Lumishore Eclipse SMX93 Bedienungsanleitung

| + 44(0)208 144 1694 | Info@Lumishore.com

Lumishore USA 7137 24TH Court East Sarasota, Florida 34234 | (941) 405-3302 | Sales@LumishoreUSA.com

Lumishore UK, Unit D12, Upper Fforest Way, Swansea Enterprise Park, Swansea, SA6 8QR

45-0204-Rev1

Voltage

10-31V DC

Color Output

Color change

Please read the following pages before attempting installation to ensure complete understanding of

Lumishore ECLIPSE SMX93. This product should only be installed, inspected, and maintained by a qualied

electrician only, in accordance with all applicable electrical codes. Be certain electrical power is OFF before

and during installation and maintenance.

Before you start:

• Always ensure that the vessel’s power source and baery are disconnected or isolated prior to installaon.

• A qualied professional should carry out both the electrical and mechanical installaon.

• For best underwater illuminaon, LUMISHORE recommends installaon 4” to 12” (100-300mm) below the

minimum load water line.

• Choose a locaon - The light must be mounted on a at (not curved) surface. For underwater installs mount

on transom or side hull only.

• A hole will be drilled to allow the cable to be inserted; care must be taken to ensure there is unrestricted

access inside the hull.

• When installing three or more lights, equal spacing 2.5’- 3’ is recommended to give a consistent light pool.

• The light is temperature sensive and must not be located close to the exhaust outlet or other heat source.

• SMX93 Lights operate on 12V or 24V DC. Never connect a light directly to the mains AC voltage, or DC voltage

other than that specied.

• For Installaon on boats up to 7.5m (25 ). Isolaon kit (39-0203) MUST be used on boats with conducve

hulls.

eclipse SMX93 Color Select Installation Manual

60-0315 - SMX93 - Color Select

| + 44(0)208 144 1694 | Info@Lumishore.com

Lumishore USA 7137 24TH Court East Sarasota, Florida 34234 | (941) 405-3302 | Sales@LumishoreUSA.com

Lumishore UK, Unit D12, Upper Fforest Way, Swansea Enterprise Park, Swansea, SA6 8QR

Mechanical installaon

Tools: Drill, drill bits, marine sealant (3M 4200, or equivalent),F2 Frearson type screwdriver, Flat head screw

driver, cloth for clean-up:

Pilot Hole for Screws - 9/64” / 3.5mm

Hole for Cable - 9/32” / 7mm

Recess for Gland - 17/32” / 13.5mm hole to a depth of 5/8” / 15mm

1. Select a suitable at surface that is accessible from behind and ensure the cable can be run without a

problem.

2. With one hole at the boom center, mark and drill the pilot holes for the screws & drill a ø4mm

counter bore to a depth of 5mm in each locaon. Drill the power cable hole. The cable hole must be

recessed on the outside of the hull to accept the cable gland on the back of the light, so that the lights

sits ush.

Note: Cored hulls must be sealed prior to ng the lights - refer to the manufacturers instrucons.

3. Clean and prepare the hull ready for the sealant.

Rear side

Basic Dimensions

Apply sealant

Boom center

70 mm (2.75in)

17mm (0.67in)

12mm

(0.47in)

PCD 61mm

(2.40in)

120°

| + 44(0)208 144 1694 | Info@Lumishore.com

Lumishore USA 7137 24TH Court East Sarasota, Florida 34234 | (941) 405-3302 | Sales@LumishoreUSA.com

Lumishore UK, Unit D12, Upper Fforest Way, Swansea Enterprise Park, Swansea, SA6 8QR

4. Apply a connuous thick bead of sealant to the back of the light, making sure the recess on the outer

edge is slightly overlled. Also apply a bead of sealant around the cable gland. Refer to image above.

5. Push the power cable through the hole and align the light with the pilot hole screws.

6. Aach the light using the 3 supplied screws by hand ghtening with a screwdriver.

IMPORTANT: Do not over ghten. Do not use power tools to ghten screws.

7. Use a damp cloth to wipe o excess sealant that has squeezed out around the light. DO NOT use

chemical cleaners or solvents.

IMPORTANT: Refer to the direcons on the sealant to make sure it has fully cured before

launching the boat into the water.

| + 44(0)208 144 1694 | Info@Lumishore.com

Lumishore USA 7137 24TH Court East Sarasota, Florida 34234 | (941) 405-3302 | Sales@LumishoreUSA.com

Lumishore UK, Unit D12, Upper Fforest Way, Swansea Enterprise Park, Swansea, SA6 8QR

Installaon diagram - Single switch

Plan the cable route prior to installaon. Ensure all cables are suitable for marine applicaons, and

correctly rated for the required voltage and current. Each light must be individually fused. The cable

connecons are:

Red 12V or 24V DC

Black Ground

Fuse rangs: 12V DC 4A

24V DC 3A

An ON / OFF switch should be installed to select the modes of operaon. All connecons must be made

waterproof.

Fuse or

Circui t

Breaker

Batter y

Red

(+VDC)

Red

(+VDC)

Black

(GND)

Fuse

Switch

Use correct cable gauge -

consult ABYC recomendations

for MAX 3% voltage drop

| + 44(0)208 144 1694 | Info@Lumishore.com

Lumishore USA 7137 24TH Court East Sarasota, Florida 34234 | (941) 405-3302 | Sales@LumishoreUSA.com

Lumishore UK, Unit D12, Upper Fforest Way, Swansea Enterprise Park, Swansea, SA6 8QR

Switch operaon

The lights operate in a preset color cycle, always starng in white, The lights then go into a color cycle. The

lights can be paused on any color in the cycle. To do this turn the switch OFF / ON (wait a second before

switching back on). Switch OFF / ON to restart the color cycle. To reset to white, switch the lights o for 5

seconds, and then back on.

O/On to Pause

O/On to Resume

Installaon Diagram - Eclipse Command Center

Note: For full ECLIPSE Command Center control consult ECLIPSE Command Center installaon manual

Cut the cable just below the

heat shrink. Remove the outer

insula�on to reveal the yellow

wire

Before connuing ensure the Yellow wire from the light has been exposed (see below)

| + 44(0)208 144 1694 | Info@Lumishore.com

Lumishore USA 7137 24TH Court East Sarasota, Florida 34234 | (941) 405-3302 | Sales@LumishoreUSA.com

Lumishore UK, Unit D12, Upper Fforest Way, Swansea Enterprise Park, Swansea, SA6 8QR

Up to 2 lights per Command Center

RED

BLK

YEL

RED

WHT

BLU

YEL

RED

BLK

YEL

ECLIPSE Command Center

CONNECT AS BELOW;

ECLIPSE cable harness RED to SMX93 RED

ECLIPSE cable harness YEL to SMX93 YEL

ECLIPSE cable harness WHT & BLU to SMX93 BLK

ECLIPSE Cable

Harness

10 - 15V

Select and install appropriate

blade fuse for complete circuit

Electrical installaon - ECLIPSE Command Center

Important! The ECLIPSE Command Center

installation is suitable for 12V boats ONLY.

More than 2 lights per Command Center

YEL YEL YEL YEL YEL

RED to +10 - 31V

Fuse Fuse Fuse Fuse Fuse

RED to +10 - 31V RED to +10 - 31V RED to +10 - 31V RED to +10 - 31V

BLK to GND BLK to GND BLK to GND BLK to GND BLK to GND

ECLIPSE Command Center

CONNECT AS BELOW;

ECLIPSE cable harness YEL to SMX93 YEL

SMX93 RED to +10-31V (Individually fused)

SMX93 BLK to GND

ECLIPSE Cable

Harness

RED, WHT & BLU - No connect.

Ensure any unused wires are isolated.

| + 44(0)208 144 1694 | Info@Lumishore.com

Lumishore USA 7137 24TH Court East Sarasota, Florida 34234 | (941) 405-3302 | Sales@LumishoreUSA.com

Lumishore UK, Unit D12, Upper Fforest Way, Swansea Enterprise Park, Swansea, SA6 8QR

Cleaning and maintenance

LUMISHORE lights require simple cleaning. Lights should be checked oen to ensure the light body and lens

area are free from sea growth. In the event that your light requires cleaning, we recommend the use of a

so cloth or so bristled brush.

• DO NOT use any abrasive cleaning materials as these may damage the body of the light.

• DO NOT use any cleaning uids that contain solvents, acids or alkali’s.

• DO NOT clean using pressure washing or sandblasng equipment.

Slight discoloraon of body may occur over life. This does not aect performance, and is not subject to

warranty.

Due to nature and high build quality it may on rare occasions be possible to see small levels of condensa-

on, this is normal for high power LEDs and will disappear aer cooling and does not harm operaon in any

way.

If the lens of the light is covered for any reason, e.g. maintenance, or painng DO NOT switch the lights on

unl the covers are removed.

Warranty

LUMISHORE Ltd warrants the SMX93 to be free from defects in workmanship and materials for a period of

two years, starng from the date of original purchase. Misuse, abuse, improper installaon, neglect, im-

proper shipping, damage caused by disasters such as re, ood, and lightning, installaon by unqualied

personnel, unauthorized repair or modicaon will void this warranty. For the avoidance of confusion and

doubt, non-compliance with all installaon, maintenance and operang instrucons in this document con-

stute non-conformance with warranty terms.
