LTE GE864T-GPS Installationshandbuch

GE864T-GPS

Hardware User Guide

Rev01 - 10.06.2013

Mustafa Kemal Mah. 2131 Sok. No: 32/2 06510 Söğütözü, Çankaya, ANKARA /TURKIYE

Tel: +90 (312) 443 03 04 - Faks: +90 (312) 443 09 69

Contents

1Descripon ……………………………………………………………………………………………….… 3

2General Features ………………………………………………………………………………………… 4

3Power …………………………………………………………………………………………………………. 5

4Serial Port ………………………………………………………………………………………………..…. 5

5Digital I/O & ADC …………………..………………………………………………………………….… 6

6Antenna ………………………………………………………………………………………………….…… 6

7Debug GPS Port …….…………….……………………………………………………………………… 7

8Analog Audio ……………………………………………………………………………………………… 7

Mustafa Kemal Mah. 2131 Sok. No: 32/2 06510 Söğütözü, Çankaya, ANKARA /TURKIYE

Tel: +90 (312) 443 03 04 - Faks: +90 (312) 443 09 69

1Descripon

GE864T-GPS GSM/GPRS/GPS terminal is the new generaon based on the Quad-Band

and RoHS comliant GE864 core engine incorporang addional and new features.

The GE864T-GPS featuring the embedded Python™ script interpreter provides the possibi-

lity for running customer programs inside the modem, thus making the terminal a comp-

lete self-contained applicaon plaorm for customer soluons. Programmable I/O port,

RS232 port and Serial Second GPS Port can be used for monitoring external signals, con-

necng sensors, and switching external devices. The GE864T-GPS oers jamming detec-

on funconality allowing the unit to sense aempts to disrupt the GSM communicaon

by interference with the GSM signal.

GE864T-GPS oers extended operang temperature, integrated TCP/IP stack,direct cont-

rol by standard serial RS-232 interface and with a broad supply voltage range (5-32 VDC -

Min1.2A), the GE864T-GPS terminal is a complete stand alone soluon for m2m applica-

ons.

GE864T-GPS Terminal is integrang full 48-channels A-GPS funconality. It combines the

high performance from Telit's proven GSM/GPRS core technology with the latest

SiRFstarIV™ high sensivity single-chip A-GPS receiver.

GE864T-GPS, supports Over-the-Air rmware update by means Premium FOTA Manage-

ment. By embedding RedBend’s vCurrent® agent, a proven and bale-tested technology

powering hundreds of millions of cellular handsets world-wide is able to updateits pro-

ducts by transming only a delta le, which represents the dierence between one

rmware version and another.

Mustafa Kemal Mah. 2131 Sok. No: 32/2 06510 Söğütözü, Çankaya, ANKARA /TURKIYE

Tel: +90 (312) 443 03 04 - Faks: +90 (312) 443 09 69

2General Features

* Quad-band EGSM 850/ 900 / 1800 /1900 MHz,

* Embedded Python Version 1.5.2 ,

* Serial Debug GPS Port (Also 5.0V Fixed Voltage Output),

* RS232 ınterface (DB9-Female),

* Analog Audio Support (2.5mm jack, Mono-Mic & Mono-Ear),

* 2 Digital Inputs, 2 Digital Outputs and 2 ADC Connecons on GPIO socket,

* Dimensions: 85 x 70 x 33 mm,

* Weight: 140 grams,

* SMA female, 50 Ohm GSM RF connector,

* SMA female, 50 Ohm GPS RF connector,

* Power Socket (PWR, GND, RST),

* On board SIM card holder(Push-Push Type),

* Oponal WatchDog Timer with MCU(PIC12F675) controller.

Mustafa Kemal Mah. 2131 Sok. No: 32/2 06510 Söğütözü, Çankaya, ANKARA /TURKIYE

Tel: +90 (312) 443 03 04 - Faks: +90 (312) 443 09 69

3Power

4Serial Port

Mustafa Kemal Mah. 2131 Sok. No: 32/2 06510 Söğütözü, Çankaya, ANKARA /TURKIYE

Tel: +90 (312) 443 03 04 - Faks: +90 (312) 443 09 69

Front View

Pin Descriptions:

* GND: Ground Reference

* Input Power: 7-35V @ 1.2A min.

* Reset: Acve when Pulls Down to GND

Power Connector

The RS-232 port is available through D-TYPE 9

pin connector

The main characteriscs are:

* Baud rate from 300 to 115,200 bits/s

* Autobauding (300 to 38,400 bits/s)

* Short circuit (to Ground) protecon on all

outputs.

* Input voltage range : -12V to +12V

To connect to a PC a pin to pin, 9 pin cable

needed with D type connectors (male & fema-

le) on both sides.

Pin out (refers to DTE side):

Pin 1 = DCD Output

Pin 2 = RX Output

Pin 3 = TX Input

Pin 4 = DTR Input

Pin 5 = Ground

Pin 6 = DSR Output

Pin 7 = RTS Input

Pin 8 = CTS Output

Pin 9 = RI Output

5Digital I/O & ADC

6Antenna

Mustafa Kemal Mah. 2131 Sok. No: 32/2 06510 Söğütözü, Çankaya, ANKARA /TURKIYE

Tel: +90 (312) 443 03 04 - Faks: +90 (312) 443 09 69

Front View

I/O Connector

The I/O port is available

through 2x6 pin connector

The Main Characteriscs are:

* 2 Digital Inputs (0-220VDC),

* 2 Digital Open-Collector

Outputs,

* 2 ADC Inputs (0-2V)

GSM ANTENNA REQUIREMENTS

Frequency range Standard Dual Band GSM/DCS frequency range or Standard Quad Band

GSM/DCS/PCS frequency range if used for all four bands

Bandwidth 70 MHz in GSM850, 80 MHz in GSM & 170 MHz in DCS & 140 MHz PCS

band

Gain Gain < 3dBi

Impedance 50 ohm

Input power > 2 W peak power

VSWR absolute max <= 10:1

VSWR recommended <= 2:1

Note:

The antenna(s) used for this transmier must be installed to provide a separaon

distance of at least 20 cm from all persons and must not be co-located or operang

in conjuncon with any other antenna or transmier.

Input1—>GPIO8 Output1—>GPIO6

Input2 —>GPIO9 Output2—>GPIO3

7Debug Port

8Analog Audio

Mustafa Kemal Mah. 2131 Sok. No: 32/2 06510 Söğütözü, Çankaya, ANKARA /TURKIYE

Tel: +90 (312) 443 03 04 - Faks: +90 (312) 443 09 69

Front View

NMEA GPS Serial Port Connector

The Debug port is available

through 1x4 pin connector

The Main Characteriscs are:

* 5V Fixed Output,

* 5V Level Second Serial Port

(GPS_TX_AUX & GPS_RX_AUX)

2.5mm Audio Connector

The Main Characteriscs are:

* Headset Connecon including MIC

and EAR,

* Compable with 2.5mm 3 channel

receptacle headset jack

Document Change Log

Mustafa Kemal Mah. 2131 Sok. No: 32/2 06510 Söğütözü, Çankaya, ANKARA /TURKIYE

Tel: +90 (312) 443 03 04 - Faks: +90 (312) 443 09 69

Revision Date Changes

Rev02 07.07.2014 GPS Serial Debug NMEA

port added

Rev03 02.09.2015 GPIO Description added
