LGX Extended Temperature AU910 Bedienungsanleitung

LGX Extended Temperature

AU910/AU912

Fanless Intel® Core™ i5/i7

Embedded System

User’s Manual

Version 1.0

2011.03

- I -

Index

This page is intentionally left blank. Table of Contents

FCC Class A .............................................................................................. i

Important Safety Instructions..................................................................... i

About This User’s Manual .........................................................................ii

Warning ....................................................................................................iii

Replacing the Lithium Battery...................................................................iii

Technical Support .....................................................................................iii

Warranty ...................................................................................................iv

Ordering Information.................................................................................iv

Chapter 1........................................................................................... 1

General Information.................................................................................. 1

1.1 Introduction........................................................................................ 2

1.2 Packing List ....................................................................................... 3

1.4 Specications .................................................................................... 4

1.5 Power Information ............................................................................. 5

1.6 Dimensions........................................................................................ 6

AU910 ..................................................................................................... 6

AU912 ..................................................................................................... 6

1.7 Locating Controls and Connectors .................................................... 7

1.8 Connecting Peripherals ..................................................................... 9

1.8.1 VGA/DVI/DisplayPort Video Outputs ............................................ 9

1.8.2 Serial Ports (COM1 ~4)............................................................... 10

1.8.3 LAN Ports.................................................................................... 11

1.8.4 USB Ports ................................................................................... 12

1.8.5 Keyboard and Mouse.................................................................. 13

1.8.6 Expansion PCI Express Slots ..................................................... 13

1.8.7 Audio Line-out/Mic-in .................................................................. 14

1.8.8 DC Power Input and Power ON/OFF Button .............................. 15

Chapter 2......................................................................................... 17

The Engine of AU910/AU912 ................................................................. 17

2.1 Board Layout ................................................................................... 18

2.2 Jumpers and Connectors ................................................................ 19

2.2.1 Jumpers & Connectors List......................................................... 19

Jumpers..........................................................................................................19

Connectors .....................................................................................................19

2.2.2 Jumper Settings .......................................................................... 20

2.2.3 Pin Assignments for Connectors................................................. 20

PWRIN1 (Power Input) ...................................................................................20

CN1 (COM1 ~ COM4) ....................................................................................21

- II - - III -

Index

COM3, COM4 RS-485 PIN OUT ....................................................................21

44M-5xDB9F (COM Converter Cable) (Optional)...........................................22

VGA1 (CRT Display Connector) .....................................................................24

DP1 (DisplayPort Connector) .........................................................................24

LAN1/2 (LAN Ports)........................................................................................25

USB1/2 (USB Ports) .......................................................................................25

AUDIO1 (Audio Jacks)....................................................................................25

MC1 (Mini Card Slot) ......................................................................................25

CPUF1/2 (Fan Connector)..............................................................................26

KBM1 (Keyboard & Mouse)............................................................................26

CF1 (CFast Slot).............................................................................................26

DVI1 (DVI) ......................................................................................................28

JSPI1 (System BIOS Enable/ Disable Pin Header)........................................28

DIO1 (Digital I/O Port).....................................................................................29

LPT1 (Parallel Port) ........................................................................................30

SW1, 2, 4 (RS-232/RS-485 Function Select Jumper for COM3, COM4) ......30

SATA1/2 (Serial ATA Connectors)...................................................................31

PWR1/2 (HDD/SSD Power Connectors) ........................................................31

Chapter 3......................................................................................... 33

Installation and Maintenance.................................................................. 33

3.1 CPU and Memory Module Installation ............................................. 34

3.1.1 Removing Top Cover................................................................... 34

3.1.2 Installing CPU ............................................................................. 35

3.1.3 Installing Memory Module ........................................................... 36

3.2 How to Access CFast/SIM Card ...................................................... 37

3.3 Hard Disk Drive & PCIe Card Installation ........................................ 39

3.3.1 Removing Bottom Cover............................................................. 39

3.3.2 Installing Hard Disk Drive............................................................ 39

3.3.3 Installing PCIe Card .................................................................... 41

3.4 Wall Mounting (Optional) ................................................................. 42

3.5 DIN Rail Mounting (Optional)........................................................... 42

3.5.1 Face-Left/Right DIN Rail Mounting ............................................. 43

3.5.2 Face-Up/Down DIN Rail Mounting.............................................. 44

3.5.3 Removing the AU910/AU912 from the DIN Rail ......................... 45

3.6 Grounding the AU910/AU912 .......................................................... 45

3.7 Wiring the DC-Input Power Source ................................................. 46

Chapter 4......................................................................................... 47

BIOS ....................................................................................................... 47

4.1 BIOS Main Setup............................................................................. 48

4.2 Advanced Settings........................................................................... 49

4.2.1 ACPI Settings............................................................................. 51

4.2.2 CPU Conguration ..................................................................... 52

4.2.3 SATA Conguration .................................................................... 54

4.2.4 Intel® IGD SWSCI OpRegion Conguration.............................. 55

4.2.5 USB Conguration ..................................................................... 56

4.2.6 Super IO Conguration .............................................................. 57

4.2.7 PC Health Status ....................................................................... 58

4.2.8 Second Super IO Conguration ................................................. 59

4.2.9 Platform Thermal Conguration ................................................. 60

4.3 Chipset Settings .............................................................................. 61

4.3.1 Northbridge ................................................................................ 62

4.3.2 Southbridge Conguration ......................................................... 63

4.4 Boot Settings ................................................................................... 64

4.5 Security............................................................................................ 66

4.6 Save & Exit ...................................................................................... 67

Appendix ......................................................................................... 69

Appendix A: I/O Port Address Map ........................................................ 70

Appendix B: Interrupt Request Lines (IRQ) ........................................... 72

Appendix C: Memory Mapping .............................................................. 73

Appendix D: Digital I/O Setting .............................................................. 74

D.1 Source Code in C .......................................................................... 74

Appendix E: Watchdog Timer (WDT) Setting ........................................ 76

E.1 Source Code in C .......................................................................... 76

- IV - - i -

This page is intentionally left blank. Copyright Notice

The information in this document is subject to change without prior notice in

order to improve the reliability, design and function. It does not represent a

commitment on the part of the manufacturer.

Under no circumstances will the manufacturer be liable for any direct, indi-

rect, special, incidental, or consequential damages arising from the use or in-

ability to use the product or documentation, even if advised of the possibility

of such damages.

This document contains proprietary information protected by copyright. All

rights are reserved. No part of this document may be reproduced by any me-

chanical, electronic, or other means in any form without prior written permis-

sion of the manufacturer.

FCC Class A

This device complies with Part 15 FCC Rules. Operation is subject to the

following two conditions: (1) this device may not cause harmful interference,

and (2) this device must accept any interference received including interfer-

ence that may cause undesired operation.

Important Safety Instructions

Read these safety instructions carefully:

1. Read all cautions and warnings on the equipment.

2. Place this equipment on a reliable surface when installing. Dropping

it or letting it fall may cause damage.

3. Make sure the correct voltage is connected to the equipment.

4. For pluggable equipment, the socket outlet should be near the

equipment and should be easily accessible.

5. Keep this equipment away from humidity.

6. Disconnect this equipment from the AC outlet before cleaning it. Use

a moist cloth. Do not use liquid or sprayed detergent for cleaning.

7. The openings on the enclosure are for air convection and protect the

- ii - - iii -

equipment from overheating. DO NOT COVER THE OPENINGS.

8. Position the power cord so that people cannot step on it. Do not

place anything over the power cord.

9. If the equipment will not be used for a long time, disconnect it from

the power source to avoid damage by transient overvoltage.

10. Never pour any liquid into opening. This may cause re or electrical

shock.

11. Never open the equipment. For safety reasons, the equipment

should be opened only by qualied service personnel.

12. If one of the following situations arises, get the equipment checked

by service personnel:

a. The power cord or plug is damaged.

b. Liquid has penetrated into the equipment.

c. The equipment has been exposed to moisture.

d. The equipment does not work well, or you cannot get it to work ac-

cording to the user's manual

e. The equipment has been dropped or damaged.

f. The equipment has obvious signs of breakage.

13. The sound pressure level at the operator's position, according to

14. IEC 704-1:1982, is no more than 70dB(A).

15. Keep this User’s Manual for later reference.

About This User’s Manual

This User’s Manual is intended for experienced users and integrators with

hardware knowledge of personal computers. If you are not sure about any

description in this User’s Manual, please consult your vendor before further

handling.

Warning

The LGX AU910 and AU912 and components contain very delicately Inte-

grated Circuits (IC). To protect the unit and components against damage

caused by static electricity, you should always follow the precautions below:

1. Disconnect your system from the power source when you want to

work on the inside.

2. Use a grounded wrist strap when handling computer components.

3. Place components on a grounded antistatic pad or on the bag that

came with the unit, whenever they are separated from the system.

Replacing the Lithium Battery

Incorrect replacement of the lithium battery may lead to a risk of explosion.

The lithium battery must be replaced with an identical battery or a battery

type recommended by the manufacturer.

Do not throw lithium batteries into the trashcan. It must be disposed of in

accordance with local regulations concerning special waste.

Technical Support

If you have any technical difculties, please consult the user’s manual rst.

Please do not hesitate to call or e-mail our customer service when you still

cannot nd out the answer.

http://www.logicsupply.com

e-mail:info@logicsupply.com

- iv - - 1 -

General Information

Chapter 1

General Information

Warranty

This product is warranted to be in good working order for a period of one

year from the date of purchase. Should this product fail to be in good work-

ing order at any time during this period, we will, at our option, replace or

repair it at no additional charge except as set forth in the following terms.

This warranty does not apply to products damaged by misuse, modications,

accident or disaster.

Vendor assumes no liability for any damages, lost prots, lost savings or any

other incidental or consequential damage resulting from the use, misuse of,

or inability to use this product. Vendor will not be liable for any claim made

by any other related party.

Vendors disclaim all other warranties, either expressed or implied, includ-

ing but not limited to implied warranties of merchantibility and tness for a

particular purpose, with respect to the hardware, the accompanying prod-

uct’s manual(s) and written materials, and any accompanying hardware. This

limited warranty gives you specic legal rights.

Return authorization must be obtained from the vendor before returned

merchandise will be accepted. Authorization can be obtained by calling or

faxing the vendor and requesting a Return Merchandise Authorization (RMA)

number. Returned goods should always be accompanied by a clear problem

description.

Ordering Information

AU910 Fanless embedded controller w/ 1 x PCIe x8 slot

AU912 Fanless embedded controller w/ 1 x PCIe x1 slot +

1 x PCIe x16 slot

DMK-9XX DIN rail kit 9XX series

WMK-9XX Wall-mount kit of 9XX series

PW-19V6A3-T 120 W AC/DC adapter kit

44M-5xDB9F COM converter cable (1*44-pin male to 4*DB9 male + 1*DB9

female) L=200 mm

- 2 - - 3 -

General InformationGeneral Information

1.2 Packing List

After opening the package, carefully inspect the contents. If any of the items

is missing or appears damaged, please contact with your local dealer or dis-

tributor. The package should contain the following items:

Standard:

• 1 x AU910 or AU912 Embedded System

• 1 x Accessory Box (Driver CD/User Manual/Screws/Cable/Terminal

Block)

Options:

The following items are normally optional, but some vendors may include

them as a standard package, or some vendors may not to carry all the items.

• AC/DC Adapter Kit

• DIN Rail Kit

• Wall-mount Kit

• COM Converter Cable (1 x 44-pin male to 4 x DB9 male + 1 x DB9

female) L=200mm

1.1 Introduction

The LGX AU910 and AU912 are targeted at many different applications.

They easily meet the challenges of specic markets, such as advanced

kiosks, digital signage, GSM Server, and harsh environment applications.

All-In-One Platform

The entire unit is fully integrated in order to provide a plug-and-play device.

Compact-sized

The kernel of the AU910/AU912 is a non-standard form factor embedded

mainboard. The whole system takes up minimal space.

Fanless and Modular CPU Board

By using a low power processor, the system does not have to rely on fans,

which are often unreliable and cause dust to circulate inside the equipment.

The modular design facilitates maintenance or possible upgrades on the

CPU board. It can be easily modied to t many different applications ac-

cording to customers' requests.

Powerful Communication Capability

The AU912 provides COM, LPT, Ethernet, USB, Mini Card slot, DVI and

Digital I/O expansion slot.

Numerous Display/Video Output

Integrated with Intel® HD Graphics core, you receive improved graphics

and 3D rendering performance and supports numerous display/video output

options includes VGA and DisplayPort.

Advanced Storage Solution

The AU910 and AU912 come with a CFast slot, which offers a better, faster

and more cost-effective expansibilities for various applications.

Trustworthy

The onboard Watchdog Timer can invoke an NMI or system RESET when

your application loses control over the system.

- 4 - - 5 -

General InformationGeneral Information

Environment

Operating Temp. -20ºC ~ 55ºC (-4ºF ~ 131ºF), ambient w/ air ow

Storage Temp. -40ºC ~ 85ºC (-40ºF ~ 185ºF)

Relative Humidity 10 ~ 95% @ 40ºC (non-condensing)

Vibration 3 Grms/5 ~ 500 Hz/random operation

Shock & Crash Operating 20 G, 11 ms; Non-operating 40 G, 11 ms (HDD)

Operating 40 G, 11 ms; Non-operating 60 G, 11 ms

(CFast/SSD)

Crash 80 G, 11 ms

Mechanical

Construction Aluminum alloy

Mounting Wall mounting and DIN rail mounting

Weight 4.5 kg ( 9.9 lb)

Dimensions

(w x h x d)

AU910: 195 x 90 x 268 mm (7.68” x 3.54” x 10.55”)

AU912: 195 x 110 x 268 mm (7.68" x 4.33" x 10.55”)

* The selectable ports, including DVI-D, LPT and Digital I/O, are options that only one of which

can be equipped.

1.5 Power Information

Power Connector 1 x 4-pin DC input receptacle combined with a

power on/off switch for remote control

Input Voltage DC 10 ~ 28 V

Power Consumption 60 W (max.)

1.4 Specications

System Kernel

Processor Intel® Socket G i5/i7 series processors

BIOS AMI Flash BIOS

Chipset Intel® QM57

Graphics Intel® HD Graphics

System Memory 2 x 204-pin Dual-channel DDR3 SO-DIMM sockets

Up to 8 GB at 800/1066 MHz

Serial ATA 2 x SATA 3 Gb/sec.

Expansion Bus 1 x PCI Express Mini Card slot; 1 x SIM socket

1 x PCI Express x8 slot w/riser card (AU910)

1 x PCI Express x16 slot w/ riser card (AU912)

1 x PCI Express x1 slot w/ riser card (AU912)

Ethernet Controller 2 x Intel® WG82574IT Gigabit Ethernet controllers

Watchdog Timer 1 ~ 255 levels reset

I/O Ports

Serial Port 4 x Serial ports via one DB-44 female connector

COM1~COM4: RS-232

COM3, 4: RS-232/485

*Selectable Port 1 x LPT

1 x 16-bit Digital I/O (8-in/8-out)

1 x DVI-D (default)

USB Port 8 x USB 2.0 ports

LAN Port 2 x RJ45

Video Port 1 x DB-15 for Analog RGB

1 x DisplayPort

KB/MS 1 x 6-pin Mini-DIN for keyboard & mouse

Audio Mic-in/Line-out (6 W pre-amplied)

Storage

HDD/SSD 1 x 2.5" drive bay for HDD or SSD

CF 1 x CFAST socket (externally accessible)

Safety

FCC Class A certied

CE Certied

- 6 - - 7 -

General InformationGeneral Information

1.6 Dimensions

AU910

Dimensions (w x h x d): 195 x 90 x 268 mm (7.68” x 3.54” x 10.55”)

268.00

224.00

184.00

195.00

90.00

96.00

207.00

6.00

4.00

NUT

UNC #6-32

CFast / SIM

S/W

ACT1

LNK1

HDD

PWR

ACT2

LNK2

DisplayPort

COM1󲕏COM4

Optional

DC IN

10V󲕏 28V

+ -

Ant.

Unit: mm

AU912

Dimensions (w x h x d): 195 x 110 x 268 mm (7.68” x 4.33” x 10.55”)

268.00

224.00

184.00

195.00

110.00

116.00

207.00

6.00

4.00

NUT

UNC #6-32

CFast / SIM

S/W

ACT1

LNK1

HDD

PWR

ACT2

LNK2

Unit: mm

DisplayPort

COM1~COM4

Optional

DC IN

10V~28V

+ -

Ant.

1.7 Locating Controls and Connectors

Both AU910 and AU912 have the same I/O ports and connectors at the front

panel.

Please take a moment to identify those controls and connectors shown in the

following gures.

Front Panel

CFast / SIM

S/W

ACT1

LNK1

HDD

PWR

ACT2

LNK2

HDD status LED

CFast/SIM Socket

USB Ports

LAN1 Active LED

LAN2 Active LED

Power Status LED

LAN1 Link LED

LAN2 Link LED

Keyboard/Mouse

Port

Power

On/Off

Switch

- 8 - - 9 -

General InformationGeneral Information

Rear Panel: AU910

DisplayPort

COM1~COM4

Optional

DC IN

10V~28V

+ -

Ant.

Antenna

Port

COM1~4

Ports USB Ports

LAN Ports

VGA

DC-IN PCIe Slot

DisplayPort

Line-out

Mic-in

DIO/LPT (Optional)

Rear Panel: AU912

DisplayPort

COM1~COM4

Optional

DC IN

10V~28V

+ -

Ant.

Antenna

Port

COM1~4

Ports

USB Ports

LAN Ports

VGA

DC-IN PCIe Slots

DisplayPort

Line-out

Mic-in

DIO/LPT (Optional)

1.8 Connecting Peripherals

The user can use the I/O interfaces located at the rear side of the chassis

to connect to external peripheral devices, such as a mouse, a keyboard, a

monitor, serial devices or parallel printer, etc. Before connection, make sure

that the computer and the peripheral devices are turned off.

1.8.1 VGA/DVI/DisplayPort Video Outputs

Both the AU910 and AU912 are equipped with two video outputs: one 15-pin

VGA and one DisplayPort with an optional DVI output off the back panel.

The new DisplayPort video interface features a small USB sized connector,

WQXGA High Denition (2560 x 1600), interoperability with DVI and HDMI

over DisplayPort connector, etc.

AU910

DisplayPort

COM1~COM4

Optional

DC IN

10V~28V

+ -

Ant.

AU912

DisplayPort

COM1~COM4

Optional

DC IN

10V~28V

+ -

Ant.
