LM Technologies LM003 Bedienungsanleitung
a) Ensure that at least 50mb of free space is available on your
hard drive
b) Ensure that no other applications are running prior to
installation.
2. The LED indicator light is on, but not flashing.
a) Check that the SIM card is inserted into the SIM card slot
fully and in the correct orientation.
b) If the LED indicator is still not flashing, disconnect from the
USB port, remove and reinsert the sim card and reconnect
3. The software application will not start.
a) Once the HSUPA modem has been connected to the USB
port, please wait approx 5 seconds then run the application. The
application will automatically detect and test the modem con-
nected and also if a sim card has been inserted correctly or not.
6
b) Follow these steps to check the modem driver - Right click on
My computer, Manage, Device Manager, Modem/ Ports
i) Make sure tha modem is called Mobile connector, the ports
called Device Diagnostic Interface and Device Application
Interface are displayed and do not display warning signs
(exclamation mark)
ii) If warning sighs are displayed, disconnect the modem from
the usb port, reconnect, the driver should then install
4. HSUPA USB Modem connection failure
Check that the wireless internet service used is in the local
region. Check that the sim card supports a HSUPA service. If not
then contact your local network operator.
a) If the sim card is a pay as you go (PAYG), make sure that it
has been topped up and you have sufficient funds
7
b) Check the dial up connection, click on its “Properties” to
verify the connection uses “HSUPA USB Modem“
5. HSUPA modem connects OK, but immediately disconnected
a) There may be a problem with the sim card. Try another HSUPA
supported sim card
6. Driver did not complete the un-installation.
Do not remove the modem until the un-installation has
completed fully.
Copyright Protected by LM Technologies Ltd (2010)
8
Quick Start Guide.
LM003
INNOVATIVE TECHNOLOGY PRODUCTS
Introduction
Thank you for purchasing our HSUPA 3G USB Modem. Before use,
please read this manual carefully. This manual will help you to com-
plete the installation and help you to in using it. Then you can enjoy
the fun of surfing wirelessly anytime and anywhere on any network.
Product Overview
The LM003 HSUPA USB modem is a multi-mode, 3G USB modem,
working in HSUPA / UMTS /EDGE /GPRS / GSM networks.
With a USB interface connecting to a laptop or a desktop PC, it
integrates the functionality of a modem and a mobile phone (SMS),
and combines mobile communication with Internet perfectly. It
supports data and SMS services through the mobile phone network,
enabling you to communicate anytime and anywhere.
Note:
The LM003 HSUPA USB Modem can also be used as a mass storage
device but this depends on the capacity of the memory card that is
fitted on the device. The device can support a maximum 8GB T-Flash
memory card.
2
The Connection Manger firmware can be upgraded via the LM
Technologies Web site
Product Specification
Interface Type: USB
Frequency: EDGE/GPRS/GSM 1900/1800/900/850 Mhz
UMTS 2100 Mhz
Transfer speed: download - up to 7.20 Mbps
upload - up to 5.76 Mbps
Antenna: Built in
SIM Card: SIM/USIM
SMS: supports SMS sending and receiving
Operating System: Windows 2000, XP, Vista, Win 7 32 bit and 64bit
Mac OS X 10.4+, Ubuntu
Storage: Micro-SD memory card slot (Max 8Gb)
Product usage guidelines
1. Do not use in hot or humid environments
2. Please handle the product with care. Look after the product
and take care not to damage or drop the product.
3
3. Do not modify or destroy the product. Any such action will
invalidate the warranty on this item.
4. Avoid vibration and shock. When not in use, please store in
an appropriate place.
5. Do not use near flammable or explosive items
6. Do not insert the sim card whilst plugged in to a usb port.
Software and driver installation
The LM003 is a plug and play device and has the driver installed
in memory. It will automatically install when plugged into the
USB port for the first time.
The procedure for installation may differ dependant on your
operating system. Please follow the instructions on your PC.
1. Start your PC and connect the modem to your USB port
2. Please note that the signal strength is dependant on local
network and environmental conditions
3. Your operating system will detect the installation of new
hardware and install drivers for a storage device.
4
4. Once the storage device driver has been installed the soft-
ware on the modem will automatically install.
If Step 4 does not start automatically, follow Step 5, otherwise
go to Step 6
5. Click on My computer, then right click “HSUPA USB Modem”
CD-ROM and select Autoplay.
6. After installation is complete, click Finish
7. Please wait for the PC as the operating system will continue
to detect new hardware and install the appropriate drivers.
Once the installation has completed fully, a message will popup
to tell you the new hardware in installed and ready for use.
Troubleshooting Guide / FAQ’s
1. The driver / application software installation fails
5
