Mach M20.06 Bedienungsanleitung

M20.06 Controller

user manual

Measurements are in millimeters

1 2 3 4 5 6

A B

M20.06 System Processor

433

200

480

462

1 2

1 - AC power in

2 - Fuse (0mm x 5mm 'T' fuse, rated at 1A)

out permission in writing from Martin Professional A/S, Denmark.

Printed in Denmark.

P/N 35020002, Rev B

Introduction.....................................................................................5

Safety information............................................................................................................. 5

Compliance..................................................................................................................6

Quick start......................................................................................7

1 - Connect AC power..................................................................................................7

2 - Attach audio connections........................................................................................7

3 - Access pre-loaded program settings ......................................................................7

Installation......................................................................................9

Power................................................................................................................................ 9

Voltage setting .............................................................................................................9

AC power fusing...........................................................................................................9

Mains power connection ............................................................................................10

Mechanical installation.................................................................................................... 10

Controls........................................................................................11

Input section ................................................................................................................... 11

Store/Recall keys.......................................................................................................11

RIGHT/LEFT keys......................................................................................................11

RIGHT/LEFT/UP/DOWN access keys.......................................................................11

Main display...............................................................................................................11

Input meter.................................................................................................................11

Output section................................................................................................................. 12

Mute LED...................................................................................................................12

Mute key.....................................................................................................................12

Output meter..............................................................................................................12

Rear panel ...................................................................................................................... 12

Mains power input......................................................................................................12

RS-232 connector......................................................................................................12

6 band outputs ...........................................................................................................12

2 channel inputs.........................................................................................................13

Operation......................................................................................14

Moving about the screens............................................................................................... 14

Utilities menu .................................................................................................................. 14

Stereo link..................................................................................................................15

Delay units .................................................................................................................15

Lock out......................................................................................................................15

MIDI channel..............................................................................................................15

Contrast......................................................................................................................15

MIDI dump..................................................................................................................15

Delete program ..........................................................................................................16

Inputs menu.................................................................................................................... 17

Delay..........................................................................................................................17

EQ..............................................................................................................................17

Outputs menu ................................................................................................................. 17

Name..........................................................................................................................17

Source........................................................................................................................18

Band gain ...................................................................................................................18

Limiter threshold.........................................................................................................18

Delay ..........................................................................................................................18

Delay link....................................................................................................................18

Polarity .......................................................................................................................19

Low Xover ..................................................................................................................19

High shape .................................................................................................................19

High Xover..................................................................................................................19

EQ ..............................................................................................................................20

EQ screens ..................................................................................................................... 20

Adding a new EQ .......................................................................................................20

EQ shape ...................................................................................................................20

Frequency ..................................................................................................................20

Cut/Boost....................................................................................................................20

Width (BELL only) ......................................................................................................21

Store and recall............................................................................................................... 21

Storing........................................................................................................................21

Recalling.....................................................................................................................22

System Security........................................................................... 23

Program lock................................................................................................................... 23

Lock mode....................................................................................................................... 23

Specifications............................................................................... 24

Introduction

NTRODUCTION

Thank you for selecting the Martin M20.06 Controller. The M20.06

Controller is a one unit loudspeaker management system, capable of

operating all speakers in the Mach product range. This digital circuitry is

based on BSS OMNIDRIVE™ DSP technology and comes equipped with

24-bit A-D and D-A converters. Fast and easy set-up of Mach speaker

systems is ensured by 50 pre-set programs with settings for all Mach

speaker models. Each preset offers carefully optimized crossover points and

slopes, polarity, delay and EQ settings to exactly fit the individual

characteristics of each Mach loudspeaker.

SAFETY INFORMATION

Read this manual before powering or installing the fixture, follow the safety

precautions listed below and observe all warnings in this manual and on the

fixture. If you have questions about how to operate the fixture safely, please

contact your Mach dealer.

This product is not for household use.

Do not removed the covers. There are no user-serviceable parts inside.

Refer all servicing to qualified service personnel.

This equipment must be earthed.

Use only a source of AC power that complies with local building and

electrical codes and has both overload and ground-fault protection.

Do not removed any of the protective earth, or signal cable shield,

connections. Such action is against recommended practise and will render

any EMC or safety certification void.

Introduction

Compliance

The M20.06 has been tested and found to comply with the following

European and international Standards for Electromagnetic Compatibility

and Electrical Safety:

For continued compliance with international EMC legislation ensure that all

input and output cables are wired with the cable screen connected to Pin 1

of the XLR connectors. The input XLR Pin 1 is connected to the chassis via

a low value capacitor, providing high immunity from ground loops whilst

ensuring good EMC performance.

Radiated

Emissions (EU) EN55013 (1990)Associated Equipment

RF Immunity (EU) EN50082/1 (1992)RF Immunity, Fast

Transients ESD

Mains

Disturbance (EU) EN61000/3/2 (1995)

Electrical Safety

(EU) EN60065 (1993)

Radiated

Emissions (USA) FCC part 15

Class B

Electrical Safety

(USA) UL813/ETL (1996)Commercial Audio

Equipment

Electrical Safety

(CAN) UL813/ETLc (1996)Commercial Audio

Equipment

Quick start

UICK

START

1 - Connect AC power

The M20.06 has a universal voltage AC Power input. Connect the unit to AC

Power with the lead supplied. It will switch on automatically (there is no

separate on/off switch). The display will show the default screen, with the

name and program number of the current program. (This will be either the

last program recalled before the unit was switched off, or, in the case of a

unit with no stored programs, the default: 1 UNUSED)

2 - Attach audio connections

Connect the inputs and outputs as required. All inputs and outputs are

electronically balanced, with Pin 2 hot signal (+ve). Do not put any audio

through the unit at this time.

3 - Access pre-loaded program settings

The pre-loaded programs supplied in version 230701 are:

Program #: Supports

1 M12T and M182T

2 M15T and M182T

3 M30T and M182T

4 M154i and M182T or i

5 M129i and M182T or i

6 M156i and M182T or i

7 M12T full range ch 2+3+5+6

8 M15T full range ch 2+3+5+6

9 Slingshot 3 Way passive XO stereo. MS1262, MS118

10 Slingshot 4 Way mono. MS1262, MS118

11 Slingshot 5 Way mono. MS1262, MS15X2, M182T or MS118.

12 Slingshot 5Way mono. MS1262, MS15X2, Ballister SUB

13 M1502T active x 3 input A.

14 M1201T active x 3 input A.

Quick start

To access the pre-loaded programs:

1 Press RECALL.

2 Use the Parameter UP/DOWN keys to select the designated program.

3 Press RECALL again. Programs marked with the letter Mare Master

programs and have been designed to match the different Mach speaker

systems.

Note: It is very important that your settings have the right gain

structure depending on the amplifier size and manufacturer you

are using.

For optimizing the system with regard to gain and time alignment between

subwoofers and top boxes, the SIA Smaart Live program is very useful. If

you use SmaartLive, you can download some Smaart starting point set-ups

from the following Internet address and save them on the M20.06:

http://www.mach.dk/accessories/SmaartLive_M20.06_settings.zip

15 M127i Passive and M152i. In A: 1+2. In B 3+4. In A+B 5+6

16 M154i Passive and M182i. In A: 1+2. In B 3+4. In A+B 5+6

17 M129i Passive and M182i. In A: 1+2. In B 3+4. In A+B 5+6

18 M156i Passive and M182i. In A: 1+2. In B 3+4

Program #: Supports

Installation

NSTALLATION

This section describes how to mount the M20.06 Controller and how to

connect it to AC power.

POWER

Voltage setting

The M20.06 uses a switched-mode power supply which offers high

efficiency and low heat generation. This power supply accepts universal AC

Power input voltages in the range 100V AC to 240V AC (nominal), and

requires no setting adjustment for AC power voltages in this range. Minimum

AC input voltage is 90 Volts, and the maximum is 264 volts. Outside these

ranges the unit will not work satisfactorily, if at all. Voltages in excess of the

maximum will probably cause damage. Voltages below the minimum will

cause complete system shutdown. The flash memory in the M20.06 will

preserve all data in the event of a power failure.

AC power fusing

The green-and-yellow wire of the mains cord must always be connected to

an installation safety earth or ground. The earth is essential for personal

safety as well as the correct operation of the system, and is internally

connected to all exposed metal surfaces. Any rack framework into which this

unit may be mounted is assumed to be connected to the same grounding

circuit.

The incoming mains power is fused within the M20.06 by the fuse holder

mounted on the rear panel. Always replace with an identical 20mm x 5mm

'T' fuse, rated at 1A for continued protection from equipment damage and

fire.

It is for safety reasons that this specification is strictly adhered to.

Installation

Mains power connection

WARNING: The appliance must be earthed.

The wires in the mains lead are color coded in accordance with the following

code. The wire which is coloured:

•Green and yellow, or green, must be connected to the terminal which is marked with

the letter 'E' or by the earth signal or which is coloured green and yellow or green.

•Blue must be connected to the terminal labelled 'N' or coloured black or blue.

•Brown must be connected to the terminal labelled 'L' or coloured red or brown.

MECHANICAL INSTALLATION

A vertical rack space of 1U (1¾" / 44.5 mm high) is required. Ventilation

gaps are unnecessary.

If the M20.06 is likely to undergo extreme vibration through extensive road

trucking and touring, it is advisable to support the unit at the rear and/or

sides to lessen the stress on the front mounting flange. The necessary

support can generally be bought ready-built as a rack tray. As with any low-

level signal processing electronics, it is best to avoid mounting the unit next

to a strong source of magnetic radiation, for example, a high power

amplifier, to help keep residual noise levels in the system to a minimum.

Inhaltsverzeichnis

Andere Mach Controller Handbücher

Mach

Mach LightDrive 12 Bedienungsanleitung

Beliebte Controller Handbücher anderer Marken

Digiplex

Digiplex DGP-848 Betriebsanleitung

YASKAWA

YASKAWA SGM series Bedienungsanleitung

Sinope

Sinope Calypso RM3500ZB Bedienungsanleitung

Isimet

Isimet DLA Series Style 2 Installationshandbuch

LSIS

LSIS sv-ip5a Bedienungsanleitung

Rockwell Automation

Rockwell Automation 1769-L31 Bedienungsanleitung

Airflow

Airflow Uno hab Bedienungsanleitung

ABB

ABB ACS580-01 drives Bedienungsanleitung

Panasonic

Panasonic GM1 Series Bedienungsanleitung

Emerson

Emerson SW93 Bedienungsanleitung

AutoAqua

AutoAqua Smart ATO micro SATO-120P Bedienungsanleitung

Panasonic

Panasonic FP? Positioning Unit RTEX Bedienungsanleitung

Samson

Samson Type 5824 Service-Handbuch

Alpha IP

Alpha IP MIOB 21001 Bedienungsanleitung

Siemens

Siemens OpenAir GMA 1 Series Bedienungsanleitung

Surecom

Surecom SR-629 Bedienungsanleitung

Fishman

Fishman TriplePlay Bedienungsanleitung

Regulus

Regulus SRS1 T Bedienungsanleitung
