THANKS FOR BUYING A
MADRIGAL DESIGN PRODUCT
DIFFUSOR:
LIGHT OUTPUT: 20 LEDS - 240 LUMENS - CRI 95+
110 MM DIAMETER - 65 MM HEIGHT
HEIGHT: 350 MM
CONTROLS: TOUCH ON/OFF + STEPLESS DIMMER (WITH MEMORY)
POWER: INPUT 5V USB - 3.5W MAX POWER CONSUMPTION
BATTERY: 3.6V 5200 mAH (2 x 2600 mAh)
BATTERY LIFE: 8 - 48 HOURS BASED ON BRIGHTNESS
RECHARGING TIME: MAX 6 HOURS WITH 2A POWER SUPPLY (10W)
BASE: 100 MM DIAMETER - 12 MM THICKNESS
TOUCH SURFACE
Stilosa is a rechargeable table lamp made of painted aluminum
with a polymethylacrylate light diusor. Its 20 adjustable
intensity LEDs produce a pleasant and natural warm light.
The touch surface located on the diusor enables you to turn
the light on and o and also has a dimmer function to adjust
the brightness.
ENGLISH
2MADRIGAL-DESIGN.COM
Stilosa has an IP54 protection rating that makes it suitable for
interior and exterior use. It can be charged easily with a standard
micro USB cable which is included in the package along with the
10W USB power supply. The battery life ranges from 8 to 48
hours per charge based on the brightness.
STILOSA TONDA
BY MADRIGAL
ON/OFF
RAPID TOUCH
TURNING ON AND OFF
The lamp is turned on and o with a quick tap on
the touch surface of the lamp shade.
BRIGHTNESS ADJUSTMENT
When the lamp is turned on, hold your finger on the
touch surface of the lamp shade until the desired
brightness is reached. When turned on, the lamp
returns to the maximum brightness of 100%.
RECHARGING
To recharge the lamp, lift the protective cover
under the lamp shade and connect the provided
micro USB cable to a standard USB charger. A red
light indicates the charging status of the lamp.
Charging is complete when the light turns green.
DIMMER
PROLONGED TOUCH
USB CONNECTOR
3MADRIGAL-DESIGN.COM
USE OF THE STILOSA LAMP
TIPS AND MAINTENANCE
Charge the product completely before first use. Use a 5V - 2A (10W) char-
ger like the one provided to charge the lamp in order to reduce wait time.
The batteries last up to 500 charge cycles and can be replaced by our after-
sales service which is available on the www.madrigal-design.com website.
When the lamp has not been used for a long time, we recommend you
perform a series of charge and discharge cycles and we recommend that the
battery not be allowed to go below 20% charge. When the silicon cover of
the USB connector is closed, the lamp achieves an IP54 level of protection
and is suitable for external use.
Clean the lamp with a clean and dry cloth.
ENGLISH STILOSA TONDA
+39 02-87168002
Customer Support via WhatsApp
CONCEIVED IN ITALY
ASSEMBLED IN CHINA
4MADRIGAL-DESIGN.COM
Madrigal oers a 2 year warranty on the product from the date of
purchase for non professional use.
The warranty does not cover scratches, aesthetic imperfections or damage
caused by impacts, falls, mechanical pressure, or contamination. Madrigal
reserves the right to evaluate warranty claims, verifying that the product
and its accessories have been used according to the use instructions and
that there was no tampering.
WARRANTY
This product contains lithium-ion rechargeable batteries which can be
replaced by our aftersales support service. Do not open, destroy, or heat to
temperatures above 60º C. Keep the product away from fire. Lithium-ion
batteries and products which contain lithium-ion batteries are subject to
strict transportation regulations.
We decline any responsibility for damage caused by products
which are assembled or used in a manner that does not comply
with the instructions.
WARNING
If you need assistance, our support service is available through the
www.madrigal-design.com website or via Whatsapp by sending a
message to 0039 02 87169002.
SUPPORT AND ASSISTENCE
OUTDOOR/INDOOR
ENGLISH STILOSA TONDA
5
Madrigal is a product of
Atomium srls - Via Bebio 74 - 76125 Trani - ITALY
© Atomium. All rights reserved. Madrigal is a registered trademark.
