MaximalPower FC999 Bedienungsanleitung
1
2
3
LCD & LED Display
Battery
TYPE
Function
LED Indication
LCD display word
LCD capacity
Indication
Ni-Cd
Discharge
Yellow
DIS
Flashing
downward
Charging
Red
CHA
Flashing upward
Fully charged
Green
OK
Fully charged
Ni-MH
Charging
Red
CHA
Flashing upward
Fully charged
Green
OK
Fully charged
Alkaline
Charging
Red
CHA
Flashing upward
Fully charged
Green
OK
Fully charged
Ni-Cd
Ni-MH
Alkaline
Battery voltage
is very low short
Battery can’t recharge
Off
BAD
4
Dear Customer,
Thank you for purchasing
MaximalPower ™
universal battery charger. This product is an
excellent environmentally friendly choice which provides a comprehensive and versatile solution
to keep your battery charged when you need them and minimize battery waste.
This product meets the European and USAsafety requirements.
This charger has the following features:
Easy to use
Intelligent microprocessor controlled
Negative delta V cut-off function
Rechargeable batteries in all capacities 1-4 pcs sizeAAA ,AA,C ,D& 1PCS 9V
Recharges SINGLE or GROUPED batteries with microprocessor monitors each
charging bay individually
Short-circuit protection, heat sensor and reversed-polarity protection
LED and LCD displays the status of each battery’s charging cycle
Individual maximum timer control for overcharge protection.
Charges Ni-Cd (Nickel Cadium), Ni-Mh(Nickel Metal Hydride),Alkaline *,
RAM(Rechargeable Alkaline Manganese)
5
Note on standard alkaline batteries:
The charger can charge most types of alkaline batteries. Please use the setting “ALK” on the
sliding front panel of your charger. Please note due to the chemistry of standard alkaline batteries,
they cannot be recharged nearly as many times as standard rechargeable type batteries like Ni-Cd
or Ni-MH batteries. The charger can recharge most standard alkaline batteries 75-90% of their
original capacity, up to 30+ times which is really depending on the quality and condition of the
battery. Please make sure there’s no dirt, rust or leakage on your standard alkaline battery and the
battery hasn’t passed the expiration date before you charge them. To prevent battery leakage,
please use the alkaline battery within 3 days after charging.
Please note that this charger is intended to charge rechargeable Ni-Cd, Ni-MH and RAM batteries
AA, AAA, C, D and 9v block batteries. Not AllAlkaline batteries can be recharged.
On an environmental note, the cost/performance comparison between standard alkaline batteries
and rechargeable batteries such as Ni-Cd (Nickel Cadmium) and Ni-MH (Nickel Metal Hydride),
rechargeable batteries are more cost efficient with better performance. Using rechargeable
batteries can reduce the waste to our environment.
6
Warranty Disclaimer
No part of the product may be modified or rebuilt and the housing must not be opened.
Always observe the safety instruction.
In case of any damages which are caused due to failure to observe these operating
instructions, improper operation or the failure to observe the safety instructions, the
guarantee will be voided. We do not assume liability for consequential damages nor
for damages to property nor personal injury arising from improper use of the device.
For safety reasons, the unauthorized conversion or opening of the device is prohibited.
Never short-circuit the charging contacts or batteries. It is normal that batteries get
warm during the charging procedure. But please unplug the charger if the battery gets
too hot or there’s leakage from battery. Please handle re-charged batteries with
care.
Do not leave the charger in moist or wet condition.
Neither the device nor batteries are toys for children. Please keep them out of reach
of children.
7
Important safety instruction
Before you use your new universal rapid charger, please pay attention to the user’s manual and the
safety instructions listed below.
-Never use the unit outdoors; it is designed for indoor use only.
-This charger is only suitable for the Ni-Cd (Nickel Cadmium) batteries and the Ni-MH
(Nickel Metal Hydride) batteries and alkaline batteries. This charger does NOT charge
Lithium (Li-ion) battery.
-Don’t use an extension cord to connect the unit.
-Pay attention to the correct polarity during inserting the batteries.
-Use the unit only at ambient temperatures of 0-40℃.
-Always unplug the charger after each use and before cleaning.
-Protect the charger against humidity and heat.
-Never open the unit by yourself; otherwise the warranty will become invalid! Repair can be
carried out only by our service branch or an authorized distributor. Improper disassemble and
assemble can cause fires or electric shocks.
-Do not use damaged or corroded batteries.
-AAAbatteries with a capacity of 300 mAh can never be charged for more than 0.5 hours.
-If the power cord of this unit is damaged, it must be replaced by the manufacturer, its service
person or a similar qualified person, in order to avoid danger.
8
PRODUCT DESCRIPTION
1、This charger can charge 4 kinds of batteries Ni-Cd、Ni-MH, RAM &Alkaline.
Each charging bay functions independently
Charge up to 4 batteries simultaneously.
Note: Batteries must be the same type when charge them together (Ni-Cd、Ni-MH or
alkaline)
Accommodates both AA、AAA、C、D and 9V batteries.
Battery type is preselected, therefore only one type (Ni-Cd, Ni-MH, RAM or alkaline
(Ram Setting)) battery can be charged at one time
This charger uses the latest battery charging technology. It uses “Negative Delta V”
deletion when charging Ni-Cd &Ni-MH battery first, followed by a quick charge. Once
the battery is fully charged, a constant current trickle charge will keep the battery at
optimum capacity.
2、Discharging Ni-Cd only:
Discharge times will very depend on capacity and charge state, typically the process could take
up to one hour, before the charge cycle commences.
During the discharge process the indicator LED will glow amber
3、Operation
Please read the following instructions carefully before first use of the Charger.
Connect the AC adaptor to the charger with the DC connector end.
Insert theAC plug into the household power supply and make sure the power supply is
9
normal. LED power indicator light will turn on after the charger is plugged in.
Select the required battery type by moving the battery selector switch between
Ni-Cd ,Ni-MH or ALK.
Insert batteries into the charging bay and make sure to match the correct polarity(+ is near
the LCD display)
After approximately 2 seconds the charger will automatically detect the status of the battery.
Once battery detection is complete, one of the following charging programs will commence.
Ni-Cd batteries:A characteristic of a Ni-Cd battery is that it has memory which means after
charging the battery repeatedly, the capacity of the battery will be significantly reduced. To
improve the battery’s condition, the charger will discharge the battery first (LCD linking
“DIS”& energy LCD indicator flashing downward) while LED indicator is illuminated
yellow. Once the discharge cycle is completed, the charger will begin the quick charge
program (LCD blinking “CHA”& energy level indicator flashing upward) while the LED
indicator illuminates red.
When the battery is fully charged, the LCD will show “OK”& energy level indicator
showing full. The LED indicator turns green.
Ni-MH & Alkaline batteries: Since neither Ni-MH norAlkaline battery has memory,
the
charger will automatically start the quick charging program. Both LCD & LED will have the
same display as for charging Ni-Cd battery.
When charge 9V battery, the LED light on top will light up in Red color. The LED light
will turn Green when 9V battery is fully charged.
We suggest you to use the fully charged batteries within 3 days. If you forgot to remove the
battery from the charger after it’s fully charged, the charger will automatically trickle charge
the battery keeping it at its optimum capacity. But for Alkaline battery, please remove the
battery from the charger and use it within 3 days to prevent leakage.
10
CHARGING TIME
In order to determine the approximate charge time, the formula as below can be used as reference.
Capacity of the battery x 1.4 = charge time of the battery
Current of the charger
Battery Type
Battery size
Battery capacity
Charge time
Ni-Cd
AAA
400mAh
0.7Hours
AA
800mAh
1.4Hours
C
2200mAh
3.9Hours
D
4400mAh
7.7Hours
Ni-MH
AAA
800mAh
1.4Hours
AA
2300mAh
4Hours
C
3300mAh
5-8Hours
D
5000mAh
8Hours
Alkaline
AAA
1.5V
<1.4V 2.5Hours
AA
1.5V
<1.4V 5Hours
C
1.5V
<1.4V 6Hours
D
1.5V
<1.4V 10Hours
9V block
200mAh
7 Hours
