Maxtor FIREBALL3 Bedienungsanleitung

Maxtor Fireball3

November 21 2003

Part Number: 000001836

This publication could include technical inaccuracies or typographical errors. Changes are periodically made

to the information herein – which will be incorporated in revised editions of the publication. Maxtor may

make changes or improvements in the product(s) described in this publication at any time and without

notice.

Maxtor®, MaxFax®are registered trademarks of Maxtor Corporation, registered in the U.S.A. and other

countries. Maxtor Fireball3, AutoTransfer, AutoRead, AutoWrite, DisCache, DiskWare, Defect Free

Interface, and WriteCache are trademarks of Maxtor Corporation. All other brand names or trademarks are

the property of their manufacturers.

Maxtor reserves the right to make changes and improvements to its products, without incurring any obliga-

tion to incorporate such changes or improvements into units previously sold or shipped.

This product or document is protected by copyright and distributed under licences restricting its use, copy-

ing, distributing, and decompilation. No part of this product or document may be reproduced in any form

by any means without prior written authorization of Maxtor and its licensors, if any.

RESTRICTED RIGHTS LEGEND: Use, duplication, or disclosure by the government is subject to

restrictions as set forth in subparagraphs (c)(1)(ii) of the Rights in Technical Data and Computer Software

clause at DFARS 252.227-7013 and FAR 52.227-19.

THIS PUBLICATION IS PROVIDED “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER

EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES

OF MERCHANTABILITY, FITNESS FOR A PARTIULAR PURPOSE, OR NON-INFRINGE-

MENT.

You can download Maxtor publications directly from www.maxtor.com

Part Number: 000001836

Before You Begin

Thank you for your interest in Maxtor hard disk drives. This manual provides technical information for

OEM engineers and systems integrators regarding the installation and use of Maxtor hard drives. Drive

repair should be performed only at an authorized repair center. For repair information, contact the Maxtor

Product Support Center at 1-800-2MAXTOR.

CAUTION: Maxtor hard drives are precision products. Failure to follow these precautions and guidelines

outlined here may lead to product failure, damage and invalidation of all warranties.

1BEFORE unpacking or handling a drive, take all proper electrostatic discharge (ESD) precau-

tions, including personnel and equipment grounding. Stand-alone drives are sensitive to Elec-

trostatic discharge (ESD) damage.

2BEFORE removing drives from their packing material, allow them to reach room temperature.

3 During handling, NEVER drop, jar, or bump a drive.

4 Once a drive is removed from the Maxtor shipping container, IMMEDIATELY secure the

drive through its mounting holes within a chassis. Otherwise, store the drive on a padded,

grounded, antistatic surface.

5NEVER switch DC power onto the drive by plugging an electrically live DC source cable into

the drive's connector. NEVER connect a live bus to the drive's interface connector.

6ELECTRICAL GROUNDING - For proper operation, the drive must be securely fastened to

a device bay that provides a suitable electrical ground to the drive baseplate.

Please do not remove or cover up Maxtor factory-installed drive labels. They contain information required

should the drive ever need repair.

Thank you for your interest in Maxtor hard disk drives. This manual provides technical information for

OEM engineers and systems integrators regarding the installation and use of Maxtor hard drives. Drive

repair should be performed only at an authorized repair center. For repair information, contact the Maxtor

Customer Service Center at 800-2MAXTOR or 1-303-678-2015

Corporate Headquarters:

500 McCarthy Blvd.

Milpitas, California 95035

Tel: 408-894-5000

Fax: 408-362-4740

Maxtor Fireball3 vi

Table of Contents

Chapter 1

INTRODUCTION

1.1 Maxtor Corporation .................................................................................................. 1-1

1.2 Manual Organization................................................................................................. 1-1

1.3 Abbreviations ............................................................................................................ 1-2

1.4 Conventions.............................................................................................................. 1-2

Chapter 2

PRODUCT DESCRIPTION

2.1 Product Description .................................................................................................. 2-1

2.2 Key Features.............................................................................................................. 2-1

2.3 Product Features........................................................................................................ 2-2

2.4 Cache Management................................................................................................... 2-4

2.5 Major HDA Components.......................................................................................... 2-4

2.6 Subsystem Configuration........................................................................................... 2-6

2.7 Cylinder Limitation Jumper Description.................................................................... 2-7

Chapter 3

PRODUCT SPECIFICATIONS

3.1 Models and Capacities ............................................................................................... 3-1

3.2 Drive Configuration .................................................................................................. 3-1

3.3 Performance Specifications ........................................................................................ 3-2

3.4 Physical Dimensions .................................................................................................. 3-2

3.5 Power Requirements................................................................................................. 3-4

3.6 Power Mode Definitions ........................................................................................... 3-4

3.7 EPA Energy Star Compliance.................................................................................... 3-4

3.8 Environmental Limits ................................................................................................ 3-5

3.9 Shock and Vibration.................................................................................................. 3-6

3.10 Reliability Specifications............................................................................................ 3-7

3.11 EMC/EMI................................................................................................................ 3-8

3.11.1 Radiated Electromagnetic Field Emissions - EMC Compliance ........................ 3-8

3.11.2 Canadian Emissions Statement .......................................................................... 3-8

3.12 Safety Regulatory Compliance .................................................................................. 3-8

Table of Contents

vii Maxtor Fireball3

Chapter 4

HANDLING AND INSTALLATION

4.1 Hard Drive Handling Precautions .............................................................................. 4-1

4.2 Electro-Static Discharge (ESD) .................................................................................. 4-2

4.3 Unpacking and Inspection ......................................................................................... 4-3

4.4 Repacking ................................................................................................................. 4-6

4.5 Physical Installation.................................................................................................... 4-6

Chapter 5

ATA BUS INTERFACE AND ATA COMMANDS

5.1 INTRODUCTION ................................................................................................. 6-1

5.2 MECHANICAL INTERFACE ................................................................................ 6-1

5.2.1 Signal Cable and Connector ..............................................................................6-1

5.3 ELECTRICAL INTERFACE................................................................................... 6-1

5.3.1 ATA Bus Interface ............................................................................................6-1

5.4 REGISTER ADDRESS DECODING ..................................................................... 6-2

5.5 COMMAND INTERFACE..................................................................................... 6-2

5.5.1 General Feature Set ...........................................................................................6-2

5.5.2 Supported Commands ......................................................................................6-2

Chapter 6

SERVICE AND SUPPORT

6.1 Service Policy ............................................................................................................ 6-1

viii Maxtor Fireball3

List of Figures

Figure 2-1 PCBA Jumper Location and Configuration ................................................... 2-6

Figure 3-1 Outline and Mounting Dimensions .............................................................. 3-3

Figure 4-1 Single-Pack Shipping Container ................................................................... 4-2

Figure 4-2 25-Pack Shipping Container ......................................................................... 4-3

Maxtor Fireball3 1-1

Chapter 1

INTRODUCTION

1.1 Maxtor Corporation

Maxtor Corporation has been providing high-quality computer storage products since

1982. Along the way, we’ve seen many changes in data storage needs. Not long ago,

only a handful of specific users needed more than a couple hundred megabytes of

storage. Today, downloading from the Internet and CD-ROMs, multimedia,

networking and advanced office applications are driving storage needs even higher.

Even home PC applications need capacities measured in gigabytes, not megabytes.

Support

Maxtor provides a variety of customer support options, all designed to make sure the

user gets fast, helpful, accurate information to help resolve any difficulties. These

options include a broad searchable knowledge base of FAQ’s, product manuals,

installation guides, information on previously resolved problems, software downloads,

and contact by phone or E-mail with a support person. For more information, visit

www.maxtor.com/en/support

1.2 Manual Organization

This hard disk drive reference manual is organized in the following method:

Chapter 1–Introduction

Chapter 2–Product Description

Chapter 3–Product Specifications

Chapter 4–Handling and Installation

Chapter 5–ATA Bus Interface and ATA Commands

Chapter 6–Service and Support

Glossary

Index

Introduction

1-2 Maxtor Fireball3

1.3 Abbreviations

1.4 Conventions

If there is a conflict between text and tables, the table shall be accepted as being

correct.

Key Words

The names of abbreviations, commands, fields and acronyms used as signal names are

in all uppercase type (e.g., IDENTIFY DRIVE). Fields containing only one bit are

usually referred to as the “name” bit instead of the “name” field.

Names of drive registers begin with a capital letter (e.g., Cylinder High register).

Numbering

Numbers that are not followed by a lowercase “b” or “h” are decimal values.

Numbers that are followed by a lowercase “b” (e.g., 01b) are binary values. Numbers

that are followed by a lowercase “h” (e.g., 3Ah) are hexadecimal values.

Abbreviation Description Abbreviation Description

ATA AT attachment MB megabyte

bpi bits per inch Mbits/sec megabits per second

CHS cylinder - head - sector MB/sec megabytes per second

DA Double Amplitude (repre-

sents pk-pk shaker dis-

placement)

db decibels MHz megahertz

dBA decibels, A weighted ms millisecond

DMA direct memory access MSB most significant bit

ECC error correction code mV millivolts

fci flux changes per inch ns nanoseconds

G acceleration PIO programmed input/output

GB gigabyte RPM revolutions per minute

Hz hertz tpi tracks per inch

KB kilobyte UDMA ultra direct memory

access

LBA logical block address(ing) µsec microsecond

LSB least significant bit V volts

mA milliamperes W watts

Introduction

Maxtor Fireball3 1-3

Signal Conventions

Signal names are shown in all uppercase type.

All signals are either high active or low active signals. A dash character (-) at the end

of a signal name indicates that the signal is low active. A low active signal is true when

it is below ViL and is false when it is above ViH. A signal without a dash at the end

indicates that the signal is high active. A high active signal is true when it is above ViH

and is false when it is below ViL.

When a signal is asserted, it means the signal is driven by an active circuit to its true

state.

When a signal is negated, it means the signal is driven by an active circuit to its false

state.

When a signal is released, it means the signal is not actively driven to any state. Some

signals have bias circuitry that pull the signal to either a true or false state when no

signal driver is actively asserting or negating the signal. These instances are noted

under the description of the signal.

Maxtor Fireball3 2-1

Chapter 2

PRODUCT DESCRIPTION

2.1 Product Description

The Fireball 3 is the industries first 40Gb single-head/single platter hard drive with

an Ultra ATA/133 interface. Combining value and performance, this is an excellent

choice for entry-level desktop systems and consumer electronic applications.

The Maxtor Fireball 3 drive is the latest in the family of Maxtor single platter

5400RPM drives designed for higher reliability. The drive’s inner diameter load/

unload ramp locks the recording head into a protective carrier to cradle the head

during shipment and any other time the drive is not in operation.

The Fireball 3 take reliability and data integrity to a new level with Maxtor Shock

Protection System (SPS) and Data Protection System (DPS). SPS and DPS give the

user enhanced protection against both operation and non-operating shock and

verify essential functions in seconds to minimize costly drive returns.

Industry leading design, optimized to meet the needs of the entry level and value

applications:

• Supports popular entry level and value capacity - 40GB

• ATA/133 the fastest and latest IDE interface

• FDB (Fluid Dynamic Bearing) motor for quiet operation

• Low height to improve airflow and cooling

• Low weight to reduce shipping costs

• Improved reliability with:

~ Shock Protection System

~ Data Protection System

2.2 Key Features

• ANSI ATA-5/6 compliant PIO Mode 4 interface (Enhanced IDE)

• Supports ATA-6 UltraDMA Mode 5 (100 MBytes/sec) and Maxtor

Ultra ATA/133 MBytes/second data transfer rates

• 2 MB buffer with multi-adaptive cache manager

Inhaltsverzeichnis

Andere Maxtor Lagerung Handbücher

Maxtor

Maxtor QUICKVIEW EXPANDER Bedienungsanleitung

Maxtor

Maxtor Personal Storage 3000XT Bedienungsanleitung

Maxtor

Maxtor Personal Storage 3000LE Bedienungsanleitung

Maxtor

Maxtor OneTouch 4 Plus Bedienungsanleitung

Maxtor

Maxtor Atlas SCSI Drive 15K II Bedienungsanleitung

Maxtor

Maxtor OneTouch II Bedienungsanleitung

Maxtor

Maxtor QUICKVIEW 300 Bedienungsanleitung

Maxtor

Maxtor Maxtor Basics Desktop Bedienungsanleitung

Maxtor

Maxtor DiamondMax 22 Bedienungs- und Sicherheitshinweise

Maxtor

Maxtor Maxtor OneTouch USB Bedienungsanleitung

Maxtor

Maxtor MaXLine II 300GB Bedienungsanleitung

Maxtor

Maxtor Personal Storage 5000XT Bedienungsanleitung

Maxtor

Maxtor MaxAttach NAS 3000 Bedienungsanleitung

Maxtor

Maxtor 1394 External Storage Bedienungsanleitung

Maxtor

Maxtor Personal Storage 5000DV Bedienungsanleitung

Maxtor

Maxtor STM940215A - Maxtor MobileMax 40 GB Hard... Bedienungs- und Sicherheitshinweise

Maxtor

Maxtor Personal Storage 5000DV Bedienungsanleitung

Maxtor

Maxtor SERIAL ATA HARD DRIVE Bedienungsanleitung

Maxtor

Maxtor ATLAS 10K III Bedienungsanleitung

Maxtor

Maxtor 6E040L0 Bedienungsanleitung

Maxtor

Maxtor Maxtor OneTouch 4 Mini Bedienungsanleitung

Maxtor

Maxtor Maxtor Bedienungsanleitung

Maxtor

Maxtor External Storage Bedienungsanleitung

Maxtor

Maxtor DiamondMax 20 Serial ATA Bedienungsanleitung

Beliebte Lagerung Handbücher anderer Marken

QNAP

QNAP TS 32PXU Series Bedienungsanleitung

LaCie

LaCie RUGGED RAID Bedienungsanleitung

Freecom

Freecom CLS DOCK Bedienungsanleitung

PNY

PNY Attache P-FD64MBATT3 Bedienungsanleitung

HP StorageWorks MSL2024 Bedienungsanleitung

OLT

OLT 6x6 Maximizer Bedienungsanleitung

Transcend

Transcend JetFlash 160 Bedienungsanleitung

LaCie

LaCie RUGGED MINI Bedienungsanleitung

Thunderbolt

Thunderbolt 600 Bedienungsanleitung

Panasonic

Panasonic LB-DH8 series Handbuch

Intel

Intel RAID High Availability Bedienungsanleitung

LaCie

LaCie 12big Thunderbolt 3 Bedienungsanleitung

Spectra Logic

Spectra Logic T-Series Spectra T50e Bedienungsanleitung

Panasonic

Panasonic LKM-F931-1 Bedienungsanleitung

Tabernus

Tabernus Enterprise Erase E2400 Bedienungsanleitung

Rocstor

Rocstor COMMANDER 3F series Bedienungsanleitung

HP P9000 Bedienungsanleitung

Western Digital

Western Digital Ultrastar Data60 Bedienungsanleitung
