LIVARNO LUX 288704 Technische Daten

LED FLOOR LAMP

Assembly, operating and safety instructions

LAMPADAIRE À LED

Instructions de montage, d‘utilisation et

consignes de sécurité

STAANDE LED-LAMP

Montage-, bedienings- en veiligheidsinstructies

LED-STEHLEUCHTE

Montage-, Bedienungs- und Sicherheitshinweise

IAN 288704

Before reading, unfold both pages containing illustrations and familiarise yourself with all functions of the

device.

Avant de lire le mode d‘emploi, ouvrez les deux pages contenant les illustrations et familiarisez-vous ensuite

avec toutes les fonctions de l‘appareil.

Vouw vóór het lezen de beide pagina‘s met de afbeeldingen open en maak u vertrouwd met alle functies

van het apparaat.

Klappen Sie vor dem Lesen die beiden Seiten mit den Abbildungen aus und machen Sie sich anschließend

mit allen Funktionen des Gerätes vertraut.

GB/IE/NI Assembly, operating and safety instructions Page 5

FR/BE Instructions de montage, d‘utilisation et consignes de sécurité Page 11

NL/BE Montage-, bedienings- en veiligheidsinstructies Pagina 17

DE/AT/CH Montage-, Bedienungs- und Sicherheitshinweise Seite 23

LAMPADAIRE À LED

Instructions de montage, d‘utilisation et

consignes de sécurité

123

2 3

14115702L

14115808L

2 3

5 4

14115902L

14117902L

5GB/IE/NI

Table of contents

List of pictograms used........................................................................................................Page 6

Introduction...................................................................................................................................Page 6

Intended use........................................................................................................................................Page 6

Scope of delivery................................................................................................................................Page 6

Parts Description..................................................................................................................................Page 7

Technical Data ....................................................................................................................................Page 7

Safety.................................................................................................................................................Page 7

Safety Notices.....................................................................................................................................Page 7

Initial use.........................................................................................................................................Page 8

Mounting the light...............................................................................................................................Page 8

Switching the light on/off..................................................................................................................Page 8

Maintenance and Cleaning..............................................................................................Page 8

Disposal............................................................................................................................................Page 9

Information....................................................................................................................................Page 9

Warranty .............................................................................................................................................Page 9

Manufacturer/Service .......................................................................................................................Page 9

Declaration of conformity...................................................................................................................Page 9

6 GB/IE/NI

List of pictograms used

Read the instructions! Danger to life and risk of accidents

for infants and children!

This light is only suitable for indoor use

in dry and enclosed spaces. Short-circuit proof safety transformer

Volt (AC) Separate control unit

Hertz (mains frequency) Warning! Risk of electric shock

Watt (eﬀective power) This light is not suitable for dimmer or

electronic switches.

Safety class II For your safety

Direct current Warning - Hot surfaces!

Observe the warning and safety

instructions! b

Dispose of the packaging and device

in an environmentally-friendly manner!

LED lifespan

LED Floor Lamp

Introduction

Congratulations on the purchase of your

new appliance. You have selected a high

quality product. Please be sure to carefully

ad all the instructions for use. Fold out the page wit

illustrations. These instructions are part of the product

and contain important information on setup and han-

dling. Always observe all safety instructions. Before

using this product for the ﬁrst time verify the correct

voltage and that all parts are properly installed. If

you have any questions or are unsure about operat-

ing the product, please contact your distributor or

service centre. Please keep these instructions in a safe

place and pass them on to third parties if necessary.

Intended use

This light is only suitable for indoor use

in dry and enclosed spaces. This product

is intended for private household use only.

Scope of delivery

Check that all the parts are present and that the appli-

ance is in perfect condition immediately after unpacking.

1 LED ﬂoor lamp, model 14115702L/14115808L/

14115902L (two-part) 14117902L

1 Base

1 Power supply

2 Screws (14115702L / 14115808L /

14117902L)

4 Screws (14115902L)

1 Set of assembly instructions and usage instructions

Introduction Introduction/Safety

7GB/IE/NI

Parts Description

1Light body

2Lead

3Mains supply

4Foot operated ON / OFF switch

5Base

6Screws

7Lamp arm (14115902L)

8Screws (14115902L)

Technical Data

Model no: 14115702L/14115808L/

14115902L/14117902L

Voltage (Lamp): 230–240V∼, 50Hz

Bulb: LED module (non-replaceable)

10,5W (14115702L/

14115902L)

12W (14117902L)

18W (14115808L)

Protection class: II/

Plug-in power supply (Model 14115702L /

14115902L/14117902L)

Type: EIP012V0240PSS

220–240V∼, 50/60Hz;

0,18A;

24V max. 0,5A

Protection class: II/

Rated power incl.

Plug-in power supply: 12 W (14115702L/

14115902L)

12,5W (14117902L)

Plug-in power supply (Model 14115808L)

Type: EIP020V0240PSS

220–240V∼, 50/60Hz;

0,3A;

24V max. 0,83A

Protection class: II/

Rated power incl.

Plug-in power supply: 21 W (14115808L)

Safety

Safety Notices

Damage due to failure to comply with these instruc-

tions for use will void the warranty! We assume no

liability for consequential damages! We assume no

liability for property damage or personal injury due

to improper handling or failure to comply with the

safety instructions!

DANGER TO

LIFE AND ACCIDENT HAZARD

FOR TODDLERS AND SMALL

CHILDREN!

Never leave children unsupervised with the

packaging materials. The packaging material

poses a suﬀocation hazard. Children frequently

underestimate dangers. Please always keep the

product out of the reach of children.

This device may be used by children age 8 years

and up, as well as by persons with reduced

physical, sensory or mental capacities, or lack-

ing experience and/or knowledge, so long as

they are supervised or instructed in the safe use

of the device and understand the associated

risks. Do not allow children to play with the de-

vice. Cleaning and user maintenance must not

be performed by children without supervision.

Avoid the risk of fatal injury

from electric shock

Check the lamp for possible damage before

every use. Never use the light if it shows any

signs of damage.

A damaged light means danger of death from

electric shock. In the event of damage, repairs

or other problems with the light, please contact

the service centre or an electrician.

To prevent hazards, if the external ﬂexible lead

on this lamp is damaged it must be replaced by

the manufacturer, its service representative or

an equally qualiﬁed professional!

Introduction Introduction/Safety

8 GB/IE/NI

Before use, verify that the available mains

voltage corresponds with the operating voltage

of the lamp.

Ensure that the light does not come into contact

with water or other liquids under any circum-

stances.

Always unplug the power supply from the mains

prior to assembly, disassembly, cleaning or if

the light will not be used for extended periods.

Never open any of the components of the elec-

trical equipment or insert any objects into the

same components. This will pose a risk of fatal

injury from electric shock.

This light is not suitable for dimmer

or electronic switches.

Prevent fire and

injury hazards

Do not look directly into the light source

(light bulb, LED etc.).

Do not look at the LED with an optical instrument

(e.g. magniﬁer).

The illuminant in this light is not replaceable;

if the illuminant reaches the end of its life,

replace the entire light.

Do not cover the lamp or the mains plug with

objects. Fire can result from excessive heat

development.

Do not operate the lamp unattended.

For your safety

Mount the light so that it is protected from

moisture and dirt.

Make careful preparations for mounting and

allow yourself adequate time. Organise all parts

and any necessary additional tools or materials

before starting so they are easy to reach.

Always be attentive! Always pay attention to

what you are doing and use common sense.

Never install the light if you are having diﬃculty

concentrating or do not feel well.

To disconnect the lamp completely from the

power supply, the mains plug must be

disconnected from the mains socket.

Initial use

Mounting the light

Place the body of the light 1onto the

pre-drilled holes in the base 5.

Screw the body of the light

onto the base

ﬁrmly by tightening the screws 6.

Ensure that the side with the protective felt pad

is facing downwards.

14115902L model only: Carefully plug the

lamp body 1into the lamp arm 7.

Che

ck that the cable inside the lamp arm 7or

lamp body 1interconnects by means of the

plug connection. Then ﬁx the lamp body 1to

the lamp arm 7by tightening the screws 8.

Position the lamp arm 7over the pre-drilled

holes in the base 5. Screw the lamp arm 7

onto the base 5and tighten the screws 6

securely. Ensure that the side with the protec-

tive felt pad is facing downwards.

Plug the power supply into a properly installed

socket 3.

Your light is now ready to use.

Switching the light on/ oﬀ

Use the foot operated ON/OFF switch 4to

switch the light on or oﬀ.

Maintenance and Cleaning

DANGER OF ELECTRIC

SHOCK!

First remove the mains plug from the socket.

DANGER OF ELECTRIC

SHOCK!

For electrical safety, never clean the light with water

or other liquids, nor immerse it in water.

CAUTION! RISK OF BURNS DUE TO

HOT SURFACES!

Allow the lamp to cool down completely.

Safety/Initial use/Maintenance and Cleaning .../Disposal/Information

9GB/IE/NI

Do not use solvents, benzene or similar

substances. They could damage the light.

Only use a dry, lint-free cloth for cleaning.

Disposal

The packaging is made entirely of recy-

clable materials, which you may dispose

of at local recycling facilities.

Observe the marking of the packaging

materials for waste separation, which

are marked with abbreviations (a) and

numbers (b) with following meaning:

1–7: plastics/ 20–22: paper and ﬁbre-

board/ 80–98: composite materials.

The product and packaging materials

are recyclable, dispose of it separately

for better waste treatment. The Triman

logo is valid in France only.

Contact your local refuse disposal author-

ity for more details of how to dispose of

your worn-out product.

To help protect the environment, please

dispose of the product properly when it

has reached the end of its useful life and

not in the household waste. Information

on collection points and their opening

hours can be obtained from your local

authority.

Information

Warranty

A 36 month warranty is extended for this appliance

at the time of purchase. The appliance has been

manufactured with care under strict quality control.

During the warranty period any defects in material

or manufacture will be replaced free of charge. In

the event of a defect during the warranty period,

please send the appliance to the service address

listed, indicating the following item number:

14115702L/14115808L/14115902L/

14117902L.

Expendable parts (such as bulbs) and damage

caused by improper handling, failure to observe the

instructions for use or modiﬁcation by unauthorised

persons are excluded from the warranty. The per-

formance of services under the warranty does not

extend or renew the warranty period.

Manufacturer/Service

Briloner Leuchten GmbH

Im Kissen 2

DE-59929 Brilon

GERMANY

Tel.: +49 (0) 29 61/97 12–800

Fax: +49 (0) 29 61/97 12–199

E-Mail: [email protected]

www.briloner.com

IAN 288704

Please have your receipt and item number

(e.g IAN 12345) ready as your proof of purchase

when enquiring about your product.

Declaration of conformity

This product fulﬁls the requirements of the applicable

European and national directives. Conformity has

been demonstrated. The relevant declarations and

documents are held by the manufacturer.

Safety/Initial use/Maintenance and Cleaning .../Disposal/Information

Table des matières

Inhaltsverzeichnis

Sprachen:

Andere LIVARNO LUX Beleuchtungsausrüstung Handbücher

LIVARNO LUX

LIVARNO LUX HG00302 Bedienungsanleitung

LIVARNO LUX

LIVARNO LUX 292040 Bedienungsanleitung

LIVARNO LUX

LIVARNO LUX 970-K Bedienungsanleitung

LIVARNO LUX

LIVARNO LUX 280508 Bedienungsanleitung

LIVARNO LUX

LIVARNO LUX 285632 Bedienungsanleitung

LIVARNO LUX

LIVARNO LUX Z31172A Bedienungsanleitung

LIVARNO LUX

LIVARNO LUX 14120005L Technische Daten

LIVARNO LUX

LIVARNO LUX HG03874A Bedienungsanleitung

LIVARNO LUX

LIVARNO LUX 14102104L Bedienungsanleitung

LIVARNO LUX

LIVARNO LUX 300257 Bedienungsanleitung

LIVARNO LUX

LIVARNO LUX 280087 Bedienungsanleitung

LIVARNO LUX

LIVARNO LUX 970-G Bedienungsanleitung

LIVARNO LUX

LIVARNO LUX 93752 Bedienungsanleitung

LIVARNO LUX

LIVARNO LUX 970-K Kurzanleitung

LIVARNO LUX

LIVARNO LUX 73850 Montage- und Bedienungsanleitung

LIVARNO LUX

LIVARNO LUX 292043 Bedienungsanleitung

LIVARNO LUX

LIVARNO LUX CORDLESS WORK LIGHT Bedienungsanleitung

LIVARNO LUX

LIVARNO LUX KH 4245 Bedienungsanleitung

LIVARNO LUX

LIVARNO LUX 270696 Bedienungsanleitung

LIVARNO LUX

LIVARNO LUX 295693 Technische Daten

LIVARNO LUX

LIVARNO LUX LLPL 27 B1 Bedienungsanleitung

LIVARNO LUX

LIVARNO LUX Z31392A Bedienungsanleitung

LIVARNO LUX

LIVARNO LUX 970-G Bedienungsanleitung

LIVARNO LUX

LIVARNO LUX G1 mini Bedienungsanleitung

Beliebte Beleuchtungsausrüstung Handbücher anderer Marken

Brizo

Brizo 8SP-MU-4 Bedienungsanleitung

LUCE&LIGHT

LUCE&LIGHT BROM 1.0 Bedienungsanleitung

IKEA

IKEA BJÖRKSPIREA Bedienungsanleitung

Laserworld

Laserworld Evolution Series ES-400RGB Bedienungsanleitung

Alien

Alien RG STAR Bedienungsanleitung

EuroLite

EuroLite LED B-40 Bedienungsanleitung

Qazqa

Qazqa Suplux SL 3 Black 103062 Bedienungsanleitung

Commercial Electric

Commercial Electric 54568141 Bedienungsanleitung

CREE LIGHTING

CREE LIGHTING 304 Series Bedienungsanleitung

Goobay

Goobay 49867 Bedienungsanleitung

ECOMAN ITALIA

ECOMAN ITALIA LED T8 Bedienungsanleitung

Alkalite

Alkalite Krypton KT-81 Bedienungsanleitung

Clas Ohlson

Clas Ohlson GU10 Bedienungsanleitung

DTS

DTS DELTA 10 F Bedienungsanleitung

ring

ring Solar Steplight Bedienungsanleitung

One Stop Gardens

One Stop Gardens 57696 Montageanleitung

Chauvet DJ

Chauvet DJ COREpar UV120 ILS Bedienungsanleitung

SIREM

SIREM Swimeo A2 Bedienungsanleitung
