LiPPERT Embedded Hurricane-PM Bedienungsanleitung

TME-EPIC-HURPM-R1V5.doc

Revision 1.5/ May 08

©LIPPERT Embedded Computers GmbH

Hans-Thoma-Str. 11

D-68163 Mannheim

http://www.lippertembedded.com/

Hurricane-PM

EPIC Single Board Computer

Technical Manual

TME-EPIC-HURPM-R1V5.doc Rev 1.5

Technical Manual Hurricane-PM

LiPPERT Document: TME-EPIC-HURPM-R1V5.doc Revision 1.5

Contents and specifications within this manual are subject of change without notice.

Trademarks

MS-DOS, Windows, Windows 95, Windows 98, Windows NT and Windows XP are trademarks of

Microsoft Corporation. PS/2 is a trademark of International Business Machines, Inc. Intel is a

trademark of Intel Corporation. Geode is a trademark of Advanced Micro Devices, Inc. M-Systems

and DiskOnChip are trademarks or registered trademarks of M-Systems Flash Disk Pioneers, Ltd.

PC/104 is a registered trademark of the PC/104 Consortium. Mozilla and Firefox are registered

trademarks of the Mozilla Foundation. EPIC (Embedded Platform for Industrial Computing) is a

trademark of Octagon Systems, Micro/sys, VersaLogic, WinSystems, and Ampro Computer

Corporations.

All other trademarks appearing in this document are the property of their respective owners.

TME-EPIC-HURPM-R1V5.doc Rev 1.5 i

Table of Contents

0H1. Overview 116H1

1H1.1 Introduction .......................................................................................... 117H1

2HFeatures................................................................................................118H1

3HBlock Diagram........................................................................................119H2

4H1.2 Ordering Information............................................................................. 120H3

5HHurricane-PM Models...............................................................................121H3

6HCable Sets and Accessories ......................................................................122H3

7H1.3 Specifications ........................................................................................ 123H4

8HElectrical Specifications............................................................................124H4

9HEnvironmental Specifications....................................................................125H4

10HMTBF ....................................................................................................126H4

11HMechanical.............................................................................................127H4

12H2. Getting Started 128H5

13H2.1 Connector Locations .............................................................................. 129H5

14HFront ....................................................................................................130H5

15HTop.......................................................................................................131H6

16HBottom..................................................................................................132H7

17H2.2 On Board LED Indicators........................................................................ 133H8

18H2.3 Hardware Setup..................................................................................... 134H9

19H3. Module Description 135H10

20H3.1 Processor............................................................................................... 136H10

21H3.2 Northbridge ........................................................................................... 137H10

22H3.3 Southbridge........................................................................................... 138H11

23H3.4 Watchdog .............................................................................................. 139H11

24H3.5 Graphics Controller................................................................................ 140H13

25HVGA Connector..................................................................................... 141H14

26HLVDS .................................................................................................. 142H14

27HLVDS Connector ................................................................................... 143H14

28HDisplay Backlight Connector ................................................................... 144H15

29HDisplay Voltage Selector ........................................................................ 145H15

TME-EPIC-HURPM-R1V5.doc Rev 1.5 ii

30H3.6 Ethernet Controller 1 ............................................................................. 146H16

31H10/100Mbit Ethernet/USB Combi Connector.............................................. 147H16

32H3.7 Ethernet Controller 2 ............................................................................. 148H17

33H10/100Mbit Ethernet/USB Combi Connector.............................................. 149H17

34H3.8 On Board Power Supply ......................................................................... 150H18

35HPower Connector (standard usage and +5V-only)...................................... 151H18

36HBackup Battery..................................................................................... 152H18

37H3.9 EIDE Port............................................................................................... 153H19

38HEIDE Connector.................................................................................... 154H19

39H3.10 PS/2 Keyboard and Mouse Interface ..................................................... 155H19

40HPS/2 Connectors................................................................................... 156H19

41H3.11 On Board USB for uDOC ......................................................................... 157H20

42HUSB Connector..................................................................................... 158H20

43H3.12 Serial Ports............................................................................................ 159H21

44HCOM1 Connector................................................................................... 160H21

45HCOM2 Connector................................................................................... 161H22

46HRS485-Termination Jumpers .................................................................. 162H22

47H3.13 IrDA Interface ....................................................................................... 163H23

48HIrDA Connector .................................................................................... 164H23

49H3.14 Parallel Port LPT1 .................................................................................. 165H23

50HLPT1 Connector.................................................................................... 166H24

51H3.15 Audio Interface...................................................................................... 167H25

52HFront Audio Connector........................................................................... 168H25

53HOn Board Audio Connector ..................................................................... 169H25

54H3.16 System Panel Connector ........................................................................ 170H26

55HExternal Power-Button........................................................................... 171H26

56HReset-In Signal .................................................................................... 172H26

57HExternal Battery ................................................................................... 173H26

58HWatchdog Output.................................................................................. 174H27

59HPower LED Output................................................................................. 175H27

60HHDD LED Output................................................................................... 176H27

61H3.17 CPU Fan Supply...................................................................................... 177H28

62H3.18 Supervisory Connector........................................................................... 178H28

63H3.19 PC/104-Plus Bus Interface .................................................................... 179H29

TME-EPIC-HURPM-R1V5.doc Rev 1.5 iii

64H3.20 PC/104 Bus Interface............................................................................ 180H30

65HPC/104 Bus Connector........................................................................... 181H30

66H4. Using the Module 182H31

67H4.1 BIOS ...................................................................................................... 183H31

68HSetup.................................................................................................. 184H31

69HInitialize BIOS at first startup ................................................................. 185H31

70HBooting from alternative device .............................................................. 186H31

71HReload default BIOS values .................................................................... 187H31

72HBIOS Setup Overview............................................................................ 188H31

73H5. Address Maps 189H38

74HMemory Address Map ............................................................................ 190H38

75HI/O Address Map................................................................................... 191H39

76HInterrupts............................................................................................ 192H40

77HDMA Channels...................................................................................... 193H41

78HAppendix A, Trouble Shooting 194HA

79HAppendix B, Contact Information 195HB

80HAppendix C, Getting Help 196HC

81HAppendix D, Further Resources 197HC

82HAppendix E, Revision History 198HE

TME-EPIC-HURPM-R1V5.doc Rev 1.5 iv

List of figures

83HFigure 1: Block diagram of the Hurricane-PM....................................................................................199H2

84HFigure 2: Front plate connectors .....................................................................................................200H5

85HFigure 3: Connectors on top of the module.......................................................................................201H6

86HFigure 4: Watchdog circuit........................................................................................................... 202H12

87HFigure 5: BIOS Main screen.......................................................................................................... 203H31

88HFigure 6: BIOS Standard features setup......................................................................................... 204H32

89HFigure 7: BIOS Advanced setup .................................................................................................... 205H32

90HFigure 8: BIOS CPU features ........................................................................................................ 206H32

91HFigure 9: BIOS Advanced chipset features setup (1) ........................................................................ 207H33

92HFigure 10: BIOS Advanced chipset features (2), LVDS panel support.................................................. 208H33

93HFigure 11: BIOS Integrated peripherals, overview ........................................................................... 209H33

94HFigure 12: BIOS Integrated IDE.................................................................................................... 210H34

95HFigure 13: BIOS Integrated Audio................................................................................................. 211H34

96HFigure 14: BIOS Integrated serial ports .........................................................................................212H34

97HFigure 15: BIOS Integrated USB device ......................................................................................... 213H35

98HFigure 16: BIOS Special features setup..........................................................................................214H35

99HFigure 17: BIOS Power management setup .................................................................................... 215H36

100HFigure 18: BIOS PnP/PCI Configuration.......................................................................................... 216H36

101HFigure 19: BIOS CPU frequency and voltage control......................................................................... 217H37

TME-EPIC-HURPM-R1V5.doc Rev 1.5 Page 1 of 41

1. Overview

1.1 Introduction

The Hurricane-PM is a high-performance EPIC board based on Intel®Pentium M processor, having

only small power requirements. The board integrates all peripherals of an embedded PC on a small

115 mm x 165 mm (4.5” x 6.5”) printed circuit board. Together with the Intel® ICH4 southbridge

and a Super I/O chip, the board is a complete PC. There is graphics controller with VGA and LVDS

adapters, which connects many sorts of display terminals. Backlighting is provided for LCD modules.

Two fast 10/100BaseT Ethernet ports, two RS232/RS422/RS485 serial ports, and six USB 2.0 host

ports handle the communication with external devices. There are PS/2 connectors for keyboard and

mouse as well as a parallel printer port available. Sound I/O according to AC97 is supported, too. An

IDE ATA100 adapter allows connection of hard disk or CD drives. Applications that require non-

moving storage can use the built-in µDOC interface and connect a suitable FlashDrive to it.

The Hurricane-PM is powered by a 10 pin ATX supply connector and supports ACPI, advanced power

management and PCI power management. Additionally, digital and analog I/O is available for the

application.

System expansion is easily done using the PC/104-Plus or the PC/104 connectors and adding

suitable specialized I/O modules.

Features

The Hurricane-PM board is an embedded industrial computer based on Intel® Pentium M and Intel®

855GME chipset. It provides standard legacy I/O devices for industrial applications.

•PC/104 Plus connectors for peripherals

•2 independent Ethernet 10/100BaseT interfaces

•6 x USB 2.0 (incl. 1 x uDOC header for USB 2.0 flash drives)

•2 x RS232/RS485 software selectable serial ports

•EIDE (ATA100) on IDC44

•Analog VGA

•LVDS for displays, either single channel 18 bits or dual channel 2x18 bits, with backlight

power

•AC97 Audio with line-in, line-out, mic-in and SPDIF

•Parallel port

•PS/2 keyboard/mouse support

•10 pin ATX Power supply

TME-EPIC-HURPM-R1V5.doc Rev 1.5 Page 2 of 41

Block Diagram

Figure 1: Block diagram of the Hurricane-PM

TME-EPIC-HURPM-R1V5.doc Rev 1.5 Page 3 of 41

1.2 Ordering Information

Hurricane-PM Models

Order number Description

810-0005-10 CPU board with Intel Celeron M (0.6GHz, 512kB L2 cache, 400MHz FSB)

Operating temp. range: -20°C .. +60°C

810-0002-10 CPU board with Intel Celeron M 373 (1.0 GHz, 512kB L2 cache, 400 MHz FSB)

Operating temp. range: -20°C .. +60°C

810-0003-10 CPU board with Intel Pentium M 738 (1.4 GHz, 2MB L2 cache, 400 MHz FSB).

Operating temp. range: -20°C .. +60°C

810-0004-10 CPU board with Intel Pentium M 745 (1.8 GHz, 2MB L2 cache, 400 MHz FSB).

Operating temp. range: -20°C .. +60°C

910-0005-10 CPU board with Intel Celeron M (0.6GHz, 512kB L2 cache, 400MHz FSB)

Operating temp. range: -40°C .. +85°C

910-0002-10 CPU board with Intel Celeron M 373 (1.0 GHz, 512kB L2 cache, 400 MHz FSB)

Operating temp. range: -40°C .. +85°C

Cable Sets and Accessories

Order number Description

863-0013-10 Cable set for Hurricane-PM: COM, IDE (44 pin, 2mm), cable adapter 2.5" > 3.5",

adapter 3.5" > 2.5"

869-0007-10 Windows XP Embedded Board Support Package for the Hurricane-PM.

865-0015-10 Heat sink, passive, Hurricane-PM

865-0016-10 Heat sink, active, Hurricane-PM

TME-EPIC-HURPM-R1V5.doc Rev 1.5 Page 4 of 41

1.3 Specifications

Electrical Specifications

Supply voltage + 5V DC

Rise time < 5 ms

Supply voltage ripple ± 5 %

Supply current

0.6GHz Celeron M

810-0005-10

910-0005-10

max. 2.8 A, depending on usage and operating system

typ. 1.9 A (Windows XP idle mode)

typ. 2.1 A (MS-DOS)

1.0GHz Celeron M

810-0002-10

max. 3.2 A, depending on usage and operating system

typ. 2.0 A (Windows XP idle mode)

typ. 2.4 A (MS-DOS)

1.4GHz Pentium M

810-0003-10 max. 3,8 A, depending on usage and operating system

typ. 2.2 A (Windows XP idle mode)

typ. 3.1 A (MS-DOS)

1.8GHz Pentium M

810-0004-10 max. 5.7 A, depending on usage and operating system

typ. 2.6 A (Windows XP idle mode)

typ. 3.9 A (MS-DOS)

Inrush current 3 A peak

Environmental Specifications

Temperature range -20 … 60 °C (standard version)

-40 … 85 °C (extended version)

Storage temperature -40 … 85 °C

Temperature change max. 10K / 30 minutes

Humidity (relative) 10 … 90 % (non-condensing)

Pressure 450 … 1100 hPa

MTBF

MTBF at 25°C 153.939 hours

Mechanical

Dimensions (L x W) 115 mm x 165 mm (4.53"- x 6.5")

Height 50 mm

Weight 300 g

Mounting 4 mounting holes for PCB

4 mounting holes for PC/104 Plus

Note It is strongly recommend using plastic spacers instead of metal spacers to

mount the board. With metal spacers, there is a possible danger to create

a short circuit with the components located around the mounting holes.

This can damage the board!

Inhaltsverzeichnis

Andere LiPPERT Embedded Hauptplatine Handbücher

LiPPERT Embedded

LiPPERT Embedded Hurricane-QM57 Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

ASROCK

ASROCK ROMED8-2T Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung
