MakerPi K5 Plus Bedienungsanleitung
1
2
Content
Chapter 1 Learn about your 3D printer..................................................................... 3
1.1 3D printer introduction...................................................................................4
1.2 Cautions..........................................................................................................5
Chapter 2 Preparation before printing...................................................................... 6
Chapter 3 Adjustments to the printing platform....................................................... 9
3.1 Coarse tuning................................................................................................. 9
3.2 Fine tuning....................................................................................................11
Chapter 4 Printer functions..................................................................................... 13
4.1 Preparation......................................................................................................14
4.1.1 Return to zero........................................................................................ 14
4.1.2 Unlock stepper motor............................................................................14
4.1.3 Load filament......................................................................................... 15
4.1.4 Unload filament..................................................................................... 15
4.1.5 XYZ move axis.........................................................................................16
4.1.6 Preheat.................................................................................................. 16
4.1.7 Cool........................................................................................................17
4.2 Print................................................................................................................. 17
4.3 Machine setting............................................................................................... 18
4.3.1 Key sound...............................................................................................18
4.2.2 Alarm sound...........................................................................................18
4.3.3 Touch calibration....................................................................................19
4.3.4 Z distance measurement....................................................................... 19
4.4 Machine status query...................................................................................... 19
4.5 Other functions................................................................................................20
4.5.1 Basic functions.......................................................................................20
4.5.2 Midway refueling................................................................................... 20
4.5.3 Temperature, printing speed and nozzle fan adjustment...................... 21
4.5.4 WiFi connection and video monitoring..................................................21
3
Chapter 5 Software usage introduction...................................................................23
5.1 Slicing software installation.......................................................................... 23
5.2 Introduction to the application of slicing software.......................................26
5.2.1 Fast print（Not recommended for use）.......................................... 26
5.2.2 Full mode printing...............................................................................26
5.2.3 Basic setup..........................................................................................26
5.2.4 Advanced setup.................................................................................. 28
5.2.5 CURA print interface........................................................................... 29
5.3 View the model.............................................................................................30
Chapter 6 Printing exercises...................................................................................... 32
Chapter 7 Printing skills............................................................................................. 35
7.1 Flat bottom................................................................................................... 36
7.2 Avoid overhang.............................................................................................36
7.3 Assemble matching graphic tolerances........................................................ 38
7.4 Big size model print...................................................................................... 38
Chapter 8 Printing picture relief................................................................................ 38
Chapter 9 Exports STL format files.............................................................................40
9.1 Pro/E exports STL files.................................................................................. 41
9.2 UG export STL file......................................................................................... 42
9.3 Solidworks export STL files............................................................................44
Chapter 10 Analysis of common problems................................................................45
4
Chapter 1 Learn about your 3D printer
1.1 3D printer introduction
5
6
1.2 Cautions
1. The nozzle temperature is up to 200℃during the working period of the 3D printer
and after printing. So do not touch the nozzle with your hand;
2. Please follow the instructions in the guide to operate and use the machine. If you
have any questions, you can contact the after-sales department;
3. If the printed model needs to be disassembled for support, please wear gloves so as
not to be scratched by tools or supporting materials during the disassembled process;
4. In daily use,it is necessary to regularly clean and lubricate the optical axis of the cross
slide table of the 3D printer, and be careful not to drip onto the casing or belt when
adding lubricating oil.
5. Reading "User guide", at the same time with the actual operation of the machine will
be more conducive to your operation.
6. In the printing process encountered a problem with the machine print, you can first
take a photo to reflect the problem more intuitively, at the same time provide the
machine number of photos (the label at the bottom of the back of the machine), and
then contact after-sales.
7
Chapter 2 Preparation before printing
Take out the machine and use it for
packing, remove the tape, open the
front door, and remove the foam.
Take out the accessory box, etc.
Take out the power cord from the
accessory box, connect the power
cord.
"-" is power on, "O" is power off.
Install filament racks on the back of
the machine with an open end stuck
in the hole.
8
Install WIFI antenna on the side
of the machine, Rotate clockwise
to fix the antenna.
Install white feeding pipe,
separate the two ends insert into
hole.
9
Chapter 3 Adjustments to the printing platform
3.1 Coarse tuning
Platform leveling, filament must be unloaded.
When the platform is down, confirm that there is no debris inside
the machine.
Remove the swift-change nozzle, replace the leveling module.
1. 2.
10
3. 4.
Tighten the four nuts counterclockwise.
Twist the nut according to screen indicated
