Lightolier Calculite ProSpec PA3H3070 Bedienungsanleitung

Flanged Trimless

Top View

8 3/4"

Depth

6" OC

18"L X 6"W Opening

19 1/16"L X 7 3/16"W Cutout

13/4"

32 15/16"

6" OC

30 1/2"L x 10"W

16"

13"

Ceiling Cutout: 19 1/16" L X 7 3/16" W

Ordering Information: PAR 30 MH Series A

Cat. No. Lamp Ceiling Trim Aperture Finis

PA3H3070BL (3) 70W PAR 30 MH Overlap Black with White Flange

PA3H3070WL (3) 70W PAR 30 MH Overlap White with White Flange

PA3H3070BTL (3) 70W PAR 30 MH Trimless Black

PA3H3070WTL (3) 70W PAR 30 MH Trimless White

PA3H3070BL = (FLANGED) BLACK/WHITE

PA3H3070WL = (FLANGED) WHITE

PA3H3070BTL = (TRIMLESS) BLACK

PA3H3070WTL = (TRIMLESS) WHITE

Calculite®ProSpec®Linear Downlight PA3H3070

Page 1 of 2 3 Light PAR 30 MH Series A

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

Lig tolier a Genlyte Thomas Company www.lightolier.com

631 Airport Road, Fall River, MA 02720 • (50 ) 679- 131 • Fax (50 ) 674-4710

We reserve the right to change details of design, materials and finish.

Features

1. Aperture Frame: Provides clean support for lamp holders and overlapping

flange or trimless installation. Extruded aluminum. Rigidly welded together

on all corners.

2. Media Cartridge: Allows convenient loading and removal of up to two

accessories. Easily installed and removed for lamping with a simple twisting

motion. Constructed of die formed aluminum.

3. Cross Blade Louver: Extruded aluminum. 1" deep, provides additional

shielding and can be easily removed.

4. Adjustable Ring: Allows 35° (on width) and 45° (on length) vertical

adjustment.

5. Tortiontite Spring: For easy installation of aperture frame.

6. Housing: Die formed NYC 20 ga. steel. Finish: Black

7. Mounting Brackets: Adjustable vertically from outside of housing.

8. T ermal Protector: Meets NEC, CEC, UL, and CSA requirements.

9. Lamp older: Porcelain medium based; nickel plated screw shell. 5KV pulse

rated, prewired with #1 SF-1 leads to ballast housing.

10.Junction Box: 14 ga. steel, 4 x 3 1/2 x 3" box. Allows inspection from

below.

11.Ballast Housing: Die formed 1 ga. steel.

12.Lamp and Accessory Support: .032" steel, flared for easy entry of Media

Cartridge.

13.Lens Retaining Ring: .093" spring steel rod. Holds accessories in place.

Electrical

Electronic Ballast: Individual for each lamp. High Power Factor. Input watts:

7 , line current: .67 amps. Accessible from below.

UL listed for through branch circuit wiring with maximum of ( ) no. 12 AWG

90°C.

Finis

All painted finishes are powder coated baked enamel.

Options & Accessories

Accessories: 3 3/4" dia. series, filters, lenses, screens, and louvers (1) max.

Label

UL/cUL (Suitable for Damp Location), I B E W

(FC) is initial footcandles at center of

beam. Beam length (L) and beam

width (W) are to where the

candlepower is reduced to 50% of

center beam candlepower.

CBCP is center beam candlepower.

beam.

Performance data shown is based on

bare lamp photometrics of

MasterColor™ lamps by Philips

Lighting. Contact lamp manufacturers

for availability and performance.

Accent Lig ting Performance Data

0° Aiming Angle 30° Aiming Angle 30° Aiming Angle 45° Aiming Angle

D FC LW DC FC LW D CFC LW D CFC LW

Beam Spread Rated

50% Max CP CBCP Life-Hrs

9000

6 000

10000

10°

Lamp

70W PAR30

MC/MH)

70W PAR30

MC/MH)

70W

15’ 302 2.6’ 2.6’

20’ 170 3.5’ 3.5’

25’ 109 4.4’ 4.4’

30’ 76 5.2’ 5.2’

’ .0’ 376 2. ’ 2.0’

12’ 12.0’ 167 4.2’ 3.0’

1 ’ 16.0’ 74 5.6’ 4.0’

20’ 20.0’ 60 7.1’ 4.9’

7’ 204 5.1’ 5.1’

10’ 100 7.3’ 7.3’

13’ 59 9.5’ 9.5’

16’ 39 11.6’ 11.6’

6’ 3.5’ 1 0 6.1’ 5.0’

9’ 5.2’ 0 9.1’ 7.6’

12’ 6.9’ 45 12.2’ 10.1’

15’ .7’ 29 15.2’ 12.6’

4’ 4.0’ 221 6.7’ 4.1’

6’ 6.0’ 9 10.1’ 6.2’

’ .0’ 55 13.4’ .2’

10’ 10.0’ 35 16. ’ 10.3’

2’ 3.5’ 313 9.7’ 2.9’

3’ 5.2’ 139 14.5’ 4.4’

4’ 6.9’ 7 19.3’ 5. ’

5’ .7’ 50 24.2’ 7.3’

10’ 5. ’ 442 2.3’ 2.0’

15’ .7’ 196 3.5’ 3.0’

20’ 11.5’ 110 4.7’ 4.0’

25' 14.4’ 71 5. ’ 5.1’

5’ .7’ 340 3.6’ 1.7’

’ 13.9’ 133 5.7’ 2.9’

11’ 19.1’ 70 7.9’ 3. ’

14’ 24.2’ 43 10.0’ 4.9’

40°

Calculite®ProSpec®Linear Downlight PA3H3070

Page 2 of 2 3 Light PAR 30 MH Series A

Lig tolier a Genlyte Thomas Company www.lightolier.com

631 Airport Road, Fall River, MA 02720 • (50 ) 679- 131 • Fax (50 ) 674-4710

We reserve the right to change details of design, materials and finish.

Job Information Type:
