MasterChef 1-Tap Kegerator Bedienungsanleitung
TM
Instruction Manual
Manuel d’instructions
1-Tap Kegerator™
Product no. 399-6488-6
Référence produit 399-6488-6
2
Product no. 399-6488-6
SAFETY TABLE OF CONTENTS
SAFETY 2
IMPORTANT SAFEGUARDS 3
ADDITIONAL IMPORTANT SAFEGUARDS 3
INTRODUCTION 5
PARTS 6
INSTALLING THE CASTORS 8
ASSEMBLY OVERVIEW 8
TAP TOWER INSTALLATION 9
ATTACHING COUPLER TO TAP TOWER 9
ATTACHING COUPLER TO REGULATOR 10
ATTACHING REGULATOR TO CO2TANK 10
COMPLETED CO2TANK INSTALLATION 11
TEMPERATURE GAUGE 12
INSTALLING THE GUARDRAIL / DRIP TRAY 12
TAPPING THE BEER KEG 13
SETTING THE REGULATOR 14
HOW TO OPERATE 16
CONVERT TO REFRIGERATOR 16
HELPFUL TIPS 17
CLEANING & MAINTENANCE 18
WARRANTY 19
SAFETY
Your safety and the safety of others is very important.
We have provided many important safety messages in this manual and on your appliance. Always read and
obey all safety messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can cause serious injury to you and others.
All safety messages will follow the safety alert symbol.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and
tell you what can happen if the instructions are not followed.
Appliance Specifications:
90 W, 115 V, 60 Hz
9H72
HOUSEHOLD REFRIGERATOR
3
TM
IMPORTANT SAFEGUARDS
IMPORTANT SAFEGUARDS
A person who has not read and understood all operating and safety instructions is not qualified to
operate this appliance. All users of this appliance must read and understand this Instruction Manual
before operating or cleaning this appliance.
When using electrical appliances, basic safety precautions should always be followed, including:
1. Read all instructions before operating this appliance.
2. DO NOT TOUCH the hot surfaces. Use handles or knobs.
3. This appliance is NOT A TOY.
4. Keep out of reach of children.
5. Unsupervised young children and cognitively challenged individuals should never operate this appliance.
6. Close supervision is necessary when any appliance is used by or near children.
7. To protect against electrical shock do not immerse cord, plug or any part of this unit in water or other liquids.
8. Do not operate this appliance when parts are missing or broken.
9. Unplug from outlet when not in use, before removing parts and before cleaning. Allow to cool before putting on
or taking off any parts, and before cleaning.
10. DO NOT operate any appliance with a damaged cord or plug, or after the appliance malfunctions, or if the
appliance has been damaged in any manner. Return the appliance to the nearest repair shop for examination,
repair or adjustment.
11. The manufacturer does not recommend the use of accessory attachments other than what is provided by the
manufacturer. Use of attachments may cause injuries.
12. DO NOT use the appliance for other than its intended use.
13. DO NOT use outdoors. FOR HOUSEHOLD USE ONLY.
14. DO NOT place on or near a hot gas or electric burner, or in a heated oven.
15. DO NOT put any parts of this appliance in dishwasher.
16. DO NOT let cord hang over edge of table or counter, or touch hot surfaces.
17. NEVER leave unit unattended while in use or when plugged into an outlet.
18. Always attach plug to appliance first, then plug cord in the wall outlet. To disconnect, turn any control to "off,"
then remove plug from wall outlet.
ADDITIONAL IMPORTANT SAFEGUARDS
Operating Safety Precautions
1. Before discarding your old appliance, remove the door from its hinges so that children do not easily
become trapped inside.
2. DO NOT roll this appliance with loaded beer kegs onto carpeted floor.
3. The appliance door must be closed during operation. DO NOT leave the door open when children are near.
4. This appliance should not be recessed or built into an enclosed cabinet. It is designed for freestanding
assembly only.
5. Do not operate your appliance in the presence of explosive fumes.
6. Do not tamper with the controls.
ADDITIONAL IMPORTANT SAFEGUARDS
4
Product no. 399-6488-6
ADDITIONAL IMPORTANT SAFEGUARDS
Instructions for the Electrical Cord and Plug
1. ELECTRICAL SHOCK HAZARD: Failure to follow these instructions can result in death, fire, or electrical shock.
•Plug into a grounded 3 prong outlet.
•DO NOT remove ground prong.
•DO NOT use an adaptor.
•DO NOT use an extension cord.
2. This unit MUST be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric
shock by providing an escape wire for the electric current. This unit is equipped with a cord having a grounding
wire with a grounding plug.
The plug must be plugged into an outlet that is properly installed and grounded.
3. WARNING: Improper use of the grounding plug can result in a risk of electric shock. If the plug does not fit
fully into the outlet, contact a qualified electrician. Do not attempt to modify the plug in any way.
4. A short power supply cord is provided to reduce the risk of becoming entangled or tripping over a long cord.
5. The manufacturer does not recommend using this machine in countries that do not support 120 V AC even if a
voltage adaptor, transformer, or converter is in use.
CO2(Carbon Dioxide) Gas
1. CO2gas can be dangerous! CO2cylinders contain high-pressure compressed gas, which can be hazardous if not
handled properly. Make sure you read and understand all the procedures for the CO2cylinders before installation.
2. Always connect the CO2cylinder to a regulator! Failure to do so may cause an explosion resulting in possible
death or injury when the cylinder valve is opened,
3. Never connect the CO2cylinder directly to the beer keg.
4. Always follow the correct procedures when changing the CO2cylinder.
5. Never drop or throw a CO2cylinder.
6. Always keep CO2cylinders away from heat. Store extra cylinders in a cool place (preferably 21°C/ 70°F). Fasten
securely with a chain when storing in an upright position.
7. ALWAYS ventilate and leave the area immediately if CO2leakage has occurred.
8. There are two safety devices in the pressure system in the form of a valve. One safety feature is on the CO2
bottle. The second is on the regulator.
9. Never attempt to refill CO2cylinder yourself.
10. IMPORTANT! If the refrigerator has been placed in a horizontal or tilted position for any period of time, wait 8
hours before plugging in the unit.
SAVE THESE INSTRUCTIONS!
5
TM
INTRODUCTION
Sixth Barrel
23 3/8"
59.4 cm
9 1/4"
23.5 cm
13 7/8"
35.5cm
16 1/8"
41 cm
23 3/8"
59.4 cm
11 1/8"
28.3 cm
23 3/8"
59.4 cm
16 1/8"
41 cm
INTRODUCTION
Great for serving even the thirstiest crowd, this appliance keeps the beer flowing and the good times rolling. This unit
adds a unique element to backyard barbecues, garage hangouts, recreation rooms, or simply relaxing at home.
Proper Location
To ensure that your appliance works to the maximum efficiency for which it was designed, keep it in a location where
there is proper air circulation and electrical outlets. Choose a location where this appliance will be away from heat and
will not be exposed to direct sunlight.
•Indoor use only. It should not be used outdoors.
•Designed to be freestanding and should not be placed in a built-in or recessed area.
•Unit includes a 2.5 lb. CO2bottle, which should be able to dispense two to four 15 gallon kegs of beer.
•Capacity: 4.9 cu. ft.
•Unit dimensions: 20 x 24 ¾ x 48 ½"(51 x 63 x 123.3 cm)
•The following dimensions are recommended for clearances around the this appliance:
Sides …………………… ¾” (19 mm)
Back ……………………. 1” (25 mm)
•Unit weight: 87 lbs 8 oz
Compatible Keg Types
The appliance can hold one Barrel full-size Keg, or one Pony Keg, or two 5-Gallon Kegs. DOES NOT fit
non-standard keg sizes.
NOTE: Keg Coupler only fits D-Sankey Keg Valves. Attaching the Keg Coupler will add height to the Keg.
Quarter Barrel
(Pony Keg) Slim Quarter Barrel
(Tall Keg) ½ Barrel
(Full Size)
Kegs Barrel ¼ Barrel Short ¼ Barrel Slim ½ Barrel
Gallons 5.23 7.75 7.75 15.50
Keg Capacity 1 1 1 1
12 oz. Beers 55 82 82 165
Weight (Full) 58 lb
26.3 kg
87 lb
39.5 kg
87 lb
39.5 kg
161 lb
73 kg
6
Product no. 399-6488-6
PARTS
PARTS
Read all instructions carefully before assembling this appliance.
IMPORTANT! Stand this appliance in an upright position for 8-10 hours before plugging into an electrical outlet.
This will allow the coolant in the refrigeration unit to stabilize before turning on the power.
If still unsure whether your appliance has been properly assembled, it is recommended that you contact customer
service, or a qualified installer, such as a brewery or wherever kegs are sold.
Washers / Beer Line Adaptor Parts
NOTE: Most washers are already attached to this appliance. Extra parts are included in a plastic bag. Refer to the
parts diagram and corresponding part numbers to understand where each washer / extra parts belong.
Hose Clamps
(Part 4)
Body Seal Coupler
Washer (38 mm)
(Part 5)
Probe Seal Coupler
Washer (22 mm)
(Part 5)
Tap Tower
Washer (24 mm)
(Part 1)
Spigot Handle
Washer (15 mm)
(Part 2)
Inner Probe Seal
Coupler Washer
(23 mm)
(Part 5)
Tap Tower Spigot
Washer (13 mm)
(Part 3)
Top Coupler Washer
(20 mm)
(Part 5)
Regulator High Pressure
Washer (18 mm)
(Part 6)
CO2Hole Plug
(Exterior Cabinet)
CO2Directional
Washer
(Part 5)
Metal Washer
Qty. 2
(Part 11)
Backflow Stopper
(Part 5)
Tap Tower Washer
(Part 1)
7
TM
Parts
2 4
3
1
5
9
13
6
10
11
7
15
8
12
14
(1) Tap Tower
Qty. 1
(2) Spigot Handle
Qty. 1
(6) Regulator
Qty. 1
(5) Keg Coupler
(US Sankey D-System)
Qty. 1
(3) Tap Tower Spigot
Qty. 1
(7) CO2Tank Holder
Qty. 1
(10) Tap Tower
Wrench
Qty. 1
(9) Top Cabinet Plug
Qty. 1
(13) Wire Shelf
Qty. 2 (14) Guard Rail
Qty. 1
(4) CO2Line
Qty. 1
(8) CO2Tank
(unfilled)
Qty. 1
(11) Front Locking
Castors
Qty. 2
(15) Drip Tray
Qty. 1
(12) Rear Non-
Locking Castors
Qty. 2
PARTS
8
Product no. 399-6488-6
ASSEMBLY OVERVIEW INSTALLING THE CASTORS
Unlocked Locked
Tap Tower
CO2Line
Keg Coupler
CO2Tank
INSTALLING THE CASTORS
NOTE: Each of the Front Castors include a locking mechanism to ensure the unit does not roll on hard floors. The
Front Castors should be fastened at the front end of the unit, with the Non-Locking Rear Castors fastened on the
rear end.
1. Empty the inside of the cabinet and lay the unit down on its side. To prevent
dents or scratches, we recommend placing a piece of cardboard or cloth
underneath the cabinet.
2. For the Front Castors, place Metal Washers over the Castor bolts, then insert
the Castors into the holes on the bottom corners of the cabinet. (The Rear
Castors do not require Metal Washers.) Tighten each Castor by turning each
metal bracket clockwise.
3. Once all four Castors have been tightened, stand the cabinet in the upright
position.
Locking The Front Castors
ASSEMBLY OVERVIEW
Regulator
9
TM
ATTACHING COUPLER TO TAP TOWER TAP TOWER INSTALLATION
1. Remove & discard
Insert (rounded
side down)
2.
Tap Tower
3.
3.
1.
TAP TOWER INSTALLATION
Remove all packing tape from the Tap Tower.
2.
ATTACHING COUPLER TO TAP TOWER
Remove the packing spring and Backflow
Stopper from inside the Keg Coupler, then
reinsert the Backflow Stopper into the
Keg Coupler (rounded side down).
Remove the black packing cap from
the top of the Coupler, then place the
Top Coupler Washer flush and centred
on the top of the Keg Coupler.
After the Tap Tower has been placed
on top the cabinet and the hose line
feeds through the bottom, attach the
wing nut to the Keg Coupler.
Guide the Tap Tower Washer up the tap tower
hose and let it sit on the top of the cabinet.
Then feed the tap tower hose through the hole
in the top of the cabinet.
Align the notches at the bottom of the tower
with the hole in the top of the cabinet, then
insert and twist the tower clockwise to lock it
into place (about a ¼ turn).
Tap Tower Washer
10
Product no. 399-6488-6
ATTACHING REGULATOR TO CO2TANK
ATTACHING COUPLER TO REGULATOR
3.
2.
1.
2.
Hose
Clamp
ATTACHING COUPLER TO REGULATOR
1.
ATTACHING REGULATOR TO CO2TANK
IMPORTANT! When you purchase your first keg of beer, you must also have your CO2Tank filled by a local supplier.
CO2Tanks can be filled at locations such as welding supply shops, party stores, and wherever kegs are purchased.
If not already inserted, insert the CO2
Directional Washer into the Keg Coupler.
Then screw the CO2Line onto the Keg
Coupler.
Push the other end of the CO2Line through
the hole in the rear of the cabinet. Slide a Hose
Clamp onto the end of the CO2Line, then attach
the hose to the barb fitting on the bottom of the
regulator. Secure the CO2Line by tightening the
Hose Clamp with a flathead screwdriver.
Align and hook the 4 holes of the
CO2Tank Holder with the screws
on the back of the unit.
4.
Use an adjustable wrench
(not included) to attach the
Regulator to the CO2Tank.
Place the CO2Tank into the
CO2Tank Holder.
Make sure the white nylon High
Pressure Washer (already installed)
is attached to the Regulator.
Dieses Handbuch passt für folgende Modelle
1
Inhaltsverzeichnis
Sprachen:
Andere MasterChef Küchengerät Handbücher
