OWNER’S MANUAL

MM22779944DD

PREPARATION

FRONT PANEL CONTROLS

■

This is a simp ified representation of the front pane . The image shown may be somewhat different from your

set.

INPUT MENU VOL CHENTER

CHANNEL

Buttons

VOLUME

Buttons

Button

ENTER

Button

INPUT

Button

Power

Button

Headphone

Output

PREPARATION

BACK PANEL INFORMATION

■

This is a simplified representation of the ba k panel. The image shown may be somewhat different from your

set.

AC IN

AUDIO IN

(RGB/DVI) OPTICAL

DIGITAL

AUDIO OUT

VIDEO

COMPONENT

AV-IN

VIDEO

S-VIDEO

AUDIO

RS-232C IN

(CONTROL & SERVICE)

SERVICE

ONLY

RGB IN (PC)

DVI-D IN (PC)

HDMI IN

AC IN

ANTENNA/

CABLE IN

AUDIO

(MONO)

910 11

87 12

3 4

PPoowweerr CCoorrdd SSookkeett

This set operates on AC power. The voltage is indi ated

on the Spe ifi ations page. Never attempt to operate

the set on DC power.

HHDDMMII IInnppuutt

High definition inputs. These two inputs a ept TV

Video, not PC Video. They also a ept TV Video from a

DVI onne tion when using an adapter. The HDMI

inputs support video and audio. When using an adapter

for DVI, they only a ept video.

RRGGBB//DDVVII AAuuddiioo IInnppuutt

This is the audio input for the RGB and DVI-D video

inputs.

OOppttiiaall DDiiggiittaall AAuuddiioo OOuutt

Use this to export audio to an external amplifer.

RRGGBB IINNPPUUTT ((PPCC))

Analog PC input. Also known as VGA.

SS--VViiddeeoo IInnppuutt

Standard definition (480i), but better quality than

standard A/V input.

SSEERRVVIICCEE OONNLLYY PPOORRTT

DDVVII--DD IInnppuutt

Digital PC input.

RRSS--223322CC IINN ((CCOONNTTRROOLL && SSEERRVVIICCEE)) PPOORRTT

Serial port used for external ontrol or servi e.

CCoommppoonneenntt IInnppuutt

High definition analog input.

AAuuddiioo//VViiddeeoo IInnppuutt

Standard definition input.

AAnntteennnnaa IInnppuutt

Conne t over-the-air or able signals to this ja k.

PREPARATION

STAND INSTALLATION

■

The image shown may be somewhat different from your set.

Carefu y p ace the product screen side down on a

cushioned surface that wi protect product and

screen from damage.

Insert the ssttaanndd bbaasseeinto the product

Attach the monitor to the Stand Base by turning

the screw to the right.

* Turn the screw by using the screw hand e

Screw

PREPARATION

DETACHING STAND

P ace the set screen side down on a cushion or

soft c oth.

Detach the monitor from the Stand Base by

turning the screw to the eft.

Turn the screw by using the screw hand e 4

Pu the stand base.

■

The image shown may be somewhat different from your monitor.

PREPARATION

DESKTOP PEDESTAL INSTALLATION

For proper venti ation, a ow a c earance of 4 inches on each side and from the wa .

WALL MOUNT: HORIZONTAL INSTALLATION

For proper venti ation, a ow a c earance of 4 inches on each side and from the wa . Fo ow the instructions

inc uded with the wa mount.

4 inches

4 inches 4 inches

4 inches

PREPARATION

POSITIONING YOUR DISPLAY

■

The image shown may be somewhat different from your set.

Adjust the position of the pane in various ways for maximum comfort.

•• TTiitt rraannggee

LOCATION

Position your set so that no bright ight or sun ight fa s direct y onto the screen. Care shou d be taken not to expose

the set to any unnecessary vibration, moisture, dust or heat. A so, ensure that the set is p aced in a position to a ow a

free f ow of air. Do not cover the venti ation openings on the back cover.

If you intend to mount the set to a wa , attach the wa mounting interface (optiona parts) to the back of the set.

When you insta the set using the wa mounting interface (optiona parts), attach it carefu y so it wi not drop.

- Be sure to use screws and a wa mount that meet VESA standards.

- Using screws onger than those recommended might damage the product.

- Using screws that do not meet VESA standards might either damage the product or resu t in it coming away from the

wa . We wi not be he d responsib e for any damage resu ting from fai ure to fo ow these instructions.

< Screw Mounting Interface Dimension >

* 75mm x 75mm ho e spacing

* Wa mount interface(LG) : RW120

-5

~ -2

~ 13

WWaarrnniinngg::

When adjusting the ang e of the

screen, do not put your finger(s)in

between the head of the monitor

and the stand body. You can hurt

your finger(s).

RW120

PREPARATION

SECURING THE SET TO THE WALL TO PREVENT FALLING

WHEN THE SET IS USED ON A STAND

We recommend that you set up the set c ose to a wa so it cannot fa over if pushed backwards.

Additiona y, we recommend that the set be attached to a wa so it cannot be pu ed in a forward direction,

potentia y causing injury or damaging the product.

Caution: P ease make sure that chi dren don’t c imb on or hang from the set.

■Insert the eye-bo ts (or set brackets and bo ts) to tighten the product to the wa as shown in the picture.

*If your product has the bo ts in the eye-bo ts position before inserting the eye-bo ts, oosen the bo ts.

* Insert the eye-bo ts or set brackets/bo ts and tighten them secure y in the upper ho es.

Secure the wa brackets with the bo ts (so d separate y) to the wa . Match the height of the bracket that is

mounted on the wa to the ho es in the product.

Ensure the eye-bo ts or brackets are tightened secure y.

■Use a sturdy rope or cord (so d separate y) to tie the product. It is

safer to tie the rope so it becomes horizonta between the wa and the

product.

■

Image shown may differ from your set.

GWhen moving the set, undo the cords first.

GUse a p atform or cabinet strong enough and arge enough to support the size and weight of the set.

GTo use the set safe y make sure that the height of the bracket on the wa and the one on the set are the same.

NOTE

PREPARATION

KENSINGTON SECURITY SYSTEM

- The product is equipped with a Kensington Security System connector on the back pane . Connect the

Kensington Security System cab e as shown be ow.

- For detai ed insta ation and use of the Kensington Security System, refer to the user’s guide provided with the

Kensington Security System.

For further information, contact hhttttpp::////wwwwww..kkeennssiinnggttoonn..ccoomm, the internet homepage of the Kensington

company. Kensington se s security systems for expensive e ectronic equipment such as notebook PCs and

LCD projectors.

NOTE

- The Kensington Security System is an optiona accessory avai ab e at most e ectronics stores.

NOTES

a. If the product fee s co d to the touch, there may be a sma “f icker” when it is turned on.

This is norma , there is nothing wrong with product.

b. Some minute dot defects may be visib e on the screen, appearing as tiny red, green, or b ue spots. However,

they have no adverse effect on the monitor's performance.

c. Avoid touching the LCD screen or ho ding your finger(s) against it for ong periods of time.

PREPARATION

■For optimum picture qua ity, adjust antenna direction.

■An antenna cab e and converter are not supp ied.

■To prevent equipment damage, never p ug in any power cords unti you have finished connecting a equipment.

Mu ti-fami y Dwe ings/Apartments

(Connect to wa antenna socket)

Sing e-fami y Dwe ings /Houses

(Connect to wa jack for outdoor antenna)

Outdoor

Antenna

(VHF, UHF)

Antenna

Socket

RF Coaxia Wire (75 ohm)

ANTENNA CONNECTION

Antenna

UHF

VHF

■In poor signa areas, to get better picture qua ity, insta a signa amp ifier to the antenna as shown above.

■If signa needs to be sp it for two TVs, use an antenna signa sp itter for connection.

AC IN

ANTENNA/

CABLE IN

AC IN

ANTENNA/

CABLE IN

Signa

Amp ifier
