MasterCraft 055-6767-0 Bedienungsanleitung

IMPORTANT:

Please read this manual carefully before using

this mitre saw and save it for reference.

Model no. 055-6767-0

INSTRUCTION

MANUAL

Dual-beveling Sliding Compound Mitre Saw

with Laser Line

model no. 055-6767-0 | contact us 1-800-689-9928

TABLE OF CONTENTS

NOTE: If any parts are missing or damaged, or if you have any

questions, please call our toll-free helpline at 1-800-689-9928.

SAVE THESE INSTRUCTIONS

This manual contains important safety and operating instructions.

Read all instructions and follow them with use of this products.

TABLE OF CONTENTS

QUICK START GUIDE 4

SYMBOLS 6

SPECIFICATIONS 7

SAFETY GUIDELINES 8

ACCESSORIES AND ATTACHMENTS 15

TOOLS NEEDED FOR ASSEMBLY 17

CARTON CONTENTS 18

KNOW YOUR SLIDING MITRE SAW 19

ASSEMBLY 21

ADJUSTMENTS 29

OPERATION 38

MAINTENANCE 55

TROUBLESHOOTING GUIDE 58

REPLACEMENT PARTS 60

WARRANTY 64

model no. 055-6767-0 | contact us 1-800-689-9928

Read and understand the instruction manual to get the best use of the dual-bevel

sliding compound mitre saw.

Make sure the all accessories and the

blade are installed correctly and are

tight before operating the saw.

NOTE: The blade has been installed

in the mitre saw at the factory.

Recheck and adjust the alignment of

the blade before cutting if necessary.

Place hands at least 7 1/2" (19 cm)

away from the path of the blade—

out of the “no-hands zone.”

7 1/2”

(19 cm)

7 1/2”

(19 cm)

Use the hold-down clamp to hold the

workpiece firmly against the fence

to prevent movement towards the

blade. It is safer than using your hand

and it frees both hands to operate

the mitre saw.

QUICK START GUIDE

Turn the laser guide on for

pre-alignment of your cut. Use the

laser adjustment knobs to adjust the

laser beam if necessary.

With the power switch OFF, bring

the saw blade down to the workpiece

to see the cutting path of the blade.

Then, squeeze trigger switch to

start the saw and lower the blade

into the workpiece with a firm

downward motion.

Hold the cutting arm in the down

position. Release the trigger switch

and wait for all moving parts to

stop before moving your hands and

raising the cutting arm.

QUICK START GUIDE

model no. 055-6767-0 | contact us 1-800-689-9928

WARNING ICONS

Your power tool and its Operator’s Manual may contain “WARNING ICONS” (a picture

symbol intended to alert you to, and/or instruct you how to avoid, a potentially hazardous

condition). Understanding and heeding these symbols will help you operate your tool

better and safer. Shown below are some of the symbols you may see.

SAFETY ALERT: Precautions that involve your safety.

PROHIBITION

WEAR EYE PROTECTION: Always wear safety goggles or safety glasses with

side shields.

READ AND UNDERSTAND INSTRUCTION MANUAL: To reduce the risk of injury,

user and all bystanders must read and understand instruction manual before

using this product.

SUPPORT AND CLAMP WORK

KEEP HANDS AWAY FROM BLADE: Failure to keep your hands away from the

blade will result in serious personal injury.

WEAR RESPIRATORY AND HEARING PROTECTION: Always wear respiratory

and hearing protection.

DANGER



WARNING



CAUTION



DANGER: indicates an imminently hazardous situation which, if not

avoided, will result in death or serious injury.

WARNING: indicates a potentially hazardous situation which, if not

avoided, could result in death or serious injury.

CAUTION: indicates a potentially hazardous situation which, if not

avoided, may result in minor or moderate injury.

SYMBOLS

SPECIFICATIONS

MOTOR

POWER SOURCE 120V AC, 60 Hz, 15A

SPEED 3200 RPM (No load)

BRAKE ELECTRIC

DOUBLE INSULATED Yes

ARBOUR SHAFT SIZE 5/8" (15.9 mm)

BLADE

DIAMETER 10" (25.4 cm), 60-tooth carbide-tipped

ARBOUR SIZE 5/8" (15.9 mm)

ROTATING TABLE

MITRE ANGLE RANGE 0°–50° Right & Left

POSITIVE MITRE STOPS 0°, 15°, 22.5°, 31.6°, 45° Right & Left

BEVEL ANGLE RANGE 0°–45° Right / 0°–47° Left

BEVEL POSITIVE STOPS 0°, 33.9°, 45° Right & Left

CUTTING CAPACITY

CROSSCUT (MAXIMUM HEIGHT) 3 1/2" x 11 1/2" (8.9 x 29.2 cm)

CROSSCUT (MAXIMUM WIDTH) 3 1/2" x 12 1/2" (8.9 x 31.8 cm)

MITRE 45° RIGHT & LEFT 3 1/2" x 8 3/4" (8.9 x 22.2 cm)

BEVEL 45° RIGHT 1" x 12 1/2" (2.5 x 31.8 cm)

BEVEL 45° LEFT 1 5/8" x 12 1/2" (4.1 x 31.8 cm)

45° MITRE AND 45° BEVEL 1 5/8" x 8 3/4" (4.1 x 22.2 cm)

CROWN MOULDING NESTED 5 3/4" (14.6 cm)

BASE MOULDING AGAINST FENCE 3 1/2" (8.9 cm)

NET WEIGHT 20.06 kg (44 lb 4 oz)

LASER

CLASS IIIA

LASER WAVELENGTH 630–660 nm

MAX. LASER OUTPUT < 5 mW

SPECIFICATIONS

model no. 055-6767-0 | contact us 1-800-689-9928

GENERAL SAFETY INSTRUCTIONS BEFORE USING THIS POWER TOOL

Safety is a combination of common sense, staying alert and knowing how to use your

power tool.

• READ and become familiar with the entire Operator’s Manual. LEARN the

tool’s application, limitations and possible hazards.

• KEEP GUARDS IN PLACE and in working order.

• REMOVE ADJUSTING KEYS AND WRENCHES. Form the habit of checking to see that

keys and adjusting wrenches are removed from the tool before turning ON.

• KEEP WORK AREA CLEAN. Cluttered areas and benches invite accidents.

• DO NOT USE IN DANGEROUS ENVIRONMENTS. Do not use power tools in damp

locations, or expose them to rain or snow. Keep work area well lit.

• KEEP CHILDREN AWAY. All visitors and bystanders should be kept a safe distance

from work area.

• MAKE WORKSHOP CHILD PROOF with padlocks, master switches or by removing

starter keys.

• DO NOT FORCE THE TOOL. It will do the job better and safer at the rate for which it

was designed.

• USE THE RIGHT TOOL. Do not force the tool or an attachment to do a job for which

it was not designed.

• USE PROPER EXTENSION CORDS. Make sure your extension cord is in good

condition. When using an extension cord, be sure to use one heavy enough to carry

the current that the product will draw. An undersized cord will result in a drop in line

voltage and in loss of power, which will cause the tool overheat. The table on page 14

shows the proper wire gauge size usage for each extension cord length and ampere

rating. If in doubt, use the next heavier gauge. The smaller the gauge number, the

heavier the cord.

• WEAR PROPER APPAREL. Do not wear loose clothing, gloves, neckties, rings,

bracelets or other jewellery which may get caught in moving parts. Nonslip footwear

is recommended. Wear protective hair covering to contain long hair.

WARNING!

• To avoid mistakes that could cause serious injury, do not plug the tool in

until you have read and understood the safety guidelines.

SAFETY GUIDELINES

• ALWAYS WEAR EYE PROTECTION. Any power tool can throw foreign objects

into the eyes and could cause permanent eye damage. ALWAYS wear Safety

Goggles (not glasses) that comply with ANSI Safety standard Z87.1. Everyday

eyeglasses have only impact–resistant lenses. They ARE NOT safety glasses. NOTE:

Glasses or goggles not in compliance with ANSI Z87.1 could seriously injure you when

they break.

• WEAR A FACE MASK OR DUST MASK. Sawing produces dust.

• SECURE WORK. Use clamps or a vice to hold work when practical. It is safer

than using your hand and it frees both hands to operate the tool.

• DISCONNECT TOOLS FROM POWER SOURCE before servicing, and when changing

accessories such as blades, bits and cutters.

• REDUCE THE RISK OF UNINTENTIONAL STARTING. Make sure switch is in the OFF

position before plugging the tool in.

• USE RECOMMENDED ACCESSORIES. Consult this Operator’s Manual for

recommended accessories. The use of improper accessories may cause a risk of

injury to yourself or others.

• NEVER STAND ON THE TOOL. Serious injury could occur if the tool is tipped or if the

cutting tool is unintentionally contacted.

• CHECK FOR DAMAGED PARTS. Before further use of the tool, a guard or other

part that is damaged should be carefully checked to determine that it will operate

properly and perform its intended function—check for alignment of moving parts,

binding of moving parts, breakage of parts, mounting and any other conditions that

may affect its operation. A guard or other part that is damaged should be properly

repaired or replaced.

• NEVER LEAVE THE TOOL RUNNING UNATTENDED. TURN THE POWER “OFF”. Do

not walk away from a running tool until the blade comes to a complete stop and the

tool is unplugged from the power source.

• DO NOT OVERREACH. Keep proper footing and balance at all times. NEVER reach

across the path of the cutting blade while tool is in operation.

• MAINTAIN TOOLS WITH CARE. Keep tools sharp and clean for best and safest

performance. Follow instructions for lubricating and changing accessories.

• DO NOT use power tool in the presence of flammable liquids or gases.

• DO NOT operate the tool if you are under the influence of any drugs, alcohol or

medication that could affect your ability to use the tool properly.

SAFETY GUIDELINES

model no. 055-6767-0 | contact us 1-800-689-9928

• People with electronic devices, such as pacemakers, should consult their physician(s)

before using this product. Operation of electrical equipment in close proximity to a

heart pacemaker could cause interference or failure of the pacemaker.

• WEAR HEARING PROTECTION to reduce the risk of induced hearing loss.

SPECIFIC SAFETY INSTRUCTIONS FOR THIS SLIDING MITRE SAW

• DO NOT operate the mitre saw until it is completely assembled and installed

according to these instructions.

• IF YOU ARE NOT thoroughly familiar with the operation of mitre saws, seek guidance

from your supervisor, instructor or other qualified person.

• ALWAYS hold the work firmly against the fence and table. DO NOT perform any

operation free hand (use clamp wherever possible).

• KEEP HANDS out of the path of the saw blade. If the workpiece you are cutting

would cause your hands to be within 7 1/2" (19 cm) of the saw blade, the workpiece

should be clamped in place before making the cut.

• BE SURE the blade is sharp, runs freely and is free of vibration.

• ALLOW the motor to come up to full speed before starting a cut.

• KEEP THE MOTOR AIR SLOTS CLEAN and free of chips or dust.

• ALWAYS MAKE SURE all handles are tight before cutting, even if the table is

positioned in one of the positive stops.

• BE SURE both the blade and the collar are clean and the arbour bolt is tightened

securely.

• USE only blade collars specified for your saw.

• NEVER use blades larger in diameter than 10 inches.

• NEVER apply lubricants to the blade when it is running.

SAFETY GUIDELINES

WARNING!

• Dust generated from certain materials can be hazardous to your health.

Always operate saw in well-ventilated area and provide for proper

dust removal.

Inhaltsverzeichnis

Andere MasterCraft Gesehen Handbücher

MasterCraft

MasterCraft 055-4500-6 Bedienungsanleitung

MasterCraft

MasterCraft 055-6742-8 Bedienungsanleitung

MasterCraft

MasterCraft 055-6789-8 Bedienungsanleitung

MasterCraft

MasterCraft 055-6761-2 Bedienungsanleitung

MasterCraft

MasterCraft 055-6737-2 Bedienungsanleitung

MasterCraft

MasterCraft 055-6717-0 Bedienungsanleitung

MasterCraft

MasterCraft 55-6883-2 Bedienungsanleitung

MasterCraft

MasterCraft 55-6857-6 Bedienungsanleitung

MasterCraft

MasterCraft 055-6739-8 Bedienungsanleitung

MasterCraft

MasterCraft 55-6896-2 Bedienungsanleitung

MasterCraft

MasterCraft MAXIMUM 055-6768-8 Bedienungsanleitung

MasterCraft

MasterCraft Maximum Hawkeye Laser 055-6746-0 Bedienungsanleitung

MasterCraft

MasterCraft 054-8357-6 Bedienungsanleitung

MasterCraft

MasterCraft 054-8326-0 Bedienungsanleitung

MasterCraft

MasterCraft 054-1237-4 Bedienungsanleitung

MasterCraft

MasterCraft 55-6863-0 Bedienungsanleitung

MasterCraft

MasterCraft 055-6742-8 Bedienungsanleitung

MasterCraft

MasterCraft 055-6740-2 Bedienungsanleitung

MasterCraft

MasterCraft 55-6898-8 Bedienungsanleitung

MasterCraft

MasterCraft 055-6778-4 Bedienungsanleitung

MasterCraft

MasterCraft 055-6744-4 Bedienungsanleitung

MasterCraft

MasterCraft 54-8340-4 Bedienungsanleitung

MasterCraft

MasterCraft Hawkeye Laser 54-8347-0 Bedienungsanleitung

MasterCraft

MasterCraft 055-6755-8 Bedienungsanleitung

Beliebte Gesehen Handbücher anderer Marken

RIDGID

RIDGID BS1400 Bedienungsanleitung

ATIKA

ATIKA BWS 400-2 Bedienungsanleitung

RGC

RGC FS20 Bedienungsanleitung

Makita

Makita M2300 Bedienungsanleitung

IMET Spa

IMET Spa BASIC 300 PLUS SHI Bedienungsanleitung

IMET Spa

IMET Spa SIRIO 370 AF-E Bedienungsanleitung

Optimum

Optimum OPTisaw CS 275 Bedienungsanleitung

Makita

Makita BPB180 Bedienungsanleitung

Stihl

Stihl MS 462 C-M Bedienungsanleitung

AEG

AEG TS 250 K Bedienungsanleitung

Meec tools

Meec tools 004665 Bedienungsanleitung

Makita

Makita LS1018L Bedienungsanleitung

Ryobi

Ryobi RCS1400 Bedienungsanleitung

DeWalt

DeWalt DCS391 Bedienungsanleitung

Sealey

Sealey SA72 Bedienungsanleitung

skilsaw

skilsaw SPT88 Montageanleitung

Urrea

Urrea SI810 Abmessungen und Installationsanleitung

EINHELL

EINHELL BKG 210/1 Bedienungsanleitung
