M-Spa B-090 Alpine Bedienungsanleitung

DO NOT RETURN MERCHANDISE TO YOUR DEALER STORE DIRECTLY.

CALL MSPA AFTER SALES SERVICE CENTER FOR PRODUCT QUESTIONS

OR CONTACT MSPA AT [email protected]

Due to MSpa continuous product improvement, MSpa reserves the right to change

specifications and product appearance, which may result in updates to the instruction

manual without notice.

Where Luxury Is Affordable

www.the-mspa.com

MSpa® Owner’s Manual

and Warranty Card

B-090/091

B-091A

B-100

B-110/B-112

B-120

Alpine

Soho

Nest

Silver Cloud

Glow

B-121

B-141

B-130

B-150

B-131/B-151

B-132/B-152

Castello

Super Castello

Camaro

Super Camaro

Luxury Exotic

Birkin

3127647

CUS

ENTER THE WORLD OF MSPA

Thank you for choosing MSpa and for your confidence in our brand. We believe that you will enjoy many benefits

of using MSpa products for years to come.

To guide you in your initial MSpa experience, we are pleased to present you with this instruction manual. Please

carefully and thoroughly read this manual entirety before using the product for the first time.

We are delighted to welcome you to the MSpa family, and look forward to sharing with you the full spectrum of

our expertise.

Enjoy your MSpa!

Scan the QR code to enter the MSpa official website

CONTENT

Safety precautions………………………………………………………………......................................................

Specifications and product overview………………………………………………..............………........................

First use and set-up preparation…………………………………………….........................……………...............

Spa set-up……………………………………............................…………………………......….............................

Control panel operation…………………………………………........................…................................................

Water maintenance and chemicals……………….......................................………..………………..…...............

Drainage, cleaning and storage………………………...................................………………..………..……..........

Disposal and environmental protection………………………....................................…......................................

Troubleshooting…………………………………………….......……………………….…...…...…..........................

MSpa and MSpa LITE limited warranty policy...................................................................................................

MSpa service center locations...........................................................................................................................

MSpa warranty card…………………………............………................................………………..........................

Welcome,

SAFETY PRECAUTIONS

For your own safety and that of your product, make sure to following the safety

precautions below. Fail to follow the instruction may result in serious injury, property

damage or death. Improper installation or operation will void the warranty.

DANGER

Risk of accidental drowning. Extreme caution must be exercised to

prevent unauthorized access by children. To avoid accidents, ensure

that children can not use this spa unless they are supervised at all

times.

Risk of injury.

a) Replace damaged cord immediately.

b) Do not bury cord.

c) Connect to a grounded, grounding type receptacle only.

Risk of Injury. The suction fittings in this spa are sized to match the

specific water flow created by the pump. Should the need arise to

replace the suction fittings or the pump, be sure that the flow rates are

compatible. Never operate spa if the suction fittings are broken or

missing. Never replace a suction fitting with one rated less than the

flow rate marked on the original suction fitting.

Risk of Electric Shock. Install at least 5 feet (1.5 m) from all metal

surfaces. As an alternative, a spa may be installed within 5 feet of

metal surfaces if each metal surface is permanently connected by

a minimum 6 AWG solid copper conductor to the wire connector

on the terminal box that is provided for this purpose.

Risk of Electric Shock. Do not permit any high voltage electric

appliance, such as a light, telephone, radio, or television, within 5

feet (1.5 m) of a spa.

DANGER:

READ, UNDERSTAND AND FOLLOW ALL

INSTRUCTIONS

WARNING

Risk of electric shock. Insert the plug only to a properly grounded

socket.

The spa must be supplied by an isolating transformer or supplied

through a ground-fault circuit interrupter (GFCI) having a rated

residual operating current not exceeding 30mA.

GFCI must be tested before each use.

If the supply cord is damaged, it must be replaced immediately by the

manufacturer, its service agent or similarly qualified person in order

to avoid a hazard.

To reduce the risk of electric shock, do not use extension cord to

connect unit to electric supply; provide a properly located receptacle.

No part of the appliance is to be located above the bath during use.

Parts containing live parts, except parts supplied with safety extra-low

voltage not exceeding 12V, must be inaccessible to a person in spa

pool; Earthed appliance must be connected to the fixed receptacle

which is permanently connected to fixed wiring. Parts incorporating

electrical components, except remote control devices, must be

located or fixed so that they cannot fall into the spa pool.

The plug of spa shall be more than 3.5m away from the pool.

Spray head must not be used.

The outlet of Spa must not be connected to any tap or fitting other

than those specified.

Electric installations should fulfill the requirements of local standards.

To avoid the electric shock, do not use the spa when it is

raining.

To reduce the risk of injury, do not permit children to use this product

unless they are closely supervised at all times.

WARNING:

A wire connector is provided on this unit to connect a minimum 6 AWG solid

copper conductor between this unit and any metal equipment, metal enclosures of

electrical equipment, metal water pipe, or conduit within 5 feet (1.5 m) of the unit.

Water attracts children. Always have the Spa locked with its cover

after each use.

Do not bury cord. Locate cord to minimize abuse from lawn mowers,

hedge trimmers, and other equipment.

WARNING:

Do not overexert press down or uplift the control panel device. Do not

put any heavy on control panel device after installation.

Pets should be kept away from spa to avoid damage.

When the bubble function is going to be in function, make sure the

cover of Spa must be opened first.

Do not switch on if there is any possibility that the water in the spa is

frozen.

Use only approved accessories. Use of non-approved accessories

could void the warranty.

RISK OF ELECTRIC SHOCK. Install at least 1.5m from all metal

surfaces.

RISK OF ELECTRIC SHOCK. Never operate any electrical appliance

when in your spa or when your body is wet. Never place any electric

appliance, such as a light, telephone, radio, or television, within 1.5m

of spa. During pregnancy, soaking in hot water may cause damage to

the fetus. Limit use to 10 minutes at a time.

Do not expose spa under direct sunshine.

This product is provided with a ground-fault circuit-interrupter in

the plug. The GFCI must be tested before each use. With the

product operating, open the service door. When the product

stops operating, this merely indicates that the door is equipped

with an electrical interlock. Next, push the test button on the

GFCI and close the service door. The product should not

operate. Now open the service door, push the reset button on

the GFCI and close the service door. The product should now

operate normally. When the product fails to operate in this

manner, there is a ground current flowing indicating the

possibility of an electric shock. Disconnect the power until the

fault has been identified and corrected.

TO REDUCE THE RISK OF INJURY:

A. The water in a spa should never exceed 104°F(40°C). Water

temperature between 100°F(38°C) and 104°F(40°C) are

considered safe for a healthy adult. Lower water temperature is

recommended for young children and when spa use exceeds 10

minutes.

B. Since excessive water temperatures have a high potential for

causing fetal damage during the early months of pregnancy,

WARNING:

pregnant or possibly pregnant women should limit spa water

temperature to 100°F(38°C).

C. Before entering a spa, the user should measure the water

temperature with an accurate thermometer since the tolerance of

water temperature regulating devices varies.

D. The use of alcohol, drugs, or medication before or during spa use

may lead to unconsciousness with the possibility of drowning.

E. Obese person and person with a history of heart disease, low or

high blood pressure, circulatory system problems, or diabetes

should consult a physician before use a spa...

F. Person using medication should consult a physician before using

a spa since some medication may induce drowsiness while other

medication may affect heart rate, blood pressure, and circulation.

CHILDREN SHOULD NOT USE SPAS OR HOT TUBS WITHOUT

ADULT SUPERVISION

DO NOT USE SPAS OR HOT TUBS UNLESS ALL SUCTION

GUARDS ARE INSTALLED TO PREVENT BODY AND HAIR

ENTRAPMENT

A green coloured terminal or a terminal marked G, GR, Ground, Grounding,

or the symbol* is located inside the electric box. To reduce the risk of

electric shock, this terminal must be connected to the grounding means

provided in the electric supply service panel with a continuous copper wire

equivalent in size to the circuit conductors supplying this equipment.

* IEC Publication 417, Symbol 5019.

At least two lugs marked "BONDING LUGS" are provided on the external

surface or on inside the electric box. To reduce the risk of electric shock,

connect the local common bonding grid in the area of the hot tub or spa to

these terminals with an insulated or bare copper conductor not smaller than

No. 6 AWG.

All field—installed metal components such as rails, ladders, drains or other

similar hardware within 3 m of the spa or hot tub shall be bonded to the

equipment grounding bus with copper conductors not smaller than No. 6

AWG.

WARNING:

SAVE THIS INSTRUCTIONS

PEOPLE USING MEDICATIONS AND/OR HAVING AN ADVERSE

MEDICAL HISTORY SHOULD CONSULT A PHYSICIAN BEFORE

USING A SPA OR HOT TUB

PEOPLE WITH INFECTIOUS DISEASES SHOULD NOT USE A

SPA OR HOT TUB

TO AVOID INJURY EXERCISE CARE WHEN ENTERING OR

EXITING THE SPA OR HOT TUB

DO NOT USE DRUGS OR ALCOHOL BEFORE OR DURING THE

USE OF A SPA OR HOT TUB TO AVOID UNCONSCIOUSNESS

AND POSSIBLE DROWNING

PREGNANT OR POSSIBLY PREGNANT WOMEN SHOULD

CONSULT A PHYSICIAN BEFORE USING A SPA OR HOT TUB

WATER TEMPERATURE IN EXCESS OF 100°F(38°C) MAY BE

INJURIOUS TO YOUR HEALTH

BEFORE ENTERING THE SPA OR HOT TUB MEASURE THE

WATER TEMPERATURE WITH AN ACCURATE THERMOMETER

DO NOT USE A SPA OR HOT TUB IMMEDIATELY FOLLOWING

STRENUOUS EXERCISE

PROLONGED IMMERSION IN A SPA OR HOT TUB MAY BE

INJURIOUS TO YOUR HEALTH

DO NOT PERMIT ELECTRIC APPLIANCES (SUCH AS A LIGHT,

TELEPHONE, RADIO, OR TELEVISION) WITHIN 1.5 M OF THIS

SPA OR HOT TUB

MAINTAIN WATER CHEMISTRY IN ACCORDANCE WITH

MANUFACTURER' S INSTRUCTION

WARNING:

CAUTION:

Hyperthermia occurs when the internal temperature of the body reaches a

level several degrees above the normal body temperature of 98.6°F(37°C).

The symptoms of hyperthermia include drowsiness, lethargy, and an

increase in the internal temperature of the body. The effects of hyperthermia

include

(a) unawareness of impending hazard;

(b) failure to perceive heat;

(d) physical inability to exit spa;

(e) fetal damage in pregnant women; and

(f) unconsciousness and danger of drowning.

CAUTION

THE USE OF ALCOHOL OR DRUGS CAN GREATLY INCREASE

THE RISK OF FATAL HYPERTHERMIA IN HOT TUBS AND SPAS

TO REDUCE THE RISK OF INJURY: Never pour water which higher

than 104°F(40°C) into the spa pool directly.

The use of alcohol, drugs, or medication can greatly increase the risk

of fatal hyperthermia.

Hyperthermia occurs when the internal temperature of the body

reaches a level several degrees above the normal body temperature

of 98.6°F(37°C). The symptoms of hyperthermia include an increase

in the internal temperature of the body, dizziness, lethargy,

drowsiness, and fainting, The effects of hyperthermia include failure

to perceive heat; failure to recognize the need to exit spa;

unawareness of impending hazard; fetal damage in pregnant women;

physical inability to exit the spa; and unconsciousness resulting in the

danger of drowning.

Warning Label Instruction

Please carefully read the warning label at the first time you are going

to use MSpa.

Please post this warning label on where is at a distance to MSpa

within 1.5m/5’, people in spa can see it clearly.

Please retain this information for future reference.

If the warning label is damaged or missing, please contact your

country MSpa service center to get a new one.

WARNING:

The spa should not be setup or left out in temperature lower than

39°F (4°C):

Do not use the spa alone.

People with infectious diseases should not use a spa.

Do not use the spa immediately following strenuous exercise.

Always enter and exit the spa slowly and cautiously. Wet surfaces

are slippery.

To avoid damage to the pump, the spa must never be operated

unless the spa is filled with water.

Immediately leave spa if uncomfortable or sleepy.

CONSULT YOUR PHYSICIAN FOR RECOMMENDATIONS.

CAUTION:

Never add water to chemicals. Always add chemicals to water to

avoid strong fumes or violent reactions that may result in hazardous

chemical spray.

Place only on surface that can withstand the floor loading

requirement of your Spa.

NOTE: Please examine equipment before use. Notify after service

center listed on this manual for any damaged or missing parts at the

time of purchase. Verify that the equipment components represent

the models that you had intended to purchase.

CAUTION:

SPECIFICATIONS

4 + 2

MSPA BUBBLE SPA

Model No. / code Shape Seating

Capacity Water

Capacity Outside

Dimensions Inside

Dimensions Height Weight

B-091A / Soho

B-121 / Castello

B-130 / Camaro

B-131 / Luxury Exotic

B-132 / Birkin

B-141 / Super Castello

B-150 / Super Camaro

B-151 / Luxury Exotic

B-152 / Birkin

Square

Round

930Ltr

(245gal)

700Ltr

(184gal)

700Ltr

(184gal)

700Ltr

(184gal)

700Ltr

(184gal)

930Ltr

(245gal)

930Ltr

(245gal)

930Ltr

(245gal)

930Ltr

(245gal)

1.85m

(73”)

1.80m

(71”)

1.80m

(71”)

1.80m

(71”)

1.80m

(71”)

2.04m

(80”)

2.04m

(80”)

2.04m

(80”)

2.04m

(80”)

1.45m

(57”)

1.40m

(55”)

1.40m

(55”)

1.40m

(55”)

1.40m

(55”)

1.60m

(63”)

1.60m

(63”)

1.60m

(63”)

1.60m

(63”)

0.68m

(27”)

0.70m

(28”)

0.70m

(28”)

0.70m

(28”)

0.70m

(28”)

0.70m

(28”)

0.70m

(28”)

0.70m

(28”)

0.70m

(28”)

33.9kg

(74.6lbs)

31kg

(68.2lbs)

31kg

(68.2lbs)

34kg

(74.8lbs)

34kg

(74.8lbs)

39kg

(85.8lbs)

39kg

(85.8lbs)

42kg

(92.4lbs)

42kg

(92.4lbs)

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere M-Spa Whirlpool Handbücher

M-Spa

M-Spa Soho P-SH063 Bedienungsanleitung

M-Spa

M-Spa DELIGHT BUBBLE Spa Bedienungsanleitung

M-Spa

M-Spa F-MO063W Bedienungsanleitung

M-Spa

M-Spa ELITE Series Bedienungsanleitung

M-Spa

M-Spa M-CA061 Bedienungsanleitung

M-Spa

M-Spa OSLO Bedienungsanleitung

M-Spa

M-Spa TRIBECA F-TR063W Bedienungsanleitung

M-Spa

M-Spa Tekapo C-TE062 Bedienungsanleitung

M-Spa

M-Spa MONO C-MO04 Bedienungsanleitung

M-Spa

M-Spa Blue Sea B110 Bedienungsanleitung

M-Spa

M-Spa P-SH069 Bedienungsanleitung

M-Spa

M-Spa MONO Bedienungsanleitung

M-Spa

M-Spa Ottoman Bedienungsanleitung

M-Spa

M-Spa TRIBECA F-TR062W Bedienungsanleitung

M-Spa

M-Spa TUSCANY P-TU049 Bedienungsanleitung

M-Spa

M-Spa Alpine Bedienungsanleitung

M-Spa

M-Spa TUSCANY Bedienungsanleitung

M-Spa

M-Spa E-BA04 Bedienungsanleitung

M-Spa

M-Spa OSLO Bedienungsanleitung

M-Spa

M-Spa Carlton M-CA062 Bedienungsanleitung

M-Spa

M-Spa Alpine D-AL04GS Bedienungsanleitung

M-Spa

M-Spa MONT BLANC P-MB04 Bedienungsanleitung

M-Spa

M-Spa B-091 Alpine Leitfaden

M-Spa

M-Spa F-NA062W Bedienungsanleitung

Beliebte Whirlpool Handbücher anderer Marken

Bestway

Bestway Lay-Z-Spa 54189 Bedienungsanleitung

Jacuzzi

Jacuzzi ARGA ARG101C0110 Stücklistenhandbuch

Morphy Richards

Morphy Richards Essentials PC4006 Bedienungsanleitung

Softub

Softub PRESTIGE Bedienungsanleitung

JNJ SPAS

JNJ SPAS SPA-318 Installationshandbuch

KIRAMI

KIRAMI Comfort Family Bedienungsanleitung

QCA Spa

QCA Spa VS501 PAK (VL260 TOPSIDE) Bedienungsanleitung

HoMedics

HoMedics FB-655HJ-GB Bedienungsanleitung

Everyday Hot Tubs

Everyday Hot Tubs 530 Bedienungsanleitung

anko

anko SS-601A Bedienungsanleitung

Jacuzzi

Jacuzzi Duetta 6042 Bedienungsanleitung

Pooli

Pooli OS030979B Bedienungsanleitung

Jacuzzi

Jacuzzi alimia Bedienungsanleitung

ab Solares Smart Spa Bedienungsanleitung

CalderaSpas

CalderaSpas CalderaSpas Utopia Series Bedienungsanleitung

Outsunny

Outsunny 848-047V70 Bedienungsanleitung

Aquatic

Aquatic INFINITY 1 Bedienungsanleitung

Master Spas

Master Spas MP Force Bedienungsanleitung
