O W N E R S G U I D E

M A R V E L U N D E R C O U N T E R R E F R I G E R A T I O N

T H E O R I G I N A L R E F R I G E R A T I O N E X P E R T S S I N C E 1 8 9 2

F O R MO D E L # M L D R 2 2 4

Welcome to the Marvel Experience

Thank you for choosing our quality American-built product

to add to your home. We are thrilled to welcome you to

our growing community of Marvel owners, who trust in our

products and our support.

The information in this guide is intended to help you install

and maintain your new Marvel undercounter model to pro-

tect and prolong its lifetime. We encourage you to contact

our Technical Support team at (616) 754-5601 with any

questions.

Got a Marvelous Design?

We would love to see how your Marvel product looks in its

new home. Send us photos at marketing@marvelrefrigera-

tion.com, and we might feature your Marvel home design

on our website and social media!

XXXXXXXXXXXX

MARVEL

Figure 1

R600A

WELCOME

It is important you send in your warranty registration card

immediately after taking delivery of your appliance or you

can register online at www.marvelrefrigeration.com.

The following information will

be required when registering

your appliance.

Service Number

Serial Number

Date of Purchase

Dealer’s name and address

The service number and serial number can be found on the

serial plate which is located inside the cabinet on the left

side near the top. See gure 1.

Warranty Registration

Online registra-

tion available at

www.marvelrefrig-

eration.com

TABLE OF CONTENTS

Tip: Click on any section below to jump directly there

Safety

Important Safety Instructions

Installation

Unpacking Your Appliance

Electrical

Installing the anti-tip device

Drawer Divider

Integrated Panel Dimensions

Integrated Panel Installation

Maintenance

Care and Cleaning

Extended Non-Use

Operating Instructions

Energy Savng Tips

Service

Obtaining Service

Product Liability

Ordering Replacement Parts

R600a Specifications

System Diagnosis Guide

Compressor Specifications

Warranty

NOTE

!CAUTION

Important Safety Instructions

Warnings and safety instructions appearing in this guide

are not meant to cover all possible conditions and situa-

tions that may occur. Common sense, caution, and care

must be exercised when installing, maintaining, or operat-

ing this appliance.

Recognize Safety Symbols,

Words, and Labels.

CAUTION-Hazards or unsafe practices which could re-

sult in personal injury or property / product damage.

NOTE-Important information to help assure a problem

free installation and operation.

!WARNING

WARNING - You can be killed or seriously injured

if you do not follow these instructions.

!WARNING

State of California Proposition 65 Warning:

This product contains one or more chemicals known

to the State of California to cause cancer.

!WARNING

State of California Proposition 65 Warning:

This product contains one or more chemicals known

to the State of California to cause birth defects or

other reproductive harm.

!WARNING

WARNING - This unit contains R600a (Isobutane)

which is a ammable hydrocarbon. It is safe for regular

use. Do not use sharp objects to expedite defrosting.

Do not damage refrigerant circuit.

IMPORTANT SAFETY INSTRUCTIONS

NOTE

!CAUTION

!WARNING

WARNING - Dispose of the plastic bags which can

be a su󰀨ocation hazard.

!WARNING

WARNING - Help Prevent Tragedies

Child entrapment and su󰀨ocation are not problems of

the past. Junked or abandoned refrigerators are still

dangerous - even if they sit out for "just a few hours".

If you are getting rid of your old refrigerator, please fol-

low the instructions below to help prevent accidents.

Before you throw away your old refrigerator or freezer:

•Take o󰀨 the doors or remove the drawers.

• Leave the shelves in place so children may not

easily climb inside.

!WARNING

EXCESSIVE WEIGHT HAZARD

Use two or more people to move product.

Failure to do so can result in personal injury.

Remove Interior Packaging

Your appliance has been packed for shipment with all parts

that could be damaged by movement securely fastened.

Remove internal packing materials and any tape holding in-

ternal components in place. The owners manual is shipped

inside the product in a plastic bag along with the warranty

registration card, and other accessory items.

Important

Keep your carton and packaging until your appliance has

been thoroughly inspected and found to be in good condi-

tion. If there is damage, the packaging will be needed as

proof of damage in transit. Afterwards please dispose of all

items responsibly.

Note to Customer

This merchandise was carefully packed and thoroughly

inspected before leaving our plant. Responsibility for its

safe delivery was assumed by the retailer upon acceptance

of the shipment. Claims for loss or damage sustained in

transit must be made to the retailer.

DO NOT RETURN DAMAGED MERCHANDISE TO THE

MANUFACTURER - FILE THE CLAIM WITH THE

RETAILER.

If the appliance was shipped, handled, or stored in other

than an upright position for any period of time, allow the ap-

pliance to sit upright for a period of at least 24 hours before

plugging in. This will assure oil returns to the compressor.

Plugging the appliance in immediately may cause damage

to internal parts.

UNPACKING YOUR APPLIANCE

Electrical Connection

A grounded 115 volt, 15 amp dedicated circuit is required.

This product is factory equipped with a power supply

cord that has a three-pronged, grounded plug. It must be

plugged into a mating grounding type receptacle in accor-

dance with the National Electrical Code and applicable lo-

cal codes and ordinances (see Figure 4). If the circuit does

not have a grounding type receptacle, it is the responsibility

and obligation of the customer to provide the proper power

supply. The third ground prong should not, under any cir-

cumstances, be cut or removed.

Figure 4

NOTE

Ground Fault Circuit Interrupters (GFCI) are prone to nui-

sance tripping which will cause the appliance to shut down.

GFCI’s are generally not used on circuits with power equip-

ment that must run unattended for long periods of time, un-

less required to meet local building codes and ordinances.

ELECTRICAL

Figure 2

Do not remove

ground prong

Figure 3

Electrical Shock Hazard

• Do not use an extension cord with this appliance.

They can be hazardous and can degrade product

performance.

• This appliance should not, under any circumstanc-

es, be installed to an un-grounded electrical supply.

• Do not remove the grounding prong from the power

cord. (See Figure 2).

• Do not use an adapter. (See Figure 3).

• Do not splash or spray water from a hose on the

appliance. Doing so may cause an electrical shock,

which may result in severe injury or death.

!WARNING

INSTALLING THE ANTI TIP DEVICE

Step by step instructions for locating the po-

sition of the bracket:

1) Decide where you want to place the beverage center.



leaving 1" (2.5 cm) of clearance from the rear wall to allow

room for the anti-tip bracket.

¹" (6 mm) to

allow engagement with the anti-tip bracket. Level the unit

by adjusting all the leveling legs as required. Turning the

leveling leg counterclockwise will raise the unit and clock-

wise will lower the unit.

3) Make sure the beverage center is in the desired loca-



cabinet where the anti-tip bracket will be installed. If the

installation does not allow marking the rear corner of the





beverage center out of the way. From the temporary line

12" (54.6 cm) as shown in

Figure 15.



the side of the bracket lines up with the side of the cabinet

mark, and the "V" notches on the anti-tip bracket line up

with the end of the 2112" (54.6 cm) line (Rear of cabinet

line).



screw. (See Figure 15).

6) Slide the cabinet back into position, making sure the rear

cabinet leveling leg slides under the anti-tip bracket engag-

ing the slot.

Front of cabinet

Figure 14

2112"

(54.6 cm)

Anti-Tip

Bracket Leveling Leg

Bottom View of

Beverage

Center

Floor Mount Installation



or right rear corner of the wine cellar as shown in Figure 14.

!WARNING

• ALL APPLIANCES CAN TIP

RESULTING IN INJURY.

• INSTALL THE ANTI-TIP

BRACKET PACKED WITH

THE APPLIANCE.

• FOLLOW THE INSTRUC-

TIONS BELOW

!CAUTION

NOTE



material to avoid damage when moving the unit.



required, (not included with the anti-tip kit).

Anti-Tip Device

!WARNING

If your beverage center is not located under a counter

top (free standing), you must use an anti-tip device

installed as per these instructions. If the beverage

center is removed from its location for any reason,

make sure that the device is properly engaged with

the anti-tip bracket when you push the beverage

center back into the original location. If the device is

not properly engaged, there is a risk of the beverage

center tipping over, with the potential for property dam-

age or personal injury.

NOTE

INSTALLING THE ANTI TIP DEVICE

-

mum adjusted height of the cabinet is increased by

38" (9 mm).

Figure 15a

"V" notches

in bracket

"V" notches

in bracket

Figure 15

2112"

(54.6 cm)

Front of cabinet line

Rear Leveling leg

Side of cabinet line

Rear of cabinet line

Screw

Drawer Divider

The top and bottom drawer have an adjustable drawer

divider. To adjust the divider, making the 4 areas larger or

smaller, move the center post along the length of the rods

in either direction. See Figure 16 and 16a. The divider can

also be removed from the drawer.

Move rods within

center post

Figure 16a

Figure 16

Top drawer

"V" notches

in bracket

DRAWER DIVIDER

1429⁄32"

(379 mm)

Panel

thickness

117⁄8"

(302 mm)

11⁄32"

233⁄4"

(603 mm)

INTEGRATED PANEL DIMENSIONS

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Marvel Kühlschrank Handbücher

Marvel

Marvel MACL215-IS01A Bedienungsanleitung

Marvel

Marvel MPFZ424-IS31A Bedienungsanleitung

Marvel

Marvel MLCR215 Bedienungsanleitung

Marvel

Marvel MPWD424-IS31A Bedienungsanleitung

Marvel

Marvel MOKR224 Bedienungsanleitung

Marvel

Marvel MLRE124-SS21A Bedienungsanleitung

Marvel

Marvel MLBD224-SS01A Bedienungsanleitung

Marvel

Marvel MODR224-SS71A Bedienungsanleitung

Marvel

Marvel MLRE124 Bedienungsanleitung

Marvel

Marvel 60RDE Bedienungsanleitung

Marvel

Marvel MLCL215-SG01A Bedienungsanleitung

Marvel

Marvel 61WC-BB-G Leitfaden

Marvel

Marvel MLBV224-IG01A Bedienungsanleitung

Marvel

Marvel MLRF224-SS01A Bedienungsanleitung

Marvel

Marvel 60ARM-SS-F Bedienungsanleitung

Marvel

Marvel MLBV215-IG01A Bedienungsanleitung

Marvel

Marvel MLRE024 Bedienungsanleitung

Marvel

Marvel 8SBARE-BB-G Bedienungsanleitung

Marvel

Marvel 61WCM-BD Bedienungsanleitung

Marvel

Marvel MPBV415SS31A Bedienungsanleitung

Marvel

Marvel 30WC-BB-G Bedienungsanleitung

Marvel

Marvel 80RF-BB-F Handbuch

Marvel

Marvel MLBD224-SG01A Bedienungsanleitung

Marvel

Marvel 3SBARE-BB-G Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
