MAGNEPLANAR MMG C Bedienungsanleitung
MAGNEPLANAR® MMG C
Instruction Manual
White Bear Lake, Minnesota
www.ma nepan.com
1. GENERAL DESCRIPTION
Con ratulations on your purchase of the Ma neplanar® MMG C Center Channel
Loudspeaker. The Ma neplanar was conceived and desi ned for perfectionists. The
MMG C consists of a curved, one-way planar ma netic driver. Due to the ele ant
simplicity and ru edness of the desi n, the Ma neplanar MMG C Center Channel will
ive many years of trouble-free service.
2. CARTON CONTENTS
1 - MMG C Center Channel Loudspeaker
1 - 4 Amp Normal Blow Fuse
1 - Hex Wrench
1 - Speaker Emblem
1 - Owners Manual
3. PACKAGING
Save all packa in . If you ever need to ship the MMG C, it can be shipped safely
only in the ori inal packa in . Should you discard it, packa in is available from
Ma nepan.
4. HOOKUP
The MMG C employs a unique, hi h-current connector. To install speaker cable,
simply strip approximately 1/4-inch of insulation from the speaker cable end, insert the
cable into the connector, and ti hten the set screw. Cables terminated with banana
plu s or pins may also be used. For cables terminated with spade lu s, spade lu
adapters are available for purchase from Ma nepan.
Proper phasin is critical in obtainin ood performance from your home theater
system. Double check all of your connections to be certain the left, ri ht, and center
speakers are all connected in phase.
5. INSTALLATION PLACEMENT
A. INSTALLATION ON A TV
The MMG C may be placed on top of a TV monitor as shown below. Ma netic
shieldin is not required. To achieve the smoothest vertical response, rotate the
adjustment feet located on the bottom of the speaker. Adjust until the speaker is
aimed approximately at the listener's head, as shown below.
B. INSTALLATION IN A CABINET
The MMG C may be placed above or below the TV monitor in a cabinet. If the
speaker is placed in an enclosed part of the cabinet, a space of 12" or more is
required behind the speaker for dampin material.
Startin at the rear of the cabinet, LOOSELY pack insulation in the cavity
behind the speaker. Leave an empty space of about 6 inches between the rear
of the speaker and the insulation.
Whenever possible, the rear of the cabinet should be vented or left open to
allow the rear wave from the MMG C to escape.
If the speaker is placed below the TV or screen, the speaker can be tilted
upward by removin the 2 existin adjustable feet. Locate the front T nut shown
in the followin dia rams. Usin a hot solderin iron, burn a hole in the fabric to
allow installation of an adjustable foot in the front T nut. If the speaker is placed
below the TV or screen, the speaker can be tilted upward by removin the 2
existin adjustable feet. Locate the front T-nut shown in the followin dia rams.
A ain, for the smoothest response, tilt the MMG C to aim it approximately at the
listener's head as shown above.
C. INSTALLATION USING BUILT- IN "T" NUTS
As shown below, there are 3 "T" nuts built into the top and bottom of the MMG
C, at the desi nated locations. These built-in T nuts allow han in or any other
type of installation you may devise. Carefully burn a hole in the cloth with a hot
solderin tip or a method that will seal the hole in the cloth. Eye-bolts or hooks
may be installed in the built-in nuts, and use 1/4-inch X 20-inch threads.
D. DAMPING
When the MMG C is placed close to a rear wall, the sound quality can
usually be improved with a dampin material, such as a wall han in ,
behind the speaker.
6. PROCESSOR SETTINGS
Set your receiver or processor on "small" speaker for the center channel, and "lar e" or
"full ran e" for the left/ri ht speakers. (This does not apply if the MC1 or MMG W are
used as front left/ri ht speakers.) Set the MMG C crossover point at 100Hz. Try hi her
crossover points to achieve natural reproduction of male voice. Dependin upon your
room conditions and the center channel placement, a different crossover point from
100Hz may be needed.
Even thou h you will probably be usin a subwoofer, set your receiver or processor for
"no subwoofer." This may seem stran e, but it is necessary for the proper inte ration
of the center channel bass. To drive your subwoofer, use a pre-amp output from the
front left/ri ht of the processor or receiver. (It may be necessary to use Y adapters.)
How (and why) this setup works-normally, when "small" center speaker is specified,
the center channel bass is routed to the subwoofer. In reality, this doesn't work very
well, especially for Ma neplanars. There is usually a frequency "hole" in the response
or the sonic inte ration is poor. When "no subwoofer" is specified, the processor
automatically routes the center channel bass to the front left/ri ht "full ran e"
Ma neplanars (because there is no alternative). The front left/ri ht Ma neplanars
provide the bass for the center channel speaker; and the inte ration is seamless,
havin the same characteristics as the MMG C.
Since the si nal from the front left/ri ht pre-amp outputs is "full ran e," the subwoofer
receives all the bass information. The .1 channel (effects) is not needed. Adjust the
subwoofer crossover point so it does not overlap with the "full ran e" front left/ri ht
Ma neplanars.
7. AMPLIFICATION
WARNING: The MMG C is a 5 ohm speaker. Be certain the amplifier or receiver you
are usin is capable of drivin a 5 ohm load. If you are uncertain, call the manufacturer
of the amplifier.
8. SPECIFICATIONS
System Description: Curved, one-way planar ma netic dipole loudspeaker
Frequency Response: 100Hz - 16kHz + 5dB
Recommended Power: See "Frequently Asked Questions" on our web site at
www.ma nepan.com
Sensitivity: 88dB @ 2.83V/1 Meter/500Hz
Impedance: 5 Ohms
Dimensions: 36" W X 9" H X 5-1/" D
Warranty: Limited 3-Year to Ori inal Owner Shippin
Wei ht: 18 Lbs.
