LIBRATONE LOOP Bedienungsanleitung

LIBRATONE LOOP OWNER’S MANUAL

YOU HAVE TAKEN A LEAP OF FAITH. A step towards a world of wireless bliss. It takes a great deal

of courage to liberate yourself from the shackles of speaker cables and ordinary stereo systems.

But you have jumped right into it. FOR THIS WE SALUTE YOU.

We have done everything in our power to make your Libratone sound system as simple and user

friendly as possible. Hopefully this manual will answer any questions you might have.

Thank you for buying our product. Thank you for joining the revolution.

4 FullRoom™

5 AirPlay / PlayDirect™

6 Introduction

8Quick AirPlay Setup (Wi-Fi)

10 Setup AirPlay - iPhone, iPad or iPod touch (Wi-Fi)

18 Music on the go - PlayDirect

20 Setup AirPlay - Mac/PC (Wi-Fi)

28 DLNA - Android or Windows

29 Libratone app

30 Factory reset

31 Cover change

32 Wall mount

32 Troubleshooting / Register / Warranty

34 Speaker specs

CONGRATULATIONS!

For manuals in other languages please visit www.libratone.com/manual

2 3

Libratone Loop is based on a patent-pending audio technology. We call it FullRoom™ sound.

Allow us to explain:

Regular speakers have closed cabinets. They push the sound waves in one direction - forward.

Libratone Loop, on the other hand, plays like an acoustic instrument, dispersing sound waves

in multiple directions, giving you a 360° sound experience.

FullRoom™ technology means that you only need one sound source to get a room full of sound.

To create the best sound conditions Libratone Loop should be placed against a hard backdrop.

Whether you hang it on the wall, place it on a shelf or put it on the ground you get the same

amazing sound quality.

Placing Libratone Loop close to a wall will reﬂect the sound o the wall. This gives you a

deeper bass and an even fuller soundscape. We don’t recommend you place Libratone Loop in

a corner since this will limit the FullRoom™ experience, but it’s up to you.

FULLROOM™ MUSIC AT HOME AIRPLAY

AirPlay is a technology designed by Apple to transmit audio and video instantly, from source

to source, within a Wi-Fi network. Once AirPlay is installed, you can stream from iTunes - both

on Mac and PC - or you can use your iOS devices: iPad, iPhone or iPod touch. This means that

you have your entire music and movie library in the palm of your hand, ready to be set free.

MUSIC ON THE GO

Libratone PlayDirect™ is AirPlay to go. It allows you to stream your music wirelessly in non-Wi-Fi

areas from PC/Mac or your iOS devices: iPad, iPhone or iPod touch. Libratone PlayDirect™

technology creates a direct network connection between your speaker and music device.

4 5

INTRODUCTION

USB

Power

AUX audio input

AirPlay

PlayDirect

Status Indicator

WHITE Breathing

I’m Standby

WHITE Sequence

I’m OK - Ready for

PlayDirect and in Setup Mode

White Solid

I’m playing

(AirPlay, PlayDirect, DLNA or AUX)

WHITE Pulsing

I’m Muted

YELLOW Pulse

Booting - Updating

RED Pulse

Help Me (Network problem)

RED Pulse

I’m OK - Just sleeping

Logo Button

Mute/UnMute or Wake Me Up

Press

Sleep

Hold

Setup Mode

Press PlayDirect &

AirPlay Simultaneously

Up/Down

Press or Hold

Volume Button

SETUP AIRPLAY WITH USB CABLE

Make sure your home Wi-Fi is up and running, and within range of both your speaker and iPhone.

• Press the Libratone “Logo Button” to turn it on.

• Connect your iOS device (iOS 5 or later) and Libratone Loop with a USB cable.

• Press the “PlayDirect” and “AirPlay” buttons simultaneously for “Share Wi-Fi Settings” to pop up.

Quick AirPlay Setup - Wi-Fi

• Press “Allow” on your device and wait for Libratone Loop to reboot.

• Swipe from the bottom of the display to access Control Center.

• Press the “AirPlay” icon and choose your speaker.

• Select “Music” and set your music free.

Quick AirPlay Setup - Wi-Fi

SET YOUR MUSIC FREE

1 5

8 9

SETUP AIRPLAY WITH LIBRATONE APP

Download the “Libratone” app from Apple’s App Store.

iPhone, iPad or iPod touch - Wi-Fi

TURN ON YOUR LIBRATONE LOOP

• Press the Libratone “Logo Button” to turn it on.

Make sure your home Wi-Fi is up and running, and within range of both your speaker and iPhone.

iPhone, iPad or iPod touch - Wi-Fi

Logo Button

10 11

Status Indicator

• Press the “PlayDirect” and “AirPlay” buttons simultaneously and wait.

• When the “Status Indicator” shows the WHITE PlayDirect sequence, you’re ready to proceed.

PUT YOUR SPEAKER IN SETUP MODE

iPhone, iPad or iPod touch - Wi-Fi

FIND YOUR SPEAKER

• Open “Settings” and press “Wi-Fi” connections on your iPhone.

• Choose the “Libratone” network.

iPhone, iPad or iPod touch - Wi-Fi

Setup

12 13

SETUP YOUR LIBRATONE LOOP

• Open “Libratone” app, “Select Speaker” and press “Setup”.

• Click “Guided Setup”.

• Type in your Speaker name, select your Home Wi-Fi network and enter Password (if needed).

• Click “Apply settings”.

iPhone, iPad or iPod touch - Wi-Fi

RE-CONNECT TO YOUR HOME NETWORK

• Open “Settings” and press “Wi-Fi” connections on your iPhone.

• Choose your Home Wi-Fi network.

Your iPhone may do this automatically.

iPhone, iPad or iPod touch - Wi-Fi

7 8

14 15

YOUR SPEAKER IS READY!

If the “Status Indicator” is breathing WHITE you’re alright and ready for AirPlay.

If it’s not, go to page 12 and start over or visit: www.libratone.com/faq for support.

Status Indicator

iPhone, iPad or iPod touch - Wi-Fi

SET YOUR MUSIC FREE

• Swipe from the bottom of the display to access Control Center.

• Select “AirPlay” icon.

• Choose your speaker.

• Select “Music” and set your music free.

iPhone, iPad or iPod touch - Wi-Fi

16 17

MUSIC ON THE GO - PLAYDIRECT

• Press the Libratone “Logo Button” to turn it on.

• Press the “PlayDirect” button and wait.

• When the “Status Indicator” shows the WHITE PlayDirect sequence, you’re ready to proceed.

• Open “Settings” and press “Wi-Fi” connections on your iPhone.

PlayDirect

Status Indicator

• Choose the “Libratone” network.

• Swipe from the bottom of the display to access Control Center.

• Press the “AirPlay” icon and choose your speaker.

• Select “Music” and set your music free.

PlayDirect

SET YOUR MUSIC FREE

3 4

18 19
