LiteOn NA121 Bedienungsanleitung

NA121

Intel® 845-G Motherboard

USER’S MANUAL

Intel® Pentium®4 Processor Motherboard

Rev. 1.0

NA121 Motherboard

Revision History

Revision Date Description

1.0 Initial release of NA121 motherboard user’s manual

Item Checklist

1 NA121 Motherboard

1 Floppy Cable

1 ATA Cable 66/100

1 Motherboard Driver CD

NA121 User’s Manual

Quick Installation Guide

Intel® Pentium® 4 are registered trademark of Intel Corporation.

NA121 Motherboard

Safety Instructions

Please follow some precautions when operating your computer.

1. Always unplug the power cord when inserting any add-on card or module inside the system.

2. Use a grounded wrist strap before handling computer components. If one is not available, touch both of your

hands to a safely grounded object or to a metal object.

3. Place components on a level grounded antistatic pad or on the packaging that came with the components

whenever the components are separated from the system.

4. Keep equipment away from moisture and humidity.

5. Keep this User’s Manual for future reference.

NA121 Motherboard

Table of Contents

Chapter 1. Introduction …………………………………………………………………… 1

Motherboard Specification …………………………………………………………………………. 1

NA121 Motherboard Layout …………………………………………………………………….…. 3

Chapter 2. Hardware Installation Process ………………………………………..4

Installing Central Process Unit (CPU) ……………………………………………………………..4

Installing Memory Modules ………………………………………………………………………… 6

Connecting IDE and Floppy Disk Cables and Drives ……………………………………………7

Installing Expansion Cards ……………………………………………………………………….. . 9

Connect Power Supply Cable ……………………………………………………………………. 10

I/O Back Panel Introduction ………………………………………………………………………. 11

Jumpers Introduction ……………………………………………………………………………… 13

Chapter 3. AMI® BIOS Setup ………………………………………………………….. 19

Entering Setup ……………………………………………………………………………………... 19

The Main Menu ……………………………………………………………………………………. 19

Standard CMOS Setup …………………………………………………………………………… 20

Advanced CMOS Setup ……….…………………………………………………………………. 21

Advanced Chipset Setup …………………………………………………………………………. 22

Power Management Setup ……………………………………………………………………….. 23

PCI/Plug and Play Setup …………………………………………………………………………. 24

Peripheral Setup …………………………………………………………………………………… 25

Hardware Monitor Setup ………………………………………………………………………….. 26

Auto-Detect Hard Disks …………………………………………………………………………… 27

Change User Password …………………………………………………………………………... 28

Change Supervisor Password ……………………………………………………………………. 29

Auto Configuration with Optimal Settings ……………………………………………………….. 30

Auto Configuration with Fail Safe Settings ……………………………………………………… 31

Save Settings and Exit ……………………………………………………………………………. 32

Exit Without Saving ………………………………………………………………………………... 33

NA121 Motherboard

Chapter 1 Introduction

Motherboard Specifications

Form Factor:

• ATX Form Factor 12” x 8.9” (30.5cm x 22.6cm)

Processor:

• Supports IntelPentium4 Willamette and Northwood Processor

• Processor socket mPGA478B

• 400 MHz system bus, capable to enhance processor system bus to 533 MHz with Northwood

processor

Super I/O:

• Winbond W83627HF

System Memory:

• Three DIMM socket support

• Supports PC200 and PC266 DDR SDRAM

Clock Generator:

• ICS950220 setting for jumpless

Audio:

• 3D audio compliant with AC’97 rev. 2.2

• Realtek ALC202A

Video:

• External 1.5V 2X/4X AGP Slot

• Integrate High Performance 2D/3D Acceleration

IDE Ports:

• Two IDE ports to support four devices

• Supports all PIO modes

• Support Ultra DMA 33/66/100

NA121 Motherboard

Expansion Slots:

• One AGP slot

• One CNR slot shared with one PCI slot (optional)

• Six PCI Slots

BIOS:

• 4Mbit flash EEPROM

• AMI® BIOS, PnP, ACPI, SMBIOS 2.3, Boot Block DMI

• WfM v.2.0, DMI v2.0, WOL, SMBus support

Additional Features:

• Keyboard/Mouse/USB wake up

• Support S1, S3, S4 and S5 ACPI status

• Hardware Monitor Capability (LPC47M192)

• Optional On Board LAN (Realtek RTL8100B, Support 10/100 Mbps Ethernet)

Expansion Slots:

• Single AGP 2.0 slot (AGP 4X, 1.5 signaling)

• Six PCI 2.2 slots

• 1 CNR slot shared with one PCI slot (option)

Rear Side I/O Ports:

• PS2 Keyboard and Mouse

• Two USB 2.0 ports

• RJ45 LAN connector (option)

• Single Serial Port

• Single Parallel Port

• Single VGA connector

• Dual Channel Game Port

• Three Audio Jacks (Line-Out, Line-In, Mic-In)

On Board I/O Interface:

• Single ATX and +12V Power Connector

• Single Floppy Connector

• Front Panel Connector (Switch, LED, IRDA)

• Header for front side Line-Out and Mic-In (option)

• Three Fan Headers for CPU, chassis and system

• Two ATAPI headers (CD In, AUX In)

• Header to support two front side USB ports

NA121 Motherboard

NA121 Motherboard Layout

A CPU Socket H Front SideUSB

B CPU Fan Socket I COM Port

C Memory Sockets J Expansion Slots

D Power Supply Connectors K Audio Connector

E Floppy Connector L Jumper Connector

F IDE Connectors M Back Panel Connectors

G Front Panel Connector

Front Panel Connector Pin Definition

Pin Signal Name I/O Description

1 HDD LED+ O Pull up 330ohm to VCC

2 Suspend LED- O SUS LED

3 HDD LED- O IDEACTP-

4 Suspend LED+ O Pull up 330ohm to VCC

5 H/W reset- - GND

6 Power Button+ I Pull up 1Kohm to VCC

7 H/W reset+ I HWRST SW

8 Power Button- - PWRBTIN

9 VCC - VCC

10 EXT, SMI+ I Pull up 8.2Kohm to 3.3V

11 IRRX I IRRX

12 EXT, SMI- - GND

13 GND - GND

14 KEY - KEY

15 IRTX O IPTX

16 Power LED+ O VCC

17 CIRRX - CIRRX

18 NC - NC

19 NC - NC

20 Power LED- - GND

NA121 Motherboard

Chapter 2 Hardware Installation Process

Installing the Central Process Unit (CPU)

CPU Installation

1. Unlock the CPU socket by pulling the lever up to a 90-degree angle.

2. Position the CPU above the socket such that the marked corner (pin1) matches the corner near the

base of the lever.

3. Place the CPU into the socket. If the CPU is unable to insert properly, check its orientation and

attempt to re-install.

Warning! Do not force the CPU into the socket. Doing so will prompt bending of the pins and create

damage to the CPU.

4. Close the socket by lowering the lever and locking the lever in place.

Step 1

90 degree angle

Step 2

Pin1

NA121 Motherboard

Installing the Central Process Unit (CPU)

cont.

CPU Heat Sink Installation

1. Read the related CPU heat sink user’s manual for more detailed installation procedures.

2. Connect CPU fan power cable into the CPU fan connector on the motherboard.

CPU Fan Connector

NA121 Motherboard

Installing Memory Modules

1. Push the white retaining clips on each of the memory socket outwards.

2. Match the notches on the contact edge of the memory module to the ridges in the memory socket.

3. Insert the memory module vertically into place. When properly inserted, the white retaining clips will

move inward to lock in the module.

4. Repeat installation process when adding additional modules.

Double-sided DDR modules can be plugged into either DIMM2 or DIMM3 only.

DIMM2 and DIMM3 only can plug single side DDR (DIMM2: single side, DIMM3: single side)

Slot Option 1 Option 2 Option 3 Option 4 Option 5 Option 6

DIMM 1 Single Double Single Double Single Double

DIMM 2 Single Single Double Double

DIMM 3 Single Single Double Double

Total Memory Sizes With Unbuffered DDR DIMM

Devices used on DIMM 1 DIMM x64 2 DIMMs x64

64 Mbit (2Mx8x4 banks) 128 MBytes 256 MBytes

64 Mbit (1Mx16x4 banks) 64 MBytes 128 MBytes

128 Mbit (4Mx8x4 banks) 256 MBytes 512 MBytes

128 Mbit (2Mx16x4 banks) 128 MBytes 256 MBytes

256 Mbit (8Mx8x4 banks) 512 MBytes 1 GByte

256 Mbit (4Mx16x4 banks) 256 MBytes 512 MBytes

512 Mbit (16Mx8x4 banks) 1 GByte 2 GBytes

512 Mbit (8Mx16x4 banks) 512 MBytes 1 GByte

Retaining Clip
