153.743UK User Manual
Pairing the RF remote control handset
Each controller is supplied with an RF handheld remote control that has been uniquely coded to work with the controller.
In some circumstances, it might be useful to operate several controllers independently from separate remote controls.
The controller can be paired to a remote control using either of the following two methods…
Method 1:
Step 1: Press and hold the “FLASH” key, power on the controller, the LEDs will be 50% brightness white to confirm.
Step 2: Press the “FLASH” key 3 times within 3 seconds, the LEDs will change 25%-10%, then back to preset level.
Once the above process is completed, the controller should operate remotely from the paired handset.
If pairing is not successful, re-try by repeating steps 1 and 2 above.
Method 2:
Step 1: Once all connections are made, power up the controller.
Step 2: Press and hold the “SET” button on the receiver for 5 seconds until the indicator light lights up.
Step 3: Hold down the “SET”button on the controller and press “FLASH” on the remote control once to finish
The LED tape will flash 3 times to confirm.
Once the above process is completed, the controller should operate remotely from the paired handset.
If pairing is not successful, re-try by repeating steps 1 to 3 above.
Clearing pairing of RF remote control handsets
To revert remote control pairing back to the factory default, follow one of the two methods below.
Method 1:
Step 1: Press and hold the “SMOOTH” key, power on the controller, the LEDs will be 50% brightness white to confirm.
Step 2: Press the “SMOOTH” key 3 times within 3 seconds, the LEDs will change 25%-10%, then back to preset level.
If the pairing is cleared successfully, the receiver can be controlled by any remote control.
If pairing is not cleared successfully, re-try by repeating steps 1 and 2 above.
Method 2:
Step 1: Once all connections are made, power up the controller.
Step 2: Press and hold the “SET” button on the receiver for 5 seconds until the indicator light lights up.
Step 3: Hold down the “SET”button on the controller and press “SMOOTH” on the remote control once to finish
The LED tape will flash 3 times to confirm.
Once the above process is completed, the controller should operate remotely from the paired handset.
If pairing is not successful, re-try by repeating steps 1 to 3 above.
Hereby, AVSL Group Ltd. declares that the radio equipment type 153.743UK is in compliance with
Directive 2014/53/EU
The full text of the EU declaration of conformity is available at the following internet address:
http://www.avsl.com/assets/exportdoc/1/5/153743UK%20CE.pdf
Errors and omissions excepted. Copyright© 2022. AVSL Group Ltd.
