Marathon MFF104W Bedienungsanleitung
MFF104W | MFF122W | MFF122SS
Mid-size Frost Free
Refrigerator
Congratulations on the purchase of your new Marathon Refrigerator!
To activate your Warranty, please register your appliance at www.stirlingmarathon.com
or by completing and mailing the enclosed Warranty Registration Card. We are confident
you will have years of hassle-free enjoyment and ask that you please retain the
Use & Care Guide for future reference and your safety.
Before installing please, read your Use & Care guide carefully and pay special attention
to the Safety & Warning information outlined in the following pages.
For immediate assistance: 1-844-309-9777
www.stirlingmarathon.com
Important Safety Instructions
WARNING
To reduce the risk of fire, electrical shock, or injury follow these basic
precautions when using your appliance.
•
•
Completely remove the doors.
Leaves the shelves in place so that children not may easily climb inside.
Before you discard or recycle your old refrigerator
1. Keep ventilation openings, in the appliance enclosure or built-in structure, clear of obstruction.
2. Do not use mechanical devices or other means to accelerate the defrosting process.
3. Do not use electrical appliances inside the appliance
4. DANGER: Never allow children to play with, operate, or crawl inside the appliance. Risk of child entrapment.
5. GROUNDING INSTRUCTIONS This appliance must be grounded. In the event of an electrical short circuit, grounding
reduces the risk of electrical shock by providing an escape wire for the electrical current. This appliance is equipped with
a cord having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed
and grounded.
6. DO NOT USE AN EXTENSION CORD
7. Use an exclusive 120V wall outlet. Do not connect your refrigerator to extension cords or together with any other
appliance in the same wall outlet. Do not splice the cord.
8. Always unplug before any maintenance or service on the appliance.
9. If a part is damaged, it must be replaced by the manufacturer, its service agent or similar qualified persons in
order to avoid a hazard.
10. Follow local regulations regarding disposal of the appliance due to flammable refrigerant. All refrigeration products
contain refrigerants, which under the guidelines of federal law must be removed before disposal.
It is the consumer’s responsibility to comply with federal and local regulations when disposing of this product.
11. This appliance is intended to be used in household and similar environment such as:
a Staff kitchen, workshop, office and other working environments;
b Farmhouses and by clients in hotels, motels and other residential type environments;
c Bed and breakfast type environments;
d Catering and similar non-retail applications.
12. Do not store or use gasoline or any inflammable liquors and liquids inside or in the vicinity of the refrigerator.
13. Do not use an extension cord with t his appliance. If the power cord is too short, have a qualified electrician install an
outlet near the appliance. The use of an extension can negatively affect the appliance’s performance
Freezer shelf
Refrigerator
temperature control
Freezer temperature
control
Refrigerator shelves
Glass crisper cover
Crisper
Refrigerator
door racks
Freezer
door racks
Bottle
storage bin
Covered
bottle bin
Adjustable
crisper divider
Overview
•This appliance is designed to be free-standing only, and should not be recessed or built-in.
•This unit is not designed for use in a garage or any other outside installation
•Ambient temperature below 50°F (10°C) or above 85°F (29.4°C) will hinder the performance of this
appliance.
•Avoid locating the refrigerator in moist areas.
•Locate the refrigerator away from direct sunlight and sources of heat (stove, heater, radiator, etc.).
•Direct sunlight may affect the acrylic coating and heat sources may increase electrical consumption.
•Select a location with enough space for the refrigerator doors to open easily;
•Select a location with level (or nearly level) flooring;
•Allow sufficient space to install the refrigerator on a flat surface;
•Allow clearance to the right, left, back and top when installing. This will help reduce power consumption
and keep your energy bills lower.
Installing your refrigerator
Levelling the refrigerator
To do this adjust the two levelling feet at front of the unit.
If the unit is not level, the doors and magnetic seal alignments will
not be covered properly
At least 2''
Installation
AtA least lea
5
Tool required: Philips screwdriver, Flat bladed screwdriver,
•Ensure the unit is unplugged and empty.
•To take the door off, it is necessary to tilt the unit backwards. You should rest the unit on something solid so
that it will not slip during the door reversing process.
•All parts removed must be saved to do re-installation of the door.
•Do not lay the unit flat as this may damage the coolant system.
•CAUTION: To avoid injury, we recommend someone assist you during the door reversal process.
1. Unscrew the top hinge cover and then unscrew
the top hinge. Then lift the upper door and place it
on a soft pads to avoid scratches and damage.
2.Remove the top left screw cover.
3.Unscrew the middle hinge. Lift the refrigerator
door and place it in a safe place to protect it from
damage and scratches.
4.Move shaft sleeve and pinhole plug from left
side to right side.
5.Move the middle hinge hole covers from the left
side to the right side. 6.Unscrew bottom hinge. Then remove the
adjustable feet from both.
Changing the Reversible Door
6
7.Remove the washer and nut that secure the
hinge pin to the hinge, then remove the pin and
screws with the washer and nut into to left hole
hinge.
9. Move the bottom hinge hole covers from the left
side to the right side.
10. Make the middle hinge reverse the direction 180º,
then transfer it to the left property position. Make the
middle hinge pin in the upper hole of the lower door,
then tighten the bolts.
11. Place the upper door back on. Ensure the door is
aligned horizontally and vertically so that the seal
transfer it to the left property position. Make the
middle hinge pin in the upper hole of the lower door,
then tighten the bolts.
12. Place the top left cover to the right side and
affix it by a screw.
8. Transfer the lower door to the property position.
Replace both adjustable feet.
Changing the Reversible Door
Freezer Compartment Temperature Setting
The slider at the back of the freezer section regulates the air circulation in both the freezer and refrigerator
sections. It is recommended to have the slider in the middle as shown in the below diagram. If the freezer
section is at MAX then there is less cold air circulating in the refrigerator section.
If the freezer section is at MIN then there is more cold air circulating in the refrigerator section.
Less Circulation More Circulation
Optimal Temp. Control
Refrigerator Compartment Temperature Setting
The temperature can be adjusted by pressing the SET key. The indicator light will begin to flash and proceed to
select the temperature setting to your preference (please see below table). We recommend setting #3 for optimal
performance. Setting 5 is the coldest and 1 is the warmest setting.
What is Fast Cool?
The Fast Cool function should be used to cool the refrigerator compartment quickly. This function will help retain
food freshness.
After 30 hours this function will end and the temperature mode will go back to the setting selected before Fast
Cool was activated
sing the control panelUsingU
Service Alarm
If the indicator light on setting 1, 3 or 5 begins to flash continuously this indicates a refrigerator failure.
We recommend you remove all contents from the refrigerator and contact us for after-sales support at
1-844-309-9777 if under warranty or contact a refrigeration technician immediately.
7
For hygienic reasons the appliance interior, including interior accessories, should be cleaned regularly.
Caution! The appliances may not be connected to any power supply during cleaning. Danger of electrical shock!
Before cleaning switch the appliance off and remove the plug from the outlet, or switch off the circuit breaker/fuse.
Never clean the appliance with a steam cleaner. Moisture could accumulate in electrical components, danger of
electrical shock! Hot vapours can lead to the damage of plastic parts. The appliance must be dry before it is placed
back into service.
Important! Ethereal oils and organic solvents can attack plastic parts, e.g. lemon juice or the juice from an orange
peel, butyric acid, a cleaner that contains acetic acid.
•Upon installation of your new appliance, it is recommended that it be cleaned thoroughly.
•Wash the inside with a damp warm cloth soaked in lukewarm water and baking soda solution. The solution should be
about 2 tablespoons of baking soda to a quart of water.
•Be sure to keep the door gasket (seal) clean to keep the unit running efficiently.
•The outside of the refrigerator should be cleaned with mild detergent and warm water.
•Dry the interior and exterior with a soft cloth.
•To keep the inside sanitary without odor or dirty, regular cleaning required at least once a month.
•Do not allow such substances to come into contact with the appliance parts.
•Do not use any abrasive cleaners.
Cleaning
Adjustable Glass
The walls of the refrigerator are equipped with a built-in of runners so that
the shelves can be easily positioned as desired.
Adjusting the door bins
To permit storage of food package various sizes, the door balconies can be
placed at different heights. To make these adjustments proceed as follows:
gradually pull the bin in the direction of the arrows until it the bin in the comes
free, then reposition as required.
Daily use
8
Keep ventilation openings, in the appliance enclosure or built-in structure, clear of obstruction. Do not
use mechanical devices or other means to accelerate the defrosting process, other than those
recommended by the manufacturer.
Do not change or damage the refrigerant circuit.
Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.
During transportation and installation of the appliance, be certain that none of the components of the
refrigerant circuit have become damaged.
It is dangerous to alter the specifications or modify this product in any way.
Any damage to the cord may cause a short circuit, fire and/or electric shock.
This appliance is intended to be used in residential household, office or light commercial applications
such as Hotels and College Dorms.
All electrical components (plug, power cord, compressor and, etc.) must be replaced by a certified
service agent or qualified service personnel.
The refrigerant contained within the compressor of the appliance is isobutene (R600a) which is
environmentally friendly but flammable.
Make sure that the power cord is not crushed or damaged at the back of the appliance. A crushed or
damaged power cord may overheat and cause a fire.
The power cord must not be lengthened.
Make sure that you can come to the power cord of the appliance Do not pull the unit by the power cord.
If the electrical outlet is loose, do not insert the power plug. There is a risk of electric shock or fire.This
appliance is heavy. Care should be taken when moving it.
Do not remove or touch items from the freezer compartment if your hands are damp/wet, as this could
cause skin abrasions or frost/freezer burns.
Avoid prolonged exposure of the appliance to direct sunlight.
Locate the refrigerator away from direct sunlight and sources of heat (stove, heater, radiator, etc.).
Direct sunlight may affect the acrylic coating and heat sources may increase electrical consumption.
Ambient temperature below 50°F (10°C) or above 85°F (29.4°C) will hinder the performance of this
appliance. This unit is not designed for use in a garage or any other outside installation
Important Warning
9
You can solve many common refrigerator problems easily, saving you the cost of a possible service
call. Try the suggestions below to see if you can solve the problem before calling for service.
Problem Possible Causes
The refrigerator does not operate. •
The power cord is unplugged.
•
The circuit breaker is tripped/fuse blown.
The compressor turns on and off •
The room temperature is warmer than normal
•
A large amount of food has been added to the refrigerator.
•
The door is left open or is frequently opened.
•
The temperature control is not set correctly
•
The door is not closed completely.
•
The door gasket does not seal properly.
•
The refrigerator does not have the correct clearances.
•
The refrigerator has recently been disconnected for a period of time.
•
The temperature control is not set correctly.
•
The door is left open or is not set correctly.
•
The door gasket does not seal properly.
•
A large amount of warm or hot food was stored recently.
Wait for the refrigerator to reach its selected temperature.
•
The refrigerator has recently been disconnected for a for a while
•
The door is slightly open or is frequently opened.
•
The door is not sealed properly.
Bubbling or gurgling sounds.
(like boiling water)
•
This is the normal sound of refrigerant (used to cool the refrigerator)
circulating throughout the system
The door will not close properly. •
The refrigerator is not on a level surface.
•
The gasket is dirty.
•
A storage basket is out of position.
•This is normal. Metal parts undergo expansion and contraction. The sound will
level off or disappear as the refrigerator runs.
Popping or crackling sounds
when the compressor comes on.
The temperature inside the
refrigerator is too warm.
Vibrating or rattling.
(slight vibration is normal)
The temperature of the external of
the refrigerator's surface is warm •
The exterior refrigerator walls can be as much as 30°F warmer than room
temperature.
•
This is normal while the compressor works to transfer heat from inside the
refrigerator cabinet.
•
Levelling legs need adjusting.
•
Refrigerator is placed on an uneven or weak surface.
•
The refrigerator is touching the wall. Re-level the refrigerator and move it away from
the wall.
Moisture collects inside the refrigerator.
•
Is normal in hot and humid weather. Air carries moisture into the refrigerator when
doors are opened
Moisture forms on the
outside of refrigerator.
For any questions or concerns, please contact us at
[email protected] or visit us at www.stirlingmarathon.com
Troubleshooting
10
Dieses Handbuch passt für folgende Modelle
2
Inhaltsverzeichnis
Andere Marathon Kühlschrank Handbücher
Marathon
Marathon MAR86W Bedienungsanleitung
Marathon
Marathon MFF920WBM Montageanleitung
Marathon
Marathon MFF179WBM-LH Bedienungsanleitung
Marathon
Marathon MAR35SS Bedienungsanleitung
Marathon
Marathon MFF105WBM Bedienungsanleitung
Marathon
Marathon MFF120W Bedienungsanleitung
Marathon
Marathon MFF150W/BLS Bedienungsanleitung
Marathon
Marathon MAR45W Bedienungsanleitung
Marathon
Marathon MAR86BLS Bedienungsanleitung
Marathon
Marathon MFF182W Bedienungsanleitung
Marathon
Marathon MFF100BLS Bedienungsanleitung
Marathon
Marathon MCR47W Bedienungsanleitung
Marathon
Marathon MFF101W Bedienungsanleitung
Marathon
Marathon MFF180WFD Bedienungsanleitung
Marathon
Marathon MFF105SSBM Bedienungsanleitung
Marathon
Marathon MFF100W Bedienungsanleitung
Marathon
Marathon MFF180WFD-1 Bedienungsanleitung
Marathon
Marathon MCR44W Bedienungsanleitung
Marathon
Marathon MFF150W Bedienungsanleitung
Marathon
Marathon MAR46W Bedienungsanleitung
Beliebte Kühlschrank Handbücher anderer Marken
Bonnet Neve
Bonnet Neve SKYVIEW PLUS Bedienungsanleitung
Zanussi Electrolux
Zanussi Electrolux ZERB 8441 Bedienungsanleitung
Sharp
Sharp SJ-BA31IEXW2-EU Bedienungsanleitung
CORBERO
CORBERO CC2300MCW Bedienungsanleitung
KitchenAid
KitchenAid 2205264 Bedienungsanleitung
Stengel
Stengel KU 1101 A++ Bedienungsanleitung
