Lynx QB SERIES Bedienungsanleitung
A culture of sound
Product Guide
www.lynxproaudio.com
4
QB SERIES
The QB series comprises 2 two-way, passive full range cabinets and 2 sub basses,
is the smallest series Lynx Pro Audio oers and is designed and intended for back
ground sound reinforcement where the power of the HR series is not required.
The components have been carefully selected to oer a lightweight, versatile series,
delivering a linear phase response with excellent sound distribution and delity for
background installations in bars, restaurants, conferences etc
Both QB Series Full Range cabinets are supplied with high frequency OCPP
protection (Over Current Passive protection) whilst the Sub-bass models come
with SWR (Stationary Wave Reduction) to reduce internal stationary waves.
All the cabinets are nished in rugged, premium birch plywood, coated with water-
based black paint with the QB-5 and QB-8 protected by front steel grilles all backed
with a special dark grey triple layer, acoustical textile which allows greater air ow
and reduces heat and humidity.
www.lynxproaudio.com 5
Accessories
QB-8
QB-5
Ultra-compact, full range,
two way passive cabinet
for background sound
reinforcement.
It consists of a 5” transducer
and a 1” high frequency
neodymium tweeter.
It oers 90ºconic dispersion
and 113 dB SPL peak (160W
program).
High performance, ultra-
compact, full range, two
way passive cabinet.
It consists of a 8” transducer
and a 1” high frequency
tweeter.
It o ers 90º conic
dispersion and 120 dB SPL
peak (300W program).
LF 1 x 5″ transducer / HF 1 x 1″ tweeter Components LF 1 x 8″ transducer /HF 1 x 1″ tweeter
65 Hz – 20 KHz (-10 dB) Frequency range 50 Hz – 22 KHz (-10 dB)
75 Hz – 18 KHz± 3 dB Frequency Response 60 Hz – 20 KHz± 3 dB
88 dB (1W @ 1m) Sensitivity 92 dB (1W @ 1m)
107 dB - 113 dB peak Max. SPL 114 dB - 120 dB peak
80 W (160 W program, 320 W peak) Rated Power AES 150 W (300 W program, 600 W peak)
90ºH x 90ºV Coverage angle 90ºH x 90ºV
16 Ohm Impedance 8 Ohm
2 x Neutrik Speakon NL4MP Input Connectors 2 x Neutrik Speakon NL4MP
10mm DM Material 15mm Premium birch plywood
High resistant water-based black paint. black steel grill
with acoustic fabric protection Finish High resistant water-based black paint. black steel grill
with acoustic fabric protection
254 x 172 x 186 mm Dimensions 450 x 277 x 275 mm (H x W x D)
3 kg (6.6 lbs) Weight 8.5 kg (18.7 lbs)
WB-01
for QB-5
SB-02
Stand
AGR-6
Eye bolt
TU-C01
connecting pole
TU-C02
M20 pole
WB-02
Wall bracket
VSM-V1
Top hat
TV-50
Clamp truss
TV-35
35mm adaptor
WB-03
Wall bracket
Specs
Accessories
Specs
www.lynxproaudio.com
6
SUB-08 DR-N12
Extremelly compact, high power, passive sub-bass cabinet with
one 12” low frequency transducer with rubber surround in direct
radiation conguration. 130 dB SPL peak (2000W Program).
Ultra-compact double band pass, passive sub woofer with one 8”
transducer with double independent coil and rubber suspension.
122 dB SPL peak (400W program).
LF 1 x 8″ transducer (2 x 50mm voice coil) Components LF 1 x 12″ transducer
43 Hz – 160 Hz (-10 dB) Frequency range 34 Hz – 400 Hz (-10 dB)
47 Hz – 154 Hz ± 3 dB Frequency Response 39 Hz – 220 Hz± 3 dB
93 dB (1W @ 1m) Sensitivity 94 dB (1W @ 1m)
116 dB - 122 dB peak Max. SPL 124 dB - 130 dB SPL peak
200 W (400 W program, 800 W peak) Rated power AES 1000 W (2000 W program, 4000 W peak)
Omnidirectional Coverage angle Omnidirectional
2 x 8 Ohm Impedance 8 Ohm
2 x Neutrik Speakon NL4MP Input Connectors 2 x Neutrik Speakon NL4MP
15mm Premium birch plywood Material 18mm Premium birch plywood
High resistant water-based black paint Finish High resistant water-based black paint. black steel grill
with acoustic fabric protection
268 x 641 x 304 mm Dimensions (H x W x D) 415 x 590 x 370 mm
9 kg (20 lbs) Weight 28 kg (62 lbs)
TU-C01
connecting pole
TU-C02
M20 pole
VSM-V2
pole support
www.lynxproaudio.com 7
www.lynxproaudio.com 8
The technical specications described in this catalogue can vary without previous notication.
