Data Logger Manual

PRHTemp2000

Data Logger Manual

Page 1

Table of Contents

Section 1: Device Safety............................................................................3

1.1 Model information ...................................................................3

1.2 Speciﬁcations ...........................................................................3

1.3 Warranty ..................................................................................5

Section 2: Device Overview ......................................................................6

Section 3: Status Indicator Icons ..............................................................7

3.1 Battery Status ...........................................................................7

3.1 Memory Status .........................................................................7

3.1 Running Indicator.....................................................................7

3.2 Delay Start Indicator.................................................................8

3.3 Wait Icons ................................................................................8

3.4 Stop Icon..................................................................................8

3.5 External Power Icon..................................................................8

3.1 Reset Icon.................................................................................8

Section 4: Front Panel Overview ..............................................................9

4.1 Changing the display units .......................................................9

4.2 Changing the number, type, and size of channels viewed.........9

4.3 Checking the memory status ..................................................10

4.4 Checking power status ...........................................................10

4.5 Changing the Contrast ...........................................................10

Section 5: PRHTemp2000 Function Reference .......................................11

5.1 Main Screen ...........................................................................11

5.2 Status Menu ...........................................................................12

5.3 Statistics Menu .......................................................................12

5.4 Units.......................................................................................13

5.5 Setup Menu ...........................................................................13

Section 6: PRHTemp2000 Screen Shot Descriptions..............................18

6.1 Main Screen: ..........................................................................18

6.2 Status Screens (Run Parameters): ............................................18

6.3 Status Screens (Memory Status):.............................................19

6.4 Status Screens (Time): ............................................................19

6.5 ID Parameters.........................................................................20

6.6 Statistics Menu Screen:...........................................................20

Revised 11/06/07

Page 2

MadgeTech PRHTemp2000

6.7 Channel Statistics: ..................................................................21

6.8 Type Statistics:........................................................................21

6.9 Statistics Information Screen:..................................................22

6.10 Unit Selection Menu:............................................................22

6.11 Device Conﬁguration Menu:.................................................23

6.12 Adjust Visibility: ....................................................................23

6.13 Display Conﬁguration:..........................................................24

6.14 Power Modes Screen: ...........................................................25

6.15 Display Update Mode Screen:...............................................25

6.16 Power Status Screen: ............................................................26

6.17 Device Information Screens (Minimum Device Range):.........26

6.1 Device Information Screens (Maximum Device Range): ..........27

6.2 Device Information Screens (Device Version): .........................27

6.1 Device Information Screens (Firmware Version): .....................28

6.1 Calibration Information Screens (Calibration Date): ................28

6.1 Calibration Information Screens (Temperature Calibration):....29

6.1 Calibration Information Screens (Humidity Calibration): .........29

6.1 Calibration Information Screens (Pressure Calibration):...........30

6.2 Device Reset Screen (Hardware Reset): ...................................30

6.3 Device Reset Screen (Power Interruption): ..............................31

Section 7: Computer Interface ...............................................................32

Section 8: Wall Mounting .......................................................................33

Section 9: Maintenance ..........................................................................34

Data Logger Manual

Page 3

Section 1: Device Safety

CAUTION: DEVICE MUST BE USED ONLY IN A MANNER CONSIS-

TENT WITH THIS MANUAL.

NOTICE: WHEN 230VAC SUPPLY USED, MADGETECH SPECIFIES

USE OF AC SUPPLY PART # T35-9-100R-3 MANUFACTURED BY

ENG ELECTRIC. THIS SUPPLY IS AVAILABLE FROM MADGETECH.

1.1 Model information

• Model: PRHTemp2000

• Description: Measure & record temperature, humidity, atmospheric

pressure with LCD display

• Manufactured by MadgeTech, Inc. Warner, NH USA

1.2 Speciﬁcations

Temperature

Range: -20 to +60ºC

Resolution: 0.1ºC

Calibrated Accuracy: ±0.5ºC (0 to +50ºC)

Humidity

Range: 0 to 95%RH

Resolution: 0.1%RH

Calibrated Accuracy: ±3%RH (±2%RH typical at 25ºC)

Speciﬁed Accuracy Range: +10 to +40°C, 10 to 80%RH

Pressure

Range: 0 to 30PSIA

Resolution: 0.002PSIA

Calibrated Accuracy: ±1.0%FSR at 25ºC; ±0.2% typical

Dot-Matrix LCD

Dimensions: 2.5” x 1.375” (63mm x 35mm)

Text: Conﬁgurable channel text size

Indicators: Power, status, memory

Backlight: Conﬁgurable w/auto shut-off and contrast adjustment

Page 4

MadgeTech PRHTemp2000

Start/Stop Time:

Software programmable start time and date, up to six months in

advance; programmable stop time

Memory:

87,381 readings per channel; 262,143 total readings; software

conﬁgurable memory wrap

Reading Rate:

1 reading every 2 seconds to 1 every 24 hours

Calibration:

Digital calibration through software

Calibration Date:

Automatically recorded within device

Battery Type:

9V lithium battery included, user replaceable; optional AC adapter,

7-24 VDC Volts, 100mA. For 230 VAC operation use AC supply

T35-9-100 R-3 made by ENG Electric.

Battery Life:

30 days typical @ 1 min reading rate with continuous LCD and no

backlight usage.

Data Format:

Date and time stamped ºC, ºF, K, ºR ; %RH, mg/ml water vapor

concentration, dew point; PSIA, inHg, mmHg, bar, atm, Torr, Pa,

kPa, MPa

Time Accuracy:

±1 minute/month (at 20º to 30°C)

Computer Interface:

PC serial or USB (interface cable required); 115,200 baud

Software:

Windows 95/98/ME/NT/2000/XP based software

Operating Environment:

-20 to +60ºC, 0 to 95%RH non-condensing

Dimensions:

4.8” x 3.3” x 1.25” (122mm x 84mm x 32mm)

Weight:

16 oz (440 g)

Enclosure:

Black anodized aluminum

Data Logger Manual

Page 5

1.3 Warranty

Products manufactured by MadgeTech, Inc., are warranted against defective

material and workmanship for a period of one year, starting from the date

of shipment. In the event that a MadgeTech product is found to be defec-

tive, MadgeTech will repair or replace the product at its sole discretion. Such

repair or replacement shall be the sole remedy of this warranty.

This warranty extends only to the original purchasing customer and does

not apply to any unit, which in our sole judgment, has been subjected to:

a) Operating or environmental conditions in excess of our written

speciﬁcations or recommendations;

b) Damage, misuse or neglect;

c) Improper installation, repair or alteration.

This warranty excludes batteries.

Except as to title, this is our only warranty for the products. MadgeTech,

Inc. expressly disclaims all other warranties, guarantees or remedies—wheth-

er expressed or implied or statutory—including any implied warranty of mer-

chantability or ﬁtness for a particular purpose. We also disclaim any implied

warranty arising out of trade usage or out of a course dealing or course of

performance. We do not guarantee the integrity of data or warranty that the

products will operate uninterrupted or error-free.

MadgeTech data loggers and their associated software have been thor-

oughly tested and the documentation reviewed. However, MadgeTech does

not warrant the performance of its products, or that the products or their

associated software will operate as described in this manual.

Page 6

MadgeTech PRHTemp2000

Section 2: Device Overview

LED Lights

LCD Display

Screen

Pressure Sensor

Power Jack

Temperature

and Humidity

Sensor

Ventilation

Holes

Communication

Jack

Up Key

Okay Key

Down Key

Cancel Key

Function Keys

Bleach

anodized

aluminum

enclosure

Data Logger Manual

Page 7

Section 3: Important Status Icons

3.1 Battery Status

Full Empty

Battery Battery

Battery status icons indicate the state of charge of the batteries. When the bat-

tery empty indicator is displayed, the battery should be replaced.

3.1 Memory Status

Memory Memory

Empty Full

The memory status icons indicate the amount of memory left for data storage. If

the PRHTemp2000 is in wraparound mode, the memory status icon will indicate

empty.

3.1 Running Indicator

Indicates that the PRHTemp2000 is taking readings. The icons cycle

periodically.

Page 8

MadgeTech PRHTemp2000

3.2 Delay Start Indicator

The delay start icon indicates that a logging operation is

scheduled for the future.

3.3 Wait Icons

The wait icons indicate that the device is busy.

3.4 Stop Icon

Indicates that the PRHTemp2000 is not currently taking readings.

3.5 External Power Icon

Indicates that the PRHTemp2000 is powered by an external

source.

3.1 Reset Icon

Indicates that the device has been reset.

Data Logger Manual

Page 9

Section 4: Front Panel Overview

4.1 Changing the display units

The PRHTemp2000 comes with factory default display units of °C for tem-

perature, %RH for humidity, and PSIA for pressure. These units can be easily

changed by pressing the F3 button in the main screen and then selecting

either F1 for temperature, F2 for humidity or F3 for pressure. After selecting

a channel, the available units can be scrolled through by either pressing the

channel’s function key repeatedly or using the UP and DOWN keys.

Button pressing chain:

Main Screen -> F3 -> F1(temp), F2(humidity) or F3(pressure) -> function key

repeatedly or UP and DOWN

4.2 Changing the number, type, and size of channels viewed

By default the PRHTemp2000 displays recently measured values of all 3 chan-

nels (temperature, humidity, and pressure) on its Main Screen with the three

channels taking up the maximum amount of screen space available. Chan-

nels can, however, be hidden or viewed on a smaller or larger scale.

To change the number and type of displayed channels:

From the Main Screen, press the F4 key to enter the Setup Menu and from

this menu press the F1 key to enter the Display screen. On this screen, F1

corresponds to the Temperature channel, F2 to Humidity, and F3 to Pressure.

Pressing these function keys will cause the channels to scroll between “show”

or “hide” channels displaying “show” will appear on the main screen and

channels displaying “hide” will not. Any number of channels between zero

and three may be shown.

Button pressing chain:

Main Screen -> F4 -> F1 -> F1(temp), F2(humidity) or F3(pressure)

To change the size of displayed channels:

From the Main Screen, press the F4 key to enter the Setup Menu and from

this menu press the F1 key to enter the Display screen, then F4 to scroll to

the next screen. Here the F2 key will change the size of the channels viewed.

By pressing F2 repeatedly the size parameter will scroll between 3 sizes:

Small: Up to three channels can be displayed and appear much smaller than

the available screen space.

Medium: Up to three channels can be displayed and take up entire available

screen space.

Andere Handbücher für PRHTemp2000

Inhaltsverzeichnis

Andere MadgeTech Datenlogger Handbücher

MadgeTech

MadgeTech HITEMP140-1 Technisches Datenblatt

MadgeTech

MadgeTech MicroTemp100 Technisches Datenblatt

MadgeTech

MadgeTech OctVolt Technisches Datenblatt

MadgeTech

MadgeTech Logicbus X Series Technisches Datenblatt

MadgeTech

MadgeTech Rain101A Technisches Datenblatt

MadgeTech

MadgeTech MadgeNET RFTemp2000A Technisches Datenblatt

MadgeTech

MadgeTech HiTemp140-PT-1-KR Technisches Datenblatt

MadgeTech

MadgeTech Pulse101A Bedienungsanleitung

MadgeTech

MadgeTech UltraShock Technisches Datenblatt

MadgeTech

MadgeTech RTDTemp2000 Bedienungsanleitung

MadgeTech

MadgeTech QuadTemp2000 Bedienungsanleitung

MadgeTech

MadgeTech Bridge101A-150 Bedienungsanleitung

MadgeTech

MadgeTech IC-RFCO2RH Technisches Datenblatt

MadgeTech

MadgeTech HiTemp140-FP Technisches Datenblatt

MadgeTech

MadgeTech QuadRTDTempV2 Technisches Datenblatt

MadgeTech

MadgeTech Pulse101A Technisches Datenblatt

MadgeTech

MadgeTech UltraShock Series Bedienungsanleitung

MadgeTech

MadgeTech PR2000 Technisches Datenblatt

MadgeTech

MadgeTech Process101A Bedienungsanleitung

MadgeTech

MadgeTech MadgeNET RFTemp2000A Technisches Datenblatt

MadgeTech

MadgeTech 902152-00 Technisches Datenblatt

MadgeTech

MadgeTech HiTemp140-FPST-36 Bedienungsanleitung

MadgeTech

MadgeTech X Series Technisches Datenblatt

MadgeTech

MadgeTech Shock101-100 Technisches Datenblatt

Beliebte Datenlogger Handbücher anderer Marken

TESTO

TESTO 176 Bedienungsanleitung

HT Italia

HT Italia XL421 Bedienungsanleitung

HBM

HBM SOMAT XR CX22B-R Bedienungsanleitung

Agtrix

Agtrix 380i Bedienungsanleitung

Hobo

Hobo H8 Pro Bedienungsanleitung

Beijing ART Tech

Beijing ART Tech PCI2320 Bedienungsanleitung

Athena

Athena GET SL1 Bedienungsanleitung

Motec Systems

Motec Systems C185 Bedienungsanleitung

Beijing ART Tech

Beijing ART Tech USB2832 Bedienungsanleitung

Rotronic

Rotronic HygroLog HL20 Bedienungsanleitung

MRC

MRC DW-6092 Bedienungsanleitung

Racelogic

Racelogic VBOX LapTimer Bedienungsanleitung

Edu-Logger

Edu-Logger 900-240 Bedienungsanleitung

Elma

Elma DT173 Bedienungsanleitung

Comet

Comet U0121M Bedienungsanleitung

pico Technology

pico Technology PT-104 Bedienungsanleitung

Soil Instruments

Soil Instruments GTecLink Bedienungsanleitung

APLICOM

APLICOM A11 Bedienungsanleitung
