ABuilding Safety. Building Security.

Thermal Max Detector

FC600/TMAX/78

• Addressable conventional technology

• Individual detector identiﬁ cation with

optional address module

• Alarm temperature 78°C

• Allows for connection of external

remote indicator

• Anti-tamper locking feature on

detector base

• Function check by means of test

magnet

Description

Speciﬁ cations

The Thermal Max Detector FC600/TMAX/78 recogni-

ses a temperature of 78°C as alarm threshold and is

compliant to EN 54 -5 (class BS) standards. It can be

used in rooms with a height of up to 6m. Any alarm

will be transmitted to the ﬁ re detection panel in con-

ventional technology. An individual detector identiﬁ ca-

tion can be obtained with the optional Address Module

NG58-1.

The detector is equipped with an LED indicator which

is visible from all sides at any angle and thus facilitates

easy identiﬁ cation of the alarming detector. In addition,

a remote indicator can also be connected.

Several types of detector bases are available to faci-

litate quick and easy installation. To prevent unautho-

rized removal of the detector, all detector bases are

equipped with an anti-tamper locking feature. A de-

tector function test can be conveniently conducted by

using a test magnet.

Operating voltage 10 – 30VDC (supply through detector line voltage)

Current consumption typ. 40µA (normal condition)

Alarm temperature 78°C

Operating temperature max. +60°C

Ambient temperature -30°C to +70°C (continuous operation)

Relative humidity max. 95% (no condensation)

Dimensions ø × h (without base) 106 × 46 (mm)

Colour white

Weight 80g

Approvals LPCB 603b/01

0832-CPD-0126

Order number 242071

Order name Thermal Max Detector/Conv./FC600 FC600/TMAX/78
