Linksys WPC11 Original Betriebsanleitung

1. Before installing your

adapter, insert the

Setup CD into your

CD-ROM drive. Unless you have deactivated the auto-run

feature of Windows, the following screen should appear auto-

matically.

If this screen does not appear automatically, you can access

the installation by pressing the Start button and choosing

Run. In the drop down box provided, type D:\setup.exe

(where D: is the letter of your cd-rom drive). Alternately,

double-click My Computer, and then double-click the cd-

rom drive where the Setup CD is located. Then double-click

the Setup.exe icon that appears.

2. The first tab across the top of the screen, labeled Install,

should now be highlighted. Click on the Install button.

3. This screen will appear next, indicating that Windows is ready

to continue the installation. Click the Next button.

Note: You must install this software

before installation of the hardware.

This sheet will guide you through the basic steps needed to install this

Linksys product on your computer. If you have any problems during

installation, visit our support page at www.Linksys.com.

4. The next screen that appears will be the Warranty Policy.

Read the entire policy by pressing the Page Down button on

your keyboard. Click on the Yes button if you agree, or No if

you disagree. Clicking No will terminate the installation. If

you click Yes, the installation will continue.

5. The following window will appear next. To install the

Configuration Utility in the default directory (recommended),

click the Next button. If you prefer to install the Utility in

another directory, click the Browse button, locate the preferred

directory then click the Next button.

6. When the next screen appears, choose either Infrastructure

mode or Ad-Hoc mode, depending on your needs. If you are

unsure whether to choose Infrastructure or Ad-Hoc, refer to the

Ad-Hoc versus Infrastructure section in your User Guide for

more information. Once you have made your choice, click the

Next button.

Model No.:WPC11 V2.5

Network PC Card

Instant Wireless

™

Series

Quick Installation

Making Connectivity Easier™

For Windows 95,98, ME, and 2000

Continued on back...

QI-WPC11V2.5-10605NC DG

7. The following screen will appear. You will be prompted to

enter an SSID value in the box provided. The SSID may be

up to 32 characters in length and may include any character

on the keyboard. All SSID values on your wireless network

must match. If you are unsure, use the default value of

“linksys”. Then, click the Next button.

8. The next screen to appear will be the Review Settings screen.

Verify that all the settings are correct and click the Next but-

ton to continue. Another screen will appear, indicating that

all of the appropriate files are being copied onto your drive.

9. Once Windows has finished copying the necessary files, the

following screen will appear. In order for the drivers to be

installed properly, you must restart your computer.

If you choose to do it now, select Yes, I want to restart my

computer now. If you do not want to do it now, choose No,

I will restart my computer later. Once you have made your

choice, click the Finish button to continue.

The Driver and Configuration Utility Installation is com-

plete. Refer to your User Guide for instructions on

physically installing your Network PC Card.

7. The following screen will appear. You will be prompted to

choose a Channel from the list provided. All computers on

your wireless network must be using the same channel in

order to communicate with each other. If you are unsure

about which channel to use, select the default channel

(Channel 6). Once you have chosen your channel, click the

Next button.

8. The following screen will appear. You will be prompted to

enter an SSID value in the box provided. The SSID may be

up to 32 characters in length and may include any character

on the keyboard. All SSID values on your wireless network

must match. If you are unsure, use the default value of

“linksys”. Then, click the Next button.

9. The next screen to appear will be the Review Settings screen.

Verify that all the settings are correct and click the Next but-

ton to continue. Another screen will appear, indicating that

all of the appropriate files are being copied onto your drive.

10. Once Windows has finished copying the necessary files, the

following screen will appear. In order for the drivers to be

installed properly, you must restart your computer. If you

choose to do it now, select Yes, I want to restart my com-

puter now. If you do not want to do it now, choose No, I

will restart my computer later. Once you have made your

choice, click the Finish button to continue.

The Driver and Configuration Utility Installation is com-

plete. Refer to your User Guide for instructions on

physically installing your Network PC Card.

If you chose Infrastructure... If you chose Ad-Hoc...
