MAJORITY PEMBROKE II Handbuch
PEM-NET-DAB -BLK-2
Instructions Guide
PEMBROKE II
INTERNET RADIO & MUSIC SYSTEM
What’s in the Box?..................................................... 1
Controls And Funcons..............................................2
Support .................................................................... 6
Instrucons Guide .....................................................7
Basic Operaon �������������������������������������������������������� 8
Internet Radio�����������������������������������������������������������11
Media Centre����������������������������������������������������������� 13
FM Radio������������������������������������������������������������������ 15
DAB/DAB+ Radio ����������������������������������������������������� 16
Informaon Centre �������������������������������������������������� 18
Connecons������������������������������������������������������������� 19
Bluetooth���������������������������������������������������������������� 20
Spofy Connect ������������������������������������������������������� 21
Conguraon Sengs ���������������������������������������������22
Sengs: Addional Features����������������������������������� 27
Remote Control App ������������������������������������������������29
Troubleshoong ...................................................... 31
Specicaons .......................................................... 32
Warranty ................................................................. 32
Safety Informaon................................................... 33
Contents
Watch video tutorials and register
your product for a FREE 3-year warranty
at https://www.majority.co.uk
3YEAR
WARRANTY
1
What’s in the Box?
Box Contents
1. Majority Pembroke
2. Remote Control
3. Power Adapter
4. Instructions Guide
2
Controls And Funcons
Front View
1
2 3
1. Display Screen
2. Volume dial
3. Navigation/OK dial
1210
4 5 6
7
8
911
4. Standby
5. Mode
6. Home
7. Dimmer
8. Favourite
9. Alarm
10. Previous
11. Sleep
12. Next
3
Controls And Funcons
Back View/Connections
13
15
1714 16
13. ON/OFF Switch
14. DC power input
15. Line Out
16. Aux In
17. USB Charging Port
4
Controls And Funcons
Remote Control
EQ
HOMEMODE
AlarmSleepDimmer
VOL+
FAV FAV+
VOL-
ABC DEF
JKLGHI MNO
TUV
1
2
3
5
4
6
7
8
19
9
11
12
13
21
15
14
16
17
20
PQRSPQRS WXYZWXYZ
18
10 22
5
Controls and Funcons
1. Power On/O
Switch the unit between on and
Standby mode
2. Dimmer
Switch between two dimmer
settings
3. Equaliser
Adjust the sound to dierent
media options for the best
sound
4. Skip forward button
Skip forward through tracks in
Bluetooth mode
5. Skip backward button
Skip backwards through tracks
in Bluetooth Mode
6. MODE button
Scroll through available audio
modes on display screen
7. Scroll up
8. < back button/scroll left
Go back to previous display
screen or options available. Also
use to scroll left
9. Vol - button
10. Fav Preset recall
When in the audio mode view
favourite stations that have
been set
11. MUTE button
Stop/start audio sounding
12. Sleep button
Select repeatedly until desired
sleep timer set on top right of
display
13. Alarm button
Select to view and create alarm
options
14. Stop button
15. Pause/Play
16. HOME button
View main display screen
17. > forward button/scroll
right
Use to go to next option/screen
or scroll right.
18. Select button
Select chosen option
19. Scroll down
20. Vol + button
21. Keypad
Type numbers and letters
22. Add as a favourite/preset
When on the desired station,
press to set as a favourite. Use
the select OK button to choose
preset number
6
Support
Support
Thank you for your purchase of the Majority Pembroke II
internet radio.
Please follow the guidance of the manual to set up your
new purchase and begin enjoying its features.
If you require further assistance with your new radio,
please contact our support team on the Majority website:
https://www.majority.co.uk/support/
7
Instrucons Guide
Navigation Settings
Standby button: This should be used to turn your radio on
and o. The Standby screen will display the time, date and any
settings set such as alarms.
To turn o standby, press the Standby button to be taken to the
home screen, or last function that you were using before putting
into standby.
Navigation/OK/Volume Dial: Rotate the dial clockwise or
anticlockwise to scroll through choices and press down the dial
to conrm selections.
This dial will allow you to change the volume when you are on
the radio station playing screen.
Home button: Select the Home button to view the main menu
screen and browse through audio options such as Local Radio,
Internet Radio, DAB Radio, FM Radio, Spotify Connect, Media
Centre, Information Centre, AUX, Conguration Settings.
Use the Home button to cancel out of settings being made.
Dimmer: Select Dimmer to choose between the two default
options. Alter dimmer’s brightness in Conguration settings.
< and > buttons: Buttons used to alter settings. Use the
‘previous’button to go back a step.
8
Basic Operation
Instrucons Guide
Please note that the instructions within this manual will refer to
the radio button number e.g (Ref.*number*) in accordance to
the diagrams on pages 2-3 and (Rem.*number*) to represent
the remote on pages 4-5.
Starting up your internet radio
Plug the adaptor connector into the back of the system labelled
‘DC in’ (Ref. 14) and turn the power on from the mains. Switch
the button at the back of the radio to‘ON’ (Ref. 13) to display the
Welcome screen.
Ensure the antenna is extended as far as possible. This will
enable you to get the best signal you can.
After the Welcome screen, you will be able to select your chosen
language by scrolling with the Navigation dial (Ref.). Select
your language by pressing down the dial.
If this is the rst time of using your radio, you will get the option
to set up your Wi-Fi to stream Internet Radio with the message
“Would you like to congure network now?”. If you select YES,
your radio will begin to scan for nearby networks to connect to.
If you select NO then you can set this up later in conguration
settings.
