PSP711RF REMOTE
INSTRUCTIONS
LUX PRODUCTS CORPORATION • Mt. Laurel, New Jersey 08054, USA • www.luxproproducts.com
WARNING: Use Energizer®or DURACELL®Alkaline Batteries Only.
Energizer®is a registered trademark of Eveready Battery Company, Inc.
DURACELL®is a registered trademark of The Gillette Company, Inc.
1. GENERAL INFORMATION
The wall plate of your thermostat houses the unit’s receiver, antenna, and its’
batteries. The remote transmitter and its batteries are housed in its own
hand-held enclosure.
2. BATTERIES
Your RF remote receiver and transmitter each require two AA Alkaline batteries in
addition to the thermostats two AA batteries.
2.1. Remote Batteries: Replace/Install
Replace transmitter batteries at least every 12 months with two Energizer®
or Duracell®AA Alkaline batteries.
1. Remove fresh batteries from their carton.
2. The battery cover of your remote is on its rear. To gain access to your
remote’s batteries, place your thumb over the triangle on the battery cover and
slide it off in the direction that the triangle points.
3. Remove the used batteries if present and replace them with two new “AA”
size Energizer®or Duracell®alkaline batteries. Observe the polarity marking
shown in the battery compartment.
4. Replace the battery cover.
2.2. RF Remote Receiver Batteries: Replace/Install
Replace receiver batteries at least every 6 months with two Energizer®or Duracell®
AA Alkaline batteries.
1. Remove fresh batteries from their carton.
2. To gain access to your receiver’s batteries, remove the thermostat body from
the wall plate as described in the installation section of your thermostat’s primary
manual. The receiver’s batteries are visible on the left side of the wall plate.
3. Remove the used batteries if present and replace them within 90 seconds to
avoid having to reinitialize your receiver’s security code. Use two new “AA” size
Energizer®or Duracell®alkaline batteries. Observe the polarity marking shown in
the compartment.
4. Place the thermostat body back on the wall.
3. ENABLING (AND DISABLING) YOUR REMOTE WITH LEARN MODE
1. With the body of the thermostat removed from its wall plate, press and hold the
recessed LEARN CODE switch with a small Phillips screwdriver until the LED
above illuminates.
2. Press and release any button on the remote.
3. Wait until the LED is extinguished.
4. Replace the thermostat on its wall plate.
5. Your thermostat should now respond to remote commands within a few
seconds of each button press.
Skipping step 2 in the above procedure will disable the remote.
3.1. Change Transmitter Security Code.
If you are using more than one RF transmitter unit in your home, and one responds
to commands from the other, then you will need to change the security code of one
unit.
To do this:
1. Remove the transmitter batteries from their compartment. See 2.2
2. Find the ID selector at the inside top of the battery compartment. It is a three
position slide switch. You may slide it left, right, or center position. Each sets a
different ID code.
3. Replace the batteries and their cover.
4. Follow the instructions under Enabling (and Disabling) Your Remote With Learn
Mode.
WARNING: Use Energizer®or DURACELL®Alkaline Batteries Only.
Cancel
Temperature
Control
+
-
43373
4. USING YOUR REMOTE
The UP/DOWN arrow keys function like those on the thermostat itself, though
there will be a short delay before your thermostat responds.
●
Press and release the UP button to raise the temperature of the current mode
by one degree. If your thermostat was in Run Mode and you have changed the
temperature setting from its programmed value, then your thermostat will change
to Override Mode. If your thermostat had already been in Override Mode, and you
returned the setting to its programmed temperature, then the Override will be
canceled, and the unit will return to Run.
●
Press and release the DOWN button to lower the temperature of the current
mode by one degree. If your thermostat was in Run Mode, and you have changed
the temperature setting from its programmed value, then your thermostat will then
be in Override Mode. If your thermostat had already been in Override Mode, and
you returned the setting to its programmed temperature, then the Override will be
canceled, and the unit will return to Run.
●
Press and release the Cancel button to allow your thermostat to control
temperature at its program settings. If your thermostat had been in Override
mode, that Override will be cancelled. If your thermostat is in Hold Mode, then
pressing cancel changes the set temperature to its current program value, but it
does not cancel the Hold Mode.
5. FCC COMPLIANCE
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following
measures:
●
Reorient or relocate the receiving antenna.
●
Increase the separation between the equipment and receiver.
●
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
●
Consult the dealer or an experienced radio/TV technician for help.
LUX Products Corporation
●
6000 I Commerce Parkway
●
Mt. Laurel, NJ 08054
856-234-8803
●
www.luxproproducts.com
IC: 4970A-TX9000TX
IC: 4970A-TX9000RX
6. TRANSMITTER SPECS
●
EIRP power: less than 1mW
●
Radio frequency range: 315MHz ± 150kHz
●
Modulation method: OOK
●
Maximum range: approx. 150ft.
LEARN
CODE
YOGWBRHRC
Recessed LEARN CODE Switch
Remote Control (Cover and Batteries Removed)
Code Switch
Positions
Slide Switch
123
