Looxcie LXHD Bedienungsanleitung

Power Switch

Wi-Fi ON = blinking blue

Power ON = blinking green

Power OFF= no light

Tip: To save power while recording,

turn Wi-Fi off when not using

Looxcie mobile app.

Battery Latch

Slide to release battery

Battery

USB Port

Charge or connect to computer

Microphone

Record Light

Red = Recording

Camera Lens

Record Button

Start & stop recording

Instant Clip Button

Instantly create 30-sec clips

Wi-Fi ON

Power ON

Power OFF

USER MANUAL

Version 1.0

FEATURES

> Full HD recording up to

1080p @30fps or 720p @60fps

> 480p mobile streaming for sharing a live

feed anytime, anywhere

> Simultaneous streaming & recording

> Sleek, hands-free design with a wide

range of mounting options

> Instant sharing over mobile

networks to Facebook and web

> Mobile app for viewﬁnder and controls

> Built-in Wi-Fi connectivity

> Weather-resistant enclosure for use in

virtually any climate

> Low-light sensor for use in dim lighting

> Unique Instant Clip button for creating

“instant replays” of what just happened

> Protective lens ﬁlter

> Rechargeable and replaceable battery

> Supports microSDHC card up to 32GB

(Class 4 type; Card not included)

ACCESSORIES

Looxcie HD features a variety of mounting

accessories for hats, helmets, tripods, bikes,

cars & more.

Click here to shop Looxcie HD accessories.

CHARGE

Fully charge battery before ﬁrst use.

1. Remove rubber rear panel cover. Conﬁrm power switch is

in OFF position (closest to micro-USB port).

2. Plug USB Cable into camera’s micro-USB port.

3. Plug USB Cable into USB port on computer or AC adapter.

(Power switch blinks green.)

4. Power switch turns solid green when fully charged.

5. Replace rubber rear panel cover to ensure weather-resistance.

DOWNLOAD

LOOXCIEDESKTOP UTILITY (compatibility page 6)

Click here to install LooxcieDesktop for ﬁrmware updates

& transfering video to your computer.

1. Download, install & launch LooxcieDesktop on PC or Mac.

2. Slide camera power switch to ON position & connect to

computer via USB cable.

3. Install ﬁrmware updates if available.

4. Select “Manage” to copy or delete video clips & raw video buffer.

Note: To download raw video buffer, ﬁrst copy & delete video clips.

LOOXCIE MOBILE APP (compatibility page 6)

Click here to download Looxcie mobile app for Android or iOS.

1. Download & launch Looxcie app on smartphone or tablet.

2. Setup Looxcie account & follow login steps.

3. Record & stream live video or watch friend & community videos.

Note: To live stream, connect to mobile network (3G or 4G).

BATTERY

1. Align metal prongs on battery & camera.

2. Insert front battery hooks into camera.

3. Close back of battery to lock in place.

4. To release battery, slide battery latch on

rear panel.

Note: Battery is replaceable.

SETUP

MEMORY CARD

1. Memory card is not included.

2. Slide silver slot toward USB port to unlock

and then lift to open (as shown below).

3. Insert card with metal prongs facing down

directly on top of metal prongs in slot.

4. Close slot & slide forward to lock in place.

Make sure card is seated properly.

(Card should lie ﬂat.)

Note: Camera requires Class 4 (or higher)

microSDHC card & supports up to 32GB.

GETTING STARTED

CONNECT

Android

1. Slide camera power switch to Wi-Fi ON

(farthest from micro-USB port).

2. Turn on your smartphone’s or tablet’s Wi-Fi (under Settings).

3. Launch Looxcie mobile app & login or record ofﬂine.

4. Tap red camera button to choose from camera modes.

5. Select your “Looxcie_######” or “LX-HD” from connection options.

6. Follow connections help steps on next screen.

If you are unable to connect after following the steps above,

see troubleshooting section on pages 7 & 8.

iOS

1. Slide camera power switch to Wi-Fi ON

(farthest from micro-USB port).

2. Turn on your smartphone’s or tablet’s Wi-Fi (under Settings).

3. Select your “Looxcie_######” from list of Wi-Fi networks.

4. Launch Looxcie mobile app & login or record ofﬂine.

5. Tap red camera button to choose from camera modes.

6. Select your “Looxcie_######” or “LX-HD” from connection options.

7. Follow connections help steps on next screen.

If you are unable to connect after following the steps above,

see troubleshooting section on pages 7 & 8.

GETTING STARTED

MY VIDEOS – ON CLOUD

View & share your streams.

1. Tap “My Videos” then “On Cloud”.

2. Tap on stream title (iOS) OR option button (Android).

3. Choose actions from the control panel.

Delete: Select to permanently delete stream from cloud.

Stop Sharing: Select to stop sharing stream to viewers.

Add Remove: Select to add or remove viewers.

Share Link: Select to email viewing link to friend.

Post: Select to post viewing link to Facebook.

MY VIDEOS – ON CAMERA

View & share your videos & clips.

> Tap “My Videos” then “On Camera”.

VIDEO – From buffer mode.

1. Tap “My Instant Replay Video” (iOS) OR “Videos”

(Android) to view video loop & create new clips.

2. To create new clip, tap “New Clip”.

3. Select start & end time for clip & add title.

CLIPS – From record mode OR 30- sec instant clips.

1. Tap options button next to clip title.

2. Choose actions from the control panel.

Edit: Select to edit clip title.

Play: Select to play clip.

Download: Select to save clip to your mobile device.

> Create Looxcie account using email or Facebook.

Note: Connect using Facebook to add Facebook friends

as contacts, post automatic status updates & stream live

to Looxcie App for Facebook.

HOME SCREEN

LIVE STREAMS & VIDEOS – VIEWING

1. Choose from community, recent, or friends videos.

2. To view videos, tap on individual thumbnails.

3. To view public videos by category, tap on

“Community Channels” and choose from the options.

HOME SCREEN CONTROLS

My Videos: Select to view & share your streams & videos.

Friends: Select to add friends to invite to your streams.

Camera: Select to stream, record & instant replay.

Help: Select to get more information about Looxcie app.

Settings: Select to access account settings & general info.

LOOXCIE MOBILE APP

iOS shown here.

Android appears

differently.

iOS shown here.

Android appears

differently.

STREAM VIDEO

Broadcast public or invite-only live streams.

1. Tap “Stream” then tap “Public” or “Invite Friends”.

2. Tap “Select” to add viewers to your stream.

3. Add title & choose category for stream.

4. Tap Broadcaster Options button to choose timer.

5. Tap red broadcast button to start streaming.

Note: Tap “Camera” to stream with your smartphone’s

or tablet’s front or back camera.

BROADCAST CONTROLS

Options: Select to edit title & choose light mode.

Invite: Select to invite friends to view your stream.

Broadcast: Select to start & end live streaming.

Viewers: Select to see your stream’s viewer history.

Mute: Select to mute your stream’s audio.

FRIENDS

Add contacts as friends to invite them to view streams.

1. Tap + to add contacts to your Looxcie friends.

2. Add contacts from email, address book & Facebook.

3. Use back button to view friends, sent invitations &

received invitations.

CAMERA

Live stream, record and instant replay.

> Tap red camera button to choose from camera modes.

RECORD VIDEO

Record like a regular HD camcorder.

1. Tap “Record Video”.

2. Choose resolution & light mode.

3. Tap record button in app or on camera to start &

stop recording.

4. To view & share video, tap “My Videos”.

Note: Tap battery symbol to view camera battery %.

BUFFER VIDEO

Record loop video & create “instant replay” clips.

1. Tap “Buffer”.

2. Choose resolution & light mode.

3. Tap on/off switch to start & stop recording.

4. Tap “Instant Clip” in app or instant clip button on

camera to instantly save a clip of last 30 seconds.

5. To view & share video, tap “My Videos”.

Note: Tap battery symbol to view camera battery level.

LOOXCIE MOBILE APP

iOS shown here.

Android may

appear differently.

Broadcaster Options:

Select to choose

broadcast time & start

chat with viewers.

Memory Activity Resolution Record Time Battery Life

32 GB

Stream VGA Up to 1 hr Up to 40 mn

Record

(23 GB)

1080p @ 30fps

720p @ 60fps

720p @ 48fps

720p @ 30fps

Up to 2.5 hr

Up to 3.5 hr

Up to 5 hr

Up to 1 hr

Up to 1.5 hr

Buffer

(9GB)

1080p @ 30fps

720p @ 60fps

720p @ 48fps

720p @ 30fps

Up to 1 hr

Up to 1.5 hr

Up to 2 hr

Up to 1 hr

Up to 1.5 hr

16GB

Stream VGA Up to 30 mn Up to 40 mn

Record

(12 GB)

1080p @ 30fps

720p @ 60fps

720p @ 48fps

720p @ 30fps

Up to 1.25 hr

Up to 2 hr

Up to 2.5 hr

Up to 1 hr

Up to 1.5 hr

Buffer

(4 GB)

1080p @ 30fps

720p @ 60fps

720p @ 48fps

720p @ 30fps

Up to 30 mn

Up to 45 mn

Up to 1 hr

Up to 1.5 hr

8GB

Stream VGA Up to 15 mn Up to 40 mn

Record

(6 GB)

1080p @ 30fps

720p @ 60fps

720p @ 48fps

720p @ 30fps

Up to 45 mn

Up to 1.25 hr

Up to 1.5 hr

Up to 1 hr

Up to 1.5 hr

Buffer

(2 GB)

1080p @ 30fps

720p @ 60fps

720p @ 48fps

720p @ 30fps

Up to 15 mn

Up to 20 mn

Up to 30 mn

Up to 1 hr

Up to 1.5 hr

4GB

Stream VGA Up to 10 mn Up to 40 mn

Record

(3 GB)

1080p @ 30fps

720p @ 60fps

720p @ 48fps

720p @ 30fps

Up to 25 mn

Up to 40 mn

Up to 50 mn

Up to 1 hr

Up to 1.5 hr

Buffer

(1 GB)

1080p @ 30fps

720p @ 60fps

720p @ 48fps

720p @ 30fps

Up to 10 mn

Up to 15 mn

Up to 30 mn

Up to 1 hr

Up to 1.5 hr

CAMERA SPECS

CAMERA BODY

> Weather-resistant enclosure

> Wi-Fi connectivity

> Replaceable 1250mAh lithium polymer battery

> MicroSDHC card slot: minimum class 4,

maximum 32GB

> Micro-USB port for charging battery and

connection to computer

> Dimensions: 1” x 1.25” x 3.75”

(2.6cm x 3.2cm x 9.6cm)

> Weight: 2.6oz (74g)

CAMERA SENSOR & VIDEO

> Selectable video resolution (1080p & 720p)

> Low-light sensor (650 mV/lux-sec)

> Automatic light correction for indoor/outdoor

operation

> High-quality CMOS sensor with 75° FOV

> Clips saved in iTunes-compatible format (mp4)

COMPATIBILITY

SYSTEM REQUIREMENTS

> Looxcie mobile app (free download)

> Smartphone or tablet with Android 2.3.3 or

higher or with iOS 5.0 or higher

> Looxcie desktop application (free download)

> Computer running Mac OS X (10.5 and up) or

Windows XP (32-bit), Windows Vista,

Windows 7, Windows 8

> 1 available USB Port

TECH SPECS

TROUBLESHOOTING

My Looxcie HD is not operating.

> Looxcie HD will NOT be recognized by the computer or

operate without a microSD card properly installed. If a

microSD card is not installed (or not installed properly) the

red record light and the green/blue power switch light will

blink repeatedly. Install (or properly seat) microSD card.

My Looxcie HD is not recognized by my computer when I

try to connect it via USB.

1. Looxcie HD will NOT be recognized by the computer or

operate without a microSD card properly installed. If a

microSD card is not installed (or not installed properly)

the red record light and the green/blue power switch

light will blink repeatedly. Install (or properly seat) mi-

croSD card.

2. With device not connected to your computer, turn the de-

vice “off” for a few seconds, and then turn it “on” and wait

for the device to complete its internal start-up process

(usually takes about 5 seconds).

3. Connect Looxcie HD to your computer from a direct USB

port on your computer (not a USB splitter or hub)

My Looxcie HD won’t connect to my smartphone. I see the

Looxcie HD in my Wi-Fi device list, but it refuses to connect.

> Your Looxcie HD “remembers” the device that it was last

connected to, and won’t let you connect to another device

unless you clear this information from your Looxcie video

cam. See instructions on next page.

TROUBLESHOOTING

POWER ON RECORD OR STREAM

1. Record Light = Red for 2 Sec

2. Power Switch = Blue & Green for 2 Sec

3. Power Switch = Blinks Green every 3 Sec

> Record Light = Red

> Power Switch = Blinks Blue & Green every 3 Sec

Wi-Fi ON CHARGING

1. Power Switch = Blue for 2 Sec

2. Power Switch = Blinks Blue every 3 Sec

1. Power Switch = Blinks Green

2. Power Switch = Solid Green (fully charged)

POWER OFF LOW BATTERY

> Power Switch = Blinks Green 3 times > Power Switch = Blinks Green 2 times every 5 Sec

LIGHT MODES

Wi-Fi ON

Power ON

Power OFF

SUPPORT

Online Support

Click here to email questions to our support team.

U.S. Phone Support

Call: 1-855-LOOXCIE (566-9243) or +1-408-935-2600

Available Monday thru Friday, 9 am to 5 pm Paciﬁc Time

REGISTRATION

Product Registration

to sign up to receive important product notiﬁcations.

Click here to register your product.

or registered trademarks of Looxcie, Inc. US and international

patents pending. Looxcie Model: LXHD

Follow these steps to connect your Looxcie video cam to a

different Android or iOS smartphone or tablet.

Android

1. Hold record button & slide power switch to Wi-Fi ON

(farthest from micro-USB port). Continue holding

button until switch glows green & then blinks blue

every 3 seconds.

2. Turn on smartphone’s or tablet’s Wi-Fi

(under Settings).

iOS

1. Hold instant clip button & slide power switch to

Wi-Fi ON (farthest from micro-USB port). Continue

holding button until switch glows green.

2. Turn on smartphone’s or tablet’s Wi-Fi

(under Settings).

3. Select your “Looxcie_######” from list of

Wi-Fi networks.

My Looxcie HD is not connecting to the Looxcie app.

> If your Looxcie HD was previously paired with another

phone, it will not be able to be paired with a different

phone unless you ﬁrst clear the ownership register on the

video cam device.

> The Looxcie mobile app will not connect if it is conﬁgured

for a different Looxcie model. Please check the settings

screen and ensure that the proper Looxcie model is

conﬁgured.

TROUBLESHOOTING

Andere Handbücher für LXHD

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Looxcie Webcam Handbücher

Looxcie

Looxcie LXHD Bedienungsanleitung

Beliebte Webcam Handbücher anderer Marken

Digitus

Digitus DA-70815 Bedienungsanleitung

Logitech

Logitech C510 Bedienungsanleitung

D-Link

D-Link DCS-5025L Bedienungsanleitung

BTC

BTC PC160S Bedienungsanleitung

Philips

Philips SPC715NC Bedienungsanleitung

Trust

Trust 12440 Bedienungsanleitung

FS FC270S Bedienungsanleitung

Adesso

Adesso CyberTrack V10 Bedienungsanleitung

MAGINON

MAGINON M-Cam 1 Bedienungsanleitung

RoboCam

RoboCam SPARK Bedienungsanleitung

Logitech

Logitech C170 Bedienungsanleitung

Real-El

Real-El FC-225 Bedienungsanleitung

Logitech

Logitech TV Cam Bedienungsanleitung

Gigaware

Gigaware 25-1176 Bedienungsanleitung

birddog

birddog EYES P200 Bedienungsanleitung

Dicota

Dicota Contact Bedienungsanleitung

Afidus

Afidus ATL-200 Bedienungsanleitung

Connectland

Connectland CAM-CNL-C119 Bedienungsanleitung
