa to the ho es in the product.

Ensure the eye-bo ts or brackets are tightened secure y.

■Use a sturdy rope or cord (so d separate y) to tie the product. It is

safer to tie the rope so it becomes horizonta between the wa and the

product.

■

Image shown may differ from your set.

GGWhen moving the set, undo the cords first.

GGUse a p atform or cabinet strong enough and arge enough to support the size and weight of the set.

GGTo use the set safe y make sure that the height of the bracket on the wa and the one on the set are the same.

NOTE

Downloaded from ManualMonitor.com Manuals

PREPARATION

KENSINGTON SECURITY SYSTEM

- The product is equipped with a Kensington Security System connector on the back panel. Connect the

Kensington Security System cable as shown below.

- For detailed installation and use of the Kensington Security System, refer to the user’s guide provided with

the Kensington Security System.

For further information, contact hhttttpp::////wwwwww..kkeennssiinnggttoonn..ccoomm, the internet homepage of the

Kensington company. Kensington sells security systems for expensive electronic equipment such as note-

book PCs and LCD projectors.

NOTE

- The Kensington Security System is an optional accessory available at most electronics stores.

NOTES

a. If the product feels cold to the touch, there may be a small “flicker” when it is turned on.

This is normal, there is nothing wrong with product.

b. Some minute dot defects may be visible on the screen, appearing as tiny red, green, or blue spots.

However, they have no adverse effect on the monitor's performance.

c. Avoid touching the LCD screen or holding your finger(s) against it for long periods of time.

Downloaded from ManualMonitor.com Manuals

PREPARATION

■For optimum picture qua ity, adjust antenna direction.

■An antenna cab e and converter are not supp ied.

■To prevent equipment damage, never p ug in any power cords unti you have finished connecting a equipment.

Multi-family D ellings/Apartments

(Connect to all antenna socket)

Single-family D ellings /Houses

(Connect to all jack for outdoor antenna)

Outdoor

Antenna

(VHF, UHF)

Wall

Antenna

Socket

RF Coaxial Wire (75 ohm)

ANTENNA CONNECTION

Antenna

UHF

VHF

■In poor signa areas, to get better picture qua ity, insta a signa amp ifier to the antenna as shown above.

■If signa needs to be sp it for two TVs, use an antenna signa sp itter for connection.

AC IN

ANTENNA/

CABLE IN

AC IN

ANTENNA/

CABLE IN

Signal

Amplifier

Downloaded from ManualMonitor.com Manuals
