Listen LS-88 Bedienungsanleitung
LS-88 Quick Start Guide
How to Set Up Your ListenIR Portable System
Your Portable ListenIR System Comes
with the Following Products
1
Transmitter & Microphone Set-Up
2
•LT-84 ListenIR Transmitter/Radiator Combo
•Power Supply
• Tripod
• Microphone
• LR-4200-IR iDSP Receivers
• Universal Ear Speakers
• Neck Loop/Lanyards
• 4-Port USB Charger
•USB to Micro-USB Charging cables
• Assistive Listening Compliance Sign
• Portable IR Carrying Case
POWER
POWER
SWITCH
MICROPHONE
INPUT
VOLUME CONTROL
Step One: Remove the LT-84, power supply, tripod
and microphone.
Step Two: Screw the tripod into the bottom of the LT-84.
Step Three: Plug the power supply into the back of the
LT-84.
Step Four: Plug the microphone into the back of the
LT-84.
Step Five: Plug power supply into an outlet. Turn
on power switch.
Step Six: Make sure the microphone is placed
close to the sound source.
Step Seven: Turn the volume all the way up.
PRO TIP:
Make sure that the LT-84 is not concealed
behind walls, curtains, or treated glass, as
Infrared light needs a clear line-of-sight to
the receiver for the best performance.
Listening with the iDSP IR Receiver
3
Charging your iDSP IR Receiver
4
Step One: Plug the Neck
loop/lanyard into both audio
jacks on the iDSP IR receiver.
Step Two:
For Listeners Using Ear Speakers:
Plug the ear speaker into the audio
jack two thirds up the Neck
loop/lanyard, then place the Neck
loop/ lanyard around the listener's
neck, and the speaker on the ear.
For Listeners with Telecoils:
Telecoil users do not need an ear
speaker. Place the Neck loop/lanyard
around the listener's neck; it will
interact with the listener's telecoil.
Step Three: Turn on by holding
down the power button for one
second; turn off by holding down
for three seconds.
Step Four: Adjust volume with
the volume buttons on the front
of the receiver.
Option One: Use the 4-Port USB Charger and USB
to Micro-USB charging cables. Insert the charging
cables into the receiver and charger, then plug into
an outlet to charge.
POWER BUTTON
VOLUME
CONTROLS
PRO TIP:
Make sure your iDSP IR
Receiver is worn on the
outside of clothing for the
best performance.
PRO TIP:
It is best to let the receivers charge fully
between each use.
There are two ways to charge your iDSP IR Receiver.
Option Two: Use the USB to Micro-USB charging
cables with your PC. Insert the charging cables into the
receiver, then plug into the USB on your computer.
LISTEN TECHNOLOGIES 14912 Heritage Crest Way, Bluffdale, Utah 84065-4818 USA
Phone: +1.801.233.8992 Toll-Free: 1.800.330.0891 www.listentech.com
Copyright © 1998 - 2022 Listen Technologies Corporation. All rights reserved. 20221017.
