Linksys WRT54G3G-ST Bedienungsanleitung

Sprint® Choices

All-in-one Internet-sharing

Router, 4-port Switch, and

Wireless-G (802.11g) Access

Point

Standard PC Card slot for a

Sprint Mobile Broadband

Connection Card (available

separately)

Shares a Mobile Broadband

Internet Connection and other

resources with Ethernet wired

and Wireless-G clients

High security: Wi-Fi Protected

Access™ (WPA/WPA2 Personal),

wireless MAC address ltering,

powerful SPI rewall

The Linksys Wireless-G Router for Mobile Broadband is really three devices in

one box. First, there's the Wireless Access Point, which lets you connect both

screaming fast Wireless-G (802.11g at 54Mbps) and Wireless-B (802.11b at

11Mbps) devices to the network. Second, it’s a built-in 4-port full-duplex

10/100 Switch to connect your wired-Ethernet devices together. Connect

four PCs directly or attach more hubs and switches to create as big a network

as you need. Thirdly, the Router function ties it all together and lets your

whole network share a mobile broadband Internet connection (requires a

mobile broadband data card). Alternatively, you can also connect a cable or

DSL modem to the Ethernet port and access the Internet via your available

broadband service.

Once your computers are connected to the Router and the Internet, they can

communicate with each other too, sharing document les, a printer, storage

space, and other resources.

To protect your data and privacy, the Wireless-G Router for Mobile Broadband

can encode all wireless LAN transmissions securely with WEP or WPA

Personal encryption. The Router can serve as a DHCP Server, has a powerful

SPI rewall to protect your PCs against intruders and most known Internet

attacks, and supports VPN pass-through. Conguration is a snap with the

web-based conguration utility.

With the Wireless-G Router for Mobile Broadband, you can create a

secure wireless network with Internet connectivity, anywhere that mobile

broadband Internet service is available.

Share your Mobile Broadband

Internet Connection!

Sprint Mobile Broadband

Connection Card sold separately.

Linksys Wireless-G Router for Mobile Broadband

Check the product package and contents for specic features support. Specications are subject to change without notice. As of 11/2005, Sprint Mobile Broadband service is available in 219 major markets covering 150 million people in

the U.S. Coverage not available everywhere. Please see www.sprint.com for a complete list of available markets. ©2006 Sprint Nextel. All rights reserved. Sprint, the “Going Forward” logo, the NEXTEL name and logo, and other trademarks

are trademarks of Sprint Nextel. Linksys is a registered trademarks or trademark of Cisco Systems, Inc. and/or its afliates in the U.S. and certain other countries.

Sprint® Choices

Linksys Wireless-G Router for

Mobile Broadband

Specications

Model WRT54G3G-ST

Standards IEEE 802.3, IEEE 802.3u, IEEE 802.11g, IEEE 802.11b

Channels 11 Channels (US, Canada)

13 Channels (Europe)

14 Channels (Japan) )

Ports/Buttons Internet: One 10/100 RJ-45 Port

PC Card Slot: for a mobile broadband data card

LAN: Four 10/100 RJ-45 Switched Ports

One Power Port, One SMA Port

One Reset Button, One Data Card Connect/Disconnect Button

Cabling Type UTP CAT 5

LED(s) Power, Ethernet (1, 2, 3, 4), Wireless, DMZ, Data Card, Internet

RF Power Output 802.11g: Typical 13.5dBm (+/-2), 802.11b: Typical 16.5dBm

Receive Sensitivity 11Mbps @ -90dBm Typical, 54Mbps @ -65dBm Typical

UPnP able/cert Able

Security features Stateful Packet Inspection (SPI) Firewall, Internet Policy

Wireless Security Wi-Fi Protected Access™ (WPA/WPA2 Personal), WEP, Wireless MAC

Filtering

Environmental

Device Dimensions 170mm x 170mm x 33 mm

(W x H x D) 6.69” x. 6.69” x 1.3”

Weight 12.35 oz

Power External 12V DC, 1.0A

Certication FCC, Wi-Fi (802.11b/g)

Operating Temp. 0° C to 45° C (32° F to 113° F)

Storage Temp. -20° C to 70° C (-4° F to 158° F)

Operating Humidity 20% to 80% Non-Condensing

Storage Humidity 10% to 90% Non-Condensing

Warranty 1-year Limited

Features

n Complies with 802.11g and 802.11b

(2.4GHz) Standards

n Unsurpassed Wireless Security with Wi-Fi

Protected Access™ (WPA/WPA2 Personal)

n External 2.2dBi Removeable (Reverse SMA)

Antenna

n All LAN Ports Support Auto-Crossover

(MDI/MDI-X) - No Need for Crossover

Cables

n Standard PC Card slot for Mobile Internet

Connectivity

Minimum Requirements

n 400 MHz or Faster Processor

n 128 MB of RAM

n Internet Explorer 4.0 or Netscape

Navigator 4.7 or Higher for Web-based

conguration

n CD-ROM Drive

n Windows 2000 or XP

n Network Adapter

Package Contents

n Wireless-G Router for Mobile Broadband

n Setup CD-ROM

n Quick Install Guide

n User Guide on CD-ROM

n Power Adapter

n RJ-45 Ethernet Cable

Contact Name

Address 1

Address 2

Phone

Wireless

065481
