8292WE

0400

Ordering Information

Lytespan®Track Lighting System 8292WE

Page 1 of 2 PowerArcTM Double Ended Metal Halide Wall Washer

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

Lightolier a Genlyte Thomas Company www.lightolier.com

631 Airport Road, Fall River, MA 02720 •(508) 679-8131 •Fax (508) 674-4710

We reserve the right to change details of design, materials and finish.

Features

1. Ballast Housing: 0.09”extruded aluminum housing with die cast endcaps.

2. Ballast: High power factor electronic metal halide ballast.

3. Reflector Housing: .095”thick extruded aluminum body with die cast end

caps.

4. Vertical Pivot: 0 - 90°vertical adjustment.

5. Horizontal Pivot: Die cast track adapter with positive rotation stop provides

385°horizontal rotation.

6. Sockets: 5 Kv pulse rated sockets with nickel plated contacts; leads

enclosed in silicone coated fiberglass sleeving.

7. Contact Holder: High temperature thermoplastic. Secures luminaire

mechanically and makes electrical contact with track.

8. Brass Contact: Extends for connection to second circuit in Advent®

Lytespan®track.

9. Wall Washer Reflector: Asymmetrical aluminum reflector with internal

kick reflector provides even illumination on vertical surface.

10. Safety Interlock Switch: Disconnects power when safety lens is removed.

11. Safety Lens: Tempered 1/8”UV filtering glass. Meets or exceeds safety

requirements for metal halide lamps.

12. Indicator Guide: Aiming indicator assures consistent and precise multiple

unit alignment.

13. Locking Lever: Nickel plated steel. For mechanical/electrical connection to

track.

Electrical

Electronic Ballast

Input Voltage: 120V, 60Hz

Power Factor: >95%

Input Power: 78W

Input Current: .67 amp

Electrical (Continued)

Harmonic Distortion: <10%

DO NOT USE ON A DIMMING CIRCUIT

Options and Accessories

Accepts PowerArc Accessory Holder (8293AC), Vertical Blade Louver (8293LV),

Spread Lens (8293BE), UV Filter (8293UV), and Visor (8293VS).

NOTE: 8293UV or 8293BE must be combined with 8293AC.

Finish

All painted finishes are baked enamel.

Labels

UL; cUL.

Catalog No. Finishes Track Mountings Lamps

8292WEWH Matte White All Lytespan®Track Systems, Multipoint, and 70W CDM or CMH T-6

8292WEBK Matte Black Monopoint. DO NOT USE with any other mounting Double Ended Metal Halide (M-98)

8292WEAL Metallic Aluminum accessories or stem mounted Radius®Track.

29/32"

(23mm)

1 1/8"

(29mm

(76mm)

3/4"

(19mm)

2 3/4"

(70mm)

4 7/8"

(12mm)

2 7/16"

(80mm)

1 13/16"

(46mm)

4 3/16"

(106mm)

3 7/8"

(98mm)

3/32"

(2mm)

8 1/16"

(205mm)

6 1/4"

(159mm)

Lighting Data

1’176 137 73 31 13 7

2’113 95 62 33 14 5

3’72 64 48 29 15 7

4’49 46 37 25 15 8

5’34 32 26 20 13 8

6’24 23 19 15 11 7

7’16 15 13 11 8 6

8’11 18 9 8 6 5

9’877654

200 156 208

141 127 141

103 101 103

83 83 83

62 61 62

50 50 50

37 36 37

27 27 27

21 21 21

186 66 186

116 65 116

78 58 78

60 55 60

42 40 43

35 34 36

26 25 26

19 18 19

15 15 15

Footcandles on Wall

Track 3 Feet From Wall Single Unit Multiple Units

4’6’

3’

Distance From Ceiling

50˚

EXAMPLE: With track located 4’ from wall and multiple units spaced

6’ on center and aimed 50˚ from horizontal, the illumination on wall 4’

from ceiling will be 53 f.c. beneath units and 50 f.c. between units.

1’89 78 51 26 11 4

2’82 72 52 32 17 8

3’56 51 40 28 17 10

4’41 38 32 24 16 10

5’31 29 25 21 15 10

6’23 22 20 16 13 9

7’18 17 15 13 10 8

8’14 13 12 10 9 7

9’10 10 9 8 7 6

106 102 107

116 109 116

92 90 92

77 76 77

66 65 66

53 53 53

44 44 44

37 37 37

30 30 30

94 71 94

97 83 97

74 70 74

62 61 62

53 53 53

43 42 43

36 35 36

31 30 31

24 24 25

89 49 89

88 62 88

64 56 64

53 50 53

45 45 45

36 36 36

30 30 30

26 26 26

21 21 21

Track 4 Feet From Wall Single Unit Multiple Units

4’5’6’

4’

Distance From Ceiling

50˚

Footcandles are average and rounded off and data for multiple units are based on a minimum of five units.

Footcandles on wall:

0’1’2’3’4’5’

Beam Center

Lamp Information:

70W CDM or CMH T6 Double Ended Metal Halide.

Initial Lumens: 6200 to 7000

CRI: 85

Rated Avg. life: 12,000 hrs.

192 102 192

123 93 123

86 78 86

68 68 68

50 49 50

41 40 41

30 29 30

22 22 22

17 17 17

5’

Lytespan®Track Lighting System 8292WE

Page 2 of 2 PowerArcTM Double Ended Metal Halide Wall Washer

Lightolier a Genlyte Thomas Company www.lightolier.com

631 Airport Road, Fall River, MA 02720 •(508) 679-8131 •Fax (508) 674-4710

We reserve the right to change details of design, materials and finish.

Job Information Type:
