Logitech G933 Artemis Spectrum Bedienungsanleitung
Logitech® G933
Artemis Spectrum™
Wireless 7.1 Surround
Gaming Headset
User Manual
Logitech® G933 Artemis Spectrum
2
Contents
English. . . . . . . . . . . . . . . . . . 3
По-русски . . . . . . . . . . . . . . 255
Українська . . . . . . . . . . . . . . 360
www.logitech.com/support/g933
Logitech® G933 Artemis Spectrum
3 English
What’s in the box
1. G933 Artemis Spectrum
Gaming Headset
2. Custom tags (L/R)
3. PC cable (USB to Micro-USB, 3m)
4. 3.5mm cable (1.5m)
5. 3.5mm to 2.5mm adapter
6. RCA to 3.5mm cable (1m)
7. Documentation
1
2 2
3
6
45
Logitech® G933 Artemis Spectrum
4 English
1
8
7
9
11
12
13
14
4
5
3
2
6
10
15
3.5mm
Features
1. Adjustable padded sports
mesh headband
2. Removable backlit custom tags
3. Boom mic mute indicator LED
4. Retractable boom microphone
Automatically mutes in “up” position
5. Lighting zones (G logo + light strip)
6. Washable soft sports mesh earpads
7. Wireless On/O switch
8. Pro-G™ Audio Drivers
9. Programmable buttons (G1/G2/G3)
10. Battery housed in earcup
11. Microphone Mute
12. Volume Wheel
13. 3.5mm
(mobile) connection
14. USB charging connection
15. USB Wireless Mix Adapter
housed in earcup
• 3.5mm jack
(stereo input only)
Logitech® G933 Artemis Spectrum
5 English
Headset button layout
1. Wireless On/O switch
2. G3 (programmable):
Default equalizer (EQ) cycle
• Will cycle through EQ settings in
Logitech Gaming software, including:
Flat, MOBA, FPS presets, or custom EQ
3. G2 (programmable): Default surround
sound on/o
4. G1 (programmable): Lighting cycle
• Will cycle through lighting settings in
Logitech Gaming Software, including:
breathing, solid cyan, custom, and o
5. Microphone mute
6. Volume wheel
G1, G2, and G3 are programmable
using the Logitech Gaming Software
(in PC mode only):
www.logitech.com/support/g933
Note: Buttons and volume wheel only operate
in Wireless On mode. Some buttons and features
may require PC connection and Logitech
Gaming Software.
1
2
3
4
5
6
Logitech® G933 Artemis Spectrum
6 English
Inline 3.5mm audio controls
1. Mic select switch (headset boom/inline,
mobile mode only)
• Headset boom unavailable for mobile
device while in Wireless O mode
2. Inline volume wheel
3. Mobile device play/pause/answer call
4. Inline microphone
5. Mobile mic mute switch
Note:
The inline 3.5mm audio control is fully compatible
with Apple devices but may have partial or no
functions with old Android devices.
Please insert the 3.5mm plug nearest the inline
volume wheel into headset, and the far end
into the audio output device (i.e. PC, controller,
mobile, etc.).
2
3
5
4
1
Logitech® G933 Artemis Spectrum
7 English
Battery management
G933 Artemis Spectrum wireless headset
is powered via a battery housed in
the right earcup. When you are not using
your G933 Artemis Spectrum wireless
headset, plug it in via the USB port on the
bottom of the unit to charge. When fully
depleted, the battery takes approximately
3.5 hours to reach full charge on standard
USB output. For the optimal experience,
plug in your unit and allow it to charge fully
before first use.
Logitech Gaming Software
The headset home screen in Logitech
Gaming Software has a battery charge
level indicator:
When using battery, this will indicate
charge level
This indicates the unit is charging
Critical Battery Warning
G933 Artemis Spectrum gaming
headset will play a tone at low charge.
The headset’s lighting will also dim when at
low charge. At critical charge level, the unit
will play a tone and lighting will turn o.
Use USB charging cable to plug in headset
immediately if you hear these tones to
ensure uninterrupted listening or gaming.
Charge indicator
Logitech® G933 Artemis Spectrum
8 English
Idle sleep mode
G933 Artemis Spectrum will go into sleep
mode to conserve battery power when
it has not received an audio signal in
5 minutes.
In idle sleep mode, the unit’s lighting will
turn o, and it will disconnect from the USB
wireless mix adapter.
To wake up your headset from sleep mode,
press any button on the unit.
Your unit will continue to use battery
power at a reduced rate while in idle sleep
mode. If you plan to leave your headset
idle for an extended period of time,
turn o your headset and plug it in via USB
to charge.
On/O tones and lights
When your headset is turned on, it will play
a tone to indicate that your headset has
turned on. The lights will perform a power
on light cycle sequence, then switch to
the currently selected lighting.
When the unit is turned o, lights will
switch to blue and fade out while
it powers down.
Logitech® G933 Artemis Spectrum
9 English
Wireless On/O
G933 has two operation modes,
Wireless On, and Wireless O.
Wireless On
In Wireless On mode, most headset
features are available,
1including custom
sound profiles, RGB lighting, wireless,
and audio mixing. When battery charge
is low, lighting will dim and low battery
notification tone will play. When battery
charge level is critical, lighting will turn o.
Boom mic is available for devices
connected through the on-headset 3.5mm
audio port in this mode. Select between
boom mic and inline mic using switch on
included mobile cable.
Wireless range2
Indoor: 15 meters
Battery life3
No lighting: 12 hours
Default lighting: 8 hours
1 Some features may require Logitech Gaming Software.
2 Range may vary with environmental conditions.
3 Rechargeable batteries have a limited number of charge cycles.
Battery life measured at 50% volume.
ON
Logitech® G933 Artemis Spectrum
10 English
Wireless O (passive mode)
In Wireless O (passive mode),
your headset will operate in passive
unpowered mode. Your headset will play
audio from any device connected through
the 3.5mm input on the headset.
Features that require power,
including 7.1 surround sound,
custom sound profiles, on-headset buttons,
volume wheel operation, and button/
lighting customization functions are not
available in this mode.
Boom mic is not available for devices
connected through the on-headset 3.5mm
audio port in this mode. Select inline mic
using switch on included mobile cable.
This mode can be used to preserve
battery life.
OFF
