Chapter

Chapter 1:

Introduction

This chapter briefly describes the features of Matrox

RadientPro CL, as well as the software that can be used with

the board.

8 Chapter 1: Introduction

Matrox RadientPro CL

Matrox RadientPro CL is a family of high-performance PCIe frame grabbers that

acquires images from Camera Link video sources and offers FPGA-based

processing-offload capabilities.

There are two Matrox RadientPro CL members: RadientPro CL-SF and

RadientPro CL-DB. Matrox RadientPro CL-DB supports acquisition from two

Camera Link video sources in Base configuration; Matrox RadientPro CL-SF

supports acquisition from one Camera Link video source in Medium, Full, or

80-bit configuration.

Matrox RadientPro CL supports power-over Camera Link (PoCL) compliant

video sources and Camera Link frequencies of 20 MHz to 85 MHz.

This manual refers to all Matrox RadientPro CL boards as Matrox RadientPro CL.

When necessary, this manual distinguishes between the boards using their full

names.

Matrox RadientPro CL 9

General acquisition features

Matrox RadientPro CL supports frame and line-scan monochrome and color

video sources. The color video sources can be RGB video sources or video sources

with a Bayer color filter. Matrox RadientPro CL can decode Bayer color-encoded

images and perform color space conversions while transferring the image to the

Host. Besides standard Camera Link video sources, Matrox RadientPro CL also

supports additional types of video sources, including some time-multiplexed video

sources.

Auxiliary I/O

interface

Opto Aux In (2)

LVDS Aux In (2)

LVDS Aux Out (1)

TTLAux I/Os (3)

Memory

Controller

Optional

Dedicated

Processing

Memory

4 or 8 MB

Altera Stratix V

Processing FPGA

(customizable)

Processing

Units

(QDR-II SRAM

250 MHz)

Host PCIe busx8 2.x

MIL icenseL

ingerprintF

and Supplemental

MIL license storage

Up to

12.8 GB/s

Up to

12.8 GB/s

Total of

up to .0 GB/s write4 and

up to .0 GB/s read4

Acquisition

Controller Up to

GB/s1.6

Color space

converter &

pixel

formatter

Host Interface

DMA

Read DMA

Write

Up to

GB/s3.2

Up to

GB/s3.2

Up to

GB/s4

Up to

GB/s4

Main On-board Memory

(DDR-3 SDRAM)

2GB

Matrox RadientPro CL

Optional

Adapter Bracket

Power over

Cameral Link

Auxiliary 12V

Power Supply

Camera Link

Interface

Data

Pixel Clock

CC (4)

PoCL

UART

Auxiliary I/O

nterfaceI

Opto Aux In (2)

LVDS Aux In (2)

Auxiliary I/O

interface

Opto Aux In (2)

LVDS Aux In (2)

LVDS Aux Out (1)

TTLAux I/Os (3) Auxiliary I/O

nterfaceI

Opto Aux In (2)

LVDS Aux In (2)

Camera Link

Interface

Data

Pixel Clock

CC (4)1

PoCL

UART1

1Only available on Matrox RadientPro -DBCL

Bayer decoder

10 Chapter 1: Introduction

Processing capabilities

Matrox RadientPro CL features an on-board real-time processing FPGA device,

which can be configured to offload and even accelerate the most

compute-intensive part of typical image processing applications, without

generating additional data traffic within the host computer (Host).

Processing FPGA The Processing FPGA on Matrox RadientPro CL is a highly customizable Altera

Stratix V FPGA. The operations performed on-board are controlled using the

Matrox Imaging Library (MIL) application development software. Using MIL,

the processing units (PUs) of an FPGA configuration can be rearranged to perform

the operations in the required sequence, without having to necessarily generate a

new FPGA configuration. When the need arises, Matrox’s FPGA design services

can be employed to generate an application-specific FPGA configuration.

Before the Processing FPGA can process grabbed images, they must be stored in

main on-board memory. If images stored in Host memory are required, they can

be streamed directly to the Processing FPGA for processing. Images resulting from

Processing FPGA processing can be stored in main on-board memory or streamed

to the Host.

On-board acquisition and processing memory

Matrox RadientPro CL has two types of on-board memory: main on-board

memory and dedicated Processing FPGA memory (optional).

Main on-board memory is used to store acquired images, and images for or

resulting from processing. As main on-board memory, Matrox RadientPro CL is

equipped with 2 Gbytes of DDR3 SDRAM. Main on-board memory is accessed

through the memory controller of the Processing FPGA. The memory controller

has multiple input ports and a data transfer rate of up to 12.8 Gbytes/sec.

Matrox RadientPro CL can optionally feature dedicated Processing FPGA

memory to store intermediate data while the Processing FPGA performs

operation. As Processing FPGA memory, Matrox RadientPro CL uses 4 banks of

QDR-II SRAM that total 16 or 32 Mbytes of memory and have a total transfer

rate of up to 4.0 Gbytes/sec in each direction.

Inhaltsverzeichnis

Andere Matrox Computerhardware Handbücher

Matrox

Matrox RT.X2 Bedienungsanleitung

Matrox

Matrox RT.X100 Xtreme Bedienungsanleitung

Matrox

Matrox M.Key/100 Bedienungsanleitung

Matrox

Matrox Extio Series Bedienungsanleitung

Matrox

Matrox Meteor-II Bedienungsanleitung

Matrox

Matrox TripleHead2Go Analog Edition Bedienungsanleitung

Matrox

Matrox Parhelia Bedienungsanleitung

Matrox

Matrox Mojito MAX Bedienungsanleitung

Matrox

Matrox DigiSuite Bedienungsanleitung

Matrox

Matrox MXO2 Mini Bedienungsanleitung

Matrox

Matrox DigiSuite DigiMix Installations- und Betriebsanleitung

Matrox

Matrox RT.X2 Bedienungsanleitung

Matrox

Matrox Rainbow Runner Bedienungsanleitung

Matrox

Matrox ATC RG-200DL Bedienungsanleitung

Matrox

Matrox Solios eV-CL Montageanleitung

Matrox

Matrox Axio Bedienungsanleitung

Matrox

Matrox VS4 Bedienungsanleitung

Beliebte Computerhardware Handbücher anderer Marken

EMC2

EMC2 VNX Series Betriebsanleitung

Panasonic

Panasonic DV0PM20105 Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Bedienungsanleitung

Gigabyte

Gigabyte B660M DS3H AX DDR4 Bedienungsanleitung

Raidon

Raidon iT2300 Bedienungsanleitung

National Instruments

National Instruments PXI-8186 Bedienungsanleitung

Hauppauge

Hauppauge WinTV-HVR-2250 Bedienungsanleitung

Kontron

Kontron CP6002 Bedienungsanleitung

Manhattan

Manhattan 702843 Bedienungsanleitung

Aphex

Aphex 230 Bedienungsanleitung

AMD

AMD Phenom II Betriebshandbuch

Intel

Intel NUC 12 Pro Bedienungsanleitung

dbx

dbx Zone Pro 1260 Bedienungsanleitung

Galaxy

Galaxy GHDX2-2430S-24F4D Bedienungsanleitung

Intel

Intel AXXRMFBU4 Bedienungsanleitung

Kontron

Kontron DIMM-PC/MD Bedienungsanleitung

ST X-NUCLEO-SAFEA1B Betriebsanleitung

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Bedienungsanleitung
