Linx 12X64
with Keyboard Cover
Tablet Quick Guide.
3
Thank You.
Thank You for choosing the Linx 12X64 as your
new tablet.
This quick guide will help to give you an overview
of your new tablet, its features, and explain how
to setup and get going.
4
Contents.
Product overview. 5
Instructions for use. 8
Check the package contents 8
Charging your tablet. 8
Rechargeable Lithium-ion Battery 8
Using your tablet. 9
Turning your tablet on 9
Putting your tablet into Sleep Mode 9
Turning your tablet off 9
Emergency reboot 9
Increasing and decreasing the volume 9
Using headphones with your tablet 9
Installing a Micro SDHC/XC card 9
Using the kickstand 10
Using Windows 10 Home 10
Using the Keyboard Cover 11
Connecting to your tablet 11
Using the function keys 12
Using the Touchpad 13
Technical information. 15
Important safety information. 18
General use 18
Recycling 19
Disposal of Waste Electrical & Electronic
Equipment (WEEE) 19
Digital Rights Management 19
Rechargeable Lithium-Ion Battery 19
Battery and Charger Safety 19
Small children 19
Medical devices 20
Implanted medical devices 20
Hearing 20
Warranty 21
5
Product overview.
FFull-size USB 3.0 (Type-A)
GLoudspeaker
HThumbslot for kickstand access
A C D E
Specification.
A2.0 Megapxiel Front Camera
BMicro SDHC / SDXC Card Slot
CMicro HDMI 1.4
DMicro USB (Type-B)
E3.5mm Headphone Port
B
G HF
6
Product overview.
J2.0 Megapixel Rear Camera
KVolume Up / Down
LPower / Sleep
MKeyboard Mount Point
N5-Pin Connector for Keyboard Cover
OKeyboard Mount Point
PKickstand
Specification.
J K L
M N O P
7
Product overview.
AQWERTY keyboard with island-style
keys
BKeyboard Docking Mount
C5-Pin Connector for Keyboard Cover
DKeyboard Docking Mount
ELeft Mouse Click
FTrackpad
GRight Mouse Click
Specification.
A B D
FE G
C
8
Instructions for use.
Check the package contents.
The package contains:
• 1 x Linx 12X64 Tablet
• 1 x Linx 12XKDB Keyboard Cover
• 1 x Mains Charger with Micro USB cable
• 1 x User Guide
Charging your tablet.
Your battery has been partially charged at the factory,
but you may need to recharge it before you can
switch the tablet on for the first time.
Note: It is recommended to recharge the battery of
the tablet fully before turning on for the first time.
Important: Use only the provided or approved
chargers or cables with this tablet.
1. Plug the Mains Charger into a compatible wall
socket.
Important: Please ensure the power at the wall
socket is switched off.
3. Connect the Mains Charger to your tablet using
the integrated Micro USB cable.
4. Turn the power at the wall socket on, your tablet
should now begin to charge. The power indicator
LED will light up on your tablet when charging.
When the battery is full, disconnect the charger from
the tablet, then from the wall outlet.
Note: To check the current charge level of the
battery, press the icon located at the bottom
right of the screen.
Note: You don’t need to charge the tablet for
specific length of time, and you can use the tablet
while it is charging.
Note: If the battery is completely discharged, it may
take several minutes before the tablet can be used.
Rechargeable Lithium-Ion battery
Your tablet has an internal Lithium-ion polymer
battery which should last the lifetime of the product.
If you suspect that the battery is dead, try charging
it several times and follow the steps for charging
your tablet.
• Do NOT attempt to change the battery yourself.
• CAUTION: Danger of explosion if batteries are
incorrectly replaced.
• NEVER use or charge the battery if it appears to
be leaking, discoloured, deformed or in any way
abnormal.
• NEVER expose the battery to any liquid.
• NEVER expose the battery to excessive heat
such as direct sunlight or fire.
• NEVER throw batteries in a fire or attempt to
open the outer casing.
• Batteries are harmful if swallowed, so keep
away from and out of reach of infants and young
children.
9
Using your tablet.
Turning your tablet On
To turn your tablet on, press and hold the Power/
Sleep button and the tablet will begin to power up.
Putting your tablet into Sleep mode
To put your tablet into Sleep mode, press the Power/
Sleep button once. The screen should switch off and
your tablet will be in Sleep mode.
To wake the tablet from Sleep mode, press the
Power/Sleep button once. The screen should wake
up and display the lock-screen.
Turning your tablet Off
To turn your tablet off, press and hold the Power/
Sleep button until you are prompted with the ‘Slide
to shut down your PC’ message. Slide and drag
your finger down the screen to begin the shut down
process and turn off your tablet.
Emergency reboot
To reboot your tablet if the screen becomes
unresponsive, press and hold the Power/Sleep
button for approx. 10 seconds until the screen turns
off.
Note: Leave the tablet for 15 seconds before trying
to reboot the tablet.
Important: Avoid powering the tablet down
by using the emergency reboot wherever possible.
Always try to shut down your tablet using the correct
shut down method to avoid loss or damage to data.
Increasing and decreasing the volume
To increase the volume level on your device, press
the Volume up button. Repeatedly press the Volume
up button until the desired volume is reached.
To decrease the volume level on your device, press
the Volume down button. Repeatedly press the
Volume down button until the desired volume is
reached.
Using headphones with your tablet
You can connect headphones with a 3.5mm plug
(not included) to your tablet. The headphone socket
can be found on the device highlighted with .
When you have headphones connected, the tablet
speakers are switched off and all sound is sent via
the headphones.
Installing a Micro SDHC/XC card
Your tablet supports Micro SDHC and SDXC cards
(not included) for additional storage of data and files.
Important: Use only compatible memory cards
approved for use with this device. Incompatible cards
may damage both the memory card and the tablet
and may corrupt data stored on the card.
To install a Micro SDHC/SDXC memory card:
1. Locate the Micro SDHC/SDXC card slot on the
tablet.
2. Insert the Micro SDHC/SDXC card into the slot,
carefully slide the memory card into the slot, pushing
gently until it clicks into place.
Note: To remove a memory card, push the memory
card gently until it clicks and the spring will push the
card out to allow you to remove it from the tablet.
Important: Do not remove a memory card
when files are currently being used by the tablet. This
may corrupt or lose the data stored on the memory
card.
10
Using the kickstand
The integrated kickstand can be used to position the
tablet to a more suitable viewing angle to make using
the tablet easier.
To use the kickstand, locate the recess in the bottom
left and bottom right corners, towards the rear of the
tablet, and push or pull the tablet stand until it clicks
into the desired position.
Important: Do not use excessive force when
setting the kickstand angle or push down on the
tablet when stood using the kickstand. This may
damage the tablet and can cause the kickstand to
stop working correctly.
Using Windows 10 Home
For a quick introduction to Windows 10 Home and
up-to-date guides to help you get more from your
tablet, please visit our support page at:
support.linxtablets.com
11
Using the Keyboard Cover
Connecting to your tablet
Important: Before connecting the tablet with
the Keyboard Cover for the first time, please turn
on your tablet and wait for the boot process to
be completed and the Windows desktop to finish
loading.
1. Place the Keyboard Cover onto a firm surface for
support when docking your tablet.
2. Connect the tablet to the Keyboard Cover by
locating the Pogo Pin connection and placing your
tablet into the docking slot.
Windows will now automatically detect the
connection and begin to set up your accessory.
Please DO NOT undock the tablet during this
process.
Note: The time taken to automatically detect and
setup the Keyboard Cover can vary depending on
the hardware configuration, number of applications
running and number of external devices connected
to the tablet. Please be patient during this process.
3. After the auto-detection and setup of the
Keyboard Cover is complete, a confirmation prompt
will display on your tablet.
Your Linx Keyboard Cover is now successfully set up
with your tablet and is ready-to-use.
Note: When you have successfully set up the
keyboard for the first time, the setup process will not
have to be run again when docking your tablet into
the keyboard, making it faster and easier to use.
