Logitech G920 Driving Force Bedienungsanleitung
G920 Driving Force Racing Wheel FAQs 1
G920 Driving Force Racing Wheel - Xbox
INDEX
GETTING STARTED
●User guide
○What’s in the box
○Installation
○Mounting clamps
○Buttons
○Connections and mount points
○Force feedback
○Pedal unit
SPECIFICATIONS
●Product information
●Product dimensions
●General product specifications
●Wheel specifications
●Pedal specifications
FAQs
●The force feedback on my wheel has changed and I can no longer use the center
spring force setting in G HUB to adjust the strength
G920 Driving Force Racing Wheel FAQs 2
●Why don't I feel the center spring on the steering wheel when I tab away or close a
game?
●Troubleshooting G920 for power/connection issues - Xbox
●How to set up your Logitech Wheel G923, G29, G920 on Assetto Corsa Competizione
●Troubleshoot G923/G29/G920 for connection Issues
●Racing Wheel Not Recognized For ACC – Xbox One – SOLUTION
●Device does not appear in G HUB
●G HUB freezes while loading and logo animation loops
●Audio device not recognized
●Create and scan for profiles with Logitech Gaming Software
○Scan for new games
○Create new profiles
●View current profiles in Logitech Gaming Software
●Digital signature error when Logitech Gaming Software is installed on Windows 7
computers
●Blue screen after G920 racing wheel is attached to USB port or G25/G27 is not
recognized
●Import racing wheel profiles using Logitech Gaming Software
○Scan for new games (Automatic)
○Import/Export (Manual)
●Set racing wheel profiles to Persistent or Default using Logitech Gaming Software
○Set a Default Profile
○Set a Persistent Profile
●View racing wheel profiles using Logitech Gaming Software
●G920 racing wheel does not respond when connected to Xbox One
●Create and edit racing wheel profiles using Logitech Gaming Software
○Create a new profile
○Edit an existing profile
○Delete a profile
●Program buttons on the G920 racing wheels with Logitech Gaming Software
○Default Button Layouts
○Customizing Buttons
○Game-Specific Profile Commands
○Command Editor
○Resetting Buttons
●Pedals on the G920 racing wheel do not respond
G920 Driving Force Racing Wheel FAQs 3
●Lock racing wheel profile using Logitech Gaming Software
●Mounting templates for the G920 racing wheel
●Mount and secure the G920 racing wheel using the clamping system
○Wheel Unit
○Pedal Unit
○Cable Management
●Adjust sensitivity on the G920 racing wheels with Logitech Gaming Software
○Steering Sensitivity
○Wheel Operating Range
○Pedal Sensitivity
●Clutch pedal on the G920 racing wheel does not function properly
●Force feedback turns off intermittently on G920 racing wheel
●No force feedback when using the G920 racing wheel on a PC
●Supported gaming console systems for the G920 racing wheel
●Mount and secure the G920 racing wheel using built-in bolt mounting points
○Wheel Unit
○Pedal Unit
○Cable Management
●Supported PC operating systems for the G920 racing wheels
●Optimize pedal face positions on the G920 racing wheel
●Logitech G HUB - FAQs
○About Logitech G Hub
WARRANTY
●Hardware warranty
CONTACT US
●Logitech Support
DOWNLOAD
●G Hub
G920 Driving Force Racing Wheel FAQs 4
GETTING STARTED
USER GUIDE
What’s in the box
1. Racing wheel
2. Pedal unit
3. Power adapter
4. User documentation
Installation
Attach power adapter and USB cables as shown.
Every time your Racing Wheel connects with your system, it will rotate fully to each
side and then to the center to calibrate. Your wheel will be ready once this calibration
is completed.
G920 Driving Force Racing Wheel FAQs 5
Mounting clamps
G920 Driving Force Racing Wheel is
equipped with a built in clamping
system for mounting to a table.
Push down and rotate clamp knobs
to lock or unlock.
Rotate clamp knobs to tighten or
loosen clamps.
NOTE: Clamp extenders should be removed
for attachment to thicker tables.
G920 Driving Force Racing Wheel FAQs 6
Buttons
1. Left bumper
2. Directional pad
3. View button
4. Left stick button
5. Right bumper
6. A, B, X, Y buttons
7. Menu button
8. Right stick button
9. Xbox button
Connections and mount points
1. Mounting clamps
2. Cable management cleat
3. Optional shifter connection
(DB-9 male)
4. USB cable
5. Pedal unit connection (DB-9
female)
6. Power connection
7. Bolt mounting points (uses
M6X1 bolts)
G920 Driving Force Racing Wheel FAQs 7
Optimal cable routing
USB and pedal cables (1, 2) should be
routed through inner channels.
Power and optional shifter cables (3, 4)
should be routed through outer channels.
Cables may be wrapped multiple times
around cable management cleat to take
in slack.
Force feedback
Your Racing Wheel contains dual motors that will provide force feedback with supported
games and systems.
Note: Your racing wheel has an overheat protection circuit safeguard to protect it
under high-temperature operating conditions. In rare instances, force feedback
features may shut down during use while controls continue to operate. If this occurs,
allow the wheel to cool down and power it down by unplugging it. If this occurs frequently,
contact product support.
G920 Driving Force Racing Wheel FAQs 8
Pedal unit
1. Clutch pedal
2. Brake pedal
3. Throttle pedal
4. Textured heel rest
5. Bolt mounting points (uses M6X1
bolts)
6. Patented carpet grip system
7. Carpet grip release clip
Push towards rear or pedal unit
to release
8. Change pedal face position
(requires 2.5mm hex key)
G920 Driving Force Racing Wheel FAQs 9
SPECIFICATIONS
Product Information
Component
Model Number (M/N)
Location
Wheel
W-U0002
Under wheel base
Product Dimensions
Component
Height
Width
Depth
Weight
Wheel
270 mm
(10.63 in)
10.94 mm
(278 in)
260 mm
(10.24 in)
2.25 kg
(4.96 lb)
Pedals
167 mm
(6.57 in)
311 mm
(12.24 in)
428.5 mm
(16.87 in)
3.10 kg
(6.83 lb)
General Product Specifications
Software Support
(at release)
Logitech Gaming Software
OS/Platform Support
(at release)
Windows 7, Windows 8, Windows 8.1, Windows 10
Xbox One
Apps Available
(at release)
N/A
System
Requirements
• Xbox One and games that support Logitech® force feedback
racing wheel.
G920 Driving Force Racing Wheel FAQs 10
System
Requirements
• Windows 10, Windows 8, 8.1, or Windows 7, 150 MB of available
hard disk space, USB port, games that support Logitech® force
feedback racing wheel.
Wheel Specifications
Connection Type
USB (corded)
USB VID_PID
VID_046D&PID_C262 (PC Mode)
USB Protocol
USB 2.0
USB Speed
Full-speed
Indicator Lights (LED)
Power/Status
Wheel Rotation
900 degrees (Max)
AC Adapter
24V 1.75A, Auto Switching
Special Buttons
Directional Pad
X, Y, A, B
LB / RB (Paddles)
LSB / RSB
Xbox
View
Menu
Other Features
Dual-motor force feedback;
helical gearing
Cable Length (USB)
6 ft (1.8 m)
