Lowell UPS8 Series Leitfaden
UPS8 Series
Pure Sine Wave Line Interactive UPS
Models UPS8-800, UPS8-1100, UPS8-1500, UPS8-2000, UPS8-2200, UPS8-3000
User & Installation Manual
04-08-21
Lowell UPS8 Series Manual
Pg. 2
TABLE of CONTENTS
IMPORTANT SAFETY WARNING.................................................................3
Transportation .............................................................................3
Preparation ...............................................................................3
Installation ................................................................................3
Operation.................................................................................3
Maintenance, Service, Faults ..................................................................4
INSTALLATION & SET UP.......................................................................5
Rear Panel View............................................................................5
Operating Principle..........................................................................5
Install the UPS .............................................................................6
Set Up the UPS ............................................................................8
Battery Replacement .......................................................................10
Battery Kit Assembly .......................................................................12
OPERATION ................................................................................15
Button Operation ..........................................................................15
LCD Panel ...............................................................................15
Audible Alarms............................................................................17
Abbreviations in LCD Display .................................................................17
UPS Setting ..............................................................................18
Operating Mode Descriptions.................................................................21
Fault Reference Codes......................................................................22
Warning Indicators .........................................................................22
TROUBLESHOOTING .........................................................................23
STORAGE & MAINTENANCE...................................................................24
Operation................................................................................24
Storage .................................................................................24
SPECIFICATIONS ............................................................................25
OBTAINING SERVICE .........................................................................26
LIMITED WARRANTY .........................................................................27
APPENDIX A: EXTERNAL BATTERY PACK (Model UPS-XBP-48, UPS-XBP-72) .........................28
Important Safety Instructions .................................................................28
Product Overview & Set Up ..................................................................29
Type of Battery Required ....................................................................31
Battery Replacement .......................................................................31
Wiring Diagrams...........................................................................34
Storage & Maintenance .....................................................................36
Lowell UPS8 Series Manual
Pg. 3
IMPORTANT SAFETY WARNINGS
Please comply with all warnings and operating instructions in this manual strictly. Save this manual properly and read carefully
the following instructions before installing the unit. Do not operate this unit before reading through all safety information and
operating instructions carefully.
Transportation
• Transport the UPS system only in the original package to protect against shock and impact.
Preparation
• Condensation may occur if the UPS system is moved directly from cold to warm environment. The UPS system must be
absolutely dry before being installed. Allow at least two hours for the UPS system to acclimate to the environment.
• Do not install the UPS system near water or in moist environments.
• Do not install the UPS system where it would be exposed to direct sunlight or near heater.
• Do not block ventilation holes in the UPS housing.
Installation
• Do not connect appliances or devices which would overload the UPS system (e.g. laser printers) to the UPS output sockets.
• Place cables in such a way that no one can step on or trip over them.
• Do not connect domestic appliances such as hair dryers to UPS output sockets.
• The UPS can be operated by any individual with no previous experience.
• Connect the UPS system only to an earthed shockproof outlet which must be easily accessible and close to the UPS system.
• Use only VDE-tested, CE-marked mains cable (e.g. the mains cable of your computer) to connect the UPS system to the
building wiring outlet (shockproof outlet).
• Use only VDE-tested, CE-marked power cables to connect the loads to the UPS system.
• When installing the equipment, it should ensure that the sum of the leakage current of the UPS and the connected devices
does not exceed 3.5mA.
• Temperature Rating: Units are considered acceptable for use in a maximum ambient temperature of 104˚F (40˚C) .
• For PLUGGABLE EQUIPMENT, the socket-outlet shall be installed near the equipment and shall be easily accessible.
• Caution—the unit is heavy. Lifting the unit requires a minimum of two people.
• Check if there is a protection device against over current and short circuit in the upstream of the UPS system. The recommended
protection spec is 11A for 800VA/1100VA, 15A for 1500VA, 20A for 2000VA/2200VA, and 30A for 3000VA with a B or C trip
curve.
Operation
• Do not disconnect the mains cable on the UPS system or the building wiring outlet (shockproof socket outlet) during operation
since this would cancel the protective earthing of the UPS system and of all connected loads.
• The UPS system features its own internal current source (batteries). The UPS output sockets or output terminals block may
be electrically live even if the UPS system is not connected to the building wiring outlet.
• In order to fully disconnect the UPS system, rst press the OFF/Enter button to disconnect the mains.
• Prevent uids and other foreign objects from getting inside the UPS system.
• The EPO, RS-232 and USB circuits are an IEC 60950 safety extra low voltage (SELV) circuit. This circuit must be separated
from any hazardous voltage circuits by reinforced insulation.
Lowell UPS8 Series Manual
Pg. 4
Maintenance, Service & Faults
• The UPS system operates with hazardous voltages. Repairs may be carried out only by qualied maintenance personnel.
• Caution—risk of electric shock. Even after the unit is disconnected from the mains (building wiring outlet), components inside
the UPS system are still connected to the battery and electrically live and dangerous.
• Before carrying out any kind of service and/or maintenance, disconnect the batteries and verify that no current is present and
no hazardous voltage exists in the terminals of high capability capacitor such as BUS-capacitors.
• To avoid electrical shock, turn off the unit and unplug it from the AC power source before servicing the battery.
• Only persons who are adequately familiar with batteries and with the required precautionary measures may replace batteries
and supervise operations. Unauthorized persons must be kept well away from the batteries.
• Caution—risk of electric shock. The battery circuit is not isolated from the input voltage. Hazardous voltages may occur
between the battery terminals and the ground. Before touching, please verify that no voltage is present!
• Batteries may cause electric shock and have a high short-circuit current. Please take the precautionary measures specied
below and any other measures necessary when working with batteries:
– Remove wristwatches, rings and other metal objects.
– Use only tools with insulated grips and handles.
• When changing batteries, install the same number and same type of batteries.
• Do not attempt to dispose of batteries by burning them. This could cause battery explosion.
• Do not open or destroy batteries. Escaping electrolyte can cause injury to the skin and eyes. It may be toxic.
• When replacing batteries, replace with the same type and number of batteries or battery packs.
• Do not dismantle the UPS system.
• A battery can present a risk of electrical shock and high short-circuit current. The following precautions should be observed
when working on batteries:
>> Remove watches, rings, and other metal objects.
>> Use tools with insulated handles.
>> Wear rubber gloves and boots.
>> Do not lay tools or metal parts on top of batteries.
>> Disconnect charging source prior to connecting or disconnecting battery terminals.
>> Determine if battery is inadvertently grounded. If inadvertently grounded, remove source from ground. Contact with
any part of a grounded battery can result in electrical shock. The likelihood of such shock can be reduced if such
grounds are removed during installation and maintenance.
Lowell UPS8 Series Manual
Pg. 5
INSTALLATION & SET-UP
NOTE: Inspect the unit before installation. Be sure that nothing inside the package is damaged. Keep the original package in a
safe place for future use.
Rear Panel View
1. Programmable outlets: connect to non-critical loads
2. Output receptacles: connect to mission-critical loads.
3. AC input
4. Input circuit breaker
5. Network/Fax/Modem surge protection
6. Emergency power off function connector (EPO)
7. USB communication port
8. RS-232 communication port
9. SNMP intelligent slot
10.External battery connector
Models UPS8-800, UPS8-1100, UPS8-1500
Models UPS8-2000, UPS8-2200, UPS8-3000
Operating Principle
The operating principle of the UPS is shown below. The UPS is composed of mains input, EMI/RFI lters, inverter, battery
charger, DC-to-DC converter, battery, AVR TX and UPS output.
Lowell UPS8 Series Manual
Pg. 6
Install the UPS
For safety consideration, the UPS is shipped out from the factory without connecting battery wires. Before installing the UPS,
follow these steps to re-connect battery wires.
Connect Battery Wires:
Step 1: Remove front panel.
Step 2: Connect the AC input and re-connect battery wires.
Step 3: Replace front panel.
Lowell UPS8 Series Manual
Pg. 7
Rackmount Installation (with 4-point rail kit):
Step 1: Mount the 4-point rail kit to the rack. Use the (8) 10-32 screws provided to mount left and right support rails (front and
rear).
Step 2: Attach the mounting brackets to the UPS. CAUTION—DO NOT use mounting brackets to lift the UPS; brackets are
only to secure it to the rack.
Step 3: Place UPS on the support rails and secure in place with front screws, allowing the horizontal rails to support the weight
of the UPS.
Tower Installation:
NOTE: When installing the UPS or battery pack with feet, keep 2.75 inches (70mm) distance from the edge of the unit.
Lowell UPS8 Series Manual
Pg. 8
Set Up the UPS
Step 1: UPS Input Connection.
Plug the UPS into a two-pole, three-wire, grounded receptacle only. Avoid using extension cords.
Step 2: UPS Output Connection.
There are two kinds of outputs: programmable outlets and general outlets. Connect non-critical devices to the programmable
outlets and critical devices to the general outlets. During power failure, you may extend the backup time to critical devices by
setting shorter backup time for non-critical devices.
Step 3: Communication Connection.
Communication ports:
• USB Port or RS-232 Port:To allow for unattended UPS shutdown/start-up and status monitoring, connect the communication
cable, one end to the USB/RS-232 port and the other to the communication port of your PC. With the monitoring software
installed, you can schedule UPS shutdown/start-up and monitor UPS status through the PC.
NOTE: USB port and RS-232 port can’t work at the same time.
• Intelligent Slot: The UPS is equipped with an intelligent slot ideal for either an SNMP or Dry Contact/Relay card. When
installing either an SNMP or Dry Contact/Relay card in the UPS, it will provide advanced communication and monitoring
options.
Step 4: Surge Protection.
Connect a single modem/phone/fax line into surge-protected “IN” outlet on the back panel of the UPS unit. Connect from “OUT”
outlet to the equipment with another modem/fax/phone line cable.
Step 5: Disable and Enable EPO Function.
Keep the pin 1 and pin 2 closed for UPS normal operation. To activate EPO function, cut the wire between pin 1 and pin 2.
Fax/Phone Surge Port
It’s in closed status for UPS normal operation.
Lowell UPS8 Series Manual
Pg. 9
Step 6: External Battery Connection.
Connect one end of external battery cable to UPS unit and the other end to battery box. Use supplied battery connection wire
in connection port of UPS unit and plug the other end to battery bank.
CAUTION: Connection to External Battery shall be installed by SERVICE PERSONNEL only.
NOTE: External battery boxes can only be connected to one (1) UPS.
Step 7: Turn the UPS on.
Press the ON/Mute button on the front panel for two seconds to power on the UPS.
NOTE: The battery charges fully during the rst ve hours of normal operation. Do not expect full battery run capability during
this initial charge period.
Step 8: Install software.
For optimal computer system protection, install UPS monitoring software to fully congure UPS shutdown. Follow steps below
to download and install monitoring software:
1. Go to the website http://www.power-software-download.com
2. Click ViewPower software icon and then choose your required OS to download the software.
3. Follow the on-screen instructions to install the software.
4. When your computer restarts, the monitoring software will appear as an orange plug icon located in the system tray, near
the clock.
Lowell UPS8 Series Manual
Pg. 10
Battery Replacement
NOTICE: This UPS is equipped with internal batteries and only service personnel can replace the batteries.
CAUTION! Consider all warnings, cautions, and notes before replacing batteries.
Note: Upon battery disconnection, equipment is not protected from power outages.
Step 1: Remove front panel.
Step 2: Disconnect battery wires.
Step 3: Pull the battery box out by removing two screws on the front panel.
Step 4: Remove the top cover of battery box and replace the inside batteries.
Dieses Handbuch passt für folgende Modelle
6
Inhaltsverzeichnis
Andere Lowell UPS Handbücher
Beliebte UPS Handbücher anderer Marken
Pylontech
Pylontech Victron & Pylontech US5000 Bedienungsanleitung
Tecnoware
Tecnoware EVO DSP PLUS MM 6.8 Bedienungsanleitung
Mecer
Mecer ME-1000-WTU Bedienungsanleitung
Mustek
Mustek PowerMust 530(B) Plus Installations- und Betriebshandbuch
Emerson
Emerson Liebert NXL series Bedienungsanleitung
MAKELSAN
MAKELSAN BOXER SERIES Bedienungsanleitung
