Logitech LifeSize Unity 1000 Referenzhandbuch

234

5678

LifeSize® Unity 1000™

with LifeSize® Express 220™

1Unscrew the thumbnuts shipped with square foam from the base (4x)

and HD display (4x). Discard the foam. Place the base on the oor near the

nal location for the system. Remove the shipping foam from between the

foundation and metal overlay. Turn the overlay so the most presentable

side faces upward.

2Insert the phone cable (from the phone box) and the VGA cable (from

cable bag 1) through the cable channel that runs along the underside of

the base and pull them through the hole in the center. Pull at least 1 m

(3.3 ft) of the phone cable and 80 cm (32 in) of the VGA cable through the

hole.

Note: Cables can be inserted into the cable channel from the front

(shown) or back of the base.

3Thread the phone cable and VGA cable through the hole in the bottom

of the stand and place the stand on top of the base screws.

Note: LifeSize recommends two people to mount the display.

4Use 4 thumbnuts to secure the stand to the base screws.

5Insert the video system, rear panel facing upward, into the brackets on

the component panel. Adjust the brackets so the two fan ports on the

video system are centered beneath the bae.

6Place the component panel inside the stand, using the screws on the

stand as guides. Use the 3 thumbnuts included with the panel to secure

it to the screws.

7 Place the electronics box into the two brackets near the bottom of the

stand. Secure the box and panel to the stand with the 2 thumbscrews

included with the component panel. Ensure the phone cable remains to

the left side of the electronics box (inside the stand) as you secure it.

Similarly, ensure the VGA cable remains to the right of the electronics box.

8Connect the free ends of the VGA cable and phone cable to the

electronics box and video system, indicated by cables 1-2 on the wiring

diagram.

9Guide the 2 mounting hangers located on the upper back side of the

display into the corresponding keyholes in the stand, and gently slide the

display downward into place.

Note: LifeSize recommends two people to mount the display.

10 Reach into the stand from the back and secure the display to the stand

with 2 thumbnuts.

11 Remove the cables from bag 2 and connect them from the display to

the video system and electronics box, indicated by cables 3-6 on the

wiring diagram.

Note: The display requires only 4 cables, even though it features

additional ports.

LEVEL MIN MAX

10 11

12 15

16 19

20 22 23 24

13 14

LifeSize® Unity 1000™

with LifeSize® Express 220™

12 Use the camera screw to secure the camera to the top of the camera

shelf.

13 Use 2 thumbnuts to secure the camera shelf to the back of the display.

14 Connect one end of the camera’s DC power cable and HD cable (from

cable bag 3) to the back of the camera, and thread the other ends

through the slot at the top of the stand.

15 Connect the free ends of the camera’s DC power cable and HD cable

to the electronics box and video system, respectively, indicated by cables

7-8 on the wiring diagram.

16 Remove the cables from bag 4 and connect them from the video

system to the appropriate component, indicated by cables 9-12 on the

wiring diagram.

17 Use 6 thumbscrews to mount both speakers horizontally to the sides

of the stand, immediately below the HD display.

18 Facing the back of each speaker, thread the speaker’s AC power cable

and audio cable (from cable bag 5) under the mounting bracket and

connect them to the back of the speaker.

19 Connect the free ends of the speaker’s AC power cable and audio

cable to the electronics box and video system, indicated by cables 13-14

on the wiring diagram.

20 Place the back cover against the back of the stand and press it toward

the stand until it snaps into place.

21 Connect one end of the network cable (from bag 6) and system AC

power cable to the wall and the other end to the back of the electronics

box, which is exposed through the hole in the lower back of the stand.

Refer to cables 15-16 on the wiring diagram.

22 Turn on power and wait for the system to initialize. The System

Conguration screen appears after approximately two minutes, at which

point you can use the remote to congure the system. Refer to the

LifeSize Video Communications Systems User and Administrator Guide for

instructions.

23 Tuck loose cables inside the stand. Place the front cover against the

front of the stand and press it toward the stand until it snaps into place.

24 Position the speaker cover over both speakers and gently press

forward until it snaps into place.

LEVELMIN MAX

13 14

10 11

15 16

Parts

1 LifeSize Express 220 (video system)

1 LifeSize Phone, second generation

1 LifeSize Camera 10x

1 HD display

1 electronics box (INPx)

2 speakers

1 speaker cover

1 base foundation

1 base overlay

1 stand

1 component panel

1 cover

1 camera shelf

1 camera screw

8 thumbscrews

11 thumbnuts

cables

Cables

LifeSize Unity 1000 ships with more cables than are necessary for assembly. Required cables include the phone cable

shipped with the LifeSize Phone and various cables in the six cable bags that are included in the System Cables box.

DC power Network

Speaker

AC power

Speaker

Audio (RCA)

Video HD

LifeSize® Unity 1000™ Wiring Diagram

with LifeSize® Express 220™
