PRODUCT DATA
Model No. SPA8000
Higher Density Voice Solution Scales
with your Business
8-Port Telephony Gateway
Toll Quality Voice and Carrier-
Grade Feature Support
The SPA8000 delivers
clear, high-quality voice
communication in diverse
network conditions. Excellent
voice quality in a demanding
IP network is consistently
achieved via our advanced
implementation of standard
voice coding algorithms. The
SPA8000 is interoperable with
common telephony equipment
like voicemail, Fax, PBX, and
interactive voice response
systems.
Large-Scale Deployment and
Management
The SPA8000 offers all the
key features and capabilities
with which service providers
can provide customized
services to their subscribers.
The SPA8000 can be remotely
provisioned and supports
dynamic, in-service software
upgrades. A secure profile
upload saves providers the
time, expense and hassle of
managing and pre-configuring
or re-configuring customer
premise equipment (CPE) for
deployment.
Ironclad Security
Linksys understands that
security for both end users
and service providers is a
fundamental requirement for a
solid, carrier-grade telephony
service. The SPA8000 supports
secure, encryption-based
methods for communication,
provisioning and servicing.
PRODUCT DATA
Model No. SPA8000
Features
Package Contents
Specifications
Eight voice ports (RJ11) for analog phones or Fax machines
Impedance Agnostics - 8 Configurable Settings
Call Waiting, Cancel Call Waiting, Call Waiting Caller ID
Caller ID with Name/Number (Multi-national Variants)
Caller ID Blocking
Call Forwarding: No answer, Busy, All
Do Not Disturb
Call Transfer
Three-way Conference Calling with Local Mixing
Message Waiting Indication - Visual and Tone Based
Call Return
Call Back on Busy
Call Blocking with Toll Restriction
Delayed Disconnect
Distinctive Ringing - Calling and Called Number
Off-hook Warning Tone
Selective/Anonymous Call Rejection
Touch Tone Phone Keypad Configuration with Interactive Voice Response (IVR)
Fax: G.711 Pass Through or Real Time Fax over IP via T.38*
*T.38 support is dependent on fax machine and network/transport resilience
1 - SPA8000 Phone Adapter Unit
1 - 12v Power Adapter
1 - RJ45 Ethernet Cable
1- Quick Installation Guide
Model SPA8000
* Note: Many specifications are programmable within a defined range or list of options. Please see the SPA
Administration Guide for details. The target configuration profile is uploaded to the SPA8000 at the time
of provisioning.
MAC Address (IEEE 802.3)
IPv4 - Internet Protocol v4 (RFC 791) upgradeable to v6 (RFC 1883)
ARP - Address Resolution Protocol
DNS - A Record (RFC 1706), SRV Record (RFC 2782)
DHCP Client - Dynamic Host Configuration Protocol (RFC 2131)
DHCP Server - Dynamic Host Configuration Protocol (RFC 2131)
PPoE Client - Point to Point Protocol over Ethernet (RFC 2516)
ICMP - Internet Control Message Protocol (RFC792)
TCP - Transmission Control Protocol (RFC793)
UDP - User Datagram Protocol (RFC768)
RTP - Real Time Protocol (RFC 1889) (RFC 1890)
RTCP - Real Time Control Protocol (RFC 1889)
DiffServ (RFC 2475), Type of Service - TOS (RFC 791/1349)
VLAN Tagging - 802.1p
SNTP - Simple Network Time Protocol (RFC 2030)
Upload Data Rate Limiting - Static and Automatic
QoS - Voice Packet Prioritization over Other Packet Types
MAC Address Cloning
Port Forwarding
SIP channels support both UDP and TCP transport
VPN Pass-Through with IPSec ESP, PPTP, and L2TP
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
PRODUCT DATA
Model No. SPA8000
Voice Gateway
SIPv2: Session Initiation Protocol v2 (RFC 3261, 3262, 3263, 3264)
SIP Proxy Redundancy - Dynamic via DNS SRV, A Records
Re-registration with Primary SIP Proxy Server
SIP Support in Network Address Translation Networks - NAT (incl. STUN)
Secure (Encrypted) Calling via Pre-Standard Implementation of Secure RTP
Codec Name Assignment
G.711 (a-law and µ-Law)
G.726 (16/24/32/40 kbps)
G.729 A
G.723.1 (6.3 kbps, 5.3 kbps)
Dynamic Payload
Adjustable Audio Frames per Packet
Fax Tone Detection Pass-Through
Fax Pass-Though - Using G.711
DTMF: In-band & Out-of-band (RFC 2833) (SIP Info)
Flexible Dial Plan Support with Interdigit Timers and IP Dialing
Call Progress Tone Generation
Jitter Buffer - Adaptive
Frame Loss Concealment
Full Duplex Audio
Echo Cancellation (G.165/G.168)
VAD - Voice Activity Detection with Silence Suppression
Comfort Noise Generation (CNG)
QoS (Ethernet port up-stream bandwidth control, Physical port, MAC address, Application)
Attenuation / Gain Adjustments
Flash Hook Timer
MWI - Message Waiting Indicator Tones
VMWI - Visual Message Waiting Indicator via FSK
Polarity Control
Hook Flash Event Signalling
Caller ID Generation (Name & Number) - Bellcore, DTMF, ETSI
Music on Hold Client
Streaming Audio Server - up to 10 sessions
System DDR SDRAM - 16M Bytes
System Flash ROM - 4M Bytes
Security
Password Protected System Reset to Factory Default
Password Protected Admin and User Access Authority
Provisioning/Configuration/Authentication:
HTTPS with Factory Installed Client Certificate
HTTP Digest - Encrypted Authentication via MD5 (RFC 1321)
Authentication: EAP-TLS, EAP-TTLS, and EAP-PEAP
SIP TLS (Transport Layer Security)
Up to 256-bit AES Encryption
Provisioning, Administration & Maintenance
Web Browser Administration & Configuration via Integral Web Server
Telephone Key Pad Configuration with Interactive Voice Prompts
Automated Provisioning & Upgrade via HTTPS, HTTP, TFTP
Asynchronous Notification of Upgrade Availability via NOTIFY
Non-intrusive, In-Service Upgrades
Report Generation & Event Logging
Stats in BYE Message
Syslog & Debug Server Records
Per Line and Purpose Configurable Syslog and Debug Options
Specifications
PRODUCT DATA
Model No. SPA8000
Physical Interfaces
8 port standard FXS voice ports (RJ-11)
RJ-21 (50-pin telco connector) multi-port voice connection
1 WAN 100baseT RJ-45 Ethernet Port (IEEE 802.3)
Reset button
Subscriber Line Interface Circuit (SLIC)
Ring Voltage: 40-90 Vpk Configurable
Ring Frequency: 20 Hz - 25 Hz
Ring Waveform: Trapezoidal
Maximum Ringer Load: 5 REN
On-hook/off-hook Characteristics:
On-hook voltage (tip/ring): -46 ~ -56V
Off-hook current: 18-25 mA
Terminating Impedance: 600 ohm resistive or 270 ohm + 750ohm//
150nF complex impedance
Frequency Response 300 – 3400Hz
Return Loss (600 ohm, 300-3400Hz) Up to 20dB
Insertion Loss (1 Vrms @1 kHz) 3dB – 4dB
THD (350 mV peak @ 300 Hz) Up to 3%
Idle Channel Noise -72 dB (typ.)
Longitudinal Balance 55 dB (typ.)
Off Hook Threshold (Line Seizure) Rdc < 1000 ohm
On Hook Threshold (Line Release) Rdc >10000 ohm
Rdc DC Supervisory Range Rdc > 450 ohm
Regulatory Compliance
FCC (Part 15 Class B), CE, ICES-003, C-Tick Certification, RoHS, UL
Power Supply
Switching Type (100-240v) Automatic
DC Input Voltage: 12V DC at 3.0 A Max.
Power Adapter: 100-240v - 50-60Hz AC Input
Indicator Lights/LED
Power, Ethernet, Voice Status, Phone 1,2,3,4,5,6,7,8
Documentation
Quick Installation, User, and Configuration Guides are downloaded from www.Linksys.com
Administration Guide - Service Providers Only
Provisioning Guide - Service Providers Only
Dimensions 6.69 x 1.54 x 8.66” (170 x 39 x 220 mm) W x H x D
Weight 2.85 lbs (1.30 kg)
Operating Temp. 32 to 113°F (0°C to 45°C)
Storage Temp. -13 to 185°F (-20°C to 85°C)
Operating Humidity 10% to 90% Non-Condensing, operating and non-operating
Storage Humidity 10% to 90% Non-Condensing, operating and non-operating
Specifications
Environmental
PRODUCT DATA
Linksys
A Division of Cisco Systems, Inc.
121 Theory
Irvine, CA 92617 USA
E-mail: sales@linksys
Web: http://www.linksys.com
Linksys products are available in more than
50 countries, supported by 12 Linksys
Regional Offices throughout the world.
For a complete list of local Linksys Sales
and Technical Support contacts, visit our
Worldwide Web Site at www.linksys.com
Specifications are subject to change
without notice. Linksys is a registered
trademark or trademark of Cisco Systems,
Inc. and/or its affiliates in the U.S. and
certain other countries. Copyright © 2007
Cisco Systems, Inc. All rights reserved.
Other brands and product names are
trademarks or registered trademarks of
their respective holders.
7080310A-DF
Model No. SPA8000
The Linksys SPA8000 8-Port IP Telephony Gateway is a full featured Analog
Terminal Adapter (ATA) for small business enterprises providing enhanced
communication services via a broadband connection to the Internet.
The SPA8000 features eight RJ-11 FXS ports to connect analog telephones
to IP-based data networks and includes a single multi-port RJ-21 50-pin
connector offering an alternative connection choice when deploying
the telephony gateway in varied environments. The device also has one
10/100Base-T RJ-45 Ethernet interface to connect to either a router or multi-
layer switch.
Solid in design, the SPA8000 is an affordable solution that is ideally suited
for use in business and consumer VoIP service offerings including call
centers and multi-dwelling environments. Customers can also protect
and extend their investments by continuing to utilize their existing analog
telephones and teleconferencing equipment.
Installed by the end user and remotely provisioned, configured and
maintained by the service provider, each SPA8000 converts voice traffic
into data packets for transmission over an IP network and uses common
standards for voice and data networking for reliable voice and fax
operation.
SPA Model Service Lines Active Calls 3-Way Conferences PSTN (FXO) Connection
SPA2102 2 4 2 0
SPA3102 2 3 1 1
SPA8000 8 16 8 0
Andere Handbücher für SPA8000
1
Inhaltsverzeichnis
Andere Linksys Tor Handbücher
Linksys
Linksys WCG200 - Wireless-G Cable Gateway Wireless... Original Betriebsanleitung
Linksys
Linksys SPA400 Bedienungsanleitung
Linksys
Linksys Mediatrix 440 series Bedienungsanleitung
Linksys
Linksys AG241 Bedienungsanleitung
Linksys
Linksys WAG110 Bedienungsanleitung
Linksys
Linksys HG200 Bedienungsanleitung
Linksys
Linksys SPA3102 Bedienungsanleitung
Linksys
Linksys BEFDSR41W - ADSL Modem + Router Bedienungsanleitung
Linksys
Linksys VGA2200 - One Analog Voice Gateway 2... Bedienungsanleitung
Linksys
Linksys WAG54G v3 Bedienungsanleitung
Linksys
Linksys WAG200G Bedienungsanleitung
Linksys
Linksys WAG200G Bedienungsanleitung
Linksys
Linksys CG2P2WB Bedienungsanleitung
Linksys
Linksys WAG54G - Wireless-G ADSL Gateway Wireless... Original Betriebsanleitung
Linksys
Linksys WAG300N (EU/LA) Bedienungsanleitung
Linksys
Linksys WAG200G Bedienungsanleitung
Linksys
Linksys WCG200 - Wireless-G Cable Gateway Wireless... Bedienungsanleitung
Linksys
Linksys WAG54G - Wireless-G ADSL Gateway Wireless... Bedienungsanleitung
Linksys
Linksys VGA2000 Bedienungsanleitung
Linksys
Linksys AG241 Bedienungsanleitung
Beliebte Tor Handbücher anderer Marken
LST
LST M500RFE-AS Bedienungsanleitung
Kinnex
Kinnex Media Gateway Bedienungsanleitung
2N Telekomunikace
2N Telekomunikace 2N StarGate Bedienungsanleitung
Mitsubishi Heavy Industries
Mitsubishi Heavy Industries Superlink SC-WBGW256 Bedienungsanleitung
ZyXEL Communications
ZyXEL Communications ZYWALL2 ET 2WE Bedienungsanleitung
Telsey
Telsey CPVA 500 - SIP Bedienungsanleitung
