Maxtor Computer Drive Bedienungsanleitung

DiamondMax 8S 40GB Serial ATA

Product Manual

May 13, 2005

Revision 1

Part Number: 000001912

could include technical inaccuracies or typographical errors. Changes are periodically made to the

information herein – which will be incorporated in revised editions of the publication. Maxtor

may make changes or improvements in the product(s) described in this publication at any time and

without notice.

UL/CSA/VDE/TUV /RoHS

UL standard 1954 recognition granted under File No. E78016

CSA standard C22.2-950 certification granted under File No. LR49896

TUV Rheinland EN 60 950

Tested to FCC Rules for Radiated and Conducted Emissions, Part 15, Sub Part J, for Class-B Equipment.

DiamondMax 8S model number 6N040T0 meets the EU directive for the Restriction and Use of Hazard-

ous Substances (RoHS), 2002/95/EC of the European Parliament and the council of 27 January, 2003. Dia-

mondMax 8S model number 6E040T0 does not meet these initiatives.

PATENTS

These products are covered by or licensed under one or more of the following U.S. Patents:

4,419,701; 4, 538,193 4,625,109; 4,639,798; 4,647,769; 4,647,997; 4,661,696; 4,669,004;

4,675,652; 4,703,176; 4,730,321; 4,772,974; 4,783,705; 4,819,153; 4,882,671; 4,920,442;

4,920,434; 4,982,296; 5,005,089; 5,027,241; 5,031,061; 5,084,791; 5,119,254; 5,160,865;

5,170,229; 5,177,771; Other U.S. and Foreign Patents Pending.

Maxtor®, MaxFax®are registered trademarks of Maxtor Corporation, registered in the U.S.A. and

other countries. Maxtor DiamondMax 8S, AutoTransfer, AutoRead, AutoWrite, DisCache, Dis-

kWare, Defect Free Interface, and WriteCache are trademarks of Maxtor Corporation. All other

brand names or trademarks are the property of their manufacturers. Windows, Windows NT, Win-

dows 2000, Windows 98, and Windows 95 are registered trademarks of Microsoft Corporation.

Maxtor reserves the right to make changes and improvements to its products, without incurring

any obligation to incorporate such changes or improvements into units previously sold or shipped.

This product or document is protected by copyright and distributed under licences restricting its

use, copying, distributing, and decompilation. No part of this product or document may be repro-

duced in any form by any means without prior written authorization of Maxtor and its licensors, if

any.

RESTRICTED RIGHTS LEGEND: Use, duplication, or disclosure by the government is subject to

restrictions as set forth in subparagraphs (c)(1)(ii) of the Rights in Technical Data and Computer Software

clause at DFARS 252.227-7013 and FAR 52.227-19.

THIS PUBLICATION IS PROVIDED “AS IS” WITHOUT WARRANTY OF ANY KIND,

EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED

WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTIULAR PURPOSE,

OR NON-INFRINGEMENT.

You can down load Maxtor publications directly from Maxtor at: www.maxtor.com

Part Number: 000001912

Before You Begin: Thank you for your interest in Maxtor hard disk drives. This manual pro-

vides technical information for OEM engineers and systems integrators regarding the installation

and use of Maxtor hard drives. Drive repair should be performed only at an authorized repair cen-

ter. For repair information, contact the Maxtor Product Support Center at 1-800-2MAXTOR.

CAUTION: Maxtor hard drives are precision products. Failure to follow these precautions and guidelines

outlined here may lead to product failure, damage and invalidation of all warranties.

1BEFORE unpacking or handling a drive, take all proper electrostatic discharge (ESD) precau-

tions, including personnel and equipment grounding. Stand-alone drives are sensitive to Elec-

trostatic Discharge (ESD) damage.

2BEFORE removing drives from their packing material, allow them to reach room temperature.

3During handling, NEVER drop, jar, or bump a drive.

4Once a drive is removed from the Maxtor shipping container, IMMEDIATELY secure the

drive through its mounting holes within a chassis. Otherwise, store the drive on a padded,

grounded, antistatic surface.

5NEVER switch DC power onto the drive by plugging an electrically live DC source cable into

the drive's connector. NEVER connect a live bus to the drive by plugging an electrically live

signal cable in to the drive’s interface connector.

6ELECTRICAL GROUNDING - For proper operation, the drive must be securely fastened to

a device bay that provides a suitable electrical ground to the drive baseplate.

Please do not remove or cover up Maxtor factory-installed drive labels. They contain information required

should the drive ever need repair.Thank you for your interest in Maxtor hard disk drives. This manual pro-

vides technical information for OEM engineers and systems integrators regarding the installation and use of

Maxtor hard drives. Drive repair should be performed only at an authorized repair center. For repair infor-

mation, contact the Maxtor Customer Service Center at 800-2MAXTOR or 1-303-678-2015.

Corporate Headquarters:

500 McCarthy Blvd.

Milpitas, California 95035

Tel: 408-894-5000

Fax: 408-362-4740

Maxtor DiamondMax 8S 40GB SATA i

TABLE OF CONTENTS

Chapter 1

INTRODUCTION

1.1 MAXTOR CORPORATION ............................................................................... 1-1

1.2 AUDIENCE ............................................................................................................. 1-1

1.3 MANUAL ORGANIZATION..................................................................................1-1

1.4 TERMINOLOGY AND CONVENTIONS ........................................................... 1-2

1.5 REFERENCES ........................................................................................................ 1-3

Chapter 2

PRODUCT DESCRIPTION

2.1 PRODUCT DESCRIPTION.................................................................................. 2-1

2.2 THE SERIAL ATA INTERFACE ............................................................................ 2-2

2.3 KEY FEATURES..................................................................................................... 2-2

2.4 REGULATORY COMPLIANCE STANDARDS .................................................. 2-3

2.5 HARDWARE REQUIREMENTS ......................................................................... 2-4

Chapter 3

PRODUCT SPECIFICATIONS

3.1 MODELS AND CAPACITIES ................................................................................ 3-1

3.2 DRIVE CONFIGURATION.................................................................................. 3-1

3.3 PERFORMANCE SPECIFICATIONS ................................................................... 3-2

3.4 PHYSICAL DIMENSIONS ..................................................................................... 3-2

3.5 POWER REQUIREMENTS .................................................................................. 3-3

3.6 POWER MODE DEFINITIONS............................................................................ 3-3

3.7 EPA ENERGY STAR COMPLIANCE................................................................... 3-3

3.8 ENVIRONMENTAL LIMITS................................................................................. 3-4

3.9 SHOCK AND VIBRATION................................................................................... 3-5

3.10 RELIABILITY SPECIFICATIONS ......................................................................... 3-6

3.11 EMC/EMI................................................................................................................ 3-6

3.11.1 RADIATED ELECTROMAGNETIC FIELD EMISSIONS - EMC COMPLI-

ANCE................................................................................................................3-6

3.11.2 CANADIAN EMISSIONS STATEMENT ..................................................... 3-6

3.12 SAFETY REGULATORY COMPLIANCE............................................................ 3-7

3.13 RoHS COMPLIANCE.............................................................................................. 3-7

Maxtor DiamondMax 8S 40GB SATA ii

Chapter 4

INSTALLATION

4.1 SPACE REQUIREMENTS..................................................................................... 4-1

4.2 UNPACKING INSTRUCTIONS........................................................................... 4-2

4.3 HARDWARE OPTIONS ....................................................................................... 4-4

4.3.1 JUMPER POSITION....................................................................................... 4-4

4.3.2 STAGGER SPIN-UP ....................................................................................... 4-4

4.4 MOUNTING........................................................................................................... 4-6

4.4.1 ORIENTATION .................................................................................................... 4-6

4.4.2 VENTILATION ...................................................................................................... 4-9

4.5 COMMBINATION CONNECTOR......................................................................... 4-9

4.5.1 DC POWER (J-1,SECTION A) ........................................................................ 4-9

4.5.2 EXTERNAL DRIVE ACTIVITY LED ............................................................. 4-9

4.6 FOR SYSTEMS WITH A MOTHERBOARD SATA ADAPTER....................... 4-10

4.7 FOR SYSTEMS WITH AN SATA ADAPTER BOARD ..................................... 4-10

4.7.1 CONNECTING THE ADAPTER BOARD AND THE DRIVE................. 4-10

Chapter 5

SATA BUS INTERFACE AND ATA COMMANDS

5.1 INTRODUCTION ................................................................................................. 5-1

5.2 MECHANICAL INTERFACE ................................................................................ 5-1

5.2.1 SIGNAL CABLE AND CONNECTOR ........................................................ 5-1

5.3 ELECTRICAL INTERFACE .................................................................................. 5-1

5.3.1 SATA BUS INTERFACE ............................................................................... 5-1

5.3.1.1 ELECTRICAL CHARACTERISTICS..........................................................5.1

5.4 REGISTER ADDRESS DECODING ..................................................................... 5-1

5.5 COMMAND INTERFACE..................................................................................... 5-1

5.5.1 GENERAL FEATURE SET ........................................................................... 5-1

5.5.2 SUPPORTED COMMANDS ......................................................................... 5-2

Chapter 6

SERVICE AND SUPPORT

6.1 GETTING HELP ...................................................................................................... 6-1

Glossary.......................................................................................................................G-1

Table of Contents

Maxtor DiamondMax 8S 40GB SATA iii

LIST OF FIGURES

Figure 4-1 Mechanical Dimensions.................................................................................4-1

Figure 4-2 Single Pack Shipping Container..................................................................... 4-2

Figure 4-3 25-Pack Shipping Container ......................................................................... 4-3

Figure 4-4 SATA Power/Interface Connector ................................................................ 4-5

Figure 4-5 Mounting Screw Clearance ........................................................................... 4-7

Figure 4-6 Mounting Dimensions .................................................................................. 4-8

Figure 4-7 Drive Power Supply and SATA Bus Interface Cables................................... 4-12

Figure 4-8 Completing the Drive Installation ............................................................... 4-13

Table of Contents

Maxtor DiamondMax 8S 40GB SATA iv

LIST OF TABLES

Table 4-1 SATA Pin 11 Configuration....................................................................................4-5

Table 4-2 Device Plug Connector Pin Definitions ..................................................................4-12

Table 4-3 Logical Addressing Form.........................................................................................4-16

Table 5-1 Supported Commands...............................................................................................5-2

Table 5-2 Identify Drive Command Parameters..........................................................................5-5

Introduction

Maxtor DiamondMax 8S 40GB SATA 1-1

Chapter 1

Introduction

1.1 Maxtor Corporation

Maxtor corporation is one of the world’s largest suppliers of hard disk drive products-

products that help store the digital world for millions of users. Maxtor products serve

a range of markets, including personal and entertainment, small office/home office,

mid-sized business and enterprise

Products

Maxtor storage products include drives and accessories for PC’s, workstations, RAID

products, enterprise applications, enterprise servers, high-end systems, consumer

electronics and personal storage.

Support

Maxtor provides a variety of consumer support options, all designed to make sure the

user gets fast, helpful, accurate information to help resolve any difficulties. These

options include a broad, searchable knowledge base of FAQ’s, product manuals,

installation guides, information on previously resolved problems, software downloads,

and contact by phone or E-mail with a support person. For more information, visit

www.maxtor.com/en/support.

1.2 Audience

The DiamondMax 8S 40GB SATA product manual is intended for several audiences.

These audiences include: the end user, installer, developer, consumer electronics and

personal computer original equipment manufacturer (CE/PC,OEM), and distributor.

The manual provides information about installation, principles of operation, interface

command implementation, and maintenance.

1.3 MANUAL ORGANIZATION

This manual is organized into the following chapters:

• Chapter 1 – Introduction

• Chapter 2 – Product Description

• Chapter 3 – Product Specifications

• Chapter 4 – Installation

Introduction

Maxtor DiamondMax 8S 40GB SATA 1-2

•Chapter5–SATA Bus Interface and ATA Commands

• Chapter 6 – Service and Support

• Glossary

1.4 TERMINOLOGY AND CONVENTIONS

In the Glossary at the back of this manual, you can find definitions for many of the

terms used in this manual. In addition, the following abbreviations are used in this

manual:

• ASIC application-specific integrated circuit

• SATA serial advanced technology attachment

• bpi bits per inch

• DA Double Amplitude (represents ph-pk shaker displacement)

• dB decibels

• dBA decibels, A weighted

• DPS Data Protection System

•EOF EndOfFrame

• FIS Frame Information Source

• SPS Shock Protection System

• ECC error correcting code

• kfci thousands of flux changes per inch

•Hz hertz

•kB kilobytes

• LSB least significant bit

• mA milliamperes

• MB megabytes (1 MB = 1,000,000 bytes when referring to disk

transfer rates or storage capacities and 1,048,576 bytes in all

other cases)

• Mb/s megabits per second

• MB/s megabytes per second

• MHz megahertz

• ms milliseconds

• MSB most significant bit

• mV millivolts

• ns nanoseconds

Inhaltsverzeichnis

Andere Maxtor Lagerung Handbücher

Maxtor

Maxtor DIAMONDMAXTMPLUS6800 90683U2 Bedienungsanleitung

Maxtor

Maxtor 4320 Bedienungsanleitung

Maxtor

Maxtor OneTouch STM303203OTA3E1-RK Bedienungsanleitung

Maxtor

Maxtor DiamondMax VL 40 Bedienungsanleitung

Maxtor

Maxtor D540X-4G Bedienungsanleitung

Maxtor

Maxtor 4W100H6 Bedienungsanleitung

Maxtor

Maxtor ATLAS 10K IV Bedienungsanleitung

Maxtor

Maxtor ONETOUCH 1.5TB Bedienungsanleitung

Maxtor

Maxtor MobileMax Bedienungsanleitung

Maxtor

Maxtor Personal Storage 5000LE Bedienungsanleitung

Maxtor

Maxtor QUICKVIEW 300 Bedienungsanleitung

Maxtor

Maxtor Personal Storage 5000DV Bedienungsanleitung

Maxtor

Maxtor Maxtor OneTouch USB Bedienungsanleitung

Maxtor

Maxtor Personal Storage 3000XT Montage- und Bedienungsanleitung

Maxtor

Maxtor FIREBALL3 Bedienungsanleitung

Maxtor

Maxtor MaXLine III 7B250S0 Gebrauchsanweisung

Maxtor

Maxtor Personal Storage 3000LS Bedienungsanleitung

Maxtor

Maxtor STM940215A - Maxtor MobileMax 40 GB Hard... Bedienungs- und Sicherheitshinweise

Maxtor

Maxtor 2R015H1 Bedienungsanleitung

Maxtor

Maxtor Personal Storage 3000DV Bedienungsanleitung

Maxtor

Maxtor QUICKVIEW EXPANDER Bedienungsanleitung

Maxtor

Maxtor DiamondMax10 80 Leitfaden

Maxtor

Maxtor Personal Storage 3000DV Bedienungsanleitung

Maxtor

Maxtor Maxtor Basics Desktop Bedienungsanleitung

Beliebte Lagerung Handbücher anderer Marken

QNAP

QNAP TS 32PXU Series Bedienungsanleitung

LaCie

LaCie RUGGED RAID Bedienungsanleitung

Freecom

Freecom CLS DOCK Bedienungsanleitung

PNY

PNY Attache P-FD64MBATT3 Bedienungsanleitung

HP StorageWorks MSL2024 Bedienungsanleitung

OLT

OLT 6x6 Maximizer Bedienungsanleitung

Transcend

Transcend JetFlash 160 Bedienungsanleitung

LaCie

LaCie RUGGED MINI Bedienungsanleitung

Thunderbolt

Thunderbolt 600 Bedienungsanleitung

Panasonic

Panasonic LB-DH8 series Handbuch

Intel

Intel RAID High Availability Bedienungsanleitung

LaCie

LaCie 12big Thunderbolt 3 Bedienungsanleitung

Spectra Logic

Spectra Logic T-Series Spectra T50e Bedienungsanleitung

Panasonic

Panasonic LKM-F931-1 Bedienungsanleitung

Tabernus

Tabernus Enterprise Erase E2400 Bedienungsanleitung

Rocstor

Rocstor COMMANDER 3F series Bedienungsanleitung

HP P9000 Bedienungsanleitung

Western Digital

Western Digital Ultrastar Data60 Bedienungsanleitung
