3 Year Warranty
6 Year Pro-Rata Battery Warranty
LVS Inc., warrants to the original purchaser/user for the published warranty period from the date of shipment that should LVS
instruments or equipment prove defective by reason of improper workmanship or material, LVS will repair or replace the same
equipment without charge. This warranty does not cover defects or malfunctions arising from improper installation, operation or
repair, or neglect, accident or abuse. LVS will honor its warranty provided the equipment has not been physically damaged or
improperly installed or connected. To obtain warranty/repair, the defective product should be shipped freight prepaid within the
warranty period to the address below. To the extent permitted by applicable law, all warranties extending beyond repair or
replacement as described above are disclaimed, including the implied warranties of merchantability and fitness for a particular
purpose. Where applicable law prohibits disclaimers or the implied warranties of merchantability and fitness; those warranties
are limited to 12 months from date of shipment. LVS does provide a 90 day money back guarantee if equipment does not
perform in accordance with LVS published specifications. The liability of LVS and its agents under all warranties is limited to
repair and replacement as described herein, and under no circumstances shall there be liability for any other kind of loss,
damage, or labor, either consequential or for injury to person or property or otherwise.
Batteries are supplied on a pro-rata basis for six years, provided that the product
has been properly installed in the correct surroundings.
TEMPORARY STORAGE INSTRUCTIONS:
For temporary storage of CEPS-A system and batteries prior to installation select a clean, cool, dry location with
normal ventilation suitible for human habitation and level floors. DO NOT store system or batteries in a sealed room
or container. Ensure that floor is cabable of bearing load.
Do not store batteries for more than 60 days without charging. Doing so will cause irreversible damage to battery
cells and void battery warranty. Ensure batteries are stored at temperatures within the following range: 40ºF to 100ºF.
Panel Location
1. Panel should be installed in a ventilated indoor location and not subjected to temperatures above 100 °F
(37.8 °C) nor below 40 °F (4.5 °C) and at an altitude of less than 10,000 feet for optimum performance.
2. When the panel is installed on the wall, the wall must have sufficient strength to support the weight of the
panel. A minimum of 4 screws (#10) should be securely fastened in wood or concrete with plastic
inserts to secure the panel. 500W: 160 lbs (4+ screws recommended)
1000W: 240 lbs (4+ screws recommended)
1500W: 350 lbs (6+ screws recommended)
2000W: 440 lbs (8+ screws recommended)
3. Remove 2 or 3 knockouts from the top of the panel.
4. Install utility input conduit and wire from a dedicated circuit breaker, 120VAC 60 Hz or 277VAC 60 Hz, such
as provided for a fire alarm or security system.
Note: 20A breaker recommended, except for 2000W, 120V system: 25A recommended.
5. Install emergency output conduit and wire to load.
6. When you receive the panel, there may be cardboard or foam protection on front panel to protect test
switch. This should be removed after the panel has been securely mounted.
