OPERATION MANUAL

FVS25 Vibratory screed

Machine

P E R F O R M A N C E · E F F I C I E N T · R E L I A B L E

Henan Master Machinery Co., Ltd

Tel:(+86)17737606271 www.mastermachinerys.com

Master sincerely thanks you for selecting the Concrete

Cutting Machine. For your Safety and proper operation,

before you start to operate or carry out any maintenance on

this equipment, YOU MUST READ and STUDY this manual

carefully. Be sure to always keep it ready for reference.

Produced By Henan Master Machinery Co.,Ltd

Dear Customer,

Thanks for choosing Master machine.

To ensure the safety and proper use of the machine,

please read the instruction book carefully before use.

Also, please fill this card and save it for warranty use.

Buyer Name

Purchase

Time

Tel

Contact

Person

Address

Product

Name

Vibratory screed Machine

MODEL

FVS25

Motor Model

Note

Henan Master Machinery Co., Ltd

Tel:(+86)17737606271 www.mastermachinerys.com

Maintenance record

Preventative maintenance and routine service plan

This vibratory screed has been assembled with care and will provide

years of service. Preventative maintenance and routine service are

essential to the long life of your Master Vibratory screed. Your dealer is

interested in your new trowel and has the desire to help you get the

most value from it. After reading through this manual thoroughly you will

find that you can do some of the regular maintenance yourself. However,

when in need of parts or major service be sure to see your Master

dealer. For your convenience we have provided this space to record

relevant data about your ride-on Trowel. When in need of parts or

service be prepared to provide your trowel serial number. Locate the

serial number now and record in the space below.

FOREWARD

◇For your own safety and protection from bodily injuries, carefully read, understand

and follow the safety instructions in this manual.

◇Please operate and maintain your machine in accordance with the instructions in

this manual.

◇Defective machine parts are to be replaced as soon as possible.

◇Keep this owner's manual handy, so you can refer to it at any time.

◇No part of this publication may be reproduced without written permission.

◇We expressly reserve the right to technical modifications- even without express

due notice - which aim at improving our machines or their safety standards.

APPLICATION

This screed is a modern, high production machine intended to provide accurate

strike-off of concrete slabs with or without the support of grade stakes or forms. The

vibrations produced by the eccentric weight are equally transmitted along the beam

length and will provide adequate consolidation of unreinforced slabs up to eight

Henan Master Machinery Co., Ltd

Tel:(+86)17737606271 www.mastermachinerys.com

inches in depth. Multiple blade lengths and variable exciter weight positions allow

for optimum compaction and production of the slab placement.

SAFETY PRECAUTIONS

1. Before starting operation, the operator has to check that all control and safety

devices function properly.

2. NEVER allow anyone to operate this equipment without proper training. People

operating this equipment must be familiar with the risks and hazards associated

with it.

3. NEVER touch the engine or muffler while the engine is on or immediately after it

has been turned off. These areas get hot and may cause burns.

4. NEVER operate this machine in applications for which it is not intended.

5. ALWAYS wear protective clothing appropriate to the job site when operating

equipment.

6. ALWAYS remain aware of moving parts and keep hands, feet, and loose clothing

away from the moving parts of the machine.

7. ALWAYS operate the machine with all safety devices and guards in place and

in working order.

OPERATOR SAFETY WHILE USING INTERNAL COMBUSTION

ENGINES

Danger! Internal combustion engines present special hazards during operation and

fueling. Read and follow the warning instructions in the engine owner’s manual and

the safety guidelines below. Failure to follow the warnings and safety guidelines

could result in severe injury or death.

1. DO NOT run the machine indoors or in an enclosed area such as a deep trench

unless adequate ventilation, through such items as exhaust fans or hoses, is

provided. Exhaust gas from the engine contains poisonous carbon monoxide gas;

exposure to carbon monoxide can cause loss of consciousness and may lead to

Henan Master Machinery Co., Ltd

Tel:(+86)17737606271 www.mastermachinerys.com

death.

2. DO NOT smoke while operating the machine.

3. DO NOT smoke when refueling the engine.

4. DO NOT refuel a hot or running engine.

5. DO NOT refuel the engine near an open flame.

6. DO NOT run the engine near open flames.

7. ALWAYS refill the fuel tank in a well-ventilated area.

8. ALWAYS replace the fuel tank cap after refueling.

9. ALWAYS check the fuel lines and the fuel tank for leaks and cracks before

starting the engine. Do not run the machine if fuel leaks are present or the fuel

lines are loose.

SERVICE SAFETY

Warning! Poorly maintained machines can become a safety hazard! In order for the

machine to operate safely and properly over a long period of time, periodic

maintenance and occasional repairs are necessary.

1. DO NOT attempt to clean or service the machine while it is running. Rotating

parts can cause severe injury.

2. DO NOT crank a flooded engine with the spark plug removed on

gasoline-powered engines. Fuel trapped in the cylinder will squirt out the spark

plug opening.

3. DO NOT test for spark on gasoline-powered engines if the engine is flooded or

the smell of gasoline is present. A stray spark could ignite the fumes.

4. DO NOT use gasoline or other types of fuels or flammable solvents to clean parts,

especially in enclosed areas. Fumes from fuels and solvents can become

explosive.

5. ALWAYS keep the area around the muffler free of debris such as leaves, paper,

cartons, etc. A hot muffler could ignite the debris and start a fire.

6. ALWAYS keep the machine clean and labels legible. Replace all missing and

Henan Master Machinery Co., Ltd

Tel:(+86)17737606271 www.mastermachinerys.com

hard-to-read labels. Labels provide important operating instructions and warn of

dangers and hazards.

7. ALWAYS check all external fasteners at regular intervals.

8. ALWAYS handle blades carefully. The blades can develop sharp edges which

can cause serious cuts.

9. ALWAYS turn engine off before performing maintenance or making repairs.

OPERATION

BEFORE STARTING & OPERATING

◇REMEMBER! It is the owner’s responsibility to communicate information on the

safe use and proper operation of this unit to the operators.

◇Review ALL of the Safety Precautions listed on page 2 of this manual.

◇Familiarize yourself with the operation of the machine and confirm that all

controls function properly.

◇Know how to STOP the machine in case of an emergency.

◇Make sure hands, feet, and clothing are at a safe distance from any moving

parts.

◇OIL LEVEL - Check the oil level in the engine. For more information see

“Lubrication” under the respective engine’s “Owners Manual” or the

Maintenance section of this manual.

◇AIR CLEANER - Check to ensure element is in good condition and properly

installed.

◇FUEL SUPPLY - The engine requires regular grade unleaded gasoline. Use only

fresh, clean gasoline. Gasoline containing water or dirt will damage fuel system.

Consult engine Owner’s Manual for complete fuel specifications.

◇FUEL FILTER - If clogged or damaged, replace.

STARTING ENGINE

1. Turn engine switch to “ON”.

Henan Master Machinery Co., Ltd

Tel:(+86)17737606271 www.mastermachinerys.com

2. Press the primer bulb repeatedly until fuel can be seen in the clear plastic return

tube.

3. Choke engine if necessary (you may not need to choke a warm engine).

4. Pull starter rope repeatedly until engine starts.

5. If choke was moved to the closed position to start, gradually move it to the open

position as the engine warms up.

6. Allow engine to warm up for one or two minutes.

STOPPING ENGINE

1. Move throttle to idle position.

2. Let engine idle for one or two minutes.

3. Turn switch on engine to “STOP” position.

4. Turn off fuel valve

Warning! Always stop the engine before:

1. Adding fuel.

2. Leaving the equipment unattended for any amount of time.

3. Before making any repairs or adjustments to the machine.

Warning! Never run the Screed above idle when the float blade is not in contact

with concrete. This can damage the float blade.

USER SCREED

The Screed can be used with or without forms. The following describes the use of

the Screed without forms.

1. Use a hand float to make a 300-500mm diameter wet pad (A) at the desired

grade in the four corners of the area you wish to screed. The outer extents of

the wet pads should not exceed the length of the float blade being used.

NOTE: Use a laser receiver, transit level, or grade stakes to help establish the

correct grade.

Henan Master Machinery Co., Ltd

Tel:(+86)17737606271 www.mastermachinerys.com

2. Run the Screed between the wet pads to create two parallel strips (B) that define

the grade for the remainder of the wet screeding. These strips should be 300-500

wide.

2. Place one end of the float blade on each of the parallel strips (B) and screed

the concrete (C) in between the strips. Be sure the float blade follows the

contour of the parallel strips

Henan Master Machinery Co., Ltd

Tel:(+86)17737606271 www.mastermachinerys.com

TRANSPORTING

It is recommended to transport the Screed with the float bar removed. The float

bar is more likely to be damaged if attached to the main unit during transport.

STORAGE

The following steps should be taken to prepare your Screed for extended storage.

1. Close fuel shut off valve.

2. Siphon excess gasoline from tank.

3. Start engine until it stops from lack of fuel. This will use up all the fuel in the

carburetor and prevent formation of deposits due to evaporation of fuel.

4. Remove spark plug and pour 2 oz. of SAE-30 or SAE-40 motor oil into the

cylinder. Slowly crank the engine 2 or 3 times to distribute the oil throughout the

cylinder. This will help prevent rust during storage. Replace spark plug.

5. Store the unit in an upright position in a cool, dry, well ventilated area.

MAINTENANCE SCHEDULE

Henan Master Machinery Co., Ltd

Tel:(+86)17737606271 www.mastermachinerys.com

Item

Maintenance

Each

use

Every

hours

Every

100

hours

Each

year

Engine

Refer to engine

operator/owner

manual

Part

Check and

tighten as

needed

Shockmount

Check for cracks

or tears

ENGINE MAINTENANCE

Refer to the engine owner’s manual for maintenance intervals and procedures.

ENGINE SPEED

The idle speed of the engine should not exceed the following:

Honda - 3500 rpm

Robin - 2000 rpm

If the idle speed is greater the clutch may not disengage. Check engine owner’s

manual for procedure on setting idle speed.

CLEANING

Clean any concrete from the Screed immediately after each use. DO NOT allow

concrete to harden on the screed.

1. Use a hose to remove any excess concrete.

2. Remove any buildup with hard plastic bristle brush.

NOTE: DO NOT use a wire brush, hammer, or pressure washer to remove concrete

from the main unit or float blade.

3. Remove the blade.

Inhaltsverzeichnis

Andere Master Elektrowerkzeuge Handbücher

Master

Master BLP 15 kW M Bedienungsanleitung

Master

Master RW 160 Bedienungsanleitung

Master

Master PROHEAT STC PH-1600 Bedienungsanleitung

Master

Master B35CEL Handbuch

Master

Master VARITEMP VT-752C Bedienungsanleitung

Master

Master Proheat PH-1000 Bedienungsanleitung

Master

Master B 45SMS Handbuch

Master

Master EH 4 Bedienungsanleitung

Master

Master EC-200 Bedienungsanleitung

Master

Master BV 500-13 Handbuch

Master

Master BS 12-A solid Bedienungsanleitung

Master

Master BLP 33E Bedienungsanleitung

Master

Master Heat Gun HG-801D Series Bedienungsanleitung

Master

Master PROHEAT PH-1400A Bedienungsanleitung

Master

Master RS 30 Handbuch

Master

Master EM-007 Bedienungsanleitung

Master

Master HG-201A Bedienungsanleitung

Master

Master FPC90 Bedienungsanleitung

Master

Master ULTRATORCH UT-50 Bedienungsanleitung

Master

Master RS 30 Handbuch

Master

Master B 130 Handbuch

Master

Master DG307 Bedienungsanleitung

Master

Master VT D Series Bedienungsanleitung

Master

Master 17 Gebrauchsanweisung

Beliebte Elektrowerkzeuge Handbücher anderer Marken

AEG

AEG OMNI-JS Bedienungsanleitung

SIP

SIP 01533 Bedienungsanleitung

Ribimex

Ribimex PRS499 Bedienungsanleitung

3M Fiber Optic Connector Crimp Tool Bedienungsanleitung

Ryobi

Ryobi P524 Bedienungsanleitung

ROJEK

ROJEK FSN 300A Bedienungsanleitung

Kemper

Kemper 1740PRO Bedienungsanleitung

WABCO

WABCO OptiTire Bedienungsanleitung

EINHELL

EINHELL TE-MS 18/210 Li Bedienungsanleitung

Orgapack

Orgapack OR-T 85 Kurzanleitung

TOUGHCUT

TOUGHCUT Diamond 400 Bedienungsanleitung

Yaros

Yaros PB-3603 Bedienungsanleitung

Fein

Fein BSS 2.0 E Einrichtungshandbuch

Baileigh Industrial

Baileigh Industrial SS-2725 Bedienungsanleitung

Milwaukee

Milwaukee 2674-20 Bedienungsanleitung

Fein

Fein BLs 1.6 Bedienungsanleitung

Princess

Princess Electric Multi Sharpener Bedienungsanleitung

FOREDOM

FOREDOM K.1050 Handbuch
