Mastech MS6813 Bedienungsanleitung

MASTECH®

MS6813

Multi Function Network Cable Tester

Users Manual

Table of Contents

LIMITED WARRANTY AND LIMITATION OF LIABILITY .................................................................. 1

Out of Box ....................................................................................................................................................... 2

Safety Information........................................................................................................................................ 2

Using the Tester............................................................................................................................................. 3

1. INTRODUCTION.................................................................................................................... 4

1.1 MS6813 Features..................................................................................................................... 4

1.2 Components and Buttons......................................................................................................5

2. USING THE TESTER................................................................................................................ 8

2.1 Network Cable Testing........................................................................................................... 8

2.1.1 Error Indicator............................................................................................................................. 8

2.1.2 Test Mode.......................................................................................................................................9

2.1.3 Debug Mode ...............................................................................................................................10

2.2 Coaxial Cable Testing...........................................................................................................11

2.3 Continuity Testing.................................................................................................................11

Mastech MS6813 Multi Function Network Cable Tester

2.4 Network Cable Tracking .....................................................................................................12

2.3.1 Sending Audio Frequency Signal: ........................................................................................12

2.3.2 Tracking Network Cable.........................................................................................................12

2.5 Telephone Line Modes Testing........................................................................................................13

2.5.1 Differentiate TIP or RING wire:............................................................................................13

2.5.2 Determine Idle, Vibrate or in use (off-hook):..................................................................13

3. MAINTENANCE AND REPAIR............................................................................................13

3.1 Battery Replacement.............................................................................................................13

4. CONTACT MASTECH............................................ERROR! BOOKMARK NOT DEFINED.

Thank you for purchasing Mastech MS6813 Multi Function Network Cable Tester. Please

read the Users Manual carefully to be familiar with the Tester. For more information,

please visit our website at http://www.mastech.cn.

TO AVOID POSSIBLE ELECTRIC SHOCK OR PERSONAL INJURY:

Use the Tester only as specified in this manual or the protection provided by the Tester

might be impaired.

Do not place the Tester near explosive gas or vapor.

Read the Users Manual before use and follow all safety instructions.

LIMITED WARRANTY AND LIMITATION OF LIABILITY

This MS6813 product from Mastech will be free from defects in material and

workmanship for one year from the date of purchase. This warranty does not cover fuses,

disposable batteries, or damage from accident, neglect, misuse, alteration, contamination, or

abnormal conditions of operation or handling. Resellers are not authorized to extend any

other warranty on Mastech’s behalf. To obtain service during the warranty period, contact

your nearest Mastech authorized service center to obtain return authorization information,

then send the product to that Service Center with a description of the problem.

Mastech MS6813 Multi Function Network Cable Tester

Out of Box

Check the Tester and accessories thoroughly before using the Tester. Contact your local

distributor if the Tester or any components are damaged or malfunction.

Accessories

One Users Manual

1 9V 6F22 Battery

Safety Information

WARNING

TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK, PRODUCT DAMAGE OR PERSONAL

INJURY, PLEASE FOLLOW THE SAFETY INSTRUCTIONS DESCRIBED IN THE USER

MANUAL. READ THE USER MANUALS BEFORE USING THE TESTER.

WARNING

DO NOT PLACE THE TESTER IN ANY ENVIRONMENT OF HIGH PRESSURE, HIGH

TEMPERATURE, DUST, EXPLOSIVE GAS OR VAPOR. TO ENSURE SAFE OPERATION AND

LIFE OF THE TESTER, FOLLOW THESE INSTRUCTIONS

Safety Symbols

Important safety message

Conforms to relevant European Union directives

Mastech MS6813 Multi Function Network Cable Tester

Warning Symbols

Warning

Risk of danger. Important information. See Users Manual

Caution

Statement identifies conditions and actions that fail to follow the

instructions could result false reading, damage the Tester or the

equipment under test.

Using the Tester

WARNING

TO AVOID ELECTRICAL SHOCK AND INJURY, COVER THE TESTER WITH PROTECTIVE

COVER WHEN NOT IN USE.

Caution

1. Operate the Tester between 0~50°C (32~122°F).

2. Avoid shaking, dropping or taking any kind of impacts when

using or transporting the Tester.

3. To avoid possible electric shock or personal injury, repairs or servicing not covered in this

manual should be performed only by qualified personnel.

4. Check the terminals every time before operate the Tester. Do not operate the Tester if the

terminals are damaged or one or more functions are not working properly.

5. Avoid exploring the Tester to direct sunlight to ensure and extend the life of the Tester.

6. Do not place the Tester in strong magnetic field, it may cause false readings.

7. Use only the batteries indicated in the Technical Spec.

8. Avoid exploring the battery to humidity. Replace the batteries as soon as the low battery

indicator appears.

9. Sensitivity of the Tester toward temperature and humidity will be lower over time. Please

calibrate the Tester periodically for best performance

10. Please keep the original packing for future shipping purpose (ex. Calibration)

Mastech MS6813 Multi Function Network Cable Tester

1,Introduction

MS6813 is a hand held network cable tester, ideal for Coaxial Cable (BNC), UTP and STP

Cable installation, measurement, maintenance or inspection. It also offers a fast and

convenient way of testing telephone line modes, greatly simplifies telephone line installation

and maintenance.

1.1 MS6813 Features

Self implement T568A, T568B, 10Base-T and Token Ring cables testing.

UTP and STP co-axial cable testing.

Network integrity and configuration examination.

Open/ shorts circuit, miss wiring, reversals, and split pairs testing.

Network Continuity testing.

Cable open/short point tracing.

Receive signals in the network or telephone cable.

Transmitting signal to target network and tracing cable direction.

Detect telephone line modes : ideal, vibrate, or in used (off-hook)

Mastech MS6813 Multi Function Network Cable Tester

1.2 Components and Buttons

A．Transmitter (main)

B．Receiver

C．matching box (remote)

Mastech MS6813 Multi Function Network Cable Tester

1. Power Switch

2. Power Indicator

3. “BNC” Coaxial Cable Test Button

4. Coaxial Cable Indicator

5. Function Switch

6. “CONT” Indicator

7. “TONE” Indicator

8. “TEST” Network Cable Test Button

9. Short Circuit Indicator

10. Reversed Indicator

11. Miswired Indicator

12. Split Pairs Indicator

13. Wire Pair 1-2 Indicator

14. Wire Pair 3-6 Indicator

15. Wire Pair 4-5 Indicator

16. Wire Pair 7-8 Indicator

17. Shield Indicator

18. “RJ45” Adaptor

19. “BNC” Adaptor

20. “RJ11” Adaptor

21. Red Lead

22. Black Lead

23. “RJ45” Transmitter Socket

24. Receiver Probe

25. Receiver Sensitivity Knob

26. Receiver Indicator

27. Receiver Power Switch

Mastech MS6813 Multi Function Network Cable Tester

28. Remote “BNC” Socket

29. Remote “RJ45” Socket

1. Using the Tester

1.1 Network Cable Testing

WARNING

TO AVOID ELECTRICAL SHOCK AND INJURY, UNPOWER THE CIRCUIT WHILE

PERFORMING TESTS

1.1.1 Error Indicator

1.1.2 A wire pair indicator flashes (indicator #13,14,15,16) indicates an error in the

connection. Error indicator flashes specify an error. If more than one wire pair indicator

flashes, troubleshoot on each case until all the indicators go back to GREEN(Normal).

Fig.1 SHORT

Fig.2 MISWIRE

Fig.3 REVERSED

Fig.4 SPLIT PAIRS

Mastech MS6813 Multi Function Network Cable Tester

Open Circuit: Open Circuit is not commonly seen and therefore no indication is included in

the Tester. Typically there are 2 to 4 coaxial cables pairs in the network. Corresponding

indicators are off if RJ45 sockets are not connected with coaxial cable pairs. User debugs the

network with the wire pair indicators accordingly.

Short Circuit: shown in Fig.1.

Miswired: shown in Fig. 2: two pairs of wires are connected to wrong terminals.

Reversed: shown in Fig.3: Two wires within the pair are reversely connected to the pins in the

remote.

Split Pairs: shown in Fig.4: Split pairs occurs when the tip (positive conductor) and ring

(negative conductor) of two pairs are twisted and interchanged.

Note:

The Tester only shows one type of error per test. Fix one error first then make sure to perform

the test again to check other possible errors.

Test Mode

Follow the steps:

a) Connect one of the wires to RJ45 transmitter socket.

b) Connect the other end to RJ45 receiver socket.

c) Turn the Tester power on.

d) Press “TEST” button once to start testing.

e) During the test press “TEST” button again to stop testing.

Example: wires pair 1-2 and pair 3-6 are short circuit. In test mode, the error indicators will

show as following:

1-2 and 3-6 indicators flash green lights, short circuit indicator flash red

light.

4-5 indicator shows green lights (no error)

7-8 indicator shows green lights (no error)
