1. Set temperature indicator
2. Fan speed indicator
3. Lock/Hold key indicator
4. Present time indicator
5. +/- button
Increase or decrease the room tem-
perature or set the timer duration
aer pressing the timer button.
6. On/obutton
Turn the unit on or stop operation
and turn the unit o.
7. Hour button
Set the hour on the unit clock by
pressing and holding this button,
then pressing the minute button re-
peatedly to the correct time.
8. Min button
Set the minutes on the unit clock by
pressing and holding this button,
then pressing the minute button re-
peatedly to the correct time.
9. Hold button
Press this button to lock or unlock the keypad and prevent undesired changes to
the room temperature and unit settings.
10. Fan speed
Press this button repeatedly to change the unit fan speed between high, medium,
or low air output.
11. Timer button
Press this button while the unit is running to program a shutdown time set using
the up and down arrow buttons.
Press this button while the unit is in standby mode to program a startup time set
using the up and down arrow buttons.
12. Mode button
Press this button repeatedly to alternate between cooling, drying, heating, and fan
operating modes.
13. Mode indicator
Displays the unit’s current operating mode.
NOTE: Due to the universal nature of the remote control for all of our air conditioner units,
certain remote control functions may not correspond to your particular unit.
