Linksys SR216 Bedienungsanleitung

BUSINESS SERIES

USER GUIDE

16-Port and 24-Port

10/100 Switches

Model: SR216 and SR224

Model: SR216

Model: SR224

16-Port and 24-Port 10/100 Switches

Table of Contents

About This User Guide 1

Icon Descriptions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Online Resources. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Chapter 1: Introduction 3

The 10/100 Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Chapter 2: Product Overview 5

16-Port and 24-Port 10/100 Switches . . . . . . . . . . . . . . . . . . . 5

Front Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Back Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Side Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Placement Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Chapter 3: Connect the Switch 9

Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Connection Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Appendix A: Specifications 11

Appendix B: Warranty and Regulatory Information 13

Limited Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

FCC Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Safety Notices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Industry Canada (Canada) . . . . . . . . . . . . . . . . . . . . . . . . . 16

IC Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Règlement d’Industry Canada . . . . . . . . . . . . . . . . . . . . . . 16

EC Declaration of Conformity (Europe) . . . . . . . . . . . . . . . . . 16

ii 16-Port and 24-Port 10/100 Switches

Table of Contents

Appendix C: Contact Information 25

Need to contact Linksys? . . . . . . . . . . . . . . . . . . . . . . . . . . 25

16-Port and 24-Port 10/100 Switches

About This User Guide

Icon Descriptions

While reading through the User Guide, you may encounter various icons

designed to call attention to a specific item. Below are descriptions of

these icons:

NOTE: This check mark indicates that there is a note of interest

and is something that you should pay special attention to

while using the product.

WARNING: This exclamation point indicates that there is a

caution or warning and it is something that could damage

your property or product.

WEB: This globe icon indicates a noteworthy website address

or e-mail address.

Online Resources

Most web browsers allow you to enter the web address without adding

the http:// in front of the address. This User Guide will refer to websites

without including http:// in front of the address. Some older web

browsers may require you to add it.

Resource Website

Linksys www.linksys.com

Linksys International www.linksys.com/international

Glossary www.linksys.com/glossary

216-Port and 24-Port 10/100 Switches

About This User Guide

Specificationsaresubjecttochangewithoutnotice.Linksysis aregistered

trademark or trademark of Cisco Systems, Inc. and/or its affiliates in the

registered trademarks of their respective holders.

16-Port and 24-Port 10/100 Switches

Chapter 1: Introduction

Chapter 1:

Introduction

The 10/100 Switch

With its advanced switching technology, the Linksys 16- or 24-Port

10/100 Switch will boost your network performance with much more

than just full duplex data transfer and dedicated bandwidth. It features

non-blocking, wire-speed switching that forwards packets as fast as

your network can deliver them. Also included are Address Learning

and Aging to prevent data transfer errors and Data Flow Control to help

prevent packet collisions.

You have several installation options. The Switch’s compact size fits onto

your desktop, or use the wall mount slots to hang it somewhere out

of the way. If your network equipment is in a rack, install it using the

included rack mount brackets.

No matter how intensive your network demands, the Linksys 16- or

24-Port 10/100 Switch has speed, flexibility, and reliability that you can

count on.

Features

Ideal for Integrating Your 10BaseT and 100BaseTX Network

Hardware

16 or 24 10/100 Ports Provide Dedicated Bandwidth in Half- or Full-

Duplex Modes

Switched 10/100 Ports Run at up to 200Mbps in Full-Duplex Mode

Each Port Supports Auto MDI/MDI-X Cable Detection

Compatible with All Major Network Operating Systems

Advanced Store-and-Forward Packet Switching Optimizes Data

Transfers

Auto Partitioning Protects PCs from Downed Network Lines

•

416-Port and 24-Port 10/100 Switches

Chapter 1: Introduction

Signal Regeneration Ensures Data Transfer Integrity

Free Technical Support—24 Hours a Day, 7 Days a Week, Toll-Free

US Calls

Limited Lifetime Warranty

•

Chapter 2: Product Overview

16-Port and 24-Port 10/100 Switches

Chapter 2:

Product Overview

16-Port and 24-Port 10/100 Switches

The 16-Port and 24-Port 10/100 Switches differ in number of LEDs and

ports. Pictured here is the 16-Port Switch; however, the 24-Port Switch is

similar in form.

Front Panel

The LEDs are located on the front panel of the Switch.

Front Panel of the 16-Port Switch

System (Green) This LED lights up and remains lit when the Switch is

powered on.

1-16 or 1-24 (Green) Each LED lights up when a connection is made

through its corresponding port. It flashes when the corresponding port

is active.

1-16 or 1-24 These ports connect the Switch to network

devices, such as computers.

Chapter 2: Product Overview

616-Port and 24-Port 10/100 Switches

Back Panel

The Ethernet network ports are located on the back panel of the

Switch.

Back Panel of the 16-Port Switch

(power) The power port is where you will connect the included

power cord.

Side Panel

The security slot is located on the side panel of the Switch.

Side Panel with Security Slot

(security slot) The security slot is where you can attach a lock

to protect the Switch from theft.
