Linksys Etherfast EF1704 Bedienungsanleitung

EtherFast®Layer 3

Management 4-Port

Gigabit Ethernet Switch

igrate your network to Gigabit speed with the EtherFast

Layer 3 Management 4-Port Gigabit Ethernet Switch.

Perfect for today’s large-scale network demands, this

switch from Linksys delivers Layer 3 switching and blazing Gigabit

transfer speeds for all your network applications.

Layer 3 switches route packets based on IP address, so unlike stan-

dard (Layer 2) switches, they can link different subnets without the

need for a router, at much higher speed, and much lower cost. Use

the EtherFast 1704 Switch as your network's backbone, and con-

nect your servers' different subnets at Gigabit speeds. The four

built-in auto MDI/MDI-X ports deliver 8Gbps of non-blocking switch-

ing performance. And as your needs grow, add Gigabit Ethernet or

Gigabit Fiber ports using the four available expansion slots.

The EtherFast 1704 Switch provides broadcast storm suppression,

has hardware MAC and IP address learning, and supports packet fil-

tering and port security. Partition your network by creating up to

256 VLANs, using port-based 802.1q tagging. Configuration and

monitoring network performance is a snap using the Web manage-

ment interface, console, telnet, or SNMP/RMON.

This expandable, managed switch is the perfect solution for your

Gigabit enterprise backbone.

• Four 10/100/1000 Mbps Ethernet ports

• Four Expansion slots for optional Gigabit Ethernet or Gigabit

Fiber Modules (EFPC2SC, and EFPC2GE)

• Auto MDI/MDI-X on the four 10/100/1000 Ethernet Ports

• Supports half duplex and full duplex modes for all

10/100/1000BaseTX ports

• Provides 8Gbps non-blocking switching performance

• Full wire-speed Layer 3 IP Switching

• Provides broadcast storm suppression

• MAC address learning and aging

• Support for up to 256 Port-Based VLANs

• Support up to 9K jumbo frame packet

EtherFast®Layer 3 Management

4-Port Gigabit Ethernet Switch

Model No.: EF1704

Supercharge Your Ethernet Backbone with this

Manageable, Expandable, Layer 3 Gigabit Switch

Features

Benefits

• Layer 3 Switch with SNMP manageability

• Four non-blocking, wire-speed Gigabit

(10/100/1000BaseTX) MDI/MDI-X ports

• Four Expansion slots for optional Gigabit

Ethernet (TX) or Gigabit Fiber (SX) Modules

• 802.1p traffic prioritization, and 802.1q port-

based VLAN tagging support

Instant EtherFast®Series

Package ContentsSpecifications

Model Number EF1704

Standards IEEE 802.3, 802.1D, 802.1p, 802.1Q,

802.3ab, 802.3u, 802.3x, 802.1ad

Ports 4 10/100/1000BaseTX, and 4 Expansion

Slots for 1000BaseTX/SX Modules

Cabling Type Category 5e

LEDs Fan, TEMP, Power, 10, 100, 1000 Per Port

Security features MAC address filtering, IP address filtering

Environmental

Dimensions 16.93" x 1.75" x 13.78"

(430 mm x 44.45 mm x 350 mm)

Unit Weight 11.68 lbs. (5.3 kg)

Power 110-120 VAC 60 Hz

Certifications FCC Part15, Class A

Operating Temp. 32ºF to 122ºF (0ºC to 50ºC)

Storage Temp. -40ºF to 158ºF (-40ºC to 70ºC)

Operating Humidity 20% to 95%, Non-Condensing

Storage Humidity 20% to 95%, Non-Condensing

• One EtherFast 1704 Layer 3 Management 4-

Port Gigabit Ethernet Switch

• One AC Power Cord

• Two mounting brackets, and six screws for rack

mounting

• One Setup CD including User Guide

• One Serial cable for Console management

• 200Mhz or Faster Processor

• 64MB of RAM

• Ethernet Network Adapter

• CD-Rom Drive

Minimum Requirements

DS-ef1704-30219NC KL

Linksys

World Headquarters:

17401 Armstrong Ave.

Irvine, CA 92614 USA

E-mail: [email protected]

[email protected]

Web: http://www.linksys.com

Linksys products are available in more than 50

countries, supported by 12 Linksys Regional

Offices throughout the world. For a complete

list of local Linksys Sales and Technical

Support contacts, visit our Worldwide Web Site

www.linksys.com
